DN-700C/DN-501C
MIDI Command Guide
1
DN-700C / DN-501C
MIDI Command Guide
September 10th, 2014
Ver.1.00

DN-700C/DN-501C
MIDI Command Guide
2
Contents
1. General ............................................................................................................................................................................................................ 3
2. Specification .................................................................................................................................................................................................... 4
2-1. RS-232C Control....................................................................................................................................................................................... 4
2-2. IP Control (Ethernet) * DN-700C only ....................................................................................................................................................... 6
3. Communication Protocol.................................................................................................................................................................................. 7
4. Command List.................................................................................................................................................................................................. 8
4-1. Playback operation.................................................................................................................................................................................... 8
4-2. Device operation ..................................................................................................................................................................................... 11
4-3. File operation .......................................................................................................................................................................................... 12
4-4. Playback setting...................................................................................................................................................................................... 13
4-5. Device setting ......................................................................................................................................................................................... 17
4-6. Playback status....................................................................................................................................................................................... 20
4-7. Device status .......................................................................................................................................................................................... 24
4-8. Get list..................................................................................................................................................................................................... 25

DN-700C/DN-501C
MIDI Command Guide
3
1. General
Note: In this document, the controlled equipment is called the “device” (our product) and the controlling equipment is called the “host”.
The Serial Remote control function can be used when the host machine, like a PC, is connected to the device. The host controls the device by
sending Control commands and detects the device's status by sending Status Request commands. The device and host can be connected in one
of two ways: RS-232C and IP (Ethernet).
Three main features:
1. Device control from the host
2. Device status detection via Status Request commands from the host
3. Device status changes are sent automatically to the host

DN-700C/DN-501C
MIDI Command Guide
4
2. Specification
2-1. RS-232C Control
The host can control the device when they are connected with a RS-232C straight cable. Connect the cable to the device's 9-pin D-sub connector
as shown in the following diagram.
• Transmission type：Asynchronous / full duplex
• Connector type：9-pin D-sub (straight)
• Transfer rate：9,600 / 38,400 bps, selectable (via “Serial Bit Rate” in the “System Setting” menu)
• Clock accuracy：< +2.0%
• Data length：8 bits
• Parity：None
• Start bit：1 bit
• Stop bit：1 bit
• Flow Control：None
• Maximum data length：93 bytes

DN-700C/DN-501C
MIDI Command Guide
5
Pin Assignments
Pin No. Signal Name I/O
1 GND -
2 TxD Transfer
3 RxD Receiver
4 NC -
5 S.GND -
6 NC -
7 NC -
8 NC -
9 NC -

DN-700C/DN-501C
MIDI Command Guide
6
2-2. IP Control (Ethernet) * DN-700C only
The host can control the device when they are connected with an Ethernet cable. Connect the cable to the device's RJ-45 connector as shown in
the following diagram. (10BASE-T / 100BASE-TX)
IP Control Connection
• Transmission type：Full duplex
• Transfer speed：10 Mbps / 100 Mbps
• TCP port number：23 (telnet)
• Maximum data length：93 bytes

DN-700C/DN-501C
MIDI Command Guide
7
3. Communication Protocol
Commands are sent using command packets between the start byte and end byte.
This is the format of command packet:
Format
(0x11)
Total Command Packet
(1 byte)
Remain Command Packet
(1 byte)
Command
(2 bytes)
Parameter Pack Length
(1 byte)
Parameter Pack
(0-80 bytes)
Checksum
(2 bytes)
Item Remarks
Format 0x11 Fixed.
Total Command Packet This is used when sending a command whose parameter length is more than 80 bytes.
When the parameter length is 80 bytes or less, the Total Command Packet is 1.
Remain Command Packet This is used when sending a command whose parameter length is more than 80 bytes.
When the parameter length is 80 bytes or less, the Total Command Packet is 0.
Command This is structured by the Category code and Command. The length is 2 bytes.
Parameter Pack Length The length of the Parameter Pack. The maximum length is 80 bytes.
Parameter Pack The command parameter.
Checksum The sum from Format to Parameter Pack.
The MSB 4-bit and LSB 4-bit are then translated into ASCII code.
Example: In ASCII, “3” is 0x33 and “F” is 0x46. When the checksum is 0x3F, this is translated into “0x33, 0x46”.
0x F0004003
(Start Byte) Command Packet 0xF7 (End byte)

DN-700C/DN-501C
MIDI Command Guide
8
4. Command List
4-1. Playback operation
Command Category Code Command Example Example Command Code * Red points are variable Remark
[STOP] 0 1 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x01,0x00,0x31,0x33,0xF7
[PLAY] 0 2 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x02,0x00,0x31,0x34,0xF7
[PAUSE] 0 3 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x03,0x00,0x31,0x35,0xF7
[CUE] 0 4 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x04,0x00,0x31,0x36,0xF7
[CUE TRK] 0 5 Move to track #1 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x05,0x04,0x30,0x30,0x30,0x31,0x44,0x43,0xF7 * 1
[CUE TIME
000:05:67]
0 6 Move to 000:05:67
in current track
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x06,0x09,0x30,0x30,0x30,0x3a,0x30,0x35,0x3b,
0x36,0x37,0x46,0x38,0xF7
* 2
[FRAME FWD] 0 7 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x07,0x00,0x31,0x39,0xF7
[FRAME REV] 0 8 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x08,0x00,0x31,0x41,0xF7
[SEARCH SS1 FWD] 0 10 Speed 1 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0A,0x00,0x31,0x43,0xF7
[SEARCH SS1 REV] 0 11 Speed 1 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0B,0x00,0x31,0x44,0xF7
[SEARCH SS2 FWD] 0 12 Speed 2 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0C,0x00,0x31,0x45,0xF7
[SEARCH SS2 REV] 0 13 Speed 2 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0D,0x00,0x31,0x46,0xF7
[SEARCH SS3 FWD] 0 14 Speed 3 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0E,0x00,0x32,0x30,0xF7
[SEARCH SS3 REV] 0 15 Speed 3 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x0F,0x00,0x32,0x31,0xF7
[SEARCH SS4 FWD] 0 16 Speed 4 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x10,0x00,0x32,0x32,0xF7
[SEARCH SS4 REV] 0 17 Speed 4 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x11,0x00,0x32,0x33,0xF7
[SEARCH SS5 FWD] 0 18 Speed 5 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x12,0x00,0x32,0x34,0xF7
[SEARCH SS5 REV] 0 19 Speed 5 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x13,0x00,0x32,0x35,0xF7
[TRACK FWD] 0 20 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x14,0x00,0x32,0x36,0xF7
[TRACK REV] 0 21 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x15,0x00,0x32,0x37,0xF7
* 1 The parameter and checksum (written in red) are variable. The parameter should be “0001” to “2000” in ASCII.
* 2 The parameter and checksum (written in red) are variable. The parameter should be “000:00;00” to “999:59;74” in ASCII.

DN-700C/DN-501C
MIDI Command Guide
9
Command Category Code Command Example Example Command Code * Red points are variable Remark
[HOT START] 0 22 Start HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x01,0x32,0x41,0xF7
Start HOT #02 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x02,0x32,0x42,0xF7
Start HOT #03 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x03,0x32,0x43,0xF7
Start HOT #04 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x04,0x32,0x44,0xF7
Start HOT #05 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x05,0x32,0x45,0xF7
Start HOT #06 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x06,0x32,0x46,0xF7
Start HOT #07 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x07,0x33,0x30,0xF7
Start HOT #08 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x08,0x33,0x31,0xF7
Start HOT #09 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x09,0x33,0x32,0xF7
Start HOT #10 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0A,0x33,0x33,0xF7
Start HOT #11 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0B,0x33,0x34,0xF7
Start HOT #12 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0C,0x33,0x35,0xF7
Start HOT #13 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0D,0x33,0x36,0xF7
Start HOT #14 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0E,0x33,0x37,0xF7
Start HOT #15 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x0F,0x33,0x38,0xF7
Start HOT #16 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x10,0x33,0x39,0xF7
Start HOT #17 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x11,0x33,0x41,0xF7
Start HOT #18 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x12,0x33,0x42,0xF7
Start HOT #19 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x13,0x33,0x43,0xF7
Start HOT #20 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x16,0x01,0x14,0x33,0x44,0xF7

DN-700C/DN-501C
MIDI Command Guide
10
Command Category Code Command Example Example Command Code * Red points are variable Remark
[HOT CUE] 0 23 Cue up HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x01,0x32,0x42,0xF7
Cue up HOT #02 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x02,0x32,0x43,0xF7
Cue up HOT #03 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x03,0x32,0x44,0xF7
Cue up HOT #04 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x04,0x32,0x45,0xF7
Cue up HOT #05 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x05,0x32,0x46,0xF7
Cue up HOT #06 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x06,0x33,0x30,0xF7
Cue up HOT #07 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x07,0x33,0x31,0xF7
Cue up HOT #08 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x08,0x33,0x32,0xF7
Cue up HOT #09 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x09,0x33,0x33,0xF7
Cue up HOT #10 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0A,0x33,0x34,0xF7
Cue up HOT #11 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0B,0x33,0x35,0xF7
Cue up HOT #12 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0C,0x33,0x36,0xF7
Cue up HOT #13 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0D,0x33,0x37,0xF7
Cue up HOT #14 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0E,0x33,0x38,0xF7
Cue up HOT #15 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x0F,0x33,0x39,0xF7
Cue up HOT #16 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x10,0x33,0x41,0xF7
Cue up HOT #17 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x11,0x33,0x42,0xF7
Cue up HOT #18 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x12,0x33,0x43,0xF7
Cue up HOT #19 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x13,0x33,0x44,0xF7
Cue up HOT #20 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x17,0x01,0x14,0x33,0x45,0xF7
[SKIP BACK] 0 24 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x18,0x00,0x32,0x41,0xF7
[FRAME ON] 0 25 Frame On 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x19,0x01,0x01,0x32,0x44,0xF7
Frame Off 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x19,0x01,0x00,0x32,0x43,0xF7
[END MONITOR] 0 26 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x00,0x1A,0x00,0x32,0x43,0xF7

DN-700C/DN-501C
MIDI Command Guide
11
4-2. Device operation
Command Category Code Command Example Example Command Code * Red points are variable Remark
[POWER ON] 1 1 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x01,0x00,0x31,0x34,0xF7
[POWER STANDBY] 1 2 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x02,0x00,0x31,0x35,0xF7
[RETRACT] 1 3 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x03,0x00,0x31,0x36,0xF7
[EJECT] 1 4 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x04,0x00,0x31,0x37,0xF7
[UNBAL VOL UP 10] 1 5 Volume up 0.1 dB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x05,0x02,0x30,0x31,0x37,0x42,0xF7 * 1
Volume up 1.0 dB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x05,0x02,0x30,0x41,0x38,0x42,0xF7
[UNBAL VOL DN 10] 1 6 Volume down 0.1 dB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x06,0x02,0x30,0x31,0x37,0x43,0xF7 * 1
Volume down 1.0 dB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x06,0x02,0x30,0x41,0x38,0x43,0xF7
[UNBAL VOL -123] 1 7 Volume -12.3dB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x07,0x04,0x01,0x31,0x32,0x33,0x42,
0x35,0xF7 * 2
Volume +10.0dB
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x07,0x04,0x00,0x31,0x30,0x30,0x41,
0x46,0xF7
[ENTER] 1 8 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x08,0x00,0x31,0x42,0xF7
[ESC] 1 9 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x09,0x00,0x31,0x43,0xF7
[ABORT] 1 10 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x0A,0x00,0x31,0x44,0xF7
[ARROW D] 1 11 Arrow down 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x0B,0x00,0x31,0x45,0xF7
[ARROW U] 1 12 Arrow up 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x0C,0x00,0x31,0x46,0xF7
[ARROW R] 1 13 Arrow right 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x0D,0x00,0x32,0x30,0xF7
[ARROW L] 1 14 Arrow left 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x01,0x0E,0x00,0x32,0x31,0xF7
* 1 The parameter and checksum (written in red) are variable. The parameter should be “00” to “FF” (hexadecimal) in ASCII (e.g., 1.0dB = “0A”, 1.6dB = “10”).
* 2 The parameter and checksum (written in red) are variable. The parameter should be as below:
Byte 1: 0:Plus / 1:Minus
Byte2 to Byte5: 10 times the value of the volume in ASCII (+1.23 is 0x00,0x31,0x32,0x33)

DN-700C/DN-501C
MIDI Command Guide
12
4-3. File operation
Command Category Code Command Example Example Command Code * Red points are variable Remark
[HOT LOAD] 3 3 Load Hot List from USB:¥¥DN-700C.PPL 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x03,0x22,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x33,0x30,0x34,0x33,0x32,0x45,0x35,
0x30,0x35,0x30,0x34,0x43,0x37,0x43,0xF7
* 1
Load Hot List from USB:¥¥¥DN-700C.ppl 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x03,0x22,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x33,0x30,0x34,0x33,0x32,0x45,0x37,
0x30,0x37,0x30,0x36,0x43,0x38,0x32,0xF7
* 1
[HOT SAVE] 3 4 Save Hot List to USB:¥¥DN-700CS.PPL 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x04,0x24,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x33,0x30,0x34,0x33,0x35,0x33,0x32,
0x45,0x35,0x30,0x35,0x30,0x34,0x43,0x45,0x37,0xF7
* 1
[PRG LOAD] 3 5 Load Program List from USB:¥¥DN-700C.M3U 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x05,0x22,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x33,0x30,0x34,0x33,0x32,0x45,0x34,
0x44,0x33,0x33,0x35,0x35,0x38,0x35,0xF7
* 1
[PRG SAVE] 3 6 Save Program List to USB:¥¥DN-700CS.M3U 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x06,0x24,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x33,0x30,0x34,0x33,0x35,0x33,0x32,
0x45,0x34,0x44,0x33,0x33,0x35,0x35,0x46,0x30,0xF7
* 1
Save Program List to USB:¥¥DN-70CS.M3U 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x03,0x06,0x22,0x35,0x35,0x35,
0x33,0x34,0x32,0x33,0x41,0x35,0x43,0x35,0x43,0x34,0x34,0x34,0x45,
0x32,0x44,0x33,0x37,0x33,0x30,0x34,0x33,0x35,0x33,0x32,0x45,0x34,
0x44,0x33,0x33,0x35,0x35,0x38,0x42,0xF7
* 1
* 1 The parameter and checksum (written in red) are variable. The file name is specified as below:
The separator is "¥(0x5C". The media name is “CDA:”, “CDD:”, “USB:”, or ”NETxxx:”.
The folder name ends with "¥". The root directory is specified by “¥¥”. The upper folder is specified by “..¥”. (Example of the file path:i“USB:¥¥FOLDER1¥TRACK.mp3”.)
All characters are transferred to 2 bytes. (Example: “A” is 0x41 in ASCII. This MSB is “4” (0x34), and this LSB is “1” (0x31). Therefore, the “A” is transferred to 0x34,0x31.)

DN-700C/DN-501C
MIDI Command Guide
13
4-4. Playback setting
Command Category Code Command Example Example Command Code * Red points are variable Remark
[HOT SET] 5 1 Set current track to HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x01,0x31,0x41,0xF7
Set current track to HOT #02 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x02,0x31,0x42,0xF7
Set current track to HOT #03 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x03,0x31,0x43,0xF7
Set current track to HOT #04 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x04,0x31,0x44,0xF7
Set current track to HOT #05 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x05,0x31,0x45,0xF7
Set current track to HOT #06 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x06,0x31,0x46,0xF7
Set current track to HOT #07 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x07,0x32,0x30,0xF7
Set current track to HOT #08 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x08,0x32,0x31,0xF7
Set current track to HOT #09 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x09,0x32,0x32,0xF7
Set current track to HOT #10 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0A,0x32,0x33,0xF7
Set current track to HOT #11 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0B,0x32,0x34,0xF7
Set current track to HOT #12 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0C,0x32,0x35,0xF7
Set current track to HOT #13 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0D,0x32,0x36,0xF7
Set current track to HOT #14 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0E,0x32,0x37,0xF7
Set current track to HOT #15 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x0F,0x32,0x38,0xF7
Set current track to HOT #16 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x10,0x32,0x39,0xF7
Set current track to HOT #17 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x11,0x32,0x41,0xF7
Set current track to HOT #18 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x12,0x32,0x42,0xF7
Set current track to HOT #19 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x13,0x32,0x43,0xF7
Set current track to HOT #20 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x01,0x01,0x14,0x32,0x44,0xF7

DN-700C/DN-501C
MIDI Command Guide
14
Command Category Code Command Example Example Command Code * Red points are variable Remark
[HOT SET] 5 2 Set track #0010 to HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x02,0x05,0x01,0x30,0x30,0x31,0x30,0
x45,0x30,0xF7 * 1
Set track #0009 to HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x02,0x05,0x01,0x30,0x30,0x30,0x39,0
x45,0x38,0xF7
Set track #0008 to HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x02,0x05,0x01,0x30,0x30,0x30,0x38,0
x45,0x37,0xF7
[HOT RMV] 5 3 Remove HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x01,0x31,0x43,0xF7
Remove HOT #02 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x02,0x31,0x44,0xF7
Remove HOT #03 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x03,0x31,0x45,0xF7
Remove HOT #04 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x04,0x31,0x46,0xF7
Remove HOT #05 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x05,0x32,0x30,0xF7
Remove HOT #06 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x06,0x32,0x31,0xF7
Remove HOT #07 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x07,0x32,0x32,0xF7
Remove HOT #08 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x08,0x32,0x33,0xF7
Remove HOT #09 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x09,0x32,0x34,0xF7
Remove HOT #10 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0A,0x32,0x35,0xF7
Remove HOT #11 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0B,0x32,0x36,0xF7
Remove HOT #12 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0C,0x32,0x37,0xF7
Remove HOT #13 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0D,0x32,0x38,0xF7
Remove HOT #14 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0E,0x32,0x39,0xF7
Remove HOT #15 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x0F,0x32,0x41,0xF7
Remove HOT #16 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x10,0x32,0x42,0xF7
Remove HOT #17 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x11,0x32,0x43,0xF7
Remove HOT #18 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x12,0x32,0x44,0xF7
Remove HOT #19 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x13,0x32,0x45,0xF7
Remove HOT #20 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x03,0x01,0x14,0x32,0x46,0xF7
[HOT IN ] 5 7 Set 000:01:23 to HOT #01 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x07,0x0A,0x01,0x30,0x30,0x30,0x3a,
0x30,0x31,0x3b,0x32,0x33,0x46,0x34,0xF7 * 2
* 1 The parameter and checksum (written in red) are variable. The first byte is the hot list number (hexadecimal). The second byte to fifth byte is the track number (“0000” to “2000” in
ASCII).
* 2 The parameter and checksum (written in red) are variable. The first byte is the hot list number (hexadecimal). The time information after that is in ASCII ( “000:00;00” to “999:59;74”).

DN-700C/DN-501C
MIDI Command Guide
15
Command
Category
Code
Command Example Example Command Code * Red points are variable Remark
[PRG INS ] 5 11 Insert current track to
program #0001 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x0B,0x04,0x30,0x30,0x30,0x31,0x45,0x37,0xF7 * 1
[PRG INS]
5 12 Insert track #1 to
Program #0001
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x0C,0x08,0x30,0x30,0x30,0x31,0x30,0x30,0x30,0x31,
0x41,0x44,0xF7 * 2
[PRG RMV] 5 13 Remove program
#0001 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x0D,0x04,0x30,0x30,0x30,0x31,0x45,0x39,0xF7 * 1
[SET CUR FDR] 5 17 Set Current folder
USB:¥¥MPGLANG1
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x11,0x1C,0x35,0x35,0x35,0x33,0x34,0x32,0x33,0x41,
0x35,0x43,0x35,0x43,0x34,0x44,0x35,0x30,0x34,0x37,0x34,0x43,0x34,0x31,0x34,0x45,0x34,0x37,
0x33,0x31,0x34,0x43,0xF7
* 3
[SET CUR FDR FWD] 5 18 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x12,0x00,0x32,0x39,0xF7
[SET CUR FDR REV] 5 19 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x13,0x00,0x32,0x41,0xF7
[SET CUR FIL] 5 20 0001 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x14,0x04,0x30,0x30,0x30,0x31,0x46,0x30,0xF7 * 1
[PITCH SW XXX] 5 21 Pitch On 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x15,0x01,0x01,0x32,0x45,0xF7
Pitch Off 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x15,0x01,0x00,0x32,0x44,0xF7
[PITCH VAL ] 5 22 Pitch +12.3% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x16,0x06,0x00,0x30,0x31,0x32,0x33,0x30,0x32,0x39,
0xF7 * 4
Pitch -12.3%
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x16,0x06,0x01,0x30,0x31,0x32,0x33,0x30,0x32,0x41,
0xF7
Pitch 0.0%
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x16,0x06,0x00,0x30,0x30,0x30,0x30,0x30,0x32,0x33,
0xF7
[KEY SW] 5 25 Master Key On 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x19,0x01,0x01,0x33,0x32,0xF7
Master Key Off 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x19,0x01,0x00,0x33,0x31,0xF7
[PITCH UP LOW] 5 27 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x1B,0x00,0x33,0x32,0xF7
[PITCH UP MID] 5 28 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x1C,0x00,0x33,0x33,0xF7
[PITCH UP HI] 5 29 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x1D,0x00,0x33,0x34,0xF7
[PITCH DN LOW] 5 30 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x1E,0x00,0x33,0x35,0xF7
[PITCH DN MID] 5 31 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x1F,0x00,0x33,0x36,0xF7
[PITCH DN HI] 5 32 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x20,0x00,0x33,0x37,0xF7
* 1 The parameter and checksum (written in red) are variable. The first 4 bytes are the insert position (“0000” to “0099” in ASCII).
* 2 The parameter and checksum (written in red) are variable. The first 4 bytes are the insert position ( “0000” to “0099” in ASCII). The file number (“0000” to “2000” in ASCII) follows it.
* 3 The parameter and checksum (written in red) are variable. The file name format is referred to File Operation.
* 4 The parameter and checksum (written in red) are variable. The parameter should be as below:
Byte 1: 0:Plus / 1:Minus Byte 2 to Byte 5: 10 times the value of the pitch in ASCII (e.g., "+1.23" is "0x00,0x31,0x32,0x33").

DN-700C/DN-501C
MIDI Command Guide
16
Command Category Code Command Example Example Command Code * Red points are variable Remark
[SET AB ] 5 33 Set AB loop
A point = 000:01;00
B point = 000:02;00
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x21,0x12,0x30,0x30,0x30,0x3A,0x30,0x31,
0x3B,0x30,0x30,0x30,0x30,0x30,0x3A,0x30,0x32,0x3B,0x30,0x30,0x44,0x37,0xF7
* 1
Set AB loop
A point = 000:01;00
B point = 000:05;00
0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x21,0x12,0x30,0x30,0x30,0x3A,0x30,0x31,
0x3B,0x30,0x30,0x30,0x30,0x30,0x3A,0x30,0x35,0x3B,0x30,0x30,0x44,0x41,0xF7
[SET CUR MEDIA XXX] 5 34
USB 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x22,0x04,0x30,0x30,0x30,0x30,0x46,0x44,
0xF7
CD 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x22,0x04,0x30,0x30,0x30,0x31,0x46,0x45,
0xF7
iPad 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x22,0x04,0x30,0x30,0x30,0x32,0x46,0x46,
0xF7
Net 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x05,0x22,0x04,0x30,0x30,0x30,0x33,0x30,0x30,
0xF7
* 1 The parameter and checksum (written in red) are variable. The first 9 bytes are the A point time information in ASCII ( “000:00;00” to “999:59;74”). The B point time information follows it
with the same format.

DN-700C/DN-501C
MIDI Command Guide
17
4-5. Device setting
Command Category Code Command Example Example Command Code * Red points are variable Remark
[DIMMER XXX] 7 1 Dimmer 100% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x01,0x01,0x01,0x31,0x43,0xF7
Dimmer 75% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x01,0x01,0x02,0x31,0x44,0xF7
Dimmer 50% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x01,0x01,0x03,0x31,0x45,0xF7
Dimmer 25% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x01,0x01,0x04,0x31,0x46,0xF7
Dimmer 0% 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x01,0x01,0x05,0x32,0x30,0xF7
[LOCK XXX] 7 2 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x02,0x01,0x01,0x31,0x44,0xF7
[PRESET X: Y] 7 3 Shift Mde= LOCK 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x03,0x06,0x30,0x30,0x30,0x30,0x30,0x30,0x34,
0x32,0xF7
* 1
[PRESET ALL CHG ] 7 4 (All 1) 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x04,0x30,0x30,0x31,0x30,0x31,0x30,0x31,0x30,
0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,
0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,
0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x36,0x35,0xF7
* 1
[PRESET DEFAULT 7 5 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x05,0x00,0x31,0x45,0xF7
[PRESET LOAD] 7 6 File name = default 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x06,0x00,0x31,0x46,0xF7
[PRESET SAVE] 7 7 File name = default 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x07,0x00,0x32,0x30,0xF7
[SET MAC ADDR] 7 8 00-05-CD-12-00-70 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x08,0x0C,0x30,0x30,0x30,0x35,0x43,0x44,0x31
,0x32,0x30,0x30,0x37,0x30,0x41,0x33,0xF7
* 2
[GET MAC ADDR] 7 9 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x09,0x00,0x32,0x32,0xF7
[SYSCFG X Y] 7 10 System config 0:0 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x0A,0x06,0x30,0x30,0x30,0x30,0x30,0x30,0x34,
0x39,0xF7
* 3
[SYSCFG ALL CHG] 7 11 (All 1) 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x0B,0x22,0x30,0x31,0x30,0x31,0x30,0x31,0x30,
0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x31,0x30,0x30,0x30,0x30,0x30,0x30,
0x30,0x30,0x30,0x30,0x30,0x30,0x30,0x30,0x30,0x30,0x41,0x46,0xF7
* 4
[SYSCFG DEFAULT] 7 12 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x07,0x0C,0x00,0x32,0x35,0xF7
* 1 The parameter and checksum (written in red) are variable. The first 2 bytes are Parameter 1 (“00” to “27” in ASCII). Parameter 2 follows (“0000” to “001D” in ASCII). Parameter 1 and 2
are specified in the following table.
* 2 The parameter and checksum (written in red) are variable. Parameter 2 is stored each in 2 bytes.
* 3 The parameter and checksum (written in red) are variable. The Mac address is specified 8 bytes ASCII strings
* 4 The parameter and checksum (written in red) are variable. The first 2 bytes is the SYSCFG index num. (It is “00” to “08” in ASCII). The value (“0000” to “0004” in ASCII) follows it.
* 5 The parameter and checksum (written in red) are variable. The parameter 2 is stored each in 2 bytes.

DN-700C/DN-501C
MIDI Command Guide
18
Parameter 1 Item
Parameter 2
0 1 2 3 4 5 6 7
0 Shift Mode Lock Momentary
1 Power On Stop Resume Play Play First
2 Play Range All Folder
3 Play Mode Single Contnuous
4 Random Off On
5 Program Off On
6 Finish Mode Stop Next Recue
7 Repeat Off On
8 Auto Cue Off -48dB -42dB -36dB
9 Skip Back 0.5sec to 60sec (0.5sec step) 0：0.5sec～29：60sec
10 Search Mode Normal Silent
11 Auto Fade In Off 0.5sec 1.0sec 3.0sec
12 Auto Fade Out Off 0.5sec 1.0sec 3.0sec
13 Start Delay Off 100msec 200msec 300msec
14 End Of Message Off 0sec 5sec 10sec 15sec 20sec 30sec 60sec
15 Next Trk Reserve Off On
16 Master Key Off On
17 Dimmer Off On
18 Display Dimmer 100% 75% 50% 25% 0%
19 LED Dimmer 100% 75% 50% 25%
20 Screen Saver Off On
21 Remain Time Mode Track Total
22 Fader Start Play Play-Pause Play-Next Play&Lock Play&Lock-Pause Play&Lock-Next
23 Para Rem Mode HotStart HotCue

DN-700C/DN-501C
MIDI Command Guide
19
Parameter1 Item
Parameter2
0 1 2 3 4
0 Mono Off On
1 Volume Output Fixed(0dB) Variable
2 Output Rate Auto 44.1k 48k
3 Auto Sleep Off 30sec 10min 20min 30min
4 IR Remote Off On
5 Ref(XLR/RCA) +24dBu/+10dBV +20dBu/+6dBV +18dBu/+4dBV +6dBV/+6dBV
6 Display Contrast 1 2 3 4 5
7 Serial Bit Rate 9600 38400
8 Serial Protocol MIDI RC

DN-700C/DN-501C
MIDI Command Guide
20
4-6. Playback status
Command
Category
Code
Command Example Example Command Code * Red points are variable Remark
[GET TRP STAT] 9 1 Get transport status 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x01,0x00,0x31,0x43,0xF7
[GET CUR FDR] 9 2 Get current folder 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x02,0x00,0x31,0x44,0xF7
[GET ELP TIME] 9 3 Get elapse time 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x03,0x00,0x31,0x45,0xF7
[GET REM TIME] 9 4 Get remain time 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x04,0x00,0x31,0x46,0xF7
[GET CUR FILE] 9 5 Get current file 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x05,0x00,0x32,0x30,0xF7
[GET CUR TRK] 9 6 Get Current Track number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x06,0x00,0x32,0x31,0xF7
[GET CUR IDX] 9 7 Get current index number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x07,0x00,0x32,0x32,0xF7
[GET CUR SIZE] 9 8 Get current file size 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x08,0x00,0x32,0x33,0xF7
[GET CUR LEN] 9 9 Get current total time 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x09,0x00,0x32,0x34,0xF7
[GET CUR TITL] 9 10 Get title name 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0A,0x00,0x32,0x35,0xF7
[GET CUR ART] 9 11 Get artist name 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0B,0x00,0x32,0x36,0xF7
[GET CUR ALBM] 9 12 Get album name 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0C,0x00,0x32,0x37,0xF7
[GET CUR CH] 9 13 Get channel number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0D,0x00,0x32,0x38,0xF7
[GET CUR FMT] 9 14 Get file format 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0E,0x00,0x32,0x39,0xF7
[GET CUR SMP] 9 15 Get sample rate 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x0F,0x00,0x32,0x41,0xF7
[GET TAT TTL] 9 16 Get total track number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x10,0x00,0x32,0x42,0xF7
[GET TAT FIL] 9 17 Get track file name 0001 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x11,0x04,0x30,0x30,0x30,0x31,0x46,0x31,0xF7 * 1
[GET CUE FILE] 9 18 Get current file name 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x12,0x00,0x32,0x44,0xF7
[GET CUE TRK] 9 19 Get current track number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x13,0x00,0x32,0x45,0xF7
[GET CUE TIME] 9 20 Get cue time 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x14,0x00,0x32,0x46,0xF7
[GET HOT NO] 9 21 Get Hot Number 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x15,0x00,0x33,0x30,0xF7
[GET HOT FILE] 9 22 Get file name of Hot start 0xF0,0x00,0x40,0x03,0x11,0x01,0x00,0x09,0x16,0x00,0x33,0x31,0xF7
* 1 The parameter and checksum (written in red) are variable. The first 4 bytes are the file number (“0000” to “2000” in ASCII).
