Denon AVR 788 - AV Receiver User manual

CONFIDENTIAL
9
AVR-788
12-6-1 FORMAT：SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
Genre
System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１
Genre
System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０ FUNC.CDR/TAPE
3 １１００００ FUNC.PHONO 19 １１００１０
4 ００１０００ FUNC.CD 20 ００１０１０
5 １０１０００ FUNC.TUNER 21 １０１０１０
6 ０１１０００ FUNC.AUX 22 ０１１０１０
7 １１１０００ 23 １１１０１０
8 ０００１００ FUNC.DBS/SAT 24 ０００１１０ VIDEO SELECT
9 １００１００ FUNC.TV 25 １００１１０
10 ０１０１００ FUNC.HDP 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ FUNC.V.AUX, 28 ００１１１０
13 １０１１００ FUNC.VCR-1(VCR) 29 １０１１１０ CURSOR RIGHT
14 ０１１１００ FUNC.VCR-2(DVR) 30 ０１１１１０ STATUS
15 １１１１００ 31 １１１１１０ ON SCREEN
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ ENTER 48 ００００１１ MUTING
33 １００００１ POWER ON 49 １０００１１ MASTER VOLUME UP
34 ０１０００１ POWER OFF 50 ０１００１１ MASTER VOLUME DOWN
35 １１０００１ FUNC.DVD 51 １１００１１
36 ００１００１ DOLBY/DTS SURROUND 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ DSP SIMULATION 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ TEST TONE 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ SPEAKER 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
AV AMP
AV AMP

CONFIDENTIAL
10
Genre
System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１
Genre
System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０ FUNC.CD( MULTI )
1 １０００００ 17 １０００１０ FUNC.TUNER( MULTI )
2 ０１００００ 18 ０１００１０ FUNC.HDP( MULTI )
3 １１００００ 19 １１００１０ FUNC.V.AUX( MULTI )
4 ００１０００ 20 ００１０１０ FUNC.VCR-1(VCR)( MULTI )
5 １０１０００ 21 １０１０１０
6 ０１１０００ 22 ０１１０１０
7 １１１０００ 23 １１１０１０
8 ０００１００ 24 ０００１１０ FUNC.AUX( MULTI )
9 １００１００ 25 １００１１０ FUNC.VCR-2( MULTI )
10 ０１０１００ FUNC.SAT( MULTI ) 26 ０１０１１０
11 １１０１００ 27 １１０１１０ FUNC.TV( MULTI )
12 ００１１００ 28 ００１１１０ FUNC.CDR/TAPE( MULTI )
13 １０１１００ MULTI VOLUME UP 29 １０１１１０
14 ０１１１００ MULTI VOLUME DOWN 30 ０１１１１０
15 １１１１００ FUNC.PHONO( MULTI ) 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ SYSTEM SET UP 48 ００００１１
33 １００００１ SURROUND PARAMETER 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ CURSOR UP 51 １１００１１
36 ００１００１ CURSOR DOWN 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１ INPUT MODE
39 １１１００１ 55 １１１０１１
40 ０００１０１ 5CH/7CH STEREO 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１ FUNC.DVD( MULTI )
47 １１１１０１ 63 １１１１１１
AVP
AVP

CONFIDENTIAL
11
Genre
System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０
Genre
System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０
4 ００１０００ 20 ００１０１０
5 １０１０００ 21 １０１０１０
6 ０１１０００ 22 ０１１０１０
7 １１１０００ 23 １１１０１０
8 ０００１００ 24 ０００１１０
9 １００１００ 25 １００１１０
10 ０１０１００ 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ 29 １０１１１０
14 ０１１１００ 30 ０１１１１０
15 １１１１００ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１ MAIN ZONE ON
42 ０１０１０１ PURE DIRECT 58 ０１０１１１ MAIN ZONE OFF
43 １１０１０１ 59 １１０１１１ MULTI ZONE ON
44 ００１１０１ 60 ００１１１１ MULTI ZONE OFF
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
PRE AMP
PRE AMP

CONFIDENTIAL
12
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１ ＤＶＤ：ＤＥＮＯＮ Ａ
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 0 17 １０００１０ MENU
2 ０１００００ 1 18 ０１００１０ RETURN
3 １１００００ 2 19 １１００１０
4 ００１０００ 3 20 ００１０１０
5 １０１０００ 4 21 １０１０１０
6 ０１１０００ 5 22 ０１１０１０
7 １１１０００ 6 23 １１１０１０
8 ０００１００ 7 24 ０００１１０ DVD ＞＞｜
9 １００１００ 8 25 １００１１０ DVD ｜＜＜
10 ０１０１００ 9 26 ０１０１１０ DVD ＞＞
11 １１０１００ 27 １１０１１０ DVD ＜＜
12 ００１１００ [phone]
13 １０１１００ SUBTITLE 29 １０１１１０ DVD ｜｜
14 ０１１１００ AUDIO 30 ０１１１１０
15 １１１１００ 31 １１１１１０
No. Data(C6～C11) ｷｰ名称 No. Data(C6～C11) ｷｰ名称
32 ０００００１ DVD ＞ 48 ００００１１
33 １００００１ DVD STOP 49 １０００１１ DVD POWER
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ DISPLAY 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ DVD DISC SKIP 59 １１０１１１ DVD ENTER
44 ００１１０１ DVD CURSOR UP 60 ００１１１１ DVD SET UP
45 １０１１０１ DVD CURSOR DOWN 61 １０１１１１
46 ０１１１０１ DVD CURSOR →62 ０１１１１１
47 １１１１０１ DVD CURSOR ←63 １１１１１１
VIDEO CD
VIDEO CD

CONFIDENTIAL
13
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０
4 ００１０００ 20 ００１０１０
5 １０１０００ 21 １０１０１０
6 ０１１０００ 22 ０１１０１０
7 １１１０００ 23 １１１０１０
8 ０００１００ 24 ０００１１０ CD ＞＞｜
9 １００１００ 25 １００１１０ CD ｜＜＜
10 ０１０１００ 26 ０１０１１０ CD ＞＞
11 １１０１００ 27 １１０１１０ CD ＜＜
12 ００１１００ 28 ００１１１０ CD ＞
13 １０１１００ 29 １０１１１０ CD ｜｜
14 ０１１１００ 30 ０１１１１０ CD STOP
15 １１１１００ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ CD DISC SKIP+ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
CD
CD

CONFIDENTIAL
14
Genre
System Address(C1～C5):００１００, Extension Bit(C12,C13):１０
Genre
System Address(C1～C5):００１００, Extension Bit(C12,C13):１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０ TAPE A / B
4 ００１０００ 20 ００１０１０
5 １０１０００ 21 １０１０１０
6 ０１１０００ 22 ０１１０１０
7 １１１０００ 23 １１１０１０ TAPE ＜
8 ０００１００ 24 ０００１１０
9 １００１００ 25 １００１１０
10 ０１０１００ 26 ０１０１１０ TAPE ＞＞
11 １１０１００ 27 １１０１１０ TAPE ＜＜
12 ００１１００ 28 ００１１１０ TAPE ＞
13 １０１１００ 29 １０１１１０
14 ０１１１００ 30 ０１１１１０ TAPE STOP
15 １１１１００ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
TAPE
TAPE

CONFIDENTIAL
15
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１ ＣＤＲ：ＤＥＮＯＮ Ａ
Genre
System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０ CDR STOP
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０
4 ００１０００ 20 ００１０１０ CDR ｜＜＜
5 １０１０００ 21 １０１０１０ CDR ＞＞｜
6 ０１１０００ 22 ０１１０１０ CDR ＜＜
7 １１１０００ 23 １１１０１０ CDR ＞＞
8 ０００１００ 24 ０００１１０
9 １００１００ 25 １００１１０
10 ０１０１００ 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ 29 １０１１１０
14 ０１１１００ CDR ＞ 30 ０１１１１０
15 １１１１００ CDR ｜｜ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
CDR
CDR

CONFIDENTIAL
16
Genre
System Address(C1～C5):００１００, Extension Bit(C12,C13):０１
Genre
System Address(C1～C5):００１００, Extension Bit(C12,C13):０１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０
4 ００１０００ 20 ００１０１０
5 １０１０００ 21 １０１０１０ CINEMA MODE
6 ０１１０００ 22 ０１１０１０ MUSIC MODE
7 １１１０００ 23 １１１０１０
8 ０００１００ 24 ０００１１０ NIGHT MODE
9 １００１００ 25 １００１１０
10 ０１０１００ 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ 29 １０１１１０ ROOM EQ
14 ０１１１００ 30 ０１１１１０
15 １１１１００ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ DVD PICTURE ADJUST 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
CAR
CAR

CONFIDENTIAL
17
Genre
System Address(C1～C5):００１１０, Extension Bit(C12,C13):１０
Genre
System Address(C1～C5):００１１０, Extension Bit(C12,C13):１１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ 48 ００００１１
33 １００００１ 49 １０００１１
34 ０１０００１ 50 ０１００１１
35 １１０００１ 51 １１００１１
36 ００１００１ 52 ００１０１１
37 １０１００１ 53 １０１０１１
38 ０１１００１ 54 ０１１０１１
39 １１１００１ 55 １１１０１１
40 ０００１０１ 56 ０００１１１
41 １００１０１ 57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１ CURSOR LEFT
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ 19 １１００１０
4 ００１０００ 20 ００１０１０
5 １０１０００ 21 １０１０１０ TUNER CHANNNEL-
6 ０１１０００ 22 ０１１０１０ TUNER CHANNNEL+
7 １１１０００ 23 １１１０１０ TUNER BAND
8 ０００１００ 24 ０００１１０ TUNER MODE
9 １００１００ 25 １００１１０ TUNER TUNING UP
10 ０１０１００ 26 ０１０１１０ TUNER TUNING DOWN
11 １１０１００ 27 １１０１１０
12 ００１１００ TUNER MEMORY 28 ００１１１０
13 １０１１００ TUNER SHIFT 29 １０１１１０
14 ０１１１００ 30 ０１１１１０
15 １１１１００ 31 １１１１１０ DIMMER
RCVR
TUNER

CONFIDENTIAL
18
Genre
System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１
Genre
System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
64 ００００００ 16 ００００１０
1 １０００００ VDP POWER 17 １０００１０
2 ０１００００ 18 ０１００１０
3 １１００００ VDP STOP 19 １１００１０
4 ００１０００ VDP ＞ 20 ００１０１０
5 １０１０００ VDP ｜｜ 21 １０１０１０
6 ０１１０００ VDP ＞＞｜ 22 ０１１０１０
7 １１１０００ VDP ｜＜＜ 23 １１１０１０
8 ０００１００ VDP ＞＞ 24 ０００１１０
9 １００１００ VDP ＜＜ 25 １００１１０
10 ０１０１００ 26 ０１０１１０
11 １１０１００ 27 １１０１１０
12 ００１１００ 28 ００１１１０
13 １０１１００ 29 １０１１１０
14 ０１１１００ 30 ０１１１１０
15 １１１１００ 31 １１１１１０
CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION
32 ０００００１ ０48 ００００１１ ＋１０
33 １００００１ １49 １０００１１
34 ０１０００１ ２50 ０１００１１
35 １１０００１ ３51 １１００１１
36 ００１００１ ４52 ００１０１１
37 １０１００１ ５53 １０１０１１
38 ０１１００１ ６54 ０１１０１１
39 １１１００１ ７55 １１１０１１
40 ０００１０１ ８56 ０００１１１
41 １００１０１ ９57 １００１１１
42 ０１０１０１ 58 ０１０１１１
43 １１０１０１ 59 １１０１１１
44 ００１１０１ 60 ００１１１１
45 １０１１０１ 61 １０１１１１
46 ０１１１０１ 62 ０１１１１１
47 １１１１０１ 63 １１１１１１
LD
LD
