Front Panel (1 of 2)
HOME
DISPLAY 1 2
USB port
Used to connect USB storages (such as USB memory devices) and the
USB cable supplied with iPod.
 SETUP MIC jack
Used to connect the supplied Setup and measurement microphone.
 MASTER VOLUME knob
This adjusts the volume level.
Display
This displays various pieces of information.
Remote control sensor
This receives signals from the remote control unit.
 SOURCE SELECT knob
This selects the input source.
Tuner preset channel buttons (TUNER PRESET CH +, –)
These select preset FM/AM radio stations
Power operation button (O)
This turns the power of MAIN ZONE on/off (standby).
Power indicator
This is lit as follows according to the power status:
• Power on : Green
• Normal standby : Off
• When “HDMI Pass Through” or “HDMI Control” is set to “On” : Red
• When “IP Control” is set to “Always On” : Red
Headphones jack (PHONES)
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers.
NOTE
• To prevent hearing loss, do not raise the volume level excessively
when using headphones.
AUX-HDMI connector
Used to connect devices such as video cameras and game consoles.
FRONT PANEL 2

ZONE2 ON/OFF button
This turns the power of ZONE2 on/off.
ZONE2 SOURCE button
This selects the input source for ZONE2.
DIMMER button
Each press of this switches the brightness of the display.
STATUS button
Each press of this switches the status information that is shown on the display.
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various settings
you’ve registered to each button such as the input source, volume level and
sound mode settings.
Front Panel (2 of 2)
HOME DISPLAY 1FRONT PANEL 1 3

Input mode indicators
These light according to the audio input mode settings of each input
source.
Surround back indicator
This lights when audio signals are being output from the surround
back speakers.
Decoder indicators
These light when Dolby or DTS signals are input or when the Dolby or
DTS decoder is running.
Audyssey® indicator
This indicator lights when the “MultEQ® XT”, “Dynamic
EQ” or “Dynamic Volume” setting is set to other than “Off” and
“Audyssey DSX®” setting is set to other than “Off”.
Tuner reception mode indicators
These light up according to the reception conditions when the input
source is set to “Tuner”.
TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
Sleep timer indicator
This lights when the sleep mode is selected.
Circle indicator
Circle indicator is displayed when the input source is “NETWORK” or
“iPod/USB” when you are playing back music.
Display (1 of 2)
HOME DISPLAY 2FRONT PANEL 2 4

HOME
DISPLAY 1
Display (2 of 2)
Volume indicator
MUTE indicator
This blinks while the sound is muted.
Information display
The input source name, sound mode, setting values and other
information are displayed here.
Input signal indicators
The respective indicator will light corresponding to the input signal.
Multizone indicator
This lights up when ZONE2 (separate room) power is turned on.
5
REAR PANEL 1

HOME
DISPLAY 2
Rear Panel (1 of 2)
6
FM/AM antenna terminals (ANTENNA)
Used to connect FM and AM antennas.
Speaker terminals (SPEAKERS)
Used to connect speakers.
PRE OUT connectors
Used to connect a subwoofer with a built-in amplifier.
 AC inlet (AC IN)
Used to connect the power cord.
Component video connectors (COMPONENT VIDEO)
Used to connect devices equipped with component video connectors.
 HDMI connectors
Used to connect devices equipped with HDMI connectors.
 Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
REMOTE CONTROL jacks
Used to connect infrared receivers/transmitters in order to operate this
unit and external devices from a different room.
Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
Network Connector (NETWORK)
Used to connect this unit to the network.
RS-232C connector
The RS-232C serial port is provided to allow compatibility with an
external home automation controller. Consult the owner’s manual
of the home automation controller for more information about serial
control of this unit. The serial port allows two-way control and status
via an external home automation controller.
REAR PANEL 2

HOME
REAR PANEL 1
Rear Panel (2 of 2)
7
TRIGGER OUT jack
Used to connect devices equipped with the trigger function.
Analog audio connectors (AUDIO)
Used to connect devices equipped with analog audio connectors.
NOTE
• Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
REMOTE CONTROL 1

ZONE SELECT buttons
These switch the zone (MAIN ZONE, ZONE2) that is operated through
the remote control unit.
Input source select buttons
These selects the input source.
FAVORITE STATION buttons (1 –3)
With a single press of these, you can call up registered radio stations
and contents.
Channel/page search buttons (CH/PAGE )
These select radio stations registered to presets or switch pages.
MUTE button ()
This mutes the output audio.
Information button (INFO)
This displays the status information on the TV screen.
Cursor buttons ()
These select items.
BACK button
This returns to the previous screen.
System buttons
These perform playback related operations.
• Skip buttons ( )
• Play/pause button (/II)
Tuning up / Tuning down buttons (TUNE +, –)
These operate the tuner.
HOME REMOTE CONTROL 2REAR PANEL 2
Remote Control (1 of 2)
8

SOUND MODE buttons
These select the sound mode.
• MOVIE button
• MUSIC button
• GAME button
• PURE button
Remote control signal transmitter
This transmits signals from the remote control unit.
SLEEP button
This sets the sleep timer.
POWER button (O)
This turns the power on/off.
InstaPrevue button
This displays the InstaPrevue screen.
VOLUME buttons ()
These adjust the volume level.
OPTION button
This displays the option menu on the TV screen.
ENTER button
This determines the selection.
 SETUP button
This displays the menu on the TV screen.
HOME Warranty 1REMOTE CONTROL 1
