Denon DP-300F User manual

TURNTABLE
DP-300F
OPERATING INSTRUCTIONS

I
ENGLISH
1. Read Instructions – All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions – The safety and operating instructions should be
retained for future reference.
3. Heed Warnings – All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners.
6. Attachments – Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water – for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.
8. Accessories – Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory
recommended by the manufacturer.
9. A product and cart combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces may
cause the product and cart
combination to overturn.
10. Ventilation – Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect it from
overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
11. Power Sources – This product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature.
If you are unable to insert the plug fully into the outlet, try reversing the plug.
If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug.
13. Power-Cord Protection – Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
15. Outdoor Antenna Grounding – If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding
electrode. See Figure A.
16. Lightning – For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges.
17. Power Lines – An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.
18. Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
19. Object and Liquid Entry – Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
20. Servicing – Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
21. Damage Requiring Service – Unplug this product from the wall outlet and
refer servicing to qualified service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance – this
indicates a need for service.
22. Replacement Parts – When replacement parts are required, be sure the
service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
23. Safety Check – Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting – The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
25. Heat – The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.
SAFETY INSTRUCTIONS
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL
ELECTRICAL CODE ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
2SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock t persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

II
ENGLISH
2NOTE ON USE
FCC INFORMATION (For US customers)
1. PRODUCT
This product complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this product may not cause harmful
interference, and (2) this product must accept any interference received,
including interference that may cause undesired operation.
2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT
This product, when installed as indicated in the instructions contained in this
manual, meets FCC requirements. Modification not expressly approved by
DENON may void your authority, granted by the FCC, to use the product.
3. NOTE
This product has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This product generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
product does cause harmful interference to radio or television reception,
which can be determined by turning the product OFF and ON, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the local retailer authorized to distribute this type of product or
an experienced radio/TV technician for help.
•Avoid high temperatures.
Allow for sufficient heat dispersion when installed
in a rack.
•Handle the power cord carefully.
Hold the plug when unplugging the cord.
•Keep the apparatus free from moisture, water, and
dust.
•Unplug the power cord when not using the
apparatus for long periods of time.
* (For apparatuses with ventilation holes)
•Do not obstruct the ventilation holes.
•Do not let foreign objects into the apparatus.
•Do not let insecticides, benzene, and thinner come
in contact with the apparatus.
•Never disassemble or modify the apparatus in any
way.

1
Getting Started
ENGLISH
Contents
Getting Started
Thank you very much for purchasing the DENON turntable.
Please read the operating instructions thoroughly in order to acquaint yourself with the turntable system and achieve maximum
satisfaction from it.
Before using···················································································1
Accessories ····················································································1
About the equalizer switch··························································2
Assembly························································································2
Mounting the turntable·································································2
Mounting the counterweight························································2
Mounting the head shell with cartridge········································2
Mounting the dust cover ······························································2
Adjustments···················································································3
Stylus pressure and anti-skating adjustment································3
Part names and functions·····························································4
Starting playback using the auto play function·························5
Starting playback manually ·························································5
Stopping playback in the middle of a record·····························5
Replacing the stylus······································································6
Replacing the cartridge·································································6
Getting Started
Operation
Accessories
Before using
Pay attention to the following before using this unit:
•Power requirements
Power requirements for electrical equipment differ from area to
area. Please ensure that your machine meets the power
requirements in your area.
If it doubt, consult a qualified electrician.
Check that the following parts are attached in addition to the main
unit:
qOperating instructions............................................................1
wWarranty.................................................................................1
eService station list ..................................................................1
rTurntable (with belt)................................................................1
tTurntable sheet.......................................................................1
yAdapter for 45 rpm records....................................................1
uHead shell with cartridge........................................................1
iDust cover..............................................................................1
oCounterweight........................................................................1
!0 Hinges.....................................................................................2
!1 Spare lead wire.......................................................................1
rty
ui
o!0
Connections ...................................................................................4
ENGLISH
•About the power switch
This turntable is not equipped with a primary power switch. The
power switch is incorporated in the tone arm of the turntable. The
power to the turntable is cut when the tone arm returns to the tone
arm rest. Note however, that the power is not completely turned off
in this case. If you wish to completely turn the power off,
disconnect the power supply cord from the household AC outlet.
•Protect the turntable too
•Never touch the plug with wet hands.
•Always pull out by the plug and never the cable.
•Only let a qualified professional repair or reassemble the turntable.
An unauthorized person might touch the internal parts and receive
a serious electric shock.
•Never allow a child to put anything, especially metal, into the
turntable.
•What you should know to protect yourself
•Use only a household AC power source. Never use a DC power
source.
•If water is spilled on the turntable, disconnect it and call your
dealer.
•Make sure that the turntable is well ventilated and away from
direct sunlight.
•To avoid damage to the internal circuits and the external surface,
keep it away from heat (stoves, etc.).
•Avoid using spray type insecticide near the turntable it can
damage the finish and might ignite suddenly.
•To avoid damaging the finish, never use paint thinner or other
similar chemicals to clean the turntable.
•Place the turntable on a flat and solid surface.
•If you don’t plan to use the turntable for a long period of time,
disconnect the power supply cord.
•To protect the insulators, always lift the turntable when you move
it. And before moving the turntable, disconnect all the connecting
cables.
•When transporting the turntable over a long distance, place it in its
original box wrapped in protective wrappers.
•Moving the unit
To prevent short-circuits or damaged wires in the connection
cables, always unplug the power supply cord and disconnect the
connection cables between all other audio components when
moving the unit.
•Before turning the power switch on
Check once again that all connections are correct and that there are
not problems with the connection cables. Always set the power
switch to the standby position before connecting and disconnecting
connection cables.
•Store these instructions in a safe place.
After reading, store this instructions along with the warranty card in
a safe place.
•Note that the illustrations in these instructions may differ from
the actual unit for explanation purposes.
Troubleshooting·············································································7
Specifications·················································································7
Others

2
Getting Started Getting Started
ENGLISH
Turntable sheet
Square hole
Turntable
Ribbon tape
Counterweight
Tone arm
Lock nut
Head shell with
cartridgeCenter spindle
Twist tie for
clamping
the tone arm
Stylus pressure
adjustment ring
Roller
Belt
Ribbon tape
Square hole
Equalizer
switch
Hinge retainer
section
Holder
Dust
cover
Hinge
Cabinet
•The equalizer switch is set to the “ON” position upon shipment
from the factory. Be sure to check before mounting the turntable
and turntable sheet.
•The sound may be extremely weak or distorted if the equalizer
switch is not properly set.
Assembly
Mount the turntable on the center spindle.
1
Turn the turntable so that the rolleris visible through
the square hole with the ribbon tape for catching the
belt.
2
Pinch the ribbon tape and catch the belt on the outer
center of the roller.
•Remove the ribbon tape once the belt is caught.
•Turn turntable slowly 5 or 6 turns. The belt is caught at the
center of the roller.
3
Mount the turntable sheet.
4
Mounting the turntable
Mounting the counterweight
Insert the counterweight onto the shaft at the back of the
tone arm and screw it in.
Mount with the stylus pressure adjustment ring towards the
front.
Mounting the head shell with cartridge
Insert the head shell with cartridge onto the tone arm
and fasten it in place with the lock nut ( page 6).
Insert the 2 included hinges securely into the holders
at the back of the cabinet.
1
Mount the hinge retainer sections of the dust cover
onto the hinges.
•Insert fully in the direction of the arrow.
•When removing the dust cover, open the dust cover fully then
pull out in the direction opposite the arrow.
2
•Hold the dust cover near the hinge retainer sections when mounting
and removing it.
Once assembly is finished, remove the twist tie for
clamping the tone arm.
OFF:
When connecting to the PHONO input terminal
(The record player’s equalizer cannot be used.)
ON:
When connecting a terminal other than the PHONO input terminal
(The record player’s equalizer can be used.)
This record player comes with a built-in equalizer.
Switch as shown below according to the terminal being used.
Mounting the dust cover
ENGLISH
About the equalizer switch
NOTE:
•Do not remove the twist tie for clamping the tone arm until
assembly is completed.
•Do not connect the power supply cord until assembly is
completed.

3
Getting Started Getting Started
ENGLISH
Adjustments
Turn the power off when making the adjustments.
Counterweight
Lifter lever
Armrest
Tone arm
Cartridge
Turntable
Stylus pressure
adjustment ring
Anti-skating knob
NOTE:
•Be very careful not to damage the stylus tip on the turntable
sheet, etc.
Set the anti-skating knob to “0”.
1
Lower the lifter lever and move the tone arm over the
turntable.
For cartridges with removable stylus covers, remove the stylus
cover.
2
Balance the tone arm.
•Move the counterweight forward or backward so that the tone
arm is parallel to the turntable surface when you are not
touching it.
3
Set the tone arm back on the armrest.
4
Holding the counterweight with a finger so that it
does not move, turn the stylus pressure adjustment
ring so that it’s “0” mark is lined up with the center
line of the tone arm’s rear shaft.
5
Turntable surface Tone arm Counterweight
(Weight too far to the back) (Weight too far to the front)
Counterweight
Center line
Stylus pressure
adjustment ring
A
Turn the counterweight in the direction of arrow “A”
and set to the appropriate stylus pressure for the
cartridge.
The appropriate stylus pressure for the included cartridge is 2.0
g (19.6 mN). Set to “2”.
6
Turn the anti-skating knob and set to the same value
as for the cartridge’s stylus pressure.
•The proper anti-skating value can be achieved.
7
Stylus pressure and anti-skating adjustment
Setting reference point
ENGLISH

4
ENGLISH
Getting Started
Part names and functions
!1
i
o
y
t
r
!2
!3!4
u
e
w
q
!0
Connections
R
L
PHONO IN
Pre-main amplifier
R
L
•If the player starts operating when the power supply cord is plugged in, press the STOP button.
qSTART button ·············································(5)
•Starts playback.
wSTOP button···············································(5)
•Stops playback.
eFinger catch
rLock nut ··················································(2, 7)
tArmrest
ySIZE button (£17 / ¢30)······················(5)
•Set according to the size of the record to be
played (11 ft/30 cm or 6 ft/17 cm).
uSPEED button (£45 / ¢33)··················(5)
•Set according to the speed (revolutions per
minute) of the record to be played.
iLifter lever···················································(3)
oAnti-skating knob·······································(3)
!0 Stylus pressure adjustment ring··············(3)
!1 Counterweight············································(3)
!2 Dust cover···················································(2)
!3 Equalizer switch·········································(2)
!4 Dust cover hinge ········································(2)
AC 120 V, 60 Hz
Power outlet
NOTE:
•Turn off the power of the device to which the record player is being connected. Do not plug the
record player’s power plug into a power outlet until all connections are finished.
•Check that all connections are proper, then plug the record player’s power plug into the AC outlet on
the amplifier or into a household AC power outlet.
¢When connecting to the PHONO input terminal
Equalizer switch : OFF ( page 2)
R
L
AUDIO IN
(AUX IN)
Pre-main amplifier
or
audio system
R
L
¢When connecting a terminal other than the PHONO input terminal
Equalizer switch : ON ( page 2)
Pin-plug cable
(length: approx. 3 ft/1.0 m)
AC 120 V, 60 Hz
Power outlet
For details on the functions of these parts, refer to the pages given in parentheses ( ).
ENGLISH

5
Operation
ENGLISH
Operation
Lifter lever
SPEED
SIZE
Armrest
Tone arm
Finger catch
STOP
START
Turntable
¢Opening the stylus cover
Raise the stylus cover before starting playback.
Place the record on the turntable.
For EP (“doughnut”) records, use the 45 rpm adapter.
1
Set the record’s playing speed using SPEED.
For 33 1/3 records ...........................Set to ¢33
For 45 records .................................Set to £45
2
Set the record size using SIZE.
For 30 cm records ...........................Set to ¢30 cm
For 17 cm records ...........................Set to £17 cm
3
Press START and hold it in for about 1 second.
•The turntable starts turning and playback starts automatically.
•Once the record is played, the tone arm returns to its original
position and the turntable automatically stops turning.
4
•Once you have finished playing records, lower the stylus cover to
protect the stylus tip.
•This set has an “auto return” function by which the tone arm
automatically returns to its original position once a specific point is
reached after a record finishes playing. Though there is no problem
with records of normal size, with records including grooves up to
this point, the auto return function may be activated before playback
is finished.
NOTE:
•Do not touch the tone arm or turntable or turn off the power
while a record is playing.
•The auto play system cannot be used for 9 ft/25 cm records.
In this case operate manually. If the tone arm does not return to
its original position after playback stops, press STOP.
Place the record on the turntable.
For EP (“doughnut”) records, use the 45 rpm adapter.
1
Set the record’s playing speed using SPEED.
For 33 1/3 records ...........................Set to ¢33
For 45 records .................................Set to £45
2
Raise the lifter lever and holding the head shell’s
finger catch move the tone arm to the beginning of
the selection you want to play.
3
Lower the lifter lever.
•The tone arm lowers the stylus tip slowly onto the record and
playback starts.
4
NOTE:
•Be careful not to scratch the record.
Press STOP.
•Playback stops and the tone arm returns to its original position.
It is also possible to stop playback by raising the lifter lever. In
this case lift it using the head shell’s finger catch and move the
tone arm back to the arm rest.
ENGLISH
Starting playback using the auto play function Starting playback manually
Stopping playback in the middle of a record
Playback
position
Position when not in use
Stylus cover Cartridge

6
Operation Operation
ENGLISH
The included stylus has a service life of about 400 hours. To avoid
damaging valuable records, replace the stylus without delay.
Purchase a replacement stylus at the store where you purchased the
record player or your nearest repair and inquiry outlet. Specify that you
want the “DSN-85” replacement stylus exclusively for the DP-300F.
q
w
¢Removing the replaceable stylus
Holding the cartridge steady with one hand, grasp the replaceable
stylus with the other hand, push down in the direction of arrow q,
then pull the stylus off gently in the direction of arrow w.
Cartridge
q
w
¢Mounting the replaceable stylus
Holding the cartridge steady with one hand, grasp the replaceable
stylus with the other hand, point the catch on the replaceable
stylus in the direction of arrow q, insert it all the way into the long
hole in the cartridge, then push up in the direction of arrow wuntil
a click is heard.
•Before replacing the stylus, turn off the amplifier’s power and
unplug the player’s power supply cord.
•The stylus tip is an extremely delicate part, so handle it very
carefully. Use a soft brush to gently remove any dust from the stylus
tip.
•Removing the head shell makes it easy to replace the stylus.
If you wish to mount a different cartridge on this player, use one
weighing about 44 to 93 mN (about 4.5 to 9.5 g).
To purchase a head shell only, ask for a “PCL-310BK” exclusively for
the DP-300F at your store of purchase or nearest repair and inquiry
outlet.
¢Removing the cartridge
1. Turn the head shell lock nut in the direction of the arrow and
remove the head shell.
2. Remove the cartridge mount screws.
3. Disconnect the lead wires on the cartridge side.
Lock nut
Head shell
Cartridge mount screw
Washer
Lead wire
Cartridge
Nut
¢Mounting the cartridge
1. Connect the lead wires. They are color-coded as shown below. Be
careful to connect them properly.
RED .........................Right channel (R)
WHITE.....................Left channel (L)
GREEN.....................Right channel ground (RG)
BLUE .......................Left channel ground (LG)
2. To achieve the required overhang, mount in such a way that the
stylus tip is positioned about 1 ft/45 mm from the edge of the head
shell’s mount surface (the rubber washer), as shown on the
diagram below. (The overhang for this player should be 0.75 ft/19
mm.)
•After replacing the cartridge, do not forget to readjust the horizontal
balance, stylus pressure, and anti-skating value ( page 3).
•The thickness of the terminal depends on the replacement cartridge,
and some may not connect securely. In this case, use the included
spare lead wire.
1 ft/
45 mm
(Back side of head shell)
Mount parallel.
(Front side of head shell)
Mount perpendicular.
(Backside of cartridge)
Above (RED) R
(GREEN) RG
(WHITE) L
(BLUE) LG
ENGLISH
Replacing the stylus Replacing the cartridge

Symptom
7
ENGLISH
If a problem should arise, first check the following.
1. Are the connections correct?
2. Have you operated the player according to the Operating Instructions?
If this unit is not operating properly, check the items listed in the table below. Should the problem persist,
there may be a malfunction. Disconnect the power immediately and contact your store of purchase.
Power supply: AC 120 V, 60 Hz
Power consumption: 2 W
Maximum external dimensions: With dust cover closed :
434 (W) x 122 (H) x 381 (D) mm
(17-3/32” x 4-51/64” x 15”) (including protruding parts)
With dust cover open :
434 (W) x 386 (H) x 413 (D) mm
(17-3/32” x 15-13/64” x 16-19/64”) (including protruding parts)
Mass: 5.5 kg (12 lbs 2 oz)
Drive type: Belt drive
Motor: DC servo motor
Speed: 33-1/3 rpm, 45 rpm
Wow & flutter: 0.10 % W.R.M.S
S/N ratio: 60 dB
Tone arm: Static balance straight type tone arm
Effective arm length: 221.5 mm
Overhang: 19 mm
Cartridge: MM type
Output voltage: With equalizer OFF : 2.5 mV
With equalizer ON : 150 mV
Optimum stylus pressure: 19.6 mN (2.0 g)
Replaceable stylus number: DSN-85
Stylus pressure adjustment range: 0 ~ 39.2 mN (0 ~ 4.0 g)
One step 0.98 mN (0.1 g)
Suitable cartridge empty weight : 44 mN ~ 93 mN (4.5 ~ 9.5 g)
Head shell weight: 98 mN (10.0 g) (including screws and nuts)
Head shell part number: PCL-310BK
* For purposes of improvement, specifications and design are subject to change without notice.
PageMeasuresCause
Power does not turn
on.
Turntable does not turn.
•Power supply cord is not fully
inserted.
•Drive belt is detached from the
turntable.
•Check the connection.
•Check the drive belt and driving roller.
If the drive belt is detached from the
turntable, attach it using the
procedure described below.
1.Remove the turntable and turn it
upside down.
2.Catch the belt on the inside perimeter.
3.Turn the turntable back right side up
and pass the tape ribbon through the
hole and between the turn tape and
drive belt.
4.Mount the turntable, referring to the
assembly instructions on page 2.
4
2
The sound is scratchy,
the stylus skips or the
sound is distorted.
•The stylus or record is dirty.
•The stylus is worn or the record is
scratched.
•Remove the dirt or replace the stylus.
•Replace the stylus.
•Check the record.
7
7
—
The sound is either
extremely weak or too
strong and distorted.
•The equalizer switch is not set at the
proper position. •Set the switch according to the
terminal to which the player is
connected.
2
Howling is produced.
•The player is too close to the
speakers.
•The player is placed in an unstable
position.
•The playback sound is too loud.
•Move the player and speakers apart.
•Check the player’s place of installation.
•Adjust the amplifier’s volume.
—
—
—
The tone arm does not
move even when the
START button is
pressed.
•The tone arm is clamped to the
armrest.
•The power supply cord is not properly
connected.
•Remove the tone arm’s clamp.
•Check the connection of the power
supply cord.
2
4
No sound is produced.
•The pin-plug cable is not properly
connected.
•The amplifier’s function is not set for
the terminals to which the turntable is
connected.
•The replaceable stylus is not properly
mounted.
•Check the connection.
•Check the amplifier’s settings.
•Check the stylus.
4
4
7
ENGLISH
Others
Troubleshooting Specifications

Denon Brand Company, D&M Holdings Inc.
Printed in China 00D 511 4430 008
TOKYO, JAPAN
www.denon.com
