SERVICE MANUAL
DIRECT DRIVE TURN TABLE SYSTEM
MODEL DP-500M
Denon Brand Company, D&M Holdings Inc.
X0193 V.05 DE/CDM 0712
Some illustrations using in this service manual are
slightly different from the actual set.
●
Please use this service manual with referring to the
operating instructions without fail.
●
For purposes of improvement, specifications and
design are subject to change without notice.
●
●
本文中に使用しているイラストは、説明の都合上現物
と多少異なる場合があります。
●
修理の際は、必ず取扱説明書を参照の上、作業を行っ
てください。
サービスをおこなう前に、このサービスマニュアルを
必ずお読みください。本機は、火災、感電、けがなど
に対する安全性を確保するために、さまざまな配慮を
おこなっており、また法的には「電気用品安全法」に
もとづき、所定の許可を得て製造されております。
従ってサービスをおこなう際は、これらの安全性が維
持されるよう、このサービスマニュアルに記載されて
いる注意事項を必ずお守りください。
●
本機の仕様は性能改良のため、予告なく変更すること
があります。
●
補修用性能部品の保有期間は、製造打切後8年です。
注 意
For U.S.A. model
Ver. 5
Please refer to the
MODIFICATION NOTICE.

2
DP-500M
2
Please heed the points listed below during servicing and inspection.
◎Heed the cautions!
Spots requiring particular attention when servicing, such as
the cabinet, parts, chassis, etc., have cautions indicated on
labels or seals. Be sure to heed these cautions and the cau-
tions indicated in the handling instructions.
◎Caution concerning electric shock!
(1) An AC voltage is impressed on this set, so touching inter-
nal metal parts when the set is energized could cause
electric shock. Take care to avoid electric shock, by for ex-
ample using an isolating transformer and gloves when
servicing while the set is energized, unplugging the power
cord when replacing parts, etc.
(2)There are high voltage parts inside. Handle with extra care
when the set is energized.
◎ Caution concerning disassembly and assembly!
Though great care is taken when manufacturing parts from
sheet metal, there may in some rare cases be burrs on the
edges of parts which could cause injury if fingers are moved
across them. Use gloves to protect your hands.
◎Only use designated parts!
The set's parts have specific safety properties (fire resis-
tance, voltage resistance, etc.). For replacement parts, be
sure to use parts which have the same properties. In particu-
lar, for the important safety parts that are marked ! on wiring
diagrams and parts lists, be sure to use the designated parts.
◎Be sure to mount parts and arrange the
wires as they were originally!
For safety reasons, some parts use tape, tubes or other insu-
lating materials, and some parts are mounted away from the
surface of printed circuit boards. Care is also taken with the
positions of the wires inside and clamps are used to keep
wires away from heating and high voltage parts, so be sure to
set everything back as it was originally.
◎Inspect for safety after servicing!
Check that all screws, parts and wires removed or discon-
nected for servicing have been put back in their original posi-
tions, inspect that no parts around the area that has been
serviced have been negatively affected, conduct an insulation
check on the external metal connectors and between the
blades of the power plug, and otherwise check that safety is
ensured.
(Insulation check procedure)
Unplug the power cord from the power outlet, disconnect the
antenna, plugs, etc., and turn the power switch on. Using a
500V insulation resistance tester, check that the insulation re-
sistance between the terminals of the power plug and the ex-
ternally exposed metal parts (antenna terminal, headphones
terminal, microphone terminal, input terminal, etc.) is 1MΩor
greater. If it is less, the set must be inspected and repaired.
Concerning important safety parts
Many of the electric and structural parts used in the set have
special safety properties. In most cases these properties are
difficult to distinguish by sight, and using replacement parts
with higher ratings (rated power and withstand voltage) does
not necessarily guarantee that safety performance will be pre-
served. Parts with safety properties are indicated as shown
below on the wiring diagrams and parts lists is this service
manual. Be sure to replace them with parts with the designat-
ed part number.
(1) Schematic diagrams ... Indicated by the ! mark.
(2) Parts lists ... Indicated by the ! mark.
Using parts other than the designated parts
could result in electric shock, fires or other
dangerous situations.
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power
cord is less than 460 kohms, the unit is defective.
CAUTION
CAUTION
サービス、点検時にはつぎのことにご注意願います。
◎注意事項をお守りください！
サービスのとき特に注意を必要とする個所についてはキャ
ビネット、部品、シャーシなどにラベルや捺印で注意事項を
表示しています。これらの注意書きおよび取扱説明書などの
注意事項を必ずお守りください。
◎感電に注意！
(1) このセットは、交流電圧が印加されていますので通電時
に内部金属部に触れると感電することがあります。従っ
て通電サービス時には、絶縁トランスの使用や手袋の着
用、部品交換には、電源プラグを抜くなどして感電にご
注意ください。
(2) 内部には高電圧の部分がありますので、通電時の取扱に
は十分ご注意ください。
◎分解、組み立て作業時のご注意！
板金部品の端面の『バリ』は、部品製造時に充分管理をして
おりますが、板金端面は鋭利となっている箇所が有りますの
で、部品端面に触れたまま指を動かすとまれに怪我をする場
合がありますので十分注意して作業して下さい。手の保護の
ために手袋を着用してください。
◎指定部品の使用！
セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は、使用されていたも
のと同じ特性の部品を使用してください。特に配線図、部品
表に!印で指定されている安全上重要な部品は必ず指定の
ものをご使用ください。
◎部品の取付けや配線の引きまわしは、
元どおりに！
安全上、テープやチューブなどの絶縁材料を使用したり、プ
リント基板から浮かして取付けた部品があります。また内部
配線は引きまわしやクランパーによって発熱部品や高圧部
品に接近しないように配慮されていますので、これらは必ず
元どおりにしてください。
◎サービス後は安全点検を！
サービスのために取り外したねじ、部品、配線などが元どお
りになっているか、またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し、外部金属端子部
と、電源プラグの刃の間の絶縁チェックをおこなうなど、安
全性が確保されていることを確認してください。
（絶縁チェックの方法）
電源コンセントから電源プラグを抜き、アンテナやプラグな
どを外し、電源スイッチを入れます。500V 絶縁抵抗計を用
いて、電源プラグのそれぞれの端子と外部露出金属部［アン
テナ端子、ヘッドホン端子、マイク端子、入力端子など］と
の間で、絶縁抵抗値が１ MΩ 以上であることを確認してく
ださい。この値以下のときはセットの点検修理が必要です。
安全上重要な部品について
本機に使用している多くの電気部品、および機構部品は安全
上、特別な特性を持っています。この特性はほとんどの場合、
外観では判別つきにくく、またもとの部品より高い定格（定
格電力、耐圧）を持ったものを使用しても安全性が維持され
るとは、限りません。安全上の特性を持った部品は、この
サービスマニュアルの配線図、部品表につぎのように表示し
ていますので必ず指定されている部品番号のものを使用願
います。
(1) 配線図…!マークで表示しています。
(2) 部品表…!マークで表示しています。
指定された部品と異なるものを使用した場合に
は、感電、火災などの危険を生じる恐れがあり
ます。
注 意
注 意

3
3
DP-500M
DISASSEMBLY
( For reassembling, do reverse manner as to disassembling.)
1. PLATTER
(1) Remove mat on the platter.
(2) Remove platter by both hands.
2. BOTTOM BASE ASS'Y
(1) Put cabinet reversely.
(2) Remove 9 screws securing the bottom base Ass’y.
(3) Remove bottom base Ass’y by both hands.

4
4
DP-500M
3. MAIN P.W.B. ASS'Y , TONE ARM ASS'Y
(1) Remove 4 screws ①fastening the main P.W.B Ass’y.
(2) Unsolder 5 wires and GND wire from arm section on the output P.W.B. Ass’y.
(3) Remove 3 screws ②secured the tone arm.( Hold tone arm during removing.)
4. D.D. MOTOR ASS'Y, TRANSFORMER
(1) Remove 5 screws ③secured the D.D.motor Ass’y.
(2) Unsolder GND wire from output P.W.B. Ass’y on the D.D.motor Ass’y.
(3) Put cabinet reversely.
(4) Remove 4 screws ④secured D.D.motor Ass’y. ( Hold D.D.motor Ass' y during removing.)
(5) While holding 4 nuts ⑤, remove 4 screws ⑥secured transformer.
1
2
CN901
3
4
6
5

5
5
DP-500M
5. BUTTON ASS'Y
(1) Remove 6 screws ⑦secured the plates.
(2) Remove 3 screws ⑧secured the 33/45 P.W.B. Ass’y.
(3) Remove the plates from the button frame.
6. BUTTON DISASSEMBLING
(1) Insert a screwdriver or similar tool into the holes ( two places ) on the bottom of button frame and
push in the arrow direction firmly to remove the button from push switch.
(2) Remove 2 screws ⑨in the button frame.
7
7
8
7
9

6
6
DP-500M
BLOCK DIAGRAM
IC302
BA10393
CIRCUIT RECTIFIER
IC301
BD4745G
RESET IC
X301
OSCILLATOR
16MHz
IC304
W27C512
ROM
IC104
4580
LEVEL ADJ.
IC105
4580
THE TWO-PHASE CONVERTS
THREE-PHASE VOLTAGE
IC106
BU4066
VOLTAGE OUTPUT
CONTROL SWITCH IC
IC101,102
NIM2147DIP
DRIVE IC
Q103,104
2SD1889,2SD1341
DRIVE TRANSISTOR
Q105,106
2SD1889,2SD1341
DRIVE TRANSISTOR
HALL IC
H11,H12,H13
US1881KUA
Q107,108
2SD1889,2SD1341
DRIVE TRANSISTOR
COIL
FG
HEDS-9700
AF51
IC901,902,903
IC904,905,906
POWER
IC303
MAX003
CPU
33 1/3,45 LED DISPLAY

7
7
DP-500M
ADJUSTMENT
1. WOW AND FLUTTER
(1) Remove the platter and put cabinet reversely.
(2) Remove the bottom base Ass’y.
(3) Connect 2 digital volt meters or testers to CN104 of D.D. motor P.W.B.( refer to the CN104 fig.)
(4) Turn ON and set the speed select switch to 33 rpm.
(5) Adjust R134 so that the absolute DC voltage of two meters may become the nearest.
or tester or tester

8
8
DP-500M
SEMICONDUCTORS
Only major semiconductors are shown, general semiconductors etc. are omitted to list.
主な半導体を記載しています。汎用の半導体は記載を省略しています。
IC’s
MAX003 (IC303)
W27E512-12/W27C512-45 (IC304)
VCL
1
PB0
2
PB1
3
PB2
4
PB3
5
PB4
6
PB5
7
PB6
8
PB7
9
RESO
10
VSS
11
P90
12
P91
13
P92
14
P93
15
P94
16
P95
17
D0/P40
18
D1/P41
19
D2/P42
20
D3/P43
21
VSS
22
D4/P44
23
D5/P45
24
D6/P46
25
D7/P47 26
D8 27
D9 28
D10 29
D11 30
D12 31
D13 32
D14 33
D15 34
VCC 35
A0 36
A1 37
VSS 44
VSS 57
P60/WAIT 58
P61/BREQ 59
P62/BACK 60
P67/ 61
STBY 62
RES 63
NMI 64
VSS 65
EXTAL 66
XTAL 67
VCC 68
AS 69
RD 70
HWR 71 LWR 72
MD0 73 MD1 74 MD2 75
AVCC
76
VREF
77
P70/AN0
78
P71/AN1
79
P72/AN2
80
P73/AN3
81
P74/AN4
82
P75/AN5
83
P76/AN6/DA0
84
P77/AN7/DA1
85
AVSS
86
IRQ0/P80
87
CS3/IRQ1/P81
88
CS2/IRQ2/P82
89
ADTRG/CS1/IRQ3/P83
90
CS0/P84
91
VSS
92
TCLKA/TP0/PA0
93
TCLKB/TP1/PA1
94
TCLKC/TIOCA0/TP2/PA2
95
TCLKD/TIOCB0/TP3/PA3
96
A23/PA4
97
A22/PA5
98
A21/PA6
99
A20/PA7
100
A2 38
A3 39
A4 40
A5 41
A6 42
A7 43
A8 45
A9 46
A10 47
A11 48
A12 49
A13 50
A14 51 A15 52 A16 53 A17 54 A18 55 A19 56
IC303
MAX003
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
28-pin
DIP
A15
A12
A7
A6
A5
A4
A3
A2
A1
A0
Q0
Q1
Q2
DND
Vcc
A14
A13
A8
A9
A11
OE/Vpp
A10
CE
Q7
Q6
Q5
Q4
Q3
SYMBOL
PIN DESCRIPTION
DESCRIPTION
A0-A15
Q0-Q7
CE
OE/Vpp
Vcc
GND
NC
Address Inputs
Data Inputs/Outputs
Chip Enable
Output Enable, Program/Erase
Supply Voltage
Power Supply
Ground
No Connection

9
9
DP-500M
NJM-2147D (IC101,102)
HEDS9700F51 (IC103)
1
2
3
4
8
7
6
5
Vcc
OUT2
OUT1
-IN1
+IN1
V
EE
-IN2
+IN2
1ch
2ch
+
+
-
-

10
10
DP-500M
US1881 (H11 〜H13)
DTC124TS
2SB1340
2SD1889
U18
135
12
3
*
PINOUT:
Pin 1 V
DD
Pin 2 GND
Pin 3 Output
(1) Emitter
(2) Collector
(3) Base
C
B
R1R2
E
B : Base
C : Collector
E : Emitter
R1≒5.0kΩ
R2≒300Ω
C
B
R1R2
E
B : Base
C : Collector
E : Emitter
R1≒5.0kΩ
R2≒300Ω

11
11
DP-500M
12 345678
A
B
C
D
E
MAINP.W.B.UNIT
33/45P.W.B.UNIT
START/STOPP.W.B.UNIT
ACP.W.B.UNIT
OUTPUTP.W.B.UNIT
FOILSIDE COMPONENTSIDE
COMPONENTSIDE
COMPONENTSIDE
COMPONENTSIDE
COMPONENTSIDE
PRINTED WIRING BOARD (1/2)

12
12
DP-500M
12 345678
A
B
C
D
E
PRINTED WIRING BOARD (2/2)
D.D.MOTERP.W.B.UNIT
COMPONENTSIDE
FOILSIDE

13
13
DP-500M
NOTE FOR PARTS LIST
5% 1/4W
1/16W
s
s
s
s
ss
ss
s
s
s
s
RD : 2B : 1/8 W F : ±1% P :
RC : 2E : 1/4 W G : ±2% NL :
RS : 2H : 1/2 W J : ±5% NB :
RW : 3A : 1 W K : ±10% FR :
RN : 3D : 2 W M : ±20% F :
RK : 3F : 3 W
3H : 5 W
RN 14K 2E 182 G FR
∗18 2 Ö1800 =1.8k
0
2
1R 2 Ö1.2
1
2 R
CE 04W 1H 2R2 M BP
CE : 0J : 6.3 V F : ±1% HS :
CA : 1A : 10 V G : ±2% BP :
CS : 1C : 16 V J : ±5% HR :
CQ : 1E : 25 V K : ±10% DL :
CK : 1V : 35 V M : ±20% HF :
CC : 1H : 50 V Z : +80% U : UL
CP : 2A : 100 V −20% C : CSA
CM : 2B : 125 V P : +100% W : UL-CSA
CF : 2C : 160 V −0% F :
CH : 2D : 200 V C : ±0.25pF
2E : 250 V D : ±0.5pF
2H : 500 V = :
2J : 630 V
∗
22 2 Ö2200µF
0
2
µF
22 2 Ö2200pF=0.0022µF
0
2
pFpF
22 1 Ö220pF
2
(0 2 )
0
(0 0 1 )
2R 2 Ö2.2µF
1
2 R
µF
AC
RD : Carbon 2B : 1/8W F : ±1% P : Pulse-resistant type
RC : Composition 2E : 1/4W G : ±2% NL : Low noise type
RS : Metal oxide film 2H : 1/2W J : ±5% NB : Non-burning type
RW : Winding 3A : 1W K : ±10% FR : Fuse-resistor
RN : Metal film 3D : 2W M : ±20% F : Lead wire forming
RK : Metal mixture 3F : 3W
3H : 5W
CE : Aluminum foil 0J : 6.3V F : ±1% HS : High stability type
electrolytic
CA : Aluminum solid 1A : 10V G : ±2% BP : Non-polar type
electrolytic
CS : Tantalum electrolytic 1C : 16V J : ±5% HR : Ripple-resistant type
CQ : Film 1E : 25V K : ±10% DL : For change and discharge
CK : Ceramic 1V : 35V M : ±20% HF : For assuring high
requency
CC : Ceramic 1H : 50V Z : +80% U : UL part
CP : Oil 2A : 100V –20% C : CSA part
CM : Mica 2B : 125V P : +100% W : UL-CSA type
CF : Metallized 2C : 160V –0% F : Lead wire forming
CH : Metallized 2D : 200V C : ±0.25pF
2E : 250V D : ±0.5pF
2H : 500V = : Others
2J : 630V
lPart indicated with the mark "" are not always in stock and possibly to
take a long period of time for supplying, or in some case supplying of
part may be refused.
lWhen ordering of part, clearly indicate "1" and "I" (i) to avoid mis-
supplying.
lOrdering part without stating its part number can not be supplied.
lPart indicated with the mark " " is not illustrated in the exploded view.
lNot including Carbon Film Resister ±5%, 1/4W Type in the P.W.Board
parts list. (Refer to the Schematic Diagram for those parts.)
lNot including Carbon Chip Resister 1/16W Type in the P.W.Board parts
list. (Refer to the Schematic Diagram for those parts.)
WARNING:
Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacturer.
ll
ll
lResistors
Ex.:RN 14K 2E 182 GFR
Type Shape Power Resist- Allowable Others
and per- ance error
formance
]Resistance
1 8 2⇒1800 ohm = 1.8 kohm
Indicates number of zeros after effective number.
2-digit effective number.
•Units: ohm
1 R 2⇒1.2 ohm
1-digit effective number.
2-digit effective number, decimal point indicated by R.
•Units: ohm
ll
ll
lCapacitors
Ex.:CE 04W 1H 2R2 M BP
Type Shape Dielectric Capacity Allowable Others
and per- strength error
formance
]Capacity (electrolyte only)
2 2 2⇒2200µF
Indicates number of zeros after effective number.
2-digit effective number.
•Units: µF.
2 R 2⇒2.2µF
1-digit effective number.
2-digit effective number, decimal point indicated by R.
•Units: µF.
]Capacity (except electrolyte)
2 2 2⇒2200pF=0.0022µF
(More than 2) Indicates number of zeros after effective number.
2-digit effective number.
•Units: pF.
2 2 1⇒220pF
(0 or 1) Indicates number of zeros after effective number.
2-digit effective number.
•Units: pF.
•When the dielectric strength is indicated in AC, "AC" is included after the dieelectric
strength value.

14
14
DP-500M
PARTS LIST OF P.W.B. UNIT ASS’Y
PARTSLISTOFMAINP.W.B.ASS'Y
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC301 941 0021 900 IC(BD4745G/BD4745G/TR) 417-HDJ2000-503 *
IC302 941 0021 803 IC(BA10393F/BA10393FE2,SOP-8) 417-DV330-197 *
IC303 941 0021 706 IC(MAX003,FP-100B) 417-DJ5500-578 *
IC304 941 0025 003 IC SOCKET(28PIN P=2.54mm) 404-HV3500K-613 *
IC304 941 0022 006 IC ASS'Y 704-1300-4440 *
- IC(W27E512-12/W27C512-45,DIP-28,OTP) 417-HV3500K-244 *
Q301 958 0040 507 TRANSISTOR(2SC1740R TAPING) 416-3113-007
Q302 958 0040 507 TRANSISTOR(2SC1740R TAPING) 416-3113-007
D301 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D302 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D303 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D304 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D305 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D306 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
RESISTORS GROUP
R301 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R302 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R303 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R304 241 2399 970 CARBON FILM RESISTOR(3.3K OHM J 1/6W TAPING 26mm) 412-3113-057
R305 241 2405 974 CARBON FILM RESISTOR(1M OHM J 1/6W TAPING 26mm) 412-3113-079
R306 241 2398 052 CARBON FILM RESISTOR(1K OHM J 1/6W TAPING 26mm) 412-3113-078
R307 241 2396 025 CARBON FILM RESISTOR(100 OHM J 1/6W TAPING 26mm) 412-3113-060
R308 241 2402 951 CARBON FILM RESISTOR(47K OHM J 1/6W TAPING 26mm) 412-3113-063
R309 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R310 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R311 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R312 241 2399 970 CARBON FILM RESISTOR(3.3K OHM J 1/6W TAPING 26mm) 412-3113-057
R313 241 2405 974 CARBON FILM RESISTOR(1M OHM J 1/6W TAPING 26mm) 412-3113-079
R314 241 2398 052 CARBON FILM RESISTOR(1K OHM J 1/6W TAPING 26mm) 412-3113-078
R315 241 2396 025 CARBON FILM RESISTOR(100 OHM J 1/6W TAPING 26mm) 412-3113-060
R316 241 2402 951 CARBON FILM RESISTOR(47K OHM J 1/6W TAPING 26mm) 412-3113-063
R317 241 2400 911 CARBON FILM RESISTOR(4.7K OHM J 1/6W TAPING 26mm) 412-3113-055
R318 241 2400 911 CARBON FILM RESISTOR(4.7K OHM J 1/6W TAPING 26mm) 412-3113-055
R319 241 2400 911 CARBON FILM RESISTOR(4.7K OHM J 1/6W TAPING 26mm) 412-3113-055
R320 241 2400 911 CARBON FILM RESISTOR(4.7K OHM J 1/6W TAPING 26mm) 412-3113-055
R321 241 2396 025 CARBON FILM RESISTOR(100 OHM J 1/6W TAPING 26mm) 412-3113-060
R322 241 2405 974 CARBON FILM RESISTOR(1M OHM J 1/6W TAPING 26mm) 412-3113-079
R323 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R324 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R325 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R326 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R327 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R328 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R329 241 2397 972 CARBON FILM RESISTOR(470 OHM J 1/6W TAPING 26mm) 412-3113-056
R330 241 2397 972 CARBON FILM RESISTOR(470 OHM J 1/6W TAPING 26mm) 412-3113-056
R331 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R332 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R333 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
CAPACITORS GROUP
C301 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C302 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C303 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C304 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C305 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035

15
15
DP-500M
PARTSLISTOFDC&33/45&START/STOPP.W.B.ASS'Y
C305 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C306 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C307 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C308 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046
C309 941 0024 703 ELEC. CAPACITOR(1uF/50V,M,TAPING 5*11) 413-3113-049
C310 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C311 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C312 941 0024 512 CERAMIC CAPACITOR(18pF/50V,J,TAPING,NPO) 413-HT7016-213 *
C313 941 0024 525 CERAMIC CAPACITOR(15pF/50V,J,TAPING,NPO) 413-KM280-173 *
C314 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C315 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C316 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C317 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C318 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C319 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C320 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
OTHER PARTS GROUP
X301 958 0074 803 CITIZEN BRAND(CSA-309,16MHz) 427-CDN88-072
L301 958 0016 900 BEAD CORE(86-019-A TAPING) 415-HV3500K-090
L302 958 0016 900 BEAD CORE(86-019-A TAPING) 415-HV3500K-090
L303 958 0016 900 BEAD CORE(86-019-A TAPING) 415-HV3500K-090
L304 958 0016 900 BEAD CORE(86-019-A TAPING) 415-HV3500K-090
CN301 941 0025 100 4P SOCKET(B4B-PH-K-S,JST,180°)404-KM300-123 *
CN302 941 0024 800 11P SOCKET 404-HDJ9700-1556 *
CN303 941 0024 907 2P SOCKET(JST WHITE B2B-PH-K-S P=2mm) 404-HP1010K-257 *
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC901 958 0040 303 IC 7805 417-KC730-123
IC902 941 0022 103 IC(7812) 417-BJ1900L-231 *
D201 941 0023 102 LED(LTL1CHKFKNN) 410-1300-243 *
D202 941 0023 209 LED(LTL1RMTGK) 410-1300-244 *
OTHER PARTS GROUP
CN201 941 0025 207 4P2.0 CONNECTOR WIRE(L=140mm,AWM1007 AWG26) 404-1300-1678 *
CN202 941 0022 909 2P CONNECTOR WIRE(L=150mm,P=2mm,90 DEGREES) 404-HDJ7100-760 *
CN903A 941 0023 403 4P SOCKET(S4B-XH-A,P=2.5mm,90°)404-QMX2-606 *
SW201 958 0018 306 TACT SW(SKHVBE3520-HF,TAPING) 403-DCM270X-101
SW202 941 0015 806 PUSH SW*SPUN12A010-HF) 403-1300-181 *
941 0015 709 START/STOP BUTTON 701-500-2907 *
941 0019 501 SCREW(M3*8,P=0.5,BLACK) 602-2002-085 *
941 0019 598 SCREW(BTP,DIA3*6) 602-DJ3000-274 *
941 0022 802 BUTTON FRAME 100-5500-2094 *
941 0023 005 SHAFT FOR KNOB 200-500-340 *
941 0023 306 LED HOLDER D201.
202
504-QD5-127 *
- HEAT SINK 425-DJ3000-023 *
Ref. No. Part No. Part Name Remarks New

16
16
DP-500M
PARTSLISTOFOUTPUT&POWERP.W.B.ASS'Y
PARTSLISTOFD.DMOTORP.W.B.ASS'Y
Ref. No. Part No. Part Name Remarks New
CAPACITORS GROUP
! C01 958 0045 308 MEX CAPACITOR(0.1uF/250V,K,BULK) 413-PROTT1-432
! C02 958 0010 003 SPARK CAPACITOR(4700pF/250V,M,BULK,Y5V) 413-1431-104
OTHER PARTS GROUP
! F01 958 0046 404 FUSE(1A/250V,T-MARK/UL/CSA) 422-CDN12F-028
! F1 941 0022 608 WAVE FILTER 415-1300-239 *
CN1 941 0022 501 2P SOCKET(P=3.96mm,90 DEGREES) 404-BEAT6-1598 *
JK601 941 0022 307 2P RCA JACK(RJ-1078-10-0500A) 420-RCC955A-089 *
958 0045 405 FUSE CLIPS(FC-1206/WL-210A,15A) F01 420-KT350A-004
958 0045 609 FUSE COVER F01 504-DJ2500J-046
958 0045 803 BRACKET(L TYPE) 300-HDJ7000-472
941 0017 901 AC CORD FIXING PLATE 300-5500-1010 *
941 0018 007 RCA FIXING PLATE 300-5500-1009 *
! 941 0019 103 AC CORD(L=2000+-30mm,J TYPE) 409-500-112 *
941 0019 608 WASHER(φ8*3.2*1t) 606-Q2221-122 *
! 958 0009 409 CORD BUSH 100-HC1421FR-991
958 0035 101 GROUND PIN 200-DJ100-231
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 409 SCREW(M3*8,P=0.5,BLACK) 602-2002-085
958 0046 103 SCREW(3*5 P=0.5) 602-B300-041
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101 941 0021 104 IC(NJM-2147D,DIP-8) 417-DJ5500-579 *
IC102 941 0021 104 IC(NJM-2147D,DIP-8) 417-DJ5500-579 *
IC104 941 0021 609 IC(NJM-4580M-TE2,SOP-8) 417-ST150-599 *
IC105 941 0021 609 IC(NJM-4580M-TE2,SOP-8) 417-ST150-599 *
IC106 941 0021 502 IC(TC4066BFN/BU4066BCF/BU4066BCF-E2,SOP-14) 417-QMX2-190 *
IC903 941 0021 007 IC(NJM7824) 417-DJ2500-268 *
IC904 941 0021 201 IC(NJM-7924FA,3PIN) 417-DJ5500-581 *
IC905 941 0021 308 IC(NJM7815FA 3PIN) 417-DV330-216 *
IC906 941 0021 405 IC(NJM7915FA) 417-RCC955A-291 *
Q101 958 0040 400 DIGITAL TRANSISTOR(DTC124TS TAPING OR 2SC4120) 416-1330-020
Q102 958 0040 808 TRANSISTOR(DTA124TS/2SA1589/DTA124TSATP,TAPING) 416-KE200S-024
Q107 941 0023 607 TRANSISTOR(2SD1889,TO-220FP) 416-DJ5500-206 *
Q108 941 0023 500 TRANSISTOR(2SB1340,TO-220FP) 416-DJ5500-205 *
! F02 941 0030 001 FUSE(2.5A/125V) 422-1300-051 *
! F03 941 0030 001 FUSE(2.5A/125V) 422-1300-051 *
D101 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D102 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D103 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D104 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D105 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D106 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D107 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D108 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D109 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D110 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D111 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D112 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D113 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005

17
17
DP-500M
D114 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D115 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D116 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D117 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D118 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D119 958 0042 806 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005
D120 958 0075 103 ZENER DIODE(MTZJ5.1-B,1/2W,T-77) 414-HDJ200-056
D121 958 0075 103 ZENER DIODE(MTZJ5.1-B,1/2W,T-77) 414-HDJ200-056
D901 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D902 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D903 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D904 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D905 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D906 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D907 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
D908 958 0018 607 DIODE(1N4002,1A/100V,TAPING) 414-DV300-5014
RESISTORS GROUP
R101 241 2400 953 CARBON FILM RESISTOR(6.8K OHM J 1/6W TAPING 26mm) 412-3113-069
R102 241 2398 010 CARBON FILM RESISTOR(680 OHM J 1/6W TAPING 26mm) 412-3113-070
R103 241 2405 013 CARBON FILM RESISTOR(560K OHM J 1/6W TAPING 26mm) 412-3113-072
R104 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R105 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R106 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R107 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R108 241 2400 953 CARBON FILM RESISTOR(6.8K OHM J 1/6W TAPING 26mm) 412-3113-069
R109 241 2398 010 CARBON FILM RESISTOR(680 OHM J 1/6W TAPING 26mm) 412-3113-070
R110 241 2405 013 CARBON FILM RESISTOR(560K OHM J 1/6W TAPING 26mm) 412-3113-072
R111 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R112 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R113 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R114 941 0025 359 CHIP RESISTOR(22K OHM,J,TP 0805,150V) 412-DV330-314 *
R115 241 2400 953 CARBON FILM RESISTOR(6.8K OHM J 1/6W TAPING 26mm) 412-3113-069
R116 241 2398 010 CARBON FILM RESISTOR(680 OHM J 1/6W TAPING 26mm) 412-3113-070
R117 241 2405 013 CARBON FILM RESISTOR(560K OHM J 1/6W TAPING 26mm) 412-3113-072
R118 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R119 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R120 241 2397 927 CARBON FILM RESISTOR(270 OHM J 1/6W TAPING 26mm) 412-3113-049
R121 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R122 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R123 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R124 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R125 941 0025 346 CHIP RESISTOR(10K OHM,1/8W,J,TP 0805,150V) 412-DV330-306 *
R126 941 0025 317 CHIP RESISTOR(680K OHM,1/8W,J,TP 0805,150V) 412-CDN88-024 *
R127 941 0025 304 CHIP RESISTOR(18K OHM,J,TP 0805,150V) 412-AMC110D-5057 *
R128 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R129 941 0025 317 CHIP RESISTOR(680K OHM,1/8W,J,TP 0805,150V) 412-CDN88-024 *
R130 241 2401 952 CARBON FILM RESISTOR(18K OHM J 1/6W TAPING 26mm) 412-3113-061
R131 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R132 941 0025 359 CHIP RESISTOR(22K OHM,J,TP 0805,150V) 412-DV330-314
R133 941 0025 375 CHIP RESISTOR(12K OHM,1/8W,J,TP 0805,150V) 412-DV330-330 *
R134 941 0024 305 RESISTOR(4.7KB,RH0615CS3J) 412-KC220-127 *
R135 941 0025 391 CHIP RESISTOR(2.7K OHM,1/8W,J,TP 0805,150V) 412-QSPAND-496 *
R136 941 0025 304 CHIP RESISTOR(18K OHM,J,TP 0805,150V) 412-AMC110D-5057 *
R137 241 2401 952 CARBON FILM RESISTOR(18K OHM J 1/6W TAPING 26mm) 412-3113-061
R138 941 0025 304 CHIP RESISTOR(18K OHM,J,TP 0805,150V) 412-AMC110D-5057 *
R139 941 0025 359 CHIP RESISTOR(22K OHM,J,TP 0805,150V) 412-DV330-314 *
R140 241 2401 978 CARBON FILM RESISTOR(22K OHM J 1/6W TAPING 26mm) 412-3113-059
R141 941 0025 362 CHIP RESISTOR(47K OHM,1/8W,J,TP 0805,150V) 412-DV330-321 *
R142 941 0025 359 CHIP RESISTOR(22K OHM,J,TP 0805,150V) 412-DV330-314 *
R143 941 0025 359 CHIP RESISTOR(22K OHM,J,TP 0805,150V) 412-DV330-314 *
Ref. No. Part No. Part Name Remarks New

18
18
DP-500M
R144 941 0025 333 CHIP RESISTOR(1K OHM,1/8W,J,TP 0805,150V) 412-DV330-305 *
R145 241 2398 052 CARBON FILM RESISTOR(1K OHM J 1/6W TAPING 26mm) 412-3113-078
R146 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R147 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R148 941 0024 101 METAL FILM RESISTOR(1 OHM,1W,J,T-73) 412-DJ5500-661 *
R149 241 2400 995 CARBON FILM RESISTOR(10K OHM J 1/6W TAPING 26mm) 412-3113-068
R150 941 0025 333 CHIP RESISTOR(1K OHM,1/8W,J,TP 0805,150V) 412-DV330-305 *
R151 941 0025 333 CHIP RESISTOR(1K OHM,1/8W,J,TP 0805,150V) 412-DV330-305 *
R152 941 0025 333 CHIP RESISTOR(1K OHM,1/8W,J,TP 0805,150V) 412-DV330-305 *
R153 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R154 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
R155 241 2397 901 CARBON FILM RESISTOR(220 OHM J 1/6W TAPING 26mm) 412-3113-058
CAPACITORS GROUP
C101 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C102 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C103 958 0049 100 CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311
C104 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C105 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C106 958 0049 100 CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311
C107 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C108 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C109 941 0024 509 CERAMIC CAPACITOR(1000pF/50V,K,TAPING,Y5P) 413-1430-071 *
C110 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C111 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C112 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C113 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C114 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C115 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C116 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C117 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C118 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C119 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C120 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C121 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C122 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C123 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C124 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C125 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C126 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C127 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C128 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C129 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C130 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C131 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C132 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C133 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C134 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C135 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C136 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C137 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C138 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C139 958 0049 100 CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311
C140 958 0049 100 CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311
C141 958 0049 100 CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311
C901 958 0044 105 ELEC. CAPACITOR(100uF/25V,M,BULK 12.5*20) 413-DJ1900-111
C904 941 0024 237 ELEC. CAPACITOR(100uF/16V,M,TAPING 5*11) 413-PXE90-109 *
C905 941 0024 208 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 *
C906 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C907 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C908 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
Ref. No. Part No. Part Name Remarks New

19
19
DP-500M
C909 941 0024 402 ELEC. CAPACITOR(2200uF/35V,M,BULK 16*25) 413-HT7016-223 *
C910 941 0024 402 ELEC. CAPACITOR(2200uF/35V,M,BULK 16*25) 413-HT7016-223 *
C911 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C912 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C913 941 0024 211 ELEC. CAPACITOR(100uF/35V,M,TAPING 8*11) 413-HMD5000-356 *
C914 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C915 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C916 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
C917 941 0024 224 ELEC. CAPACITOR(100uf/25V,M,TAPING 6.3*11) 413-HS100-180 *
C918 958 0055 505 CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035
C918 941 0024 606 CHIP CAPACITOR(0.1uF/50V,Z,0805 TYPE,Y5V) 413-DV330-313 *
CN102 941 0024 004 4P2.0 CONNECTOR WIRE(L=100mm,AWM1571 AWG28) 404-ST150-1574 *
CN103 941 0023 704 11P2.0 CONNECTOR WIRE(L=150mm,AWM1007 AWG26) 404-1300-1679 *
CN104 958 0042 204 3 PIN 424-KT350-005
CN901 941 0023 908 5P SOCKET(S5B-XH-A,P=2.5mm,90°)404-SPPW3-513 *
CN903 941 0023 801 4P CONNECTOR WIRE(L=300mm,AWM1007 AWG26) 404-CDMIX1-949 *
OTHER PARTS GROUP
L901 958 0016 900 BEAD CORE(86-019-A TAPING) 415-HV3500K-090
- HEAT SINK IC903 425-2002-001
- HEAT SINK IC904 425-2002-001
- HEAT SINK(HW-7004) IC905
&906
425-ST150-064
- HEAT SINK(HW-7004) Q107&
108 425-ST150-064
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
958 0038 302 SCREW(3*8mm BTP) 602-2002-077
Ref. No. Part No. Part Name Remarks New

20
20
DP-500M
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by the
manufacturer.
WARNING:
EXPLODED VIEW
Parts List
