Denso 400BW-CE User manual

Bar Code Handy Terminal
BHT
-
400B-CE/400B
W
-CE
User’sManual

If you leave the BHT with the battery cartridge discharged or with no battery cartridge
loaded or if you replace the battery cartridge in a wrong way, the BHT may lose the data
stored in it.
Before cold booting (refer to Chapter 2, Section 2.3.5 "Warm and Cold Booting"), it is
recommended that important data be saved into the FLASH folder or uploaded to the
host computer. Cold booting will erase all data stored in the RAM.
DENSO WAVE INCORPORATED does not assume any product liability arising out of, or in
connection with, the application or use of any product, circuit, or application described herein.
If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the
product having been dropped or subjected to impact, repairs will be made at a reasonable charge
even within the warranty period.
Intellectual Property Precaution
DENSO WAVE INCORPORATED ("DENSO WAVE") takes reasonable precautions to ensure its
products do not infringe upon any patent of other intellectual property rights of other(s), but DENSO
WAVE cannot be responsible for any patent or other intellectual property right infringement(s) or
violation(s) which arise from (i) the use of DENSO WAVE's product(s) in connection or in
combination with other component(s), product(s), data processing system(s) or equipment or
software not supplied from DENSO WAVE; (ii) the use of DENSO WAVE's products in a manner for
which the same were not intended nor designed; or (iii) any modification of DENSO WAVE's
products by other(s) than DENSO WAVE.
Limited Warranty on Software Products
In no event will DENSO WAVE INCORPORATED be liable for direct, indirect, special, incidental, or
consequential damages (including imaginary profits or damages resulting from interruption of
operation or loss of business information) resulting from any defect in the software or its
documentation or resulting from inability to apply the software or its documentation.

Copyright © DENSO WAVE INCORPORATED, 2007
All rights reserved. No part of this publication may be reproduced in any form or by any means without
permission in writing from the publisher.
Specifications are subject to change without prior notice.
Microsoft, Windows and ActiveSync are either registered trademarks or trademarks of Microsoft
Corporation.
Other products and company names mentioned in this manual are trademarks or registered trademarks
of their respective holders.
The latest precision manufacturing technology yields LCD panels whose pixels are 99.99% defect free.
The downside, note, is that up to 0.01% of the pixels can remain permanently dark or lit on today's
state-of-the-art panels.
Thin Newton's rings (rainbow-like patterns) may appear on the touch panel.
This does not necessarily indicate a problem with the touch panel.

US and Canada Regulations
BHT-400BW-CE contains Wireless LAN module (type WM-G-MR-01) that complies with Part 15 of FCC
rules and RSS-Gen of IC rules.
For Wireless LAN module
This device complies with Part 15 of FCC rules and RSS-Gen of IC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
FCC WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
CAUTION: Radio Frequency Radiation Exposure
The available scientific evidence does not show that any health problems are associated with using
low power wireless devices. There is no proof, however, that these low power wireless devices are
absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the
microwave range while being used. Whereas high levels of RF can produce health effects (by
heating tissue), exposure to low-level RF that does not produce heating effects causes no known
adverse health effects. Many studies of low-level RF exposures have not found any biological effects.
Some studies have suggested that some biological effects might occur, but such findings have not
been confirmed by additional research. This Barcode Handy Terminal that is installed WM-G-MR-01
(FCC ID: PZWWMGMR01) has been tested and found to comply with FCC radiation exposure limits
set forth for an uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. Please refer to the SAR test report that was uploaded at FCC
website.
Do not place hands or body near the antenna section to avoid RF exposure.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.

BHT-400B-CE and BHT-400BW-CE comply with Part 15 of FCC rules and ICES-003 of IC rules.
For Barcode Handy Terminal
This device complies with Part 15 of FCC rules and ICES-003 of IC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
NOTE: This Class A digital device apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Declaration of Conformity (For European Union)
The radio frequency module that complies with the Directive 99/5/EC(R&TTE) is mounted on this device
(BHT-400BW-CE).
DECLARATION OF CONFORMITY
Directive 99/5/EC (R&TTE)
Manufacturer or
Authorized representative : DENSO WAVE INCORPORATED
Address : 1-1 Showa-cho, Kariya-shi, Aichi-ken, 448-8661, Japan
We declare on our sole responsibility, that the following product :
- Kind of equipment : Radio frequency module
- Type-designation : WM-G-MR-01
is compliance with the essential requirement of §3 of the R&TTE.
- Health and safety requirements pursuant to §3(1)a :
Applied Standard(s) or other means of providing conformity :
EN60950-1
- Protection requirements concerning EMC §3(1)b :
Applied Standard(s) or other means of providing conformity :
EN301 489-1
EN301 489-17
- Measures for the effective use of the Radio frequency spectrum §3(2) :
Applied Standard(s) or other means of providing conformity :
EN300 328
CE marking

Labeling
■BHT-400B-CE
■BHT-400BW-CE
For USA and Canada For European Union
For USA and Canada For European Union

Preface
Please READ through these operating instructions carefully. It will enable you to operate your
BHT-400B-CE/400BW-CE correctly.
The following contents are explained in this guide:
•Handling and operating methods for the BHT-400B-CE/400BW-CE
•Communication
•Error messages
•Specifications
•Handling and operating methods for the optical communication unit CU-400 series
The BHT-400B-CE/400BW-CE models are designed in the same way except for the interface
differences shown in the table below. In this manual, operations common for all models are
explained unless otherwise stated.
USB
Interface Connector Interface Wireless Communication
BHT-400B-CE ●●–
BHT-400BW-CE ●●●
After you have finished reading the instructions, keep this manual handy for speedy reference.
i

How this book is organized
This manual is made up of five chapters and appendices.
Chapter 1 Quick Guide
Describes the basic operating method of the BHT and the related notes.
Chapter 2 Getting Started the BHT and System Menu
Summarizes the BHT system configuration and describes the operation including preparation and
System Mode (which is required for the efficient use of application programs).
Chapter 3 Communications Operations of the BHT
Describes the communications operations of the BHT-400B-CE/400BW-CE — the wireless
communication (BHT-400BW-CE only), infrared communication, USB interface specifications,
connector interface specifications, basic communications specifications, communication using Ymodem,
and ActiveSync--for data transfer with the host computer or other devices.
Chapter 4 Error Messages
Lists the error messages which will appear on the LCD if some error occurs in the BHT.
Chapter 5 Handling the CU-400 (Option)
Describes the handling procedure of the communication unit CU-400, the interfacing with the host
computer, and the charging of the rechargeable battery cartridge.
Appendix A: Specifications
Appendix B: Loading an Optional Compact Flash Card
Appendix C: Quality Assurance Standards
ii

Related Publications
BHT-400-CE API Reference Manual
BHT-400-CE Class Library Reference Manual
2D Code Scanner/Barcode Scanner Keyboard Interface with BHT-CE kbifCE User’s Guide
Screen Indication
The lettering in the screens in this manual is a little different from that in the actual screens. File names
used are only for description purpose, so they will not appear if you have not set files having those
names.
