Denso SE1-BB User manual

Barcode Handy Scanner
SE1-BB
User’s Manual

Copyright © DENSO WAVE INCORPORATED, 2014
Copyright © Extended Systems, Inc., 2000-2005.
Portions copyright © iAnywhere Solutions, Inc., 2005-2014.
All rights reserved.
The copyright of this User’s Manual belongs to DENSO WAVE INCORPORATED.
No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher.
QBdirect is a trademark of DENSO WAVE INCORPORATED.
iPad and iPhone are trademarks of Apple Inc.
Microsoft Windows is a trademark of Microsoft Corporation.
Bluetooth is a trademark of Bluetooth SIG.
eneloop® is a trademark of the Panasonic Group.
Other products and company names mentioned in this document are trademarks or registered trademarks of their respective
holders.
Specifications are subject to change without prior notice.

Contents
Preface..............................................................................................................................................................................i
Customer Registration and Inquiries...............................................................................................................................i
SAFETY PRECAUTIONS.............................................................................................................................................ii
Components Required ..................................................................................................................................................vii
Bluetooth®Wireless Communication Link................................................................................................................ viii
Care and Maintenance ...................................................................................................................................................ix
Chapter 1 Names and Functions.....................................................................................................................................1
Chapter 2 Basic Operations ............................................................................................................................................2
2.1 Loading the Batteries .....................................................................................................................................2
2.2 Remaining Battery Level Indications ............................................................................................................4
2.3 Turning the Scanner On and Off....................................................................................................................4
2.4 Scanning Barcodes.........................................................................................................................................5
Chapter 3 Bluetooth®Interface.......................................................................................................................................6
3.1 Enabling the Bluetooth®Interface .................................................................................................................6
3.2 Establishing Bluetooth®Wireless Links........................................................................................................7
3.3 Breaking Bluetooth®Wireless Links...........................................................................................................12
3.4 Re-establishing Bluetooth®Wireless Links ................................................................................................12
3.5 Indication of Bluetooth®Wireless Link Status ...........................................................................................12
3.6 Scanning When the Bluetooth®Wireless Link is Broken...........................................................................13
Chapter 4 Configuring Scanner Parameters .................................................................................................................14
Chapter 5 Scanning Control .........................................................................................................................................15
5.1 Trigger Switch Control ................................................................................................................................15
Chapter 6 Magic Key Control ......................................................................................................................................16
Chapter 7 Scanning Functions......................................................................................................................................17
7.1 Editing Data .................................................................................................................................................17
7.1.1 Extracting AI (Application Identifier)-prefixed strings..................................................................17
7.2 Scanning a Black-and-white Inverted Code ................................................................................................24
Chapter 8 Beeper, Indicator LED, and Illumination LEDs..........................................................................................25
8.1 Beeper...........................................................................................................................................................25
8.2 Indicator LED ..............................................................................................................................................27
8.3 Illumination LEDs........................................................................................................................................28
Chapter 9 Communication ............................................................................................................................................29
9.1 Bluetooth®Interface.....................................................................................................................................29
9.2 SPP Profile ...................................................................................................................................................29
9.3 HID Profile...................................................................................................................................................29
9.4 Communication Format ...............................................................................................................................30
Chapter 10 Parameters and Defaults ............................................................................................................................36
Chapter 11 Bar-coded Parameter Menu .......................................................................................................................49
11.1 Customizing the Scanner with the Bar-coded Parameter Menu................................................................49
11.2 Bar-coded Parameter Menu .......................................................................................................................50
Chapter 12 Troubleshooting .........................................................................................................................................66

Appendix 1 Specifications............................................................................................................................................68
Appendix 2 Control Commands ...................................................................................................................................69
Appendix 3 Bluetooth®Glossary .................................................................................................................................71

i
Preface
Thank you for using the SE1-BB DENSO WAVE Bar code Handy Scanner.
Please READ through this manual carefully. It will enable you to operate your scanner correctly.
After you have finished reading this manual, keep it handy for speedy reference.
Note: Do not use this scanner in an environment with electrical noise that can trigger malfunction.
Note: Specifications described in this manual are supported by SE1-BB Firmware version 2.01 or later.
 DENSO WAVE INCORPORATED does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
 If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the product having been
dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty period.
 Intellectual Property Precaution
DENSO WAVE INCORPORATED (“DENSO WAVE”) takes reasonable precautions to ensure its products do not infringe
upon any patent of other intellectual property rights of other(s), but DENSO WAVE cannot be responsible for any patent or
other intellectual property right infringement(s) or violation(s) which arise from (i) the use of DENSO WAVE’s product(s) in
connection or in combination with other component(s), product(s), data processing system(s) or equipment or software not
supplied from DENSO WAVE; (ii) the use of DENSO WAVE’s products in a manner for which the same were not intended
nor designed; or (iii) any modification of DENSO WAVE’s products by other(s) than DENSO WAVE.
 Limited Warranty on Software Products
In no event will DENSO WAVE be liable for direct, indirect, special, incidental, or consequential damages (including
imaginary profits or damages resulting from interruption of operation or loss of business information) resulting from any
defect in the software or its documentation or resulting from inability to apply the software or its documentation.
Customer Registration and Inquiries
Customer Registration
To allow us to provide our customers with comprehensive service and support, we request that all customers complete a
Member Registration Form. Registered members will be offered the following privileges.
 Latest upgrade information
 Free exhibition and event information for new products
 Free web-information service “QBdirect”
QBdirect Service Contents
Information search service
(FAQ)
Offers detailed information on each product.
Download service Offers downloads of repair modules for the latest SE1 Series systems or software, and
sample programs.
E-mail inquiries Allows customers to send product-related queries by e-mail.
Please note that these privileges may be subject to change without prior notice.
How to Register
Access the URL below and follow the instructions provided.
http://www.qbdirect.net

ii
SAFETY PRECAUTIONS
Be sure to observe all these safety precautions.
 Please READ through these instructions carefully. They will enable you to use the scanner correctly.
 Always keep this manual nearby for speedy reference.
Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury and
substantial property damage. Make sure you fully understand all definitions of these terms and symbols given below before
you proceed to the text itself.
Alerts you to those conditions that could cause serious bodily injury or death if the instructions
are not followed correctly.
Alerts you to those conditions that could cause minor bodily injury or substantial property
damage if the instructions are not followed correctly.
Meaning of Symbols
A triangle ( ) with a picture inside alerts you to a warning of danger. Here you see the warning for electrical
shock.
A diagonal line through a circle ( ) warns you of something you should not do; it may or may not have a picture
inside. Here you see a screwdriver inside the circle, meaning that you should not disassemble.
A black circle ( ) with a picture inside alerts you to something you MUST do. This example shows that you
MUST unplug the power cord.

iii
To System Designers:
When introducing the scanner in those systems that could affect human lives (e.g., medicines
management system), develop applications carefully through redundancy and safety design
which avoids the feasibility of affecting human lives even if a data error occurs.
Handling the battery
Wrong handling of the battery could result in a heat, smoke, explosion, or fire. Be sure to observe the
following.
Never disassemble or heat the battery, nor put it into fire or water; doing so could cause
battery-rupture or leakage of battery fluid, resulting in a fire or bodily injury.
Do not carry or store the battery together with metallic ballpoint pens, necklaces, coins,
hairpins, etc.
Doing so could short-circuit the terminal pins, causing the batteries to rupture or the battery fluid
to leak, resulting in a fire or bodily injury.
Never put the battery into a microwave oven or high-pressure container.
Doing so could cause the batteries to break, generate heat, rupture or burn.
Avoid dropping the battery or letting it undergo any shock or impact.
Doing so could cause the batteries to break, generate heat, rupture or burn.
Never charge the battery where any inflammable gases may be emitted; doing so could cause
fire.
If any abnormality is detected—smoking, abnormal odors, discoloration or deformation when
the battery is in use, in storage or being charged, remove the battery from the scanner or
charger.
Only use the dedicated charger for charging the battery.
Using a different type of charger could cause battery-rupture or leakage of battery fluid and
result in a fire, bodily injury, or serious damage to property.
The battery contains strong alkaline liquid (electrolyte).
If battery liquid leaks from the battery and it gets into your eyes, rinse them with clean water
thoroughly without rubbing and consult a doctor as soon as possible. Otherwise, you may
damage your eyes.

iv
Handling the scanner
Wrong handling of the scanner could result in a heat, smoke, or scanner failure. Be sure to observe
the following
If smoke, abnormal odors or noises come from the scanner, immediately remove the battery and
contact your nearest dealer.
Failure to do so could cause fire or electrical shock.
If foreign material or water gets into the scanner, immediately remove the battery and contact
your nearest dealer.
Failure to do so could cause fire or electrical shock.
If you drop the scanner so as to affect the operation or damage its housing, remove the battery
and contact your nearest dealer.
Failure to do so could cause fire or electrical shock.
Do not use the scanner where any inflammable gases may be emitted.
Doing so could cause fire.
Do not subject the scanning window of the scanner to direct sunlight for extended periods.
Doing so could damage the scanner, resulting in a fire.
Stop charging if it cannot be completed within the specified time.
Never put the scanner into a microwave oven or high-pressure container.
Doing so could cause the batteries to break, generate heat, rupture or burn.
Never use the scanner on the line voltage other than the specified level.
Doing so could cause the charger to break or burn.
Use the dedicated battery only.
Failure to do so could result in fire.

v
Handling the scanner
Wrong handling of the scanner could result in a heat, smoke, or scanner failure. Be sure to observe the
following
Never
disassemble
Never disassemble or modify the scanner; doing so could result in an accident such as break or
fire.
Doing so could result in a fire or electrical shock.
If you are not using the scanner for a long time, be sure to remove the battery for safety.
Failure to do so could result in a fire.
Do not use the scanner with discharged batteries.
If used, the scanner may not function properly.
Do not put the scanner on an unstable or inclined plane.
The scanner may drop, creating injuries.
Never put the scanner in places where there are excessively high temperatures, such as inside
closed-up automobiles, or in places exposed to direct sunlight.
Doing so could affect the housing or parts, resulting in a fire.
Avoid using the scanner in extremely humid areas, or where there are drastic temperature
changes.
Moisture will get into the scanner, resulting in malfunction, fire or electrical shock.
Do not place the scanner anyplace where it may be subjected to oily smoke or steam, e.g., near
a cooking range or humidifier.
Doing so could result in a fire or electrical shock.
Never cover or wrap up the scanner in a cloth or blanket.
Doing so could cause the unit to heat up inside, deforming its housing, resulting in a fire.
Always use the scanner in a well-ventilated area.
Do not insert or drop foreign materials such as metals or anything inflammable through the
openings (vents or scanning window) into the scanner.
Doing so could result in a fire or electrical shock.
Do not scratch or modify the scanner.
Doing so could damage the scanner, creating a fire hazard.
Do not put heavy material on the scanner, or allow the scanner to get pressed under heavy
material.
Do not look into the light source from the scanning window or do not point the scanning window
at other people’s eyes.
Eyesight may be damaged by direct exposure to this light.
Do not use the scanner if your hands are wet or damp.
Doing so could result in an electrical shock.

vi
Handling the scanner
Wrong handling of the scanner could result in a heat, smoke, or scanner failure. Be sure to observe the
following
Never use chemicals or organic solvents such as benzine and thinner to clean the housing. Do
not apply insecticide to the scanner.
Doing so could result in a marred or cracked housing, electrical shock or fire.
Do not use the scanner with anti-slip gloves containing plasticizer.
The scanner housing may be broken, creating injuries, electrical shock, or fire.
When taking care of the scanner, remove the battery.
Failure to do so could result in an electrical shock.
Do not drop the scanner.
The housing may be broken, creating injuries. Using the scanner whose housing is broken could
result in smoke or fire.
Remove the battery from the scanner.
Then contact your nearest dealer.
