Denver PBS-5005 User manual

Portable Power Bank
DENVER PBS-5005

Size: 92 x 64 x 18 mm
Product weight: 118g
1、Technical parameters
1.1、Product appearance
1.2、Specifications (please refer to actual item)
Battery type: A grade high-energy density Polymer cell Power bank 1
1
1
USB Cable
Manual
Capacity: 5000mAh/18.5Wh(TYP)
Micro USB Input: DC 5V/2A
USB-A Output 1: DC 5V/2.1A
USB-A Output 2: DC 5V/2.1A
1.3 、List of accessories
Specific accessories
refer to actual item
Power ON/OFF
Micro USB Input port
output port 2
Indicator light
output port 1
2、Power display light:
Indicator light:
3.1、Charge the power bank
3.2、Charge digital equipment
1. Indicator light: There are 4 lights on the device to show the capacity.
LED flashing LED switch off LED lighting
Charge the power bank
Charge the devices
Display Indicator light
Indicator light
Capacity percentage
Capacity percentage
0%--25%
25%--50%
50%--75%
75%--100%
100%
0%--25%
25%--50%
50%--75%
75%--100%
100%
Note
Note
The first light flashes
1
2
3
4
1
2
3
4
3、Charging instructions
EN
Connect the cable USB port to the charging device and the other end to the Micro input
connector of power bank.
After connecting, the power bank is automatically charged and the current power level
on the battery status indicator flashes. When the battery is fully charged, the status
indicator light will be on.
Check whether the charging voltage of the digital device matches the discharging
voltage of the power bank.
Select one matching charging cable, connect one end to the power bank output
interface, the other end to the digital device, power bank will automatically recognize to
charge digital device.
Displays
The first light flashes
When the power is
close to 5%, the last
light flashes until
power runs out
The power bank is
full charged when
all the light is
lighting
Power bank will check and show the percentage of capacity when
power on.
4 light stand for: 25 50 75 100

4、Cautions
5、Tips
If you do not use the power bank for a long time, we recommend you to fully charge the
battery then placed it the dry environment with temperature range from 5 - 35°C, please
avoid to directly expose the product in sunlight.
Please fully discharge then perform full recharging if you have not use the power bank
for more than three weeks or the battery life of the product becomes shorter.
Warning: Lithium battery inside! Do not try to open the power bank. Do not drop or expose to
impact shock in any way.
Do not expose to heat, water, moisture or direct sunlight!
Please note the new power bank can only achieve its best performance after two to
three times fully charge and discharge.
Please extend the charging time for 1-2 hours in first three times in order to maximize
the performance of Polymer battery.
Please do not try to disassemble and modify the product by yourself.
Please avoid making physical damages on this product.
Please avoid using this product in the following environments: high temperature, low
pressure, low temperature, humidity, dust, magnetic field strong and long-term exposure
to sunlight. We recommend that you at an altitude of 3000 meters, 0 ° to 35 ° C and
humidity of 5-95% of the environment using the product.
This product must not be exposed to dripping and splashing water, also it should not be
placed in the annex next to items such as cups filled with liquid a class.
Please only use the charger to charge the product which is comply with below
specification, it might have safety issue if user uses the unsuitable charger to charge the
product.
Please follow the relevant local environmental regulations to dispose the product and
accessories.
Please contact with the local dealer or local customer service center if you have any
questions.
Product is subject to change without notification, please prevail in kind.
Please notice - All products are subject to change without any notice. We take reservations
for errors and omissions in the manual.
ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S
Electric and electronic equipment and included batteries contains materials, components
and substances that can be hazardous to your health and the environment, if the waste
material (discarded electric and electronic equipment and batteries) is not handled correctly.
Electric and electronic equipment and batteries is marked with the crossed out trash can
symbol, seen below. This symbol signifies that electric and electronic equipment and
batteries should not be disposed of with other household waste, but should be disposed of
separately.
As the end user it is important that you submit your used batteries to the appropriate and
designated facility. In this manner you make sure that the batteries are recycled in
accordance with legislature and will not harm the environment.
All cities have established collection points, where electric and electronic equipment and
batteries can either be submitted free of charge at recycling stations and other collection
sites, or be collected from the households. Additional information is available at the technical
department of your city.
DENVER ELECTRONICS A/S
Omega 5A, Soeften
DK-8382 Hinnerup
Denmark
