DEPURECO ATEX Z22 II3D Instructions for use

!
INSTRUCTION AND
MAINTENANCE MANUAL
PUMA SERIES ATEX Z22 II3D
PUMA 10 Z22
PUMA 15 Z22
PUMA 18 Z22
PUMA 30 P Z22
PUMA 30 S Z22

!
TABLE OF CONTENTS:
1. INFORMATIVE SECTION
1.1 Foreword...............................................................................................................4
1.2 Main parts .............................................................................................................7
1.3 Optional parts.......................................................................................................8
1.4 Manufacturer's identification data......................................................................8
1.5 Identification plate................................................................................................8
1.6 Permitted Uses.....................................................................................................9
1.7 Authorised environmental conditions ................................................................9
1.8 Noise level...........................................................................................................10
1.9 Technical data ....................................................................................................11
1.10 Warranty.............................................................................................................12
!
2. SAFETY SECTION
2.1 Safety Information..............................................................................................13
2.2 Safety recommendations...................................................................................14
2.3 Safety plates and symbols ................................................................................16
2.4 Residual risks......................................................................................................18
2.5 Applied Directives..............................................................................................18
!
3. HANDLING, UNPACKING AND INSTALLATION SECTION
3.1 Handling..............................................................................................................19
3.2 Unpacking ...........................................................................................................20
3.3 Installation...........................................................................................................22
!
4. OPERATION SECTION
4.1 Description of the controls ................................................................................24
4.2 Operating cycle...................................................................................................25
4.3 Emptying the bin ................................................................................................29
4.4 Inserting and locking the bin.............................................................................31
4.5 Storage – Decommissioning .............................................................................32
!
!
!
!
!
!

!
Page!3!of!51!
!
!
5. MAINTENANCE SECTION
5.1 Informative notes ...............................................................................................33
5.2 General safety regulations ................................................................................34
5.3 Replacing the filter .............................................................................................36
5.4 Replacing the cartridges on the S.P. cartridge cleaning system ..................39
5.5 Positioning of the thermal relay and fuses - FOX 10.....................................42
5.6 Replacing the HEPA cartridge (if provided) ....................................................44
5.7 Troubleshooting .................................................................................................46
5.8 Scrapping............................................................................................................47

!
Page!4!of!51!
!
1. INFORMATIVE SECTION
IMPORTANT - The DEPURECO term and logo in this document refer to and are the property of
DEPURECO INDUSTRIAL VACUUMS S.r.l.
This document remains the exclusive property of DEPURECO S.r.l. Full or partial reproduction by any
means (graphical, electronic, etc.) is prohibited without prior authorisation from the Company
Management.
1.1 Foreword
Dear Customer
Thank you for having chosen DEPURECO; we hope you will enjoy using your new DEPURECO PUMA
Z22 series vacuum cleaner This manual has been drafted in order for our customer to fully appreciate
the quality of this machine. Please read all sections before using the machine for the first time.
It includes information, recommendations and important warnings concerning the use of the vacuum,
which will help fully exploit the technical properties of your machine.
Read messages, warnings and indications preceded by the following symbols carefully:
For the safety of people
For the integrity of the vacuum cleaner
For the safeguard of the environment
This manual forms an integral part of the vacuum cleaner. Read this
manual and the other attachments supplied carefully. Knowledge of
the instructions here contained is indispensable for the safe use and
maintenance of the vacuum cleaner

!
Page!5!of!51!
!
This manual describes the following models:
PUMA 10 Z22
PUMA 15 Z22
PUMA 18 Z22
PUMA 30 P Z22
PUMA 30 S Z22
The vacuum cleaner is equipped with the following filters:
q ANTISTATIC M FILTER (P09123 – PUMA 10,15,18 / P09131 – PUMA 30)
q PTFE ANTISTATIC M FILTER (P09858 – PUMA 10,15,18 / P12369 – PUMA 30)
q ABSOLUTE FILTER CARTRIDGE (P11363)
The vacuums are classified according to the following dust classes:
L
Low risk – suitable to separate dust with an exposure limit value of > 1 mg/m3 on the
basis of the occupied volume
M
Medium risk - suitable to separate dust with an exposure limit value of > 0,1 mg/m3
on the basis of the occupied volume
H
High risk – suitable to separate all dusts with all exposure limit values on the basis of
the occupied volume, including cancerogenic and pathogenic dusts.
This manual provides all the necessary information for the use and maintenance of the vacuum cleaner.
This specific model has undergone strict testing to ensure maximum reliability. Its operation and
durability will depend on proper use and maintenance.
This manual is an integral part of the vacuum cleaner and must accompany it at all times, until its
demolition.
In the event it is lost or damaged, you can request another copy from DEPURECO INDUSTRIAL
VACUUMS S.r.l. (henceforth shortened to DEPURECO).
