Design Hardware 2000V Series User manual

EXIT DEVICE
2000V
2012.03

STEP 1 ：DIRECTIONS FOR CHANGING
HANDING OF DEVICE
Handing of device is preset at factory
for RHR.To change handing of device,
follow steps shown below and see
DRAWING FOR STEP 1.
1.Loosen screws ’A’ and remove screw
‘B’ and spring ‘C’.
2.Reverse the postions of screw ’B’ and
spring ‘C’ and then tighten screw ‘A’.
3.The device is now set for LHR.
STEP 5 ：INSTALL TOP STRIKE
1.Align vertical center line of top strike and
upper connecting tube as shown on template
(B-1).Mark door as indicated on template
(B-1).
2.Tighten screws to install top strike with
proper adjustment.
Drill a hole on floor with
1/2" dia,1"deep , and align
center of bolt in lower box.
Fix the ciamp to connecting
tube in midway.
2"
2 7/16"
13/32"
STEP 6 ：INSTALL TOP LATCH ASSEMBLY
1.Align vertical center line of top latch assembly
and upper connecting tube as shown on
template (B-1). Mark door as indicated on
template (B-1).
CAUTION: BE SURE THE DISTANCE
FROM DOOR FRAME TO LINE
W MUST BE 2"
2.Tighten screws to install top latch assembly.
STEP 2：MARK CENTER LINE ON DOOR
Mark center line on inside of door.
Establish the horizontal center line of
the device by drawing a line across
the door 40” above floor line.
STEP 3：MARK DOOR AND DRILL HOLES
1.Fold and apply template (A) to edge of
door and mark door as indicated on
template (A).
2.Drill holes A X 6 in accordance with the
diameters as indicated on template (A)
STEP 4：INSTALL DEVICE BODY
1.Remove the head cover from the device
body and end cover from the mounting
bracket by removing the screws that hold
them on.
2.Align tailpiece receiver of exit device and
trim/cylinder tailpiece, so it slides onto
trim/cylinder tailpiece. Also align screw
holes on exit device head with mounting
holes on the door.
3.Install and tighten the mounting screws
for the head of the exit device and end
cover mounting bracket.

STEP 12 ：INSTALL TWO ROD GUIDES
1.Take the approximately middle of upper and
lower connecting tube.
2.Tighten screws to install rod guides.
STEP 11 ：TEST ACTUATING BAR AND
DOGGING OPERATION
1.The top latch assembly should engage the top
strike and the bottom latch assembly should
engage the floor strike when the door is closed.
If the door can be pushed open without
depressing the actuating bar, the upper
connecting tube has been over adjusted.
Readjust it as needed.
2.The top and bottom latch assembly should
disengage from the strikes freely when
the actuating bar is depressed or dogged
down. If they do not disengage, adjust the
bolt in the bottom latch assembly as needed and
retest for proper operation.
STEP 9 ：INSTALL AND ADJUST LOWER
CONNECTING TUBE
1.Keep the end of the tube with the threaded
insert downward to connect it with the
threaded bolt in the bottom latch assembly
2.Connect the other end of the tube to the
internal mechanism of the head assembly
by inserting the connecting pin into the holes.
3.Connect bolt in bottom latch assembly with
lower connecting tube.
Then, depress actuating bar and adjust lower
connecting tube until bottom latch assembly
retracts properly.
Then, fix the connecting pin by bending 2 ends.
Do not let bolt in bottom latch assembly touch
floor while depressing actuating bar.
STEP 8 ：INSTALL AND ADJUST UPPER
CONNECTING TUBE
1.Keep the end of the tube with the threaded
insert upward to connect it with the threaded
bolt in the top latch assembly
2.Connect the other end of the tube to the
internal mechanism of the head assembly
by inserting the connecting pin into the
holes.
STEP 7 ：INSTALL BOTTOM LATCH
ASSEMBLY
1.Align vertical center line of bottom
latch assembly and lower connecting tube
as shown on template. Mark door as
indicated on template (B-2).
CAUTTON : BE SURE THE DISTANCE
FROM BOTTOM SIDE OF DOOR EDGE
TO BOTTOM OF BOTTOM LATCH
ASSEMBLY IS 13/32".
2.Tighten screws to install bottom latch
assembly.
DRAWING FOR STEP 1
3.Turn and adjust upper connecting tube
until top latch assembly retracts properly
and then fix the connecting pin by bending
2 ends.
4.Drill 3 anchor / screw holes, 1/4" dia , 1 1/8" deep.
5.Hammer 3 anchors into 3 anchor / screw holes.
Tighten up 3 screws.
STEP 10：INSTALL FLOOR STRIKE
1.Let the bolt in the lower bottom latch assembly
touch the floor and mark on floor.
2.Drill a 5/8” dia, 1” deep hole.
3.Let the bolt in the lower bottom latch assembly
insert into the center hole of floor strike and
mark 3 anchor / screw holes on floor.
STEP 13 : INSTALL 4 COVERS
Install head cover, end cover, top latch
cover,bottom latch cover and tighten screws.

Latchbolt Filler Plate
Rod Guide (2PCS)
Wood Screws
5/32”x 3/4” (4 PCS)
5/32”x 3/4” (4 PCS)
,Self Tapping
Pin (2 PCS)
Flat Head
Flat Head
1/4”x 1 1/4” (12 PCS)
Round Head Round Head
1/4”x 1 ” (3 PCS)
Wood Screws
Wood Screws
Flat Head
Floor Strike
Machine Screws Machine Screws
Flat Head
1/4”-20P x 3/4” (12 PCS)
1/4”-20P x 3/4” (3 PCS)
14#x1 1/2” (15 PCS)
Machine Screws
,Self Tapping
Flat Head
5/32”x3/4” (3 PCS)
1/4” x 1” (3 PCS)
Anchor
1.
Assembly
DOGGING DEVICE
DOGGING WRENCH
Assembly
IF DOOR IS LESS THAN 36", REMOVE
END COVER AND CUT SECTION "A"
TO A DESIRED LENGTH.

1/4”-20P x 3/4” x 6
(A)For 2000V Series (UL Listed)-Drill & tap for (6) 1/4"-20P x 3/4" machine screws for exit device. Drill (6) 3/16" pilot holes for seif-tapping machine screws or wood screws for exit device. (B)For F2000V (Fire Rated)-Drill 9/32" holes inside and 3/8" holes outside for the (6) thru bolts.
Round Head Screws
1/4”-20P x 3/4” x 6
Round Head Screws
2012.03
3/4" for LE-08,LE-08A Trim 3/4" for LE-08,LE-08A Trim
2 3/4" 2 3/4"
( )
When installing 1000R x 1000V on a pair of doors,a Double Door Strike (DDS) is required. For complete template information,please refer to the DDS template.
CENTER LINE CENTER LINE

E 1/4”-20P x 3/4”
ROUND HEAD SCREW
D D 1/4”-20P x 3/4” x 2
ROUND HEAD SCREWS
D
CAUTION：
BE SURE THE DISTANCE
FROM BOTTOM SIDE OF
DOOR EDGE TO BOTTOM
OF BOTTOM LATCH
MUST BE
BOTTOM LATCH
1 39/64”
”61/72
”23/92 ”23/31
Note: When installing top latch assembly:
1. Drill (1) E hole and install screw but
do not tighten all the way.
2. Drill (2) D holes and install and
tighten screws.
3. Tighten screw in hole E all the way.
2012.03
TEMPLATE(B-2)
(A)For 2000V Series (UL Listed)-Drill & tap for (3) 1/4 "- 20P x 3/4"
machine screws (2xD,E) for latches.
Drill (3) 3/16" pilot holes (2xD,E) for self-tapping machine screws
or wood screws for latches.
(B)For F2000V (Fire Rated)-Drill 9/32" holes (2xD,E) inside and
3/8" holes (2xD,E) outside for the (3) thru bolts.
ASSEMBLY
ASSEMBLY 13/32”
E

DD
D 1/4”-20P x 3/4” x 2
ROUND HEAD SCREWS
F 1/4”-20P x 3/4” x 1
FLAT HEAD MACHINE SCREWS
FOLD REVERSELY FOR
TOP STRIKE INSTALLATION
TOP LATCH ASSEMBLY
TEMPLATE(B-1)
LINE W
1 39/64”
”61/72
FLAT HEAD MACHINE SCREWS
CAUTION:
DRILL”F” HOLE AFTER LATCH BOLT
PROPERLY WORKS.
FOLD ON DOTTED LINE
Frame Stop
AND FIT ON DOOR
FRAME
CAUTION:
BE SURE THE DISTANCE FROM DOOR
FRAME TO LINE W MUST BE 2”
Note: When installing top latch assembly:
1. Drill (1) E hole and install screw but
do not tighten all the way.
2. Make sure distance from door frame
to line W is 2".
3. Drill (2) D holes and install and
tighten screws.
4. Tighten screw in hole E all the way.
(A)For 2000V Series (UL Listed)-Drill & tap for (3) 1/4"-20P x 3/4" machine screws (2xD,E) for latches
Drill (3) 7/32" pilot holes (2xD,E) for self tapping machine screws or wood screws for latches.
(B)For F2000V (Fire Rated)-Drill 9/32" holes (2xD,E) inside and 3/8" holes (2xD,E)
outside for the (3) thru bolts.
1 ”
G
1/4”-20P x 3/4” x 2
GG
F
E
1/4”-20P x 3/4”
ROUND HEAD SCREW
2”
2012.03
3/32"
Adjust the location of the top
latch assembly and top latch
base so there is 3/32" space
between top strike and inside
of top latch.
CAUTION:
E
TOP STRIKE
TOP LATCH BOLT
