Assa Abloy Corbin Russwin PED5000 DB Series User manual

Installation Instructions
WARNING
This product can expose you to
lead which is known to the state of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65warnings.ca.gov.
Attention Installer: Improper
installation may result in damage
to the product and void the factory
warranty.
WARNING
Dummy Rail
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.

2
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Screw Chart
DESCRIPTION
TOTAL QTY
SUPPLIED
WHERE USED
#10-24 X 3/4" FLAT HEAD
MACHINE SCREW
4
(4) CHASSIS
CORNER MOUNTING HOLES
(METAL DOOR)
#10 X 1-1/4" FLAT HEAD
WOOD SCREW
4
(4) CHASSIS
CORNER MOUNTING HOLES
(WOOD DOOR)
#10-24 X 3/4" ROUND HEAD
MACHINE SCREW
2
(2) REAR MOUNTING PLATE
(METAL DOOR)
#10 X 1-1/4" ROUND HEAD
WOOD SCREW
2
(2) REAR MOUNTING PLATE
(WOOD DOOR)
#8-32 X 5/16" W/ #6 OVAL HEAD
MACHINE SCREW
4
(2) CHASSIS COVER
FRAME SIDE
(2) END CAP
#8-32 X 5/8" W/ #6 OVAL HEAD
MACHINE SCREW
2(2) CHASSIS COVER
RAIL SIDE
1/4"-20 X 2-3/8" KNURLED FLAT HEAD
MACHINE SCREW
2
(2) EXIT TRIM
(IF USED)

3
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
12
Measure 39-5/8” from the finished floor and mark
door and frame
Using a square, create a horizontal and vertical
centerline. Vertical centerline should be 2-3/4” off
of the edge of the door or centered on the door
stile.

4
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
4X 10-24 X3/4"
FLAT HEAD
SCREWS
56
4X 10-24 THREADED HOLES
34
Align supplied plastic template with the centerlines.
Mark chassis mounting holes.
Prepare chassis mounting holes. Refer to supplied
trim template as needed.
Install chassis using supplied mounting screws 10-24
x 3/4”. DO NOT FULLY TIGHTEN SCREWS.
Slide rail assembly onto the chassis.

5
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Ensure rail carrier tabs are aligned with the chassis, then fully tighten the chassis screws.
7
8
Insert the end cap bracket into the rail assembly. Level the rail and mark mounting holds using the bracket as a
guide. Ensure rail overlaps door stile by 1/2”.
Carrier tab

6
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Drill and tap end cap bracket holes 10-24
(2 places).
Install chassis cover and end cap using supplied 8-32 x 5/16” oval head screws.
910
11
Install end cap bracket using round head Phillips
10-24 x 1” screws, supplied.

7
Dummy Rail
Installation Instructions
PED5000 DB & PED5000 A DB Series Exit Devices
FM613 01/23
For installation assistance contact Corbin Russwin
1-800-543-3658 • [e-mail]
Copyright © 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
