Det-Tronics X9800 Installation and operating instructions

2.2 Rev: 9/16 95-8637
Addendum
HART® Communication with the
X9800 IR Flame Detector

Table of Contents
Interconnecting the HART Communicator with the Detector......... 1
HART Device Description Language ........................... 3
Detector Wiring ............................................ 3
HART Menu Structure....................................... 4
X9800 Root Menu .......................................... 5
Device Info Menu .......................................... 5
General Info Menu ......................................... 6
HART Info Menu ........................................... 7
HART PV Menu............................................ 8
Condensed Status ......................................... 9
Status Info Menu .......................................... 10
Hardware Menu........................................... 11
o
i
Menu ................................................. 12
Detector Settings ......................................... 13
History Menu............................................. 13
Command Menu .......................................... 14
HART Command Menu..................................... 15
Device Setup Menu........................................ 15
Conguration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Calibration Menu.......................................... 16
Write Protect ............................................. 17
HART Setup ............................................. 18
Real Time Clock .......................................... 18

195-8637 2.2
Digital communication with the X9800 allows the
operator to monitor the status of the detector,
determine factory settings, adjust field settings,
and initiate field tests. This addendum provides
guidance for establishing HART communication,
and describes the HART menu structure
when using the X9800 with a HART Handheld
Communicator, a PC, or other process interface
device that supports Device Description
Language (DD).
NOTE
A minimum level of understanding with
regard to the operation and navigation of
the HART Communicator is required. Refer
to the instruction manual supplied with the
HART Communicator for basic operating
instructions.
INTERCONNECTING THE HART COMMUNI-
CATOR WITH THE DETECTOR
Point-to-Point Mode
The HART Communicator can connect to the
X9800 at any wiring termination point in the
analog output signal loop. Connect the HART
communicator in parallel with the X9800 analog
signal or load resistor. The HART connections are
non-polarized.
IMPORTANT WIRING NOTE
The HART Communicator does not
measure loop current directly, but instead
reads a voltage signal across a resistance
(250 ohms) in the loop. The recommended
connection point is across the input
impedance of the signal receiver (PLC),
which is a nominal 250 ohms. See Figures
1 to 4. If testing/programming on a bench,
a 250 ohm load resistor must be used. See
Figure 5.
Switch on the HART Communicator. If a device
is found, the HART Communicator displays
the Main menu. If no device is found, check
the connections and verify the presence of a
minimum of 250 ohms load resistance in series
in the loop.
ADDENDUM
HART Communication
with the X9800
IR Flame Detector
©Detector Electronics Corporation 2020 Rev: 9/16

95-8637
2
2.2
24 VDC
4-20 MA
PLC
–
+
600 ΩMAX*
AT 24 VDC
–
+
B2465
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA +
4-20 mA + REF
4-20 mA –
+ Vin
– Vin
29
28
27
26
25
24
23
22
21
X9800 IR DETECTOR
Figure1—X9800 Detector Wired for Non-Isolated 0 to 20 mA
Current Output (Sourcing)
24 VDC
4-20 MA
PLC
–
+
600 ΩMAX*
AT 24 VDC
–
+
B2467
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA + 4-20 mA –
4-20 mA – REF
+ Vin
– Vin
29
28
27
26
25
24
23
22
21
X9800 IR DETECTOR
24 VDC
4-20 MA
PLC
–
+
600 ΩMAX*
AT 24 VDC
–
+
B2466
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA + 4-20 mA –
+ Vin
– Vin
29
28
27
26
25
24
23
22
21
X9800 IR DETECTOR
–+
24 VDC
24 VDC
4-20 MA
PLC
–
+
600 ΩMAX*
AT 24 VDC
–
+
B2468
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA + 4-20 mA –
+ Vin
– Vin
29
28
27
26
25
24
23
22
21
X9800 IR DETECTOR
–
+
24 VDC
250 Ω
9
8
7
6
5
4
3
2
1
19
18
17
16
15
14
13
12
11
4-20 mA + 4-20 mA –
4-20 mA – REF
+ Vin
– Vin
29
28
27
26
25
24
23
22
21
X9800 IR DETECTOR
24 VDC
–
+
B2469
Figure2—X9800 Detector Wired for Isolated 0 to 20 mA Current
Output (Sourcing)
Figure3—X9800 Detector Wired for Non-Isolated 0 to 20 mA
Current Output (Sinking)
Figure4—X9800 Detector Wired for Isolated 0 to 20 mA Current
Output (Sinking)
*Nominal input impedance of PLC = 250 ohms.
Maximum loop impedance including input impedance of PLC = 600 ohms.
Figure5—Wiring the X9800 for Benchtop Testing/Programming Using HART Protocol

395-8637 2.2
Multidrop Mode
Optical flame detectors are life safety devices
and require the 0–20 mA loop for transmitting
important detector status data. They should not
be used in conjunction with multidrop mode. If
multidrop mode is a requirement, the alarm and
fault relay contacts must be connected directly
to the safety system or fire panel for signalling
purposes.
NOTE
This addendum covers HART wiring only.
Refer to the device instruction manual
for NFPA-72 compliant releasing wiring
diagrams.
HART DEVICE DESCRIPTION LANGUAGE
The HART protocol incorporates a concept
called the Device Description Language (DD)
that enables all suppliers of HART instruments to
define and document their products in a single
consistent format. This format is readable by
handheld communicators, PCs and other process
interface devices that support DD. DD enables
full interoperability of devices, regardless of
manufacturer, allowing full functionality from any
HART device.
In the event that your Communicator does not
establish communications with the X9800, ensure
that the appropriate DDs for the X9800 have been
programmed into your Communicator. To review the
DDs programmed into your HART Communicator:
1. From the Main menu, access the Offline
menu.
2. From the Offline menu, select New
Configuration to access the list of device
descriptions programmed into the HART
Communicator.
3. Select Det-Tronics and review the list of
models to determine if the X9800 DDs are
installed in your Communicator.
If the X9800 DDs have not been programmed into
the Memory Module, you must use the generic
interface built into your HART Communicator.
The HART Communication Foundation manages
a library of Manufacturer Device Descriptions,
which are distributed to programming sites for
inclusion in master devices. A complete listing
of the HCF DD Library is available for download
in manufacturer and device type sequence at
en.hartcomm.org.
DETECTOR WIRING
Refer to the X9800 instruction manual (form
number 95-8554) for complete instructions
regarding detector installation and wiring.
NOTE
X9800 detectors with HART do not support
RS-485 communication.
NOTE
Power consumption specications for the
HART model are different than the standard
model.
Power Consumption Specications of X9800
Detector with HART Communication
Without heater: 2.1 watts at 24 Vdc nominal;
3.7 watts at 24 Vdc in alarm.
2.2 watts at 30 Vdc nominal;
4.2 watts at 30 Vdc in alarm.
Heater only: 8 watts maximum.
Total power: 16.5 watts at 30 Vdc with EOL
resistor installed and heater on
maximum.
EOL resistor must be ceramic, wirewound
type, rated 5 watts minimum, with actual power
dissipation not to exceed 2.5 watts.
HIB Hdwr Flt
When a HART field communicator is first connected
to the detector, a "HIB Hdwr Flt" message may
be displayed. If this message is displayed, set
the Real Time Clock (RTC) using the HART field
communicator as detailed in the Real Time Clock
section of this manual. See Marketing Bulletin 78-
1026 for further information.

95-8637
4
2.2
HART MENU STRUCTURE
Command Menu
1) Start Passive Oi
2) Start Active Oi
3) Clear Oi Fault
4) Reset Latches
5) Master Reset
6) Clear Data Log
7)
HART Command Menu
Hardware Menu
1) Temperature
2) Temp Range Fault
3) Voltage
4) Voltage Fault
5) Manual Oi at Start
HART Setup
1) Poll addr
2) Final asmbly num
3) Tag
4) Long tag
5) Date
6) Descriptor
7) Message
Real Time Clock
1) RTC Seconds
2) RTC Minutes
3) RTC Hours
4) RTC Date
5) RTC Month
6) RTC Year
Condensed Status
1) Xmtr Addstatus 0
2) Xmtr Addstatus 1
3) Xmtr Addstatus 2
4) Xmtr Addstatus 3
5) Operating Mode
Status Info Menu
1) Warm Up (Y/N)
2) Fire (Y/N)
3) IR Alarm (Y/N)
4) TDSA Alarm (Y/N)
5) Quick Alarm (Y/N)
6) IR Pre Alarm (Y/N)
7) Auto IR Oi Fault (Y/N)
8) Manual Oi at Start
9) Sensor Hdwr. Fault (Y/N)
10) HIB Hardware Fault (Y/N)
11)
Internal Com. Flt (Y/N)
12) Incompatible Fault (Y/N)
13) Voltage Fault (Y/N)
14) Hardware Menu
15) Oi Menu
General Info Menu
1) Manufacturer
2) Model
3) Serial Number
4) Part Number
5) Manufacture Date
6) Snsr Firmware
7) HART Firmware
8) Real Time Clock
9) Write protect (Y/N)
Oi Menu
1) Consecutive IR Oi Fails
2) Oi Calibrate Active
3) IR Oi Cal Fault
4) Manual Oi Active
5) Manual IR Oi Fault
Detector Settings
1) IR Mode
2) IR Sensitivity
3) Auto Oi Enabled
4) Fire Relay (NL/L)
5) Fault Relay (NL/L)
6) Aux Relay (NL/L)
7) Heater Disabled
8) Aux Function
9) Aux IR Function
10) Aux Relay (NE/NDE)
History Menu
1) Alarm Log
2) Fault Log
3) General Log
Write Protect
1) Set Password
2) Set Write Protect
3) Write protect (Y/N)
Configuration Menu
1) Consecutive IR Oi Fails
2) Time Delay
Calibration Menu
1) Loop test
2) D/A trim
3) Calibrate Oi
HART Command Menu
1) Self test
2) Master Reset
3) Loop test
HART Info Menu
1) Universal rev
2) Field dev rev
3) Final asmbly num
4) Tag
5) Long tag
6) Date
7) Descriptor
8) Message
9) Num req preams
10) HART PV Menu
11) Condensed Status
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5)
Real Time Clock
HART PV Menu
1) PV Unit
2) PV
3) PV Sensor Unit
4) PV USL
5) PV LSL
6) PV Minimum Span
7) PV Damp
8) PV AO
9) PV AO Alarm type
10) PV % Range
11) PV Xfer Function
12) PV Range Unit
13) PV URV
14) PV LRV
15) PV PV Snsr S/N

595-8637 2.2
X9800 ROOT MENU
When HART communication is established, the first menu displayed is the X9800 Root menu:
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Fire (Yes/No) Indicates “Y” if the device is in a fire alarm status — analog output is at 20 mA,
fire alarm relay is actuated, and LED is red.
2) Fault (Yes/No) Indicates “Y” if a fault condition exists. Go to “Device Info” and select “Status
Info” to determine the nature of the fault.
3) Device Info Menu Provides access to manufacturer and HART information, current device status,
factory settings, and history logs.
4) Command Menu This menu allows the operator to initiate a manual oi test and to perform
various reset/clear functions.
5) Device Setup Menu This menu allows various setup, configuration, and calibration functions.
DEVICE INFO MENU
This menu allows access to a variety of “read-only” information.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) General Info Menu Factory information.
2) HART Info Menu HART Specific Variables.
3) Status Info Menu Current operating status and/or diagnostic information.
4) Detector Settings Factory settings relating to relay operation, detector sensitivity, and response.
5) History Menu Display log files: Alarm, Fault, General.

95-8637
6
2.2
GENERAL INFO MENU
General Info Menu
1) Manufacturer
2) Model
3) Serial Number
4) Part Number
5) Manufacture Date
6) Snsr Firmware
7) HART Firmware
8) Real Time Clock
9) Write protect (Y/N)
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Manufacturer Det-Tronics.
2) Model X9800.
3) Serial Number Serial number of device.
4) Part Number Manufacturer’s part number for this device.
5) Manufacture Date Date of manufacture shown as XX/XX/XX (month/day/year).
6) Snsr Firmware Firmware revision level of sensor module.
7) HART Firmware Firmware revision level of HART Interface Board (HIB).
8) Real Time Clock Current time and date settings of real time clock.
9) Write protect (Y/N) This indicates whether variables can be written to the device or whether
commands that cause actions to be performed in the device can or cannot
occur.

795-8637 2.2
HART INFO MENU
HART Info Menu
1) Universal rev
2) Field dev rev
3) Final asmbly num
4) Tag
5) Long tag
6) Date
7) Descriptor
8) Message
9) Num req preams
10) HART PV Menu
11) Condensed Status
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Universal rev HART universal revision.
2) Field dev rev HART field device revision.
3) Final asmbly num A number that is used for identification purposes and is associated with the
overall field device.
4) Tag Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of eight character input.
5) Long tag Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of 32 character input.
6) Date Any date chosen by the operator to be used for any purpose. XX/XX/XXXX
(month/day/year).
7) Descriptor Text associated with the field device that can be used by the operator in any
way.
8) Message Text associated with the field device that can be used by the operator in any
way.
9) Num req preams HART specific synchronization messages.
10) HART PV Menu Display HART specific primary variable (PV) items.
11) Condensed Status Device status condensed for HART handheld display.

95-8637
8
2.2
HART PV MENU
HART PV Menu
1) PV Unit
2) PV
3) PV Sensor Unit
4) PV USL
5) PV LSL
6) PV Minimum Span
7) PV Damp
8) PV AO
9) PV AO Alarm type
10) PV % Range
11) PV Xfer Function
12) PV Range Unit
13) PV URV
14) PV LRV
15) PV PV Snsr S/N
HART Info Menu
1) Universal rev
2) Field dev rev
3) Final asmbly num
4) Tag
5) Long tag
6) Date
7) Descriptor
8) Message
9) Num req preams
10) HART PV Menu
11) Condensed Status
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) PV Unit Not implemented for X9800.
2) PV Not implemented for X9800.
3) PV Sensor Unit Not implemented for X9800.
4) PV USL Not implemented for X9800.
5) PV LSL Not implemented for X9800.
6) PV Minimum Span Not implemented for X9800.
7) PV Damp Not implemented for X9800.
8) PV AO Analog Output. The value that tracks the Digital Value representation, under
normal operating modes.
9) PV AO Alarm type Not implemented for X9800.
10) PV % Range Percent of Range. The variable that tracks the Digital Value representation with
respect to the range defined by the Lower Range Value and Upper Range
Value, for normal operating modes. The units of this variable are always in
percent.
11) PV Xfer Function Not implemented for X9800.
12) PV Range Unit Not implemented for X9800.
13) PV URV Not implemented for X9800.
14) PV LRV Not implemented for X9800.
15) PV PV Snsr S/N Not implemented for X9800.

995-8637 2.2
CONDENSED STATUS
Condensed Status
1) Xmtr Addstatus 0
2) Xmtr Addstatus 1
3) Xmtr Addstatus 2
4) Xmtr Addstatus 3
5) Operating Mode
HART Info Menu
1) Universal rev
2) Fld dev rev
3) Final asmbly num
4) Tag
5) Long tag
6) Date
7) Descriptor
8) Message
9) Num req preams
10) HART PV Menu
11) Condensed Status
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Xmtr Addstatus 0 Fire Alarm
IR Alarm
TDSA Alarm
Quick Alarm
oi Cal Alarm
Manual oiActive
Warm-up
2) Xmtr Addstatus 1 IR Pre Alarm
3) Xmtr Addstatus 2 Fault
Manual IR oiFault
Auto IR oiFault
IR oiCal Fault
Temperature Out of Range
4) Xmtr Addstatus 3 Voltage Out of Range Fault
Manual oi at Start
Hardware Fault
HART Fault
Modbus Communication Fault
Incompatible Version
5) Operating mode Fault
Fire Alarm

95-8637
10
2.2
STATUS INFO MENU
This menu (read-only) shows extensive status information about the detector.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Status Info Menu
1) Warm Up (Y/N)
2) Fire (Y/N)
3) IR Alarm (Y/N)
4) TDSA Alarm (Y/N)
5) Quick Alarm (Y/N)
6)
IR Pre Alarm (Y/N)
7) Auto IR Oi Fault (Y/N)
8) Manual Oi at Start
9) Sensor Hdwr. Fault
(Y/N)
10) HIB Hardware Fault (Y/N)
11) Internal Com. Flt (Y/N)
12) Incompatible Fault (Y/N)
13) Voltage Fault (Y/N)
14) Hardware Menu
15) Oi Menu
1) Warm Up (Y/N) Device is in the power-up time delay (warm-up) mode.
2) Fire (Y/N) Indicates “Y” if the device is in a fire alarm status — analog output is at 20 mA,
fire alarm relay is actuated, and LED is red.
3) IR Alarm (Y/N) Indicates "Y" if the IR detector is signaling an alarm.
4) TDSA Alarm (Y/N) Indicates "Y" if the IR detector is signaling a TDSA alarm.
5) Quick Alarm (Y/N) Indicates "Y" if the IR detector is signaling a quick alarm.
6) IR Pre Alarm (Y/N) Indicates "Y" if the IR detector is in a pre-alarm state. .
7) Auto IR oi Flt (Y/N) Automatic IR oiFault. Check viewing window and oireflector plate for cleanliness.
8) Manual oi at Start (Y/N) Manual oi at start. On power-up a manual oi was started. Check the external
input wiring.
9) Sensor Hdwr. Flt (Y/N) Sensor hardware fault.
10) HIB Hardware Flt (Y/N) HART Interface Board hardware fault.
11) Internal Com. Flt (Y/N) Internal communication fault.
12) Incompatible Flt (Y/N) Sensor module firmware version is not compatible with HART Interface
Board.
13) Voltage Fault (Y/N) Detector operating voltage is out of tolerance.
14) Hardware Menu Refer to sub-menu.
15) oi Menu Refer to sub-menu.

11 95-8637 2.2
HARDWARE MENU
Hardware Menu
1) Temperature
2) Temp Range Fault
3) Voltage
4) Voltage Fault
5) Manual Oi at Start
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Status Info Menu
1) Warm Up (Y/N)
2) Fire (Y/N)
3) IR Alarm (Y/N)
4) TDSA Alarm (Y/N)
5) Quick Alarm (Y/N)
6)
IR Pre Alarm (Y/N)
7) Auto IR Oi Fault (Y/N)
8) Manual Oi at Start
9) Sensor Hdwr. Fault
(Y/N)
10) HIB Hardware Fault (Y/N)
11) Internal Com. Flt (Y/N)
12) Incompatible Fault (Y/N)
13) Voltage Fault (Y/N)
14) Hardware Menu
15) Oi Menu
1) Temperature Actual integral temperature of detector.
2) Temp Range Fault Detector integral temperature out of range — Operating range: –40°F to
+167°F (–40°C to +75°C).
3) Voltage Actual detector supply voltage must be 18 to 30 Vdc.
4) Voltage Fault Supply voltage is out of range. Operating voltage must be 18 to 30 Vdc.
5) Manual oi at Start Manual oi at start. On power-up a manual oi was started. Check the external
input wiring.

95-8637
12
2.2
oiMENU
1) Consecutive IR oiFails Allowable number of consecutive IR oifailures to produce a fault. Factory set
to three (minutes). This is the time between fault occurrence and annunciation
2) oiCalibrate Active oicalibration is in progress.
3) IR oiCal Flt IR oicalibration has detected a fault condition.
4) Manual oiActive A manual oitest is in progress.
5) Manual IR oiFlt Manual IR oifault. Check IR viewing window and oi reflector plate
cleanliness.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Oi Menu
1) Consecutive IR Oi Fails
2) Oi Calibrate Active
3) IR Oi Cal Flt
4) Manual Oi Active
5) Manual IR Oi Flt
Status Info Menu
1) Warm Up (Y/N)
2) Fire (Y/N)
3) IR Alarm (Y/N)
4) TDSA Alarm (Y/N)
5) Quick Alarm (Y/N)
6)
IR Pre Alarm (Y/N)
7) Auto IR Oi Fault (Y/N)
8) Manual Oi at Start
9) Sensor Hdwr. Fault
(Y/N)
10) HIB Hardware Fault (Y/N)
11) Internal Com. Flt (Y/N)
12) Incompatible Fault (Y/N)
13) Voltage Fault (Y/N)
14) Hardware Menu
15) Oi Menu

13 95-8637 2.2
DETECTOR SETTINGS
This menu shows factory settings relating to relay operation, detector sensitivity, and response.
1) IR Mode IR Mode: TDSA and Quick or TDSA only.
2) IR Sensitivity Detector IR sensitivity setting: Low, Medium, High, or Very High.
3) Auto oi Enabled Auto oienabled. If (Y) an oi test will be conducted periodically without
manual input.
4) Fire Relay (NL/L) Fire Relay: Latching (L) or Non-Latching (NL).
5) Fault Relay (NL/L) Fault Relay: Latching (L) or Non-Latching (NL).
6) Aux Relay (NL/L) Aux Relay: Latching (L) or Non-Latching (NL).
7) Heater Disabled Heater disabled. If (Y) the optics heater is not enabled to prevent
condensation and icing.
8) Aux Function Aux function: Pre Alarm or IR Alarm.
9) Aux IR Function Aux IR function: TDSA and Quick or TDSA only.
10) Aux Relay (NE/NDE) Aux Relay: Normally Energized (NE) or Normally De-Energized (NDE)
HISTORY MENU
This menu provides historical information about the detector. Up to 32 events in each of the three
categories will be kept in non-volatile memory. When the log is full, the oldest event will be overwritten.
The most recent event will be displayed first.
1) Alarm Log Scroll through 32 Alarm Logs with time, date, and temperature stamp.
2) Fault Log Scroll through 32 Fault Logs with time, date, and temperature stamp.
3) General Log Scroll through 32 General Logs with time, date, and temperature stamp.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Detector Settings
1) IR Mode
2) IR Sensitivity
3) Auto Oi Enabled
4) Fire Relay (NL/L)
5) Fault Relay (NL/L)
6) Aux Relay (NL/L)
7) Heater Disabled
8) Aux Function
9) Aux IR Function
10) Aux Relay (NE/NDE)
History Menu
1) Alarm Log
2) Fault Log
3) General Log
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

95-8637
14
2.2
COMMAND MENU
The Command Menu allows the operator to initiate a manual oi test and also to perform various reset/
clear functions.
1) Start Passive oi A passive oi test command checks the cleanliness of the detector’s
optical surfaces. This calibrated oi test confirms the ability of the detector
to respond correctly to an IR signal. Fire and fault relays as well as
0–20 mA current loop output are unaffected by this test. A red LED signals
a successful test, and an amber LED signals a failed test. The general log
will indicate either “Man oi Pass” or “Man oi Flt.”
2) Start Active oi
CAUTION
An active oi test generates an actual Fire Alarm Output.All re
response equipment must be bypassed/disabled prior to testing to
prevent unwanted output actuation.
An active oi test performs an oi test with all detector outputs fully
operational. Fire and fault relays as well as the 0–20 mA loop are “live."
If the test is successful: Fire relay = Alarm
Fault relay = no fault
Current output is 20 mA
LED turns red
General log indicates “Man oi Pass”
Alarm log indicates "Fire Alarm"
If the test is unsuccessful: Fire relay = No Alarm
Fault relay = Fault
Current output is 2 mA
LED turns yellow
Fault log indicates “Man oi Flt”
3) Clear oi Fault If the cause of the fault has not been corrected, subsequent oi faults will
occur.
4) Reset Latches Latching relays are reset and LED turns green.
5) Master Reset This function re-initializes the microprocessor, resets the operating
software, and initiates a hardware reset for both the sensor and the HART
interface. Latched relays are reset.
6) Clear Data Log This function resets the HART data log history. To view the logs, go to
“Device Info Menu” and select “History Menu."
7) HART Command Menu This menu performs various diagnostic and/or service functions.
Command Menu
1) Start Passive Oi
2) Start Active Oi
3) Clear Oi Fault
4) Reset Latches
5) Master Reset
6) Clear Data Log
7)
HART Command Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

15 95-8637 2.2
HART COMMAND MENU
The HART Command Menu allows the operator to perform diagnostic and service functions as follows:
1) Self test Internal tests are performed and any detected problems are reported in “Status
Info.” If successful, indication will be "No Device Info on Self Test."
2) Master Reset This function re-initializes the microprocessor, resets the operating software, and
initiates a hardware reset for both the sensor and the HART interface. Latched relays
are reset.
3) Loop test This test allows the operator to manually set the analog signal output at 1, 2, 3, or
between 4 and 20 mA in increments of 2 (4, 6, 8, etc.). When the loop test is completed,
ensure that the current loop is returned to automatic operation.
DEVICE SETUP MENU
This menu allows various setup, configuration, and calibration functions. When Write Protect is off, these
menus allow the operator to reconfigure or write new variables to the device.
1) Conguration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
Refer to the appropriate sub-menus for details.
HART Command Menu
1) Self test
2) Master Reset
3) Loop test
Command Menu
1) Start Passive Oi
2) Start Active Oi
3) Clear Oi Fault
4) Reset Latches
5) Master Reset
6) Clear Data Log
7)
HART Command Menu
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

95-8637
16
2.2
CONFIGURATION MENU
1) Cons IR oi Fails Allowable number of consecutive IR oifailures to produce a fault. Factory
set to three (minutes). This is the time between fault occurrence and
annunciation.
2) Time Delay Time Delay before alarm is indicated (0 to 15 seconds). Factory default is
zero seconds.
Important: In addition to lengthening the time period between the outbreak
of a fire and the fire alarm, a time delay can also affect sensitivity. Consult the
factory for guidance before setting a time delay over five seconds.
Note: FM Approval covers the detector's performance with zero time delay
only.
CALIBRATION MENU
1) Loop test This test allows the operator to manually set the analog signal output at 1, 2,
3, or between 4 and 20 mA in increments of 2 (4, 6, 8, etc.). When the loop
test is completed, ensure that the current loop is returned to automatic operation.
2) D/A trim This function allows adjustment of the 0–20 mA span factor.
NOTE
Trim in increments of 0.1 mA resolution only.
3) Calibrate oi This procedure calibrates the oi test signal for the IR sensor.
1. Bypass/disable all Alarm outputs connected to the detector.
2. Thoroughly clean the sensor and oireflector for the IR sensor.
Check the oisource openings for contaminants and clean as
needed.
3. Cover the detector with the provided cover.
4. Initiate oiCalibration. The detector performs the calibration
automatically and notifies the operator upon completion. The
procedure takes approximately two minutes.
5. Upon completion of oicalibration, remove the cover and return all
alarm outputs to service.
Configuration Menu
1) Cons IR Oi Fails
2) Time Delay
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Calibration Menu
1) Loop test
2) D/A trim
3) Calibrate Oi
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

17 95-8637 2.2
WRITE PROTECT
This function enables the operator to enable/disable password and write protection capability, as well
as to enter or change a password. The device is provided from the factory with Write Protect off. With
Write Protect on, the use of a password is required to enable writing to the device.
1) Set Password The password is used to validate the command to enable or disable writes
in the device. (The factory default password is: 1*******. Once the password
has been changed, the default password is no longer valid.)
To change the password:
1. Select "Set Password" and enter the password. Hit "Send."
2. If enabled, disable Write Protect. Hit "Send."
3. Select "Set Password" and enter a new password. Do not hit "Send" yet.
4. From within the "Set Write Protect" menu, select "Change Password."
Hit "Send."
CAUTION
Always record the new password. If the password is forgotten, the device
must be returned to the factory for re-programming.
2) Set Write Protect With Write Protect enabled, variables cannot be written to the device and
commands that cause actions to be performed in the device cannot occur.
3) Write protect (Y/N) This indicates whether or not Write Protect is enabled.
Write Protect
1) Set Password
2) Set Write Protect
3) Write protect (Y/N)
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu

95-8637
18
2.2
HART SETUP
This menu allows editing of the following functions:
1) Poll addr Address used by the host device to identify a field device. Note that if it
is set to an address other than "0," the Detector will output 1 mA.
2) Final asmbly num A number that is used for identification purposes and is associated with the
overall field device.
3) Tag Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of eight character input.
4) Long tag Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of 32 character input.
5) Date Any date chosen by the operator to be used for any purpose. XX/XX/XXXX
(month/day/year).
6) Descriptor Text associated with the field device that can be used by the operator in any
way.
7) Message Text associated with the field device that can be used by the operator in any
way.
REAL TIME CLOCK
To set the real time clock, enter the current time and date information into the appropriate fields.
1) RTC Seconds 0 to 59
2) RTC Minutes 0 to 59
3) RTC Hours 0 to 23
4) RTC Date 1 to 31
5) RTC Month 1 to 12
6) RTC Year 0 to 99
Real Time Clock
1) RTC Seconds
2) RTC Minutes
3) RTC Hours
4) RTC Date
5) RTC Month
6) RTC Year
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
HART Setup
1) Poll addr
2) Final asmbly num
3) Tag
4) Long tag
5) Date
6) Descriptor
7) Message
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
X9800 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
