DEV 1951 User manual

User Manual
DEV 1951
Universal Switch Chassis 1 RU
DEV Systemtechnik GmbH
Grüner Weg 4A
61169 Friedberg
GERMANY
Tel: [phone]
Fax: [phone]
[e-mail]
www.dev-systemtechnik.com
Revision: 2017-10-26
DEV 91-0001-O

User Manual DEV 1951
2 Copyright DEV Systemtechnik GmbH 2004-2017
Table of Contents
1Revision History----------------------------------------------------------- 8
2Introduction---------------------------------------------------------------- 9
2.1Warranty---------------------------------------------------------------------------------- 9
2.2 Limitation of Warranty---------------------------------------------------------------- 9
2.3 Warnings---------------------------------------------------------------------------------- 9
3Product Description -----------------------------------------------------11
3.1 Features and Options---------------------------------------------------------------- 11
3.1.1 Device Panel---------------------------------------------------------------------------- 11
3.1.2 Communication Features ----------------------------------------------------------- 13
3.1.3 Autonomous Switching and Options --------------------------------------------- 14
3.1.4 TRAC Option---------------------------------------------------------------------------- 14
3.2 Modules Description ---------------------------------------------------------------- 15
3.2.1 DEV 11–0005--------------------------------------------------------------------------- 15
3.2.2 DEV 11-0009 --------------------------------------------------------------------------- 16
3.2.3 DEV 11-0010 --------------------------------------------------------------------------- 16
3.2.4 DEV 11-0011 --------------------------------------------------------------------------- 16
3.2.5 DEV 11-0024 --------------------------------------------------------------------------- 17
3.2.6 DEV 11-0027 --------------------------------------------------------------------------- 17
3.2.7 DEV 11-0028 --------------------------------------------------------------------------- 17
3.2.8 DEV 11-0033 --------------------------------------------------------------------------- 18
3.2.9 DEV 11-0050 --------------------------------------------------------------------------- 18
3.2.10 DEV 11-0057 --------------------------------------------------------------------------- 18
3.2.11 DEV 11-0058 --------------------------------------------------------------------------- 19
3.2.12 DEV 11-0107 --------------------------------------------------------------------------- 19
3.2.13 DEV 11-0108 --------------------------------------------------------------------------- 19
3.2.14 DEV 13-0169 --------------------------------------------------------------------------- 20
3.2.15 DEV 13-0170 --------------------------------------------------------------------------- 20
3.2.16 DEV 13-0171 --------------------------------------------------------------------------- 20
3.2.17 DEV 13-0174 --------------------------------------------------------------------------- 20
3.2.18 DEV 14-0014 --------------------------------------------------------------------------- 21
3.2.19 DEV 14-0087 --------------------------------------------------------------------------- 21
3.2.20 DEV 14-0088 --------------------------------------------------------------------------- 21
3.2.21 DEV 14-0091 --------------------------------------------------------------------------- 22
3.2.22 DEV 14-0093 --------------------------------------------------------------------------- 22
3.2.23 DEV 14-0095 --------------------------------------------------------------------------- 22
3.2.24 DEV 14-0102 --------------------------------------------------------------------------- 23
3.2.25 DEV 14-0110 --------------------------------------------------------------------------- 23
3.2.26 DEV 7462-------------------------------------------------------------------------------- 23
3.2.27 DEV 7463-------------------------------------------------------------------------------- 24
3.3 Product Drawings--------------------------------------------------------------------- 24

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 3
4Installation Instructions------------------------------------------------25
4.1 Scope of Delivery --------------------------------------------------------------------- 25
4.2 Installation of the Product --------------------------------------------------------- 25
4.2.1 Mechanical Integration of the Product ------------------------------------------ 25
4.2.2 Grounding, Data Cables, Alarm Cable, and Power Connection ------------ 25
4.2.3 Connection of Optical Cables ------------------------------------------------------ 26
4.2.4 Connection of RF Signal Cables ---------------------------------------------------- 26
4.2.5 Installation and Exchange of Modules ------------------------------------------- 27
4.2.6 Reset of the Device and the Restore of Factory Defaults ------------------- 27
4.2.7 Configuration Mode------------------------------------------------------------------ 28
4.3 Device Factory Settings ------------------------------------------------------------- 29
4.3.1 Factory Settings for Sensing Switch Modules ---------------------------------- 29
4.3.2 Factory Communication Protocol Configuration ------------------------------ 29
4.3.3 Factory Network Settings ----------------------------------------------------------- 29
4.3.4 Factory SNMP Settings--------------------------------------------------------------- 30
4.3.5 Factory Sandar Prosan Protocol Settings---------------------------------------- 30
4.3.6 Factory Leitch Protocol Settings--------------------------------------------------- 30
4.3.7 Factory QEC Protocol Settings ----------------------------------------------------- 30
4.4 Communication Interface Configuration --------------------------------------- 30
4.4.1 Serial Interface------------------------------------------------------------------------- 30
4.4.1.1 Standard Serial Interface Configuration ---------------------------------------------------31
4.4.1.2 Sandar Prosan Protocol Serial Interface Configuration --------------------------------31
4.4.2 Ethernet Interface -------------------------------------------------------------------- 31
4.4.2.1 Ethernet Connection----------------------------------------------------------------------------31
4.4.2.2 Network Setup via the Serial Interface-----------------------------------------------------32
4.4.2.2.1 Start and Termination of the Configuration Program ----------------------------------------------32
4.4.2.2.2 1 set IP address -----------------------------------------------------------------------------------------------34
4.4.2.2.3 2 set netmask -------------------------------------------------------------------------------------------------34
4.4.2.2.4 3 set gateway--------------------------------------------------------------------------------------------------34
4.5 Maintenance of the Product------------------------------------------------------- 34
5Operation of the Product ----------------------------------------------35
5.1 Modes of Operation ----------------------------------------------------------------- 35
5.1.1 Local Mode ----------------------------------------------------------------------------- 35
5.1.2 Remote Mode ------------------------------------------------------------------------- 35
5.1.3 Auto Mode ----------------------------------------------------------------------------- 36
5.1.3.1 Autonomous Switching Functionality ------------------------------------------------------36
5.1.4 Individual/Simultaneous Switching Mode -------------------------------------- 40
5.2 Initialization of the Device --------------------------------------------------------- 40
5.3 Operation via the Device Panel --------------------------------------------------- 40
5.4 Control via the Digital Interface -------------------------------------------------- 41
5.5 Operation via Web Interface ------------------------------------------------------ 43
5.5.1 Start of the Web Interface---------------------------------------------------------- 43

User Manual DEV 1951
4 Copyright DEV Systemtechnik GmbH 2004-2017
5.5.2 The Main Window and Common Features of the Main Tabs--------------- 45
5.5.3 Status Tab------------------------------------------------------------------------------- 46
5.5.4 Control Tab ----------------------------------------------------------------------------- 47
5.5.4.1 Switch ----------------------------------------------------------------------------------------------49
5.5.4.2 Distribution Amplifier --------------------------------------------------------------------------51
5.5.5 Events Tab ------------------------------------------------------------------------------ 52
5.5.6 Recording Tab-------------------------------------------------------------------------- 53
5.5.7 Setup Tab ------------------------------------------------------------------------------- 57
5.5.7.1 User Setup-----------------------------------------------------------------------------------------58
5.5.7.1.1 Password and Language------------------------------------------------------------------------------------58
5.5.7.1.2 User Management -------------------------------------------------------------------------------------------58
5.5.7.2 System Setup -------------------------------------------------------------------------------------60
5.5.7.2.1 Network---------------------------------------------------------------------------------------------------------60
5.5.7.2.2 SNMP ------------------------------------------------------------------------------------------------------------61
5.5.7.2.3 CPH---------------------------------------------------------------------------------------------------------------62
5.5.7.3 Feature Setup-------------------------------------------------------------------------------------64
5.5.7.3.1 Recording-------------------------------------------------------------------------------------------------------64
5.5.7.3.2 Auto Mode -----------------------------------------------------------------------------------------------------65
5.5.7.3.3 Time Based Switching ---------------------------------------------------------------------------------------67
5.5.7.3.4 TRAC -------------------------------------------------------------------------------------------------------------69
5.5.7.3.4.1 TRAC Setup-----------------------------------------------------------------------------------------------------70
5.5.7.3.4.2 IP Monitor------------------------------------------------------------------------------------------------------74
5.5.7.3.4.3 Trap Log---------------------------------------------------------------------------------------------------------75
5.5.7.3.5 Actions ----------------------------------------------------------------------------------------------------------76
5.5.7.3.5.1 Switching Actions --------------------------------------------------------------------------------------------76
5.5.7.3.5.2 Action Log ------------------------------------------------------------------------------------------------------78
5.5.7.4 Software Service ---------------------------------------------------------------------------------79
5.5.7.4.1 Restore Factory Defaults -----------------------------------------------------------------------------------79
5.5.7.4.2 Data Backup ---------------------------------------------------------------------------------------------------79
5.5.7.4.3 Firmware Update---------------------------------------------------------------------------------------------83
5.5.8 Info Tab---------------------------------------------------------------------------------- 84
5.6 Control via Remote Interface: Sandar Prosan Protocol--------------------- 85
5.6.1 Sandar Prosan Protocol Overview ------------------------------------------------ 85
5.6.2 Sandar Prosan Protocol Communication Structure --------------------------- 85
5.6.3 Sandar Prosan Commands ---------------------------------------------------------- 86
5.6.3.1 Status Query (Q) ---------------------------------------------------------------------------------86
5.6.3.2 Query Alarm Messages (AM or AMA) ------------------------------------------------------86
5.6.3.3 System Identification (XR)---------------------------------------------------------------------87
5.6.3.4 Read Status of Signal Path (S or SA)---------------------------------------------------------87
5.6.3.5 Set Signal Path (M) ------------------------------------------------------------------------------88
5.6.3.5.1 Command Set 1-----------------------------------------------------------------------------------------------88
5.6.3.5.2 Command Set 2-----------------------------------------------------------------------------------------------88
5.6.3.6 Select Remote Control Mode (PMCI/PMCE)----------------------------------------------89
5.6.3.7 Select Switching Operation Mode (PMOI/PMOS) ---------------------------------------89
5.6.3.8 Select Echo in Local Mode (PME0/PME1)-------------------------------------------------90
5.6.3.9 Select Power Supply Monitoring Mode (PMP0/PMP1) --------------------------------90
5.7 Control via Remote Interface: Leitch Protocol -------------------------------- 91
5.7.1 Leitch Protocol Overview ----------------------------------------------------------- 91

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 5
5.7.2 Leitch Protocol Communication Structure -------------------------------------- 92
5.7.3 Leitch Telnet Authentication ------------------------------------------------------- 93
5.7.4 Leitch Commands --------------------------------------------------------------------- 93
5.7.4.1 Enable Reporting (?) ----------------------------------------------------------------------------93
5.7.4.2 Alarms Request (Q?)----------------------------------------------------------------------------93
5.7.4.3 Device Description Request (I?A)------------------------------------------------------------94
5.7.4.4 Device Version Request (I?V)-----------------------------------------------------------------94
5.7.4.5 Request Crosspoint Status (S?{Lvl}) ---------------------------------------------------------95
5.7.4.5.1 One Switch Module Installed -----------------------------------------------------------------------------95
5.7.4.5.2 Two Switch Modules Installed & Individual Switch Level Assignment Disabled-------------95
5.7.4.5.3 Two Switch Modules Installed & Individual Switch Level Assignment Enabled -------------95
5.7.4.6 Direct Crosspoint Take (X:)--------------------------------------------------------------------96
5.7.4.6.1 One Switch Module Installed -----------------------------------------------------------------------------97
5.7.4.6.2 Two Switch Modules Installed & Individual Switch Level Assignment Disabled-------------97
5.7.4.6.3 Two Switch Modules Installed & Individual Switch Level Assignment Enabled -------------97
5.8 Control via Remote Interface: QEC Protocol ---------------------------------- 98
5.8.1 QEC Protocol Overview-------------------------------------------------------------- 98
5.8.2 QEC Protocol Communication Structure ---------------------------------------- 98
5.8.3 QEC Commands ----------------------------------------------------------------------100
5.8.3.1 Check Change Flag / Unit Status (C)------------------------------------------------------- 100
5.8.3.2 Check Queue (Q)------------------------------------------------------------------------------- 101
5.8.3.3 Firmware Version / Unit ID (F) ------------------------------------------------------------- 102
5.8.3.4 Query Output Channel (O) ------------------------------------------------------------------ 102
5.8.3.5 Set Crosspoint (S)------------------------------------------------------------------------------ 103
5.9 Control via Remote Interface: SNMP-------------------------------------------104
5.9.1 SNMP Overview ----------------------------------------------------------------------104
5.9.2 Private Enterprise Number, Device Index Number --------------------------104
5.9.3 The Switch MIB Tree ----------------------------------------------------------------105
5.9.4 MIB Objects ---------------------------------------------------------------------------105
5.9.4.1 .devSwitchTraps ------------------------------------------------------------------------------- 106
5.9.4.1.1 .devSwitchTraps.trapAlarmText------------------------------------------------------------------------ 106
5.9.4.1.2 .devSwitchTraps.trapAlarm------------------------------------------------------------------------------ 106
5.9.4.1.3 .devSwitchTraps.trapModeChange-------------------------------------------------------------------- 106
5.9.4.2 .instrument-------------------------------------------------------------------------------------- 107
5.9.4.2.1 .instrument.controllerMac ------------------------------------------------------------------------------ 107
5.9.4.2.2 .instrument.firmwareRevision -------------------------------------------------------------------------- 107
5.9.4.2.3 .instrument.instrumentType ---------------------------------------------------------------------------- 107
5.9.4.2.4 .instrument.antennaControllerType ------------------------------------------------------------------ 107
5.9.4.3 .application-------------------------------------------------------------------------------------- 108
5.9.4.3.1 .application.controlMode-------------------------------------------------------------------------------- 108
5.9.4.3.2 .application.switchingControl--------------------------------------------------------------------------- 108
5.9.4.3.3 .application.simultaneousMode ----------------------------------------------------------------------- 109
5.9.4.3.4 .application.numberOfSwitchGroups----------------------------------------------------------------- 109
5.9.4.3.5 .application.switchGroupTable ------------------------------------------------------------------------- 109
5.9.4.3.5.1 .application.switchGroupTable.switchGroupEntry.swGroupIndex --------------------------- 109
5.9.4.3.5.2 .application.switchGroupTable.switchGroupEntry.swGroupMembers---------------------- 109
5.9.4.3.5.3 .application.switchGroupTable.switchGroupEntry.swGroupMainRfStatus----------------- 110
5.9.4.3.5.4 .application.switchGroupTable.switchGroupEntry.swGroupRedundancyRfStatus------- 110
5.9.4.3.6 .application.numberOfSwitchUnits-------------------------------------------------------------------- 111

User Manual DEV 1951
6 Copyright DEV Systemtechnik GmbH 2004-2017
5.9.4.3.7 .application.switchUnitTable---------------------------------------------------------------------------- 111
5.9.4.3.7.1 .application.switchUnitTable.switchUnitEntry.swIndex ----------------------------------------- 111
5.9.4.3.7.2 .application.switchUnitTable.switchUnitEntry.swSize-------------------------------------------- 111
5.9.4.3.7.3 .application.switchUnitTable.switchUnitEntry.swMembers------------------------------------ 112
5.9.4.3.7.4 .application.switchUnitTable.switchUnitEntry.swPosition-------------------------------------- 112
5.9.4.3.8 .application.numberOfPorts----------------------------------------------------------------------------- 113
5.9.4.3.9 .application.portTable ------------------------------------------------------------------------------------ 113
5.9.4.3.9.1 .application.portTable.portEntry.portIndex -------------------------------------------------------- 114
5.9.4.3.9.2 .application.portTable.portEntry.poEnable --------------------------------------------------------- 115
5.9.4.3.9.3 .application.portTable.portEntry.poType------------------------------------------------------------ 115
5.9.4.3.9.4 .application.portTable.portEntry.poHasRfSense--------------------------------------------------- 115
5.9.4.3.9.5 .application.portTable.portEntry.poRfSense-------------------------------------------------------- 115
5.9.4.3.9.6 .application.portTable.portEntry.poRfLimit--------------------------------------------------------- 116
5.9.4.3.9.7 .application.portTable.portEntry.poHasBias-------------------------------------------------------- 116
5.9.4.3.9.8 .application.portTable.portEntry.poBiasOnOff----------------------------------------------------- 116
5.9.4.3.9.9 .application.portTable.portEntry.poBiasCurrent -------------------------------------------------- 116
5.9.4.3.9.10 .application.portTable.portEntry.poBiasLimitLo--------------------------------------------------- 116
5.9.4.3.9.11 .application.portTable.portEntry.poBiasLimitHi --------------------------------------------------- 116
5.9.4.3.9.12 .application.portTable.portEntry.poHasGain ------------------------------------------------------- 117
5.9.4.3.9.13 .application.portTable.portEntry.poGain ------------------------------------------------------------ 117
5.9.4.3.9.14 .application.portTable.portEntry.poHasTilt --------------------------------------------------------- 117
5.9.4.3.9.15 .application.portTable.portEntry.poTilt -------------------------------------------------------------- 117
5.9.4.3.9.16 .application.portTable.portEntry.poCardType ----------------------------------------------------- 117
5.9.4.3.9.17 .application.portTable.portEntry.poSlot ------------------------------------------------------------- 118
5.9.4.3.9.18 .application.portTable.portEntry.poRfSenseStatus ----------------------------------------------- 118
5.9.4.3.9.19 .application.portTable.portEntry.poBiasStatus ---------------------------------------------------- 118
5.9.4.3.9.20 .application.portTable.portEntry.poLightStatus --------------------------------------------------- 118
5.9.4.3.9.21 .application.portTable.portEntry.poCardStatus --------------------------------------------------- 119
5.9.4.3.10 .application.antennaStatus------------------------------------------------------------------------------ 119
5.9.4.3.11 .application.antennaPosition --------------------------------------------------------------------------- 119
5.9.4.4 .surveillance------------------------------------------------------------------------------------- 120
5.9.4.4.1 .surveillance.trapEnableMask--------------------------------------------------------------------------- 121
5.9.4.4.2 .surveillance.errorEnableMask ------------------------------------------------------------------------- 121
5.9.4.4.3 .surveillance.numberOfErrors -------------------------------------------------------------------------- 122
5.9.4.4.4 .surveillance.errorTable ---------------------------------------------------------------------------------- 122
5.9.4.4.4.1 .surveillance.errorTable.errorEntry.errorIndex ---------------------------------------------------- 122
5.9.4.4.4.2 .surveillance.errorTable.errorEntry.errorNr -------------------------------------------------------- 122
5.9.4.4.4.3 .surveillance.errorTable.errorEntry.errorCount---------------------------------------------------- 122
5.9.4.4.4.4 .surveillance.errorTable.errorEntry.errorDateTime----------------------------------------------- 123
5.9.4.4.4.5 .surveillance.errorTable.errorEntry.errorPending------------------------------------------------- 123
5.9.4.4.4.6 .surveillance.errorTable.errorEntry.errorAcknowledge------------------------------------------ 123
5.9.4.4.5 .surveillance.numberOfPowerLines ------------------------------------------------------------------- 123
5.9.4.4.6 .surveillance.powerLineTable --------------------------------------------------------------------------- 123
5.9.4.4.6.1 .surveillance.powerLineTable.powerLineEntry.powerLineIndex ------------------------------ 123
5.9.4.4.6.2 .surveillance.powerLineTable.powerLineEntry.powerLineStatus ----------------------------- 124
5.9.4.4.7 .surveillance.numberOfPowerSupplies--------------------------------------------------------------- 124
5.9.4.4.8 .surveillance.powerSupplyTable ----------------------------------------------------------------------- 124
5.9.4.4.8.1 .surveillance.powerSupplyTable.powerSupplyEntry.powerSupplyIndex-------------------- 124
5.9.4.4.8.2 .surveillance.powerSupplyTable.powerSupplyEntry.powerSupplyStatus------------------- 124
5.9.4.4.9 .surveillance.numberOfFans ---------------------------------------------------------------------------- 124
5.9.4.4.10 .surveillance.fanTable------------------------------------------------------------------------------------- 124
5.9.4.4.10.1 .surveillance.fanTable.fanEntry.fanIndex------------------------------------------------------------ 125
5.9.4.4.10.2 .surveillance.fanTable.fanEntry.fanStatus----------------------------------------------------------- 125
5.9.4.4.11 .surveillance.internalDeviceStatus--------------------------------------------------------------------- 125

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 7
5.9.4.4.12 .surveillance.externalDeviceStatus -------------------------------------------------------------------- 125
5.9.4.4.13 .surveillance.supportHardwareStatus ---------------------------------------------------------------- 125
5.9.4.4.14 .surveillance.errorDescription -------------------------------------------------------------------------- 125
6Event Indication -------------------------------------------------------- 126
6.1 Event Indication via Alarm Connector -----------------------------------------126
6.1.1 A/B Alarm ------------------------------------------------------------------------------126
6.1.2 Summary Alarm ----------------------------------------------------------------------126
6.2 Software Event Indication---------------------------------------------------------127
6.2.1 Power Events--------------------------------------------------------------------------127
6.2.2 Switch Module Events --------------------------------------------------------------127
6.2.3 Input Module Events ----------------------------------------------------------------127
6.2.4 RF Level Monitoring Events--------------------------------------------------------127
6.2.5 Digital Signal Quality Events-------------------------------------------------------128
6.2.6 Other Events --------------------------------------------------------------------------128
7Connectors -------------------------------------------------------------- 129
8Technical Data and Options ----------------------------------------- 130
9Conformance Declarations ------------------------------------------ 130
9.1 Certificate of Conformance -------------------------------------------------------130
9.2 EU Declaration of Conformity ----------------------------------------------------133
10 Glossary ------------------------------------------------------------------ 134
11 Notes---------------------------------------------------------------------- 135

User Manual DEV 1951
8 Copyright DEV Systemtechnik GmbH 2004-2017
1Revision History
Revision (Date)
Author
Short Description
A (03-Aug-2005)
MA
Recent version (added chapter SNMP and introduced
revision history)
B (02-Aug-2006)
WP
Various bug fixes
C (15-Feb-2007)
WP
Added WEEE statement
D (06-Dec-2007)
WP
Complete rework due to new microcontroller
E (27-May-2008)
WP
Complete rework to new document format and due to
changes in the FW
F (12-May-2010)
WP
Minor corrections
G (05-Oct-2010)
WP
Complete rework due to new CPU & SW
H (22-Dec-2011)
WP
Complete rework due to new features: data backup,
recording functionality, automatic switch back option,
MIB changes etc.
I (10-Jan-2012)
WP
Minor corrections
J (26-Feb-2013)
WP
Complete rework due to new modules and due to new
Web I/F functionalities
K (19-Nov-2013)
WP
Rework due to new modules / new functionalities
L (10-Apr-2014)
WP
Rework due to module modifications
M (23-Sep-2015)
WP
Rework due to changes in module portfolio
N (09-Jun-2017)
WP
Rework due to new document format including minor
corrections
O (26-Oct-2017)
WP
Complete rework

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 9
2Introduction
Thank you for purchasing a DEV 1951 Universal Switch Chassis. This user manual is
intended to familiarize you with the installation and operation of the product.
The DEV 1951 chassis for professional use can be equipped with one or two switch
modules with the same or different functionalities, thus realizing a single or dual
channel switching solution. There is a large selection of switch modules for
different applications; in addition, there are available some modules without
switching functionality that can be applied to the DEV 1951 chassis as well.
DEV Systemtechnik GmbH declares that this equipment meets all relevant
standards and rules. The unit carries a CE mark.
Please read all instructions before installation or usage of the product!
2.1 Warranty
The product has a warranty against defects in material and workmanship for a
period of two years from the date of shipment.
During the warranty period DEV Systemtechnik will, at its option, either repair or
replace the product if it turns out to be defective.
For warranty, service, or repair, the product must be returned to DEV System-
technik. The customer has to pay shipping charges to DEV Systemtechnik and
DEV Systemtechnik will pay shipping charges to return the product to the customer.
However, the customer is obliged to pay all duties, all taxes, and all other additional
costs arising from the shipment of the product.
DEV Systemtechnik warrants that the software and firmware designated by
DEV Systemtechnik for use with the product will execute its programming
instructions if installed properly. DEV Systemtechnik does not warrant that the
operation of the product, software, or firmware will be uninterrupted or error-free.
2.2 Limitation of Warranty
The preceding warranty does not apply to defects resulting from:
improper site preparation or site maintenance;
improper or inadequate interfacing of the product;
unauthorized modification or misuse of the product;
the application of software supplied by the customer;
improper or inadequate maintenance of the product;
operation beyond the environmental conditions specified for the product.
2.3 Warnings
The following safety measures must be observed during all phases of operation,
service, and repair of the device. Failure to comply with the safety precautions or
warnings in this document violates safety standards of design, manufacturing, and
intended use of the device and may affect the built-in protections. DEV System-
technik shall not be liable for the user's failure to comply with these requirements.
Disconnect the device from any external power line before opening of the housing.
In any case, the device is to be opened by trained service staff, only.

User Manual DEV 1951
10 Copyright DEV Systemtechnik GmbH 2004-2017
Environmental Conditions
The device is designed for indoor use and for an ambient temperature range.
Mechanical Integration
It is not permitted to fix the chassis on the rack mount flanges, only. Balanced
weight distribution of the chassis has to be ensured by placing it on a solid surface
or by using rack rails.
Sufficient airflow through the chassis must be ensured to achieve best cooling
results. Do not block or obstruct the airflow through the chassis at the front and at
the rear side, e.g. by placing large components close to the rear side.
Grounding, AC Connection, Cables
To minimize shock hazard the device must be connected to an electrical ground via
a ground wire, please refer to chapter 4.2.2.
For the AC connection, the device must be connected to the AC power supply
mains through two power cables with three conductors and with the ground wire
firmly connected to an electrical ground (safety ground) at the power outlet. Any
interruption of the protective ground conductor will cause a potential shock hazard
that might cause personal injury.
Risk of electrical shock and energy hazard:
Disconnecting a single power supply line only does not interrupt the AC supply of
the device. To isolate the device completely, disconnect both power supply lines.
Do not connect the device to AC mains supply exceeding the specifications for input
voltage and frequency. The recommended AC cables to be applied are standard
high temperature power cables with type IEC 60320-C13 appliance plug appro-
priately rated to the conditions of the country where the device is operated.
Laser Safety (applies if equipped with Optical Switch Modules DEV 7462, DEV 7463)
Safety of Laser Products
DEV Systemtechnik recommends following the governing standard of the
country where the product is operated to assure regulatory compliance and to
provide the necessary safety programs to protect the operators and other
persons who get in contact with the product.
It is recommended to power down the product while working on the optical
fiber wiring.
The optical modules installed in the product operate with light at a non-visible
wavelength. Highest caution has to be taken, since the modules may carry laser
light that is capable to harm the human eye!
If no optical fiber is (to be) connected to an optical module, the optical con-
nector(s) have to be equipped with the appropriate protection cover(s).
Direct exposure to the beam is to be avoided, i.e. do not look into
unterminated optical ports or at fibers that connect to unknown sources.

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 11
3Product Description
With the DEV 1951, DEV Systemtechnik has developed a modular design principle
for a universal dual channel switch chassis. A variety of different switch modules is
available that can be installed in the two slots of the device. A selection of passive
splitter modules and of distribution amplifier modules for ASI/SDI signals is avail-
able as well. Please refer to chapter 3.2 for the description of the single modules.
A device panel (chapter 3.1.1) permits the monitoring and the local control of the
DEV 1951. Some other methods for the control and for the surveillance of the
device are provided (chapter 3.1.2). The application of sensing switch modules and
of digital signal switch modules enables additional autonomous switching
capabilities of the DEV 1951 (chapter 3.1.3) as well as the application of the TRAC
(stands for "Trap Receiver Action Controller") option (chapter 3.1.4).
3.1 Features and Options
3.1.1 Device Panel
The DEV 1951 provides a device panel at the front side of the chassis. A mode push
button and three yellow LEDs are located at the left side:
Universal Switch Chassis
Local
Rem ote
DEV 1951
Auto
1 2 3 4
The mode push button (1) permits the change of the operation mode (please refer
to chapter 5.1) at the device. By pressing and holding the button for ~3 seconds the
status of the LEDs advances, i.e. always only one of the operation mode LEDs
"Auto" (2), "Local" (3), or "Remote" (4) is on.
Note:
Products with the preceding version of the device panel are providing a "Local"
push button (instead of the mode push button) and a single "Remote" LED (i.e.
there is no explicit "Local" or "Auto" LED). The behavior of the push button and
the LED differs: The "Local" push button realizes the same functionality as the
mode push button but the device can be toggled between Local Mode ("Remote"
LED off) and Remote Mode or Auto Mode ("Remote" LED on) and vice versa,
only. Switching from Local Mode via the "Local" push button toggles to the
preceding mode (Remote Mode or Auto Mode) which was activated before the
device had been switched to Local Mode. The explicit activation of Remote
Mode or of Auto Mode is performed via Web Interface (chapter 5.5.2), or via
SNMP (chapter 5.9.4.3.1), or via Sandar Prosan protocol (chapter 5.6.3.6).
Moreover, even older revisions of the DEV 1951 additionally provide a "Reset"
push button located left to the "Remote" LED and to the "Local" push button. This
"Reset" button is not supported by the firmware of the device. Please do not
operate the button it might have an impact on the behavior of the installed
switch modules!

User Manual DEV 1951
12 Copyright DEV Systemtechnik GmbH 2004-2017
The second functionality of the mode (or "Local") push button is the event
acknowledgment: If there are pending and not acknowledged event(s), this is
indicated –in addition to the alarm connector, please refer to chapter 6.1.2- at the
device panel via continuous alternate blinking of all channel LEDs, the "Individual"
LED, and the "Simultaneous" LED (see below). To acknowledge the event(s) (i.e. to stop
the event indication and thus the blinking of the LEDs at the device panel), the
mode push button is to be operated. Thus, three scenarios for the behavior of the
mode push button are to be considered:
1. There are no pending and not acknowledged event(s):
In this case, the operation mode can be altered as described above.
2. There are pending and not acknowledged event(s) in Local Mode:
In this case, a short operation of the push button acknowledges the event(s).
After that, the operation mode can be altered as described above.
3. Pending and not acknowledged event(s) in Remote Mode (or Auto Mode):
In this case, a short operation of the push button acknowledges the event(s)
and switches the device to Local Mode. After that, the operation mode can be
altered as described above.
Note:
The type of event causing the event indication can be identified via Web
Interface or via remote interface, only.
If an event is not acknowledged and if the event disappears (e.g. a detected
missing AC line is working again), the event indication will stop automatically (if
it is the sole event).
The event indication cannot be stopped if no switch (or distribution amplifier)
module is installed or detected within the device.
In the middle of the device panel, the following elements are located:
the channel push buttons and the green channel LEDs (5& 7) and
the switching mode push button and the yellow LEDs (6) for the Simulta-
neous/Individual switching mode functionality (please refer to chapter 5.1.4):
In A In B
Ch 1
Individual
Simultaneous
567
In A In B
Ch 2
With the channel push buttons labeled "Ch 1" and "Ch 2", one of the two (input) ports
(primary (input) port "In A" or secondary (input) port "In B") of a switch module can
be switched to the common (output) port in Local Mode (!). The (input) port that is
currently active is indicated via the related green channel LED.
To alter the routing of a single switch module via the related channel push button
make sure that the device is in Local Mode and that the "Individual" LED is lit. After
the operation of the desired channel push button, the LED display will indicate the
altered switching position as a receipt.

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 13
If the "Simultaneous" LED is lit (for the preconditions to activate Simultaneous
switching mode please refer to chapter 5.1.4), any of the two channel push buttons
can be operated to initiate the switching of the two installed switch modules.
Note:
If the device is equipped with a single switch module only, the channel push
button of the empty slot will not work. In addition, the Simultaneous switching
mode is not available.
Three LEDs located at the device panel on the right are signalizing the power supply
operating status of the device:
Power Supply 1
Power Supply 2
Failure
8 9 10
"Power Supply 1" LED ((8), green) and "Power Supply 2" LED ((9), green):
The related power supply unit provides secondary voltage if this LED is on.
"Failure" LED ((10), red): This LED is on if either power supply unit does not
deliver any secondary voltage. The reason for this can be a defective power
supply, a defective primary protection fuse, or a missing primary voltage.
3.1.2 Communication Features
In addition to the device panel there are provided some options for the monitoring
and control of the product:
The standard digital interface of the DEV 1951 features basic remote switching
functionality permitting the control of the device, e.g. via a PLC (Programmable
Logic Control), please refer to chapter 5.4.
The Web Interface (chapter 5.5) provides features for checking the health status
and for changing the setup of the device; it enables full control in terms of
switching and in terms of setting up specific parameters. Additionally, the features
Time Based Switching and TRAC (if installed), and -for devices with installed sensing
switch modules- the recording functionality are accessible.
The implementation of SNMP (Simple Network Management Protocol) via the
Ethernet interface is intended to serve as the standard for remote monitoring and
control of the device (chapter 5.9).
In addition, a Communication Protocol Handler (CPH) is implemented which
enables the use of one of the following remote protocols with different monitoring
and control capabilities:
Sandar Prosan protocol via serial interface (chapter 5.6);
Leitch protocol via serial interface and via Ethernet interface (chapter 5.7); and
QEC protocol via serial interface and via Ethernet interface (chapter 5.8).
The installation of sensing switch modules and of digital signal switch modules
enables the autonomous switching capability (chapter 3.1.3) of the device based on
the signal quality. Moreover, the TRAC option (chapter 3.1.4) permits a remote
device to control the switching of the DEV 1951.

User Manual DEV 1951
14 Copyright DEV Systemtechnik GmbH 2004-2017
3.1.3 Autonomous Switching and Options
Among the broad choice of other switch modules, the DEV 1951 can be equipped
with one or two sensing switch modules or with one or two digital signal switch
modules; a mix of both types of switch modules is supported as well.
The sensing switch modules (and the digital signal switch modules) are special since
they permit the device to switch autonomously (please refer to chapter 5.1.3)
based on the RF level information (and on the digital signal quality information,
respectively) at both input ports of the module.
By default, the DEV 1951 provides autonomous switching capability from the
primary to the secondary input port(s).
With Option 22, the DEV 1951 is delivered with the main backup swap feature, i.e.
the autonomous switching works in both directions instead of switching from the
primary to the secondary input port(s), only.
With Option 28 the DEV 1951 is delivered with the automatic switch back feature
which permits the autonomous switching in both directions as well, but with an
adjustable hysteresis (for sensing switch modules) or with an adjustable delay (for
digital signal switch modules) when switching back from the secondary to the
primary input port(s).
The Web Interface enables the adjustment of the RF threshold levels for each input
port of a sensing switch module and enables the modification of settings for the
automatic switch back option.
3.1.4 TRAC Option
The product can be equipped with the TRAC (stands for Trap Receiver Action
Controller) option (Option 37), which permits the remote controlled switching of
the product based on SNMP traps, or based on the availability or on the absence of
a remote device (IP Monitoring). For more details, please refer to chapter 5.5.7.3.4.

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 15
3.2 Modules Description
This paragraph points out the functionality of the modules that were designed for
the DEV 1951. There are available electrical and optical switch modules, passive
splitter modules, and distribution amplifier modules for ASI/SDI signals.
The modules described in the following can be removed, installed, and/or ex-
changed even during the operation of the device. Knurled head screws are pro-
vided on each module, which can be operated easily.
A short listing of the available DEV 1951 modules is provided here for reference:
3.2.1 DEV 11–0005 - DPST Switch Module with Monitor Port; 47…1006 MHz; 75 Ohm, BNC (f)
3.2.2 DEV 11–0009 - DPST Switch Module; DC…2500 MHz; 50 Ohm, N (f)
3.2.3 DEV 11–0010 - DPST Sensing Switch Module; DC, 950…2150 MHz; 75 Ohm, F (f)
3.2.4 DEV 11–0011 - DPST Sensing Switch Module; DC, 47…1006 MHz; 75 Ohm, F (f)
3.2.5 DEV 11–0024 - DPST Relay Switch Module with Termination; DC…18 GHz; 50 Ohm, SMA (f)
3.2.6 DEV 11–0027 - Relay Transfer Switch Module; DC…18 GHz; 50 Ohm, SMA (f)
3.2.7 DEV 11–0028 - DPST Switch Module; DC, 47…2500 MHz; 75 Ohm, F (f)
3.2.8 DEV 11–0033 - DPST Relay Switch Module; DC…18 GHz; 50 Ohm, SMA (f)
3.2.9 DEV 11–0050 - DPST Switch Module; DC…2500 MHz; 50 Ohm, SMA (f)
3.2.10 DEV 11–0057 - Transfer Switch Module; DC…1006 MHz; 75 Ohm, BNC (f)
3.2.11 DEV 11–0058 - DPST Sensing Switch Module; DC, 950…2150 MHz; 50 Ohm, SMA (f)
3.2.12 DEV 11–0107 - DPST High Power Sensing Switch Module; DC, 950…2150 MHz; 75 Ohm, F (f)
3.2.13 DEV 11–0108 - DPST High Power Sensing Switch Module; DC, 47…1006 MHz; 75 Ohm, F (f)
3.2.14 DEV 13–0169 - 1:4/4:1 Splitter/Combiner Module, Passive; 47…1006 MHz; 75 Ohm, F (f)
3.2.15 DEV 13–0170 - 1:4/4:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 75 Ohm, F (f)
3.2.16 DEV 13–0171 - 1:4/4:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 50 Ohm, SMA (f)
3.2.17 DEV 13–0174 - 1:2/2:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 75 Ohm, F (f)
3.2.18 DEV 14–0014 - Ethernet 2:1/1:2 Switch Module
3.2.19 DEV 14–0087 - DPST Switch Module with DA 1:3; ASI; 75 Ohm, BNC (f)
3.2.20 DEV 14–0088 - DPST Switch Module with DA 1:3; ASI / HD-SDI; 75 Ohm, BNC (f)
3.2.21 DEV 14–0091 - Distribution Amplifier 1:3; ASI; 75 Ohm, BNC (f)
3.2.22 DEV 14–0093 - DPST Switch Module with DA 1:3; ASI / 3G-SDI; 75 Ohm, BNC (f)
3.2.23 DEV 14–0095 - Distribution Amplifier 1:3; ASI / 3G-SDI; 75 Ohm, BNC (f)
3.2.24 DEV 14–0102 - Distribution Amplifier 1:3; ASI / HD-SDI; 75 Ohm, BNC (f)
3.2.25 DEV 14–0110 - DPST Switch Module with DA 1:3; E1/T1; 75 Ohm, BNC (f)
3.2.26 DEV 7462 - 1:2 Optribution® Switch; 1260…1360 nm, 1510…1610 nm; SC/APC
3.2.27 DEV 7463 - 1:2 Optribution® Switch; 1260…1610 nm; SC/APC
3.2.1 DEV 11–0005
DPST Switch Module with Monitor Port; 47…1006 MHz; 75 Ohm, BNC (f)
Out
In A
In B Monitor
In B Monitor Out In A
DEV 11-0005
The output port ("Out") can be switched to one of two input ports ("In A", "In B"). The
unused input port is terminated internally. The transmission is DC blocked. Failsafe
relays are used for switching. In the case of power loss, the primary input port
("In A") is routed to the output port. For measurement purposes, the monitoring
output port ("Monitor") is available.

User Manual DEV 1951
16 Copyright DEV Systemtechnik GmbH 2004-2017
3.2.2 DEV 11-0009
DPST Switch Module; DC…2500 MHz; 50 Ohm, N (f)
In A
In B
Out
OutIn B In A
DEV 11-0009
The common port ("Out") can be switched to one of two input/output ports ("In A",
"In B"). The unused input/output port is terminated internally. Latching relays are
used for switching.
3.2.3 DEV 11-0010
DPST Sensing Switch Module; DC, 950…2150 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A Out In B
DEV 11-0010
Two input ports ("In A", "In B") can be switched to one output port ("Out"). The
unused input port is terminated internally. The module is able to pass an external
10 MHz reference signal.
The module provides RF level monitoring, i.e. the RF level of both input ports is
measured and is compared with (adjustable) RF threshold levels. This enables the
functionality to indicate an event (if the present input signal levels are below a
threshold level), and/or permits the DEV 1951 to control the switching
autonomously.
3.2.4 DEV 11-0011
DPST Sensing Switch Module; DC, 47…1006 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A Out In B
DEV 11-0011
The functionality of the module DEV 11-0011 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for a
different frequency range.

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 17
3.2.5 DEV 11-0024
DPST Relay Switch Module with Termination; DC…18 GHz; 50 Ohm, SMA (f)
Com
In A
In B
In BIn A Com
DEV 11-0024
The common port ("Com") of this high performance relay switch module can be
switched to one of two input/output ports ("In A", "In B"). The unused input/output
port is terminated internally.
3.2.6 DEV 11-0027
Relay Transfer Switch Module; DC…18 GHz; 50 Ohm, SMA (f)
In A
In B
Out A
Out B
DEV 11-0027
In A
Out A
Out B
In B
The port "In A" of the high performance relay switch module is connected either to
the port "Out A" or to the port "Out B". In the latter case, the port "In B" is connected
to the port "Out A", otherwise to the port "Out B".
Note that logically, this transfer switch module is handled like any other 2:1 (DPST)
switch, i.e. the representation in the Web Interface, via SNMP, and via all CPH
protocols corresponds to a 2:1 switch even though the signal routing is realized as
described above.
3.2.7 DEV 11-0028
DPST Switch Module; DC, 47…2500 MHz; 75 Ohm, F (f)
In A
In B
Out
In A Out In B
DEV 11-0028
The common port ("Out") can be switched to one of two input/output ports ("In A",
"In B"). The unused input/output port is terminated internally. The module is able to
pass an external 10 MHz reference signal.

User Manual DEV 1951
18 Copyright DEV Systemtechnik GmbH 2004-2017
3.2.8 DEV 11-0033
DPST Relay Switch Module; DC…18 GHz; 50 Ohm, SMA (f)
In A
In B
Com
In BIn A Com
DEV 11-0033
The common port ("Com") of this high performance relay switch module can be
switched to one of two input/output ports ("In A", "In B").
3.2.9 DEV 11-0050
DPST Switch Module; DC…2500 MHz; 50 Ohm, SMA (f)
In A
In B
Out
Out
In A In B
DEV 11-0050
The common port ("Out") can be switched to one of two input/output ports ("In A",
"In B"). The unused input/output port is terminated internally. Latching relays are
used for switching.
Note:
The DEV 11-0050 is the successor of the DEV 11-0007.
3.2.10 DEV 11-0057
Transfer Switch Module; DC…1006 MHz; 75 Ohm, BNC (f)
In A
In B
Out A
Out B
In A Out A In B Out B
DEV 11-0057
The port "In A" of the module is connected either to the port "Out A" or to the port
"Out B". In the latter case, the port "In B" is connected to the port "Out A", otherwise
to the port "Out B".
Note that logically, this transfer switch module is handled like any other 2:1 (DPST)
switch, i.e. the representation in the Web Interface, via SNMP, and via all CPH
protocols corresponds to a 2:1 switch even though the signal routing is realized as
described above.

User Manual DEV 1951
Copyright DEV Systemtechnik GmbH 2004-2017 19
3.2.11 DEV 11-0058
DPST Sensing Switch Module; DC, 950…2150 MHz; 50 Ohm, SMA (f)
Logic
Out
In A
In B
External
Controller
Out
In A In B
DEV 11-0058
The functionality of the module DEV 11-0058 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for 50 Ohm
with SMA connectors (instead of 75 Ohm with F connectors).
3.2.12 DEV 11-0107
DPST High Power Sensing Switch Module; DC, 950…2150 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A Out In B
DEV 11-0107
The functionality of the module DEV 11-0107 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for high
power signals.
3.2.13 DEV 11-0108
DPST High Power Sensing Switch Module; DC, 47…1006 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A Out In B
DEV 11-0108
The functionality of the module DEV 11-0108 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for a
different frequency range and for high power signals.

User Manual DEV 1951
20 Copyright DEV Systemtechnik GmbH 2004-2017
3.2.14 DEV 13-0169
1:4/4:1 Splitter/Combiner Module, Passive; 47…1006 MHz; 75 Ohm, F (f)
In
Out 1
Out 2
Out 3
Out 4
InOut 2Out 1 Out 3 Out 4
This module for splitting or combining RF signals can be applied to a DEV 1951
equipped with a single switch module.
3.2.15 DEV 13-0170
1:4/4:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 75 Ohm, F (f)
In
Out 1
Out 2
Out 3
Out 4
InOut 2Out 1 Out 3 Out 4
This module for splitting or combining RF signals can be applied to a DEV 1951
equipped with a single switch module.
3.2.16 DEV 13-0171
1:4/4:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 50 Ohm, SMA (f)
In
Out 1
Out 2
Out 3
Out 4
InOut 2Out 1 Out 3 Out 4
This module for splitting or combining RF signals can be applied to a DEV 1951
equipped with a single switch module.
3.2.17 DEV 13-0174
1:2/2:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 75 Ohm, F (f)
In Out 1
Out 2
Out 1 Out 2
DEV 13-0174
In
This module for splitting or combining RF signals can be applied to a DEV 1951
equipped with a single switch module.
