DeVilbiss Healthcare drive King Cobra User manual

King Cobra
Instructions for use

2
CONTENTS
1. INTRODUCTION 3
2. CONTACT INFORMATION 3
3. PRODUCT DESCRIPTION 4
3.1 Environment 4
3.2 Intended User Group 4
3.3 Intended Use 4
3.4 Indications 4
3.5 Product Overview 4
4. SAFETY 5
4.1 Warnings & Cautions 5
4.2 Risk Assessment 5
4.3 Contraindications 5
4.4 Scooter Loading 6
4.5 Training 6
4.6 General Warnings 7
5. TRANSPORT & STORAGE 9
6. SYMBOL DEFINITION 10
7. PARTS IDENTIFICATION 12
8. CHARGING & PREPARING FOR USE 13
8.1 Installation 13
8.2 Battery Charging 13
8.3 Checking Before Use 14
9. OPERATION OF THE KING COBRA SCOOTER 15
9.1 Operational Limits 15
9.2 Scooter Controls 15
9.3 Driving the Scooter 22
9.4 Steps, Kerbs & Fixed Obstacles 23
9.5 Inclines 24
9.6 Outdoor Operation & Inclement Weather Precautions 25
9.7 After Use Instructions 25
10. CLEANING 26
11. MAINTENANCE & SERVICING 27
11.1 General Guidelines 27
11.2 Fault Resolution 29
11.3 Repair 29
12. DISPOSAL OF PARTS 30
13. ELECTROMAGNETIC COMPATIBILITY EMC 31
14. SPECIFICATION 32
15. WARRANTY 33
16. MAINTENANCE SCHEDULE 34
17. NOTES 35

3
2. CONTACT INFORMATION
For assistance in setting up, using, maintaining your scooter, to report unexpected
operation or for any service, warranty, sales or customer service information regarding this
product, please contact Drive DeVilbiss Healthcare Ltd.
1. INTRODUCTION
Thank you for purchasing this product. These instructions for use should be read
carefully and understood before operating the scooter. Improper use or unfamiliarity
with the scooter may result in harm, injury or trac accidents. A maintenance schedule
is also included at the back. Keep this manual with the scooter, or in a safe place.
Contact Drive DeVilbiss Healthcare Ltd. or check our website for the latest version of
this document. Users with visual, reading or cognitive disabilities should seek advice
from a professional care provider for an appropriate format. If this is not viable, users
should contact Drive DeVilbiss Healthcare Ltd. If you have any questions concerning
the operation or maintenance of the scooter, contact Drive DeVilbiss Healthcare Ltd.
Any serious incident that has occurred in relation to the device should
be reported to the manufacturer and the MHRA or competent authority of your Member
State. Please quote the product serial code on all correspondence.
For Service & Support outside the United Kingdom, please contact the local distribution
company from where this equipment was purchased. Failure to do so may result in the
product warranty becoming void.
Wu's Tech Co. Ltd.
225 Yuanpeir Street, Hsinchu City, Taiwan, R.O.C.
Drive DeVilbiss Healthcare Ltd.
Sidhil Business Park, Holmfield, Halifax, West Yorkshire,
HX2 9TN, Great Britain
Y. Sung Handelsvertretung
Toulouser Allee 9, 40211 Duesseldorf, Germany
Drive DeVilbiss Sidhil Ltd.
4 Trench Road, Mallusk, Newtownabbey
BT36 4TY, Northern Ireland
UK Aplan Corporation Ltd.
47 Wandle Road, Croydon, Surrey, CR0 1DF, England, Great Britain

4
3. PRODUCT DESCRIPTION
3.1 Environment
The King Cobra Scooter can be used in both indoor and outdoor environments
where appropriate. The King Cobra Scooter can be used on flat, even path
surfaces, however the user should avoid grass, gravel and gradients greater
than 10°, if possible. Additional care should be taken to avoid inclement weather
and wet surfaces.
3.2 Intended User Group
The King Cobra Scooter is intended for a single user of weight up to 200kg
(31.5st). The intended user group for this device is any mobility restricted
individual that requires assistance with transport. The patient / occupant is the
only intended operator. Users must be both mentally and physically capable of
operating the device with minimal risk of injury to themselves and others.
3.3 Intended Use
The intended use of the scooter is to transport an end user with restricted
mobility, as defined in section 3.2.
The scooter is intended to support a single occupant. A risk assessment must
always be performed on the suitability of the user to the scooter.
3.4 Indications
To provide transport mobility to an end user with restricted mobility.
3.5 Product Overview
The King Cobra Scooter has been designed to provide a comfortable and
secure solution for users who have mobility restrictions. The product is a class
C scooter (under EN 12184:2014), class I medical device and class 3 invalid
carriage under The Use of Invalid Carriages on Highways Regulations 1988. For
specific guidance with outdoor use, see section 9.6.
This manual is composed from the product design and specifications at the time
of publication. As designs change, some illustrations and pictures in the manual
may not correspond to the scooter that you purchased. We reserve the right to
make design modifications.

5
4. SAFETY
4.1 Warnings & Cautions
Warnings in this user manual highlight potential hazards that if
disregarded could lead to injury or death.
Cautions in this user manual highlight potential hazards that if
disregarded could lead to equipment damage or failure.
4.2 Risk Assessment
Before using the scooter, a risk assessment must be performed by a
competent individual to ensure the safe use of the scooter on a user-by-user
basis. It is the responsibility of users and carers to determine that they are
both mentally and physically capable of operating the scooter with minimal
risk of injury to themselves or others.
The risk assessment should include, but not be limited to:
• Entrapment
• Falling out of the scooter
• Small adults (and children)
• Individuals who lack capacity to operate the scooter
• Users with visual, reading or cognitive disabilities
• Very active occupants
• Unauthorised people with access to the scooter
Caution
Warning
4.3 Contraindications
• The end user exceeds maximum weight capacity indicated in section 4.4
• The end user has postural support needs that are not addressed by the
King Cobra Scooter
• Inability to safely guide a power mobility device
Other contraindications may be relevant which are specific to an individual
and / or care environment.
