Devine CABT100 User manual

CABT100
cable tester
User Manual
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:
10-03- 018 RV
Revision date and author's initials: -

Introduction
Thank you for purchasing this Devine CABT100 cable tester. The Devine CABT100 can be
used to test most pro audio, video and data cables. By testing the connector pins on both
sides of the cable and seeing if there is a connection, you can be sure that your cable is
either in orking order or defective.
The CABT100 is equipped ith the most common connections. These include 3-pin XLR,
USB, Speakon and RCA. Any connector not available directly on the unit can still be tested,
by making special adapter leads.
The Devine CABT100 operates on t o 1.5V AA batteries, hich are not included in delivery.
Box contents:
1x Devine CABT100 cable tester
Battery precautions and warnings
The DI-50 DI box orks on standard AA batteries. Due to the hazardous substances of a
battery, precautions must be met in order to use this battery and the product in hich it is
installed to, safely.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only ith the same or equivalent type of battery.
Do not expose batteries to excessive heat such as sunshine, fire and the like.
Do not leave batteries in an extremely high-temperature environment, as this may cause
explosions or leakage of flammable liquids or gas.
Do not burn batteries, do not place batteries in a hot oven, and do not crush or cut batteries,
as this may cause explosions.
Do not subject batteries to extremely lo air pressure (high altitudes), as this may cause
explosions or leakage of flammable liquids or gas.
When equipment is not used for an extended period of time (e.g. a fe months), batteries
should be removed.
Instantly remove empty batteries from the equipment.
Do not store loose batteries or carry them in your pocket or purse. Contact ith metal
objects like coins and keys, etc. may cause them to leak, rupture or short-circuit.
Keep batteries out of reach of children.
Recycling:
Do not dispose of batteries in general household aste. Batteries can contain substances
that may harm the environment. If they are properly recycled, used batteries are a valuable
source of reusable materials. Contact your local government for information on battery
disposal.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:
10-03- 018 RV
Revision date and author's initials: -

afety instructions
Important: Please note that this cable tester is only suitable to test both connection ends of
a cable, to ensure there is a connection running.
If you ish to test cables, please ensure that both ends of the cable are removed from their
source. Do not leave cables connected, as these could for example be connected to an
active amplifier output connector.
Ignoring these instructions could lead to permanent damage to this device, as ell as your
audio install.
General safety information:
Everyone involved ith the installation, operation and maintenance of this device must:
- Have read the instructions in this user manual
- Be sure that neither the device nor the included accessories are damaged. Should the
device or the included accessories be damaged, please contact your dealer for more
information.
- Ensure that the device is in good orking condition and is safe to operate. Please follo
the advice and instructions as they are described in this user manual.
Damage caused by misuse and/or modifications made to the device are not covered by the
arranty.
This device does not contain any parts that need to be repaired or replaced by the user.
Should maintenance or repairs be necessary, they must be handled by a qualified
technician.
Important information regarding health and safety:
- Do not remove any labels or stickers from this device.
- Do not leave any cables lying around.
- The device should not be opened up, and any hard are or soft are that may be present
should not be modified.
- The device should only be used indoors; contact ith ater, rain and moisture should
al ays be avoided.
- Remove the device from any nearby flames or heat sources; do not place it near
flammable fluids, gasses or objects.
- Remove the battery of this device if it ill not be used for a longer period of time, if
maintenance is necessary, or if the device needs to be cleaned.
- Do not pull on the cable to remove a connector, as it can cause damage.
- Do not use any cables other than the ones described in this manual.
- In the event that the device is exposed to extreme temperature changes (e.g. transported
through a cold outdoor environment into a arm indoor environment), it should not be turned
on until it has reached room temperature. This is necessary to prevent moisture from
forming in the device, hich can cause electric shocks and possibly permanent damage.
Guidelines and operation of this device:
- This device is intended for indoor use by adults only.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:
10-03- 018 RV
Revision date and author's initials: -

- This device is not suitable for use by children, and should al ays be operated by an adult.
- This device may only be used in a suitable environment here no damage to the device
can occur. Do not use the device in moist or dusty environments such as:
- indoor s imming pools here chlorine is used
- beaches here there is sand and salt
- outdoors
- indoors in spaces here intense heat sources are present, or here it reaches
temperature levels that ould be considered uncomfortable for a person
- Avoid impact and collisions during use and transport. Do not transport the device hile it is
in use. Avoid using excessive force hen installing and operating the device.
- The user should become familiar ith the functions of this device before using it.
- Should the device not be used in the manner described in this user manual, damages or
even injuries could occur. Devine cannot be held responsible for any injuries or damages
that occur as a result of improper use of this product.
torage and transport:
- This device is designed for fixed use. During transport, it should be ell-protected,
preferably in the original packaging or other ise in a suitable case ith foam interior.
- This device is not designed for permanent (24/7) use. The expected lifespan of the device
ill not be affected by occasionally turning the device off. Disconnect the device or turn off
the po er hen it is not actively in use.
- If the device ill not be used for a longer period of time, it should be disconnected and
stored in a dust-free environment.
- Do not expose the device to extreme temperature differences.
Housing
- Inspect the device's housing frequently, and al ays just before use. Avoid operating the
device if there are large dents or cracks, or if scre s are missing. Do not use the device if
the housing is not in good condition.
Contact your dealer or a qualified technician if you are unsure about the state of the device.
- Check the device and the scre s for corrosion. Corrosion must not be present on this
device. Contact your dealer or a qualified technician if you find any corrosion on the scre s.
Every po er and signal connector should be securely mounted. Do not use the device if the
connectors are not secure.
Avoid dust and dirt build-up. Clean the device once a month by disconnecting it from the
po er supply and iping it do n ith a dry or slightly moist cloth. If the device is used
frequently, the cleaning intervals should increase.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:
10-03- 018 RV
Revision date and author's initials: -

ymbol explanation:
WEEE: Ensure that this device is disposed of properly. This product falls under
the WEEE (Waste Electrical and Electronic Equipment) directive. The
requirements of this directive apply to all manufacturers and producers of
electronic devices in the EU. Do not thro this product a ay ith regular
rubbish. Please contact your local authority for more information about ho to
recycle and dispose of these products in your region. By recycling this product
in the proper manner, e can ork together to ensure that e can continue to
enjoy these kinds of products and still protect the environment as much as
possible from pollution.
CE: The CE logo indicates that this product meets the European norms and
requirements to hich it must legally conform.
Only suitable for indoor use: this product as only designed for indoor use.
The maximum environmental temperature must not exceed 40 degrees Celsius
(104 degrees Fahrenheit).
Contact:
Devine pro audio and studio products
Verrijn Stuart eg 18
4462 GE Goes
The Netherlands
Please do not send any products to this correspondence address.
Should you wish to send in a product for repairs or for a refund, please contact your dealer
for an RMA request (Return Merchandise Authorisation).
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:
10-03- 018 RV
Revision date and author's initials: -

Technical specifications
- universal cable tester for pro audio, lighting, PRO A/V and musical instruments
- rugged metal housing ith handle/bracket
- orks on standard batteries (2x 1.5V AA, not included)
- supports most industry standard connectors
- connection LED indicators
- batteries can be replaced ithout using tools
- ON/OFF/Auto features
- Auto mode automatically runs through all pins
- ON mode makes manual pin checks possible by pressing the 2 buttons to skip back and
forth
- testing of other cables possible by making your o n adapters (requires some cable
assembly skills and tools)
Device testing functions:
- OFF: Device shut off
- ON: Manual control, by scrolling left and right you are able to test the connector pins of the
connector cable
- AUTO: Auto control, ill go through all connector pin combinations.
Green LED: Currently active and tested connector pin
Red LED: No connection on this pin available.
Connectors available on unit:
- 3p XLR male
- 3p XLR female
- 5p MIDI female (2x)
- RJ45 female (2x)
- S-Video (2x)
- USB A
- USB B
- 8p DIN (2x)
- 3.5 mm TRS mini jack (2x)
- mono RCA (2x)
- 4p Speakon male (2x)
- 6.35 mm TRS jack female (2x)
- 8p Speakon male (2x)
