DeWalt DCR006 User manual

DCR006
12V/20V Max* Wireless Bluetooth®Speaker
Haut-parleur BluetoothMD sans fil, 12V /20V max*
Altavoz inalámbrico de Bluetooth®de 12V/20V Máx*
INSTRUCTION MANUAL
GUIDE D’UTILISATION
MANUAL DE INSTRUCCIONES
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE
USAR EL PRODUCTO.
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-800-4-DEWALT • www.dewalt.com
Page dimensions: 8.5 x 5.5 inches

Page dimensions: 8.5 x 5.5 inches

1
Page dimensions: 8.5 x 5.5 inches
English
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
these symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal
injury which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR
ANY DEWALT TOOL, CALL US TOLL FREE AT: 1-800-4-DEWALT
(1-800-433-9258).
WARNING: To reduce the risk of injury, read the instruction
manual.
General Safety Warnings
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Unplug this apparatus during lightning storms or when unused
for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.

Page dimensions: 8.5 x 5.5 inches
2
English
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and speaker.
– Connect the equipment into an outlet on a circuit different from
that to which the speaker is connected.
– Consult the dealer or an experienced radio/TV technician for
help.
• Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically
radiated (e.i.r.p.) is not more than that necessary for successful
communication.
• To comply with FCC/IC RF exposure limits for general population/
uncontrolled exposure, the antenna(s) used for this transmitter
must be installed to provide a separation distance of at least
20cm from all persons and must not be co-located or operating
in conjunction with any other antenna or transmitter.
14. Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus
The lightning flash with arrow head within a triangle is intended
to tell the user that parts inside the product are a risk of electric
shock to persons.
The exclamation point within a triangle is intended to tell the user
that important operating and servicing instructions are in the
papers with the appliance.
Additional Safety Rules for Bluetooth®
Speaker
• DO NOT splash or immerse in water or other liquids.
• Please note that changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: The Bluetooth®word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DEWALT is under license. Other trademarks and
trade names are those of their respective owners.
• This Class B digital apparatus complies with Canadian ICES-003.
• This device complies with Part 15 of the FCC rules and Industry
Canada License-exempt RSS standard(s). Operation is subject to
the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential

Page dimensions: 8.5 x 5.5 inches
3
English
• Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery pack from the
charger may ignite the dust or fumes.
• NEVER force the battery pack into the charger. DO NOT
modify the battery pack in any way to fit into a non-
compatible charger as battery pack may rupture causing
serious personal injury. Consult the chart at the end of this
manual for compatibility of batteries and chargers.
• Charge the battery packs only in designated DEWALT chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations
where the temperature may reach or exceed 105°F (40°C)
(such as outside sheds or metal buildings in summer). For
best life store battery packs in a cool, dry location.
WARNING: Fire hazard. Never attempt to open the battery pack
for any reason. If the battery pack case is cracked or damaged, do
not insert into the charger. Do not crush, drop or damage the battery
pack. Do not use a battery pack or charger that has received a sharp
blow, been dropped, run over or damaged in any way (e.g., pierced
with a nail, hit with a hammer, stepped on). Damaged battery packs
should be returned to the service center for recycling.
WARNING: Fire hazard. Do not store or carry the battery
pack so that metal objects can contact exposed battery
terminals. For example, do not place the battery pack in aprons,
pockets, tool boxes, product kit boxes, drawers, etc., with loose
nails, screws, keys, etc. Transporting batteries can possibly
cause fires if the battery terminals inadvertently come in
contact with conductive materials such as keys, coins, hand
tools and the like. The US Department of Transportation Hazardous
Material Regulations (HMR) actually prohibit transporting batteries in
commerce or on airplanes (e.g., packed in suitcases and carry-on
luggage) UNLESS they are properly protected from short circuits. So
• The label on your tool may include the following symbols. The
nameplate label is located on bottom of unit. The symbols and
their definitions are as follows:
V................... volts A......................amperes
Hz................. hertz W.....................watts
min ............... minutes or AC..........alternating
or DC... direct current current
.................Class I Construction or AC/DC...alternating
.....................
(grounded) ........................or direct
................. Class II Construction current
(double insulated) no ....................no load
…/min .......... per minute speed
BPM .............beats per minute
n ......................rated
IPM............... impacts per minute ........................speed
RPM ............. revolutions per .....................earthing
minute terminal
sfpm ............. surface feet .....................safety alert
..................... per minute symbol
SPM ............. strokes per minute
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure to include the
catalog number and voltage. Consult the chart at the end of this
manual for compatibility of chargers and battery packs.
The battery pack is not fully charged out of the carton. Before using
the battery pack and charger, read the safety instructions below and
then follow charging procedures outlined.
READ ALL INSTRUCTIONS

Page dimensions: 8.5 x 5.5 inches
4
English
the collection of spent nickel cadmium, nickel metal hydride or lithium
ion batteries. Help protect our environment and conserve natural
resources by returning the spent nickel cadmium, nickel metal hydride
or lithium ion batteries to an authorized DEWALT service center or
to your local retailer for recycling. You may also contact your local
recycling center for information on where to drop off the spent
battery.
RBRC™ is a registered trademark of the Rechargeable Battery
Recycling Corporation.
Important Safety Instructions for All
Battery Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for battery chargers.
• Before using the charger, read all instructions and cautionary
markings on the charger, battery pack and product using the
battery pack.
WARNING: Shock hazard. Do not allow any liquid to get inside the
charger. Electric shock may result.
CAUTION: Burn hazard. To reduce the risk of injury, charge only
DEWALT rechargeable battery packs. Other types of batteries may
overheat and burst resulting in personal injury and property damage.
NOTICE: Under certain conditions, with the charger plugged into the
power supply, the charger can be shorted by foreign material. Foreign
materials of a conductive nature, such as, but not limited to, grinding
dust, metal chips, steel wool, aluminum foil or any buildup of metallic
particles should be kept away from the charger cavities. Always
unplug the charger from the power supply when there is no battery
pack in the cavity. Unplug the charger before attempting to clean.
when transporting individual battery packs, make sure that the battery
terminals are protected and well insulated from materials that could
contact them and cause a short circuit.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (Li-Ion)
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium ion battery packs are burned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If battery
liquid gets into the eye, rinse water over the open eye for 15
minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic
carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persist, seek medical
attention.
WARNING: Burn hazard. Battery liquid may be flammable if
exposed to spark or flame.
The RBRC™ Seal
The RBRC™ (Rechargeable Battery Recycling Corp-
oration) Seal on the nickel cadmium, nickel metal
hydride or lithium ion batteries (or battery packs)
indicate that the costs to recycle these batteries (or
battery packs) at the end of their useful life have already
been paid by DEWALT. In some areas, it is illegal to
place spent nickel cadmium, nickel metal hydride or lithium ion
batteries in the trash or municipal solid waste stream and the RBRC
program provides an environmentally conscious alternative.
RBRC™, in cooperation with DEWALT and other battery users, has
established programs in the United States and Canada to facilitate

Page dimensions: 8.5 x 5.5 inches
5
English
Minimum Gauge for Cord Sets
Ampere
Rating
Volts Total Length of Cord
in Feet (meters)
120 V 25
(7.6) 50 (15.2) 100 (30.5) 150 (45.7)
240 V 50
(15.2) 100 (30.5) 200 (61.0) 300 (91.4)
More
Than
Not
More
Than AWG
0 6 18 16 16 14
610 1816 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
• Do not place any object on top of the charger or place the
charger on a soft surface that might block the ventilation
slots and result in excessive internal heat. Place the charger
in a position away from any heat source. The charger is ventilated
through slots in the top and the bottom of the housing.
• Do not operate the charger with a damaged cord or plug.
• Do not operate the charger if it has received a sharp blow,
been dropped or otherwise damaged in any way. Take it to
an authorized service center.
• Do not disassemble the charger; take it to an authorized
service center when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution or fire.
• Disconnect the charger from the outlet before attempting
any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce this risk.
• NEVER attempt to connect 2 chargers together.
WARNING:
•DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger and
battery pack are specifically designed to work together.
• These chargers are not intended for any uses other than
charging DEWALT rechargeable batteries. Any other uses
may result in risk of fire, electric shock or electrocution.
• Do not expose the charger to rain or snow.
• Pull by the plug rather than the cord when disconnecting
the charger. This will reduce the risk of damage to the electric
plug and cord.
• Make sure that the cord is located so that it will not be
stepped on, tripped over or otherwise subjected to damage
or stress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk of
fire, electric shock or electrocution.
• When operating a charger outdoors, always provide a dry
location and use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
• An extension cord must have adequate wire size (AWG or
American Wire Gauge) for safety. The smaller the gauge number
of the wire, the greater the capacity of the cable, that is, 16 gauge
has more capacity than 18 gauge. An undersized cord will cause a
drop in line voltage resulting in loss of power and overheating. When
using more than one extension to make up the total length, be sure
each individual extension contains at least the minimum wire size.
The following table shows the correct size to use depending on
cord length and nameplate ampere rating. If in doubt, use the next
heavier gauge. The lower the gauge number, the heavier the cord.

Page dimensions: 8.5 x 5.5 inches
6
English
Indicator Light Operation
DCB101
PACK CHARGING
PACK CHARGED
x
HOT/COLD DELAY
PROBLEM PACK OR CHARGER
PROBLEM POWERLINE
DCB107, DCB112
PACK CHARGING
PACK CHARGED
HOT/COLD DELAY
Charge Indicators
This charger is designed to detect certain problems that can arise.
Problems are indicated by the red light flashing at a fast rate. If this
occurs, re-insert the battery pack into the charger. If the problem
persists, try a different battery pack to determine if the charger is
working properly. If the new pack charges correctly, then the original
pack is defective and should be returned to a service center or other
collection site for recycling. If the new battery pack elicits the same
trouble indication as the original, have the charger and the battery
pack tested at an authorized service center.
• The charger is designed to operate on standard 120V
household electrical power. Do not attempt to use it on any
other voltage. This does not apply to the vehicular charger.
Chargers
Your speaker uses a DEWALT charger. L
FIG. 1
Be sure to read all safety instructions
before using your charger. Consult the
chart at the end of this manual for
compatibility of chargers and battery
packs.
Charging Procedure
(Fig. 1)
1. Plug the charger into an appropriate
outlet before inserting the battery
pack.
2. Insert the battery pack (L) into the charger, as shown in Figure 1,
making sure the pack is fully seated in charger. The red (charging)
light will blink continuously, indicating that the charging process
has started.
3. The completion of charge will be indicated by the red light
remaining ON continuously. The pack is fully charged and may be
used at this time or left in the charger.

Page dimensions: 8.5 x 5.5 inches
7
English
operation, flashing the red light with two fast blinks followed by a
pause. This indicates the power source is out of limits.
Wall Mounting
DCB107, DCB112
These chargers are designed to be wall mountable or to sit upright on
a table or work surface.
If wall mounting, locate the charger within reach of an electrical outlet.
Mount the charger securely using drywall screws at least 1" (25.4 mm)
long, screwed into wood to an optimal depth leaving approximately
7/32" (5.5 mm) of the screw exposed.
Important Charging Notes
1. Longest life and best performance can be obtained if the battery
pack is charged when the air temperature is between 65 °F
and 75 °F (18°–24 °C). DO NOT charge the battery pack in
an air temperature below +40 °F (+4.5 °C), or above +105 °F
(+40.5°C). This is important and will prevent serious damage to
the battery pack.
2. The charger and battery pack may become warm to the touch
while charging. This is a normal condition, and does not indicate
a problem. To facilitate the cooling of the battery pack after use,
avoid placing the charger or battery pack in a warm environment
such as in a metal shed or an uninsulated trailer.
3. A cold battery pack will charge at about half the rate of a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery pack warms.
4. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp or other
appliance;
HOT/COLD DELAY
DCB101
This charger has a hot/cold delay feature: when the charger detects a
battery that is hot, it automatically starts a delay, suspending charging
until the battery has cooled. After the battery has cooled, the charger
automatically switches to the pack charging mode. This feature
ensures maximum battery life. The red light flashes long, then short
while in the hot/cold delay mode.
DCB107, DCB112
The DCB107 and DCB112 chargers have a hot/cold delay feature.
When the charger detects a battery that is hot, it automatically delays
charging until the battery has cooled. When the charger detects a
battery that is cold, it automatically delays charging until the battery
has warmed.
The red light will continue to blink, but a yellow indicator light will
be illuminated during this operation. Once the battery has cooled,
the yellow light will turn off and the charger will resume the charging
procedure.
LEAVING THE BATTERY PACK IN THE CHARGER
The charger and battery pack can be left connected with the charge
indicator showing Pack Charged.
WEAK BATTERY PACKS: Weak batteries will continue to function
but should not be expected to perform as much work.
FAULTY BATTERY PACKS: This charger will not charge a faulty
battery pack. The charger will indicate faulty battery pack by refusing
to light or by displaying problem pack or charger.
NOTE: This could also mean a problem with a charger.
PROBLEM POWER LINE (DCB101)
Some chargers have a Problem Powerline indicator. When the charger
is used with some portable power sources such as generators or
sources that convert DC to AC, the charger may temporarily suspend

Page dimensions: 8.5 x 5.5 inches
8
English
Storage Recommendations
1. The best storage place is one that is cool and dry, away from
direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool dry place out of the charger for optimal
results.
NOTE: Battery packs should not be stored completely depleted of
charge. The battery pack will need to be recharged before use.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (Fig. 2)
WARNING: Never modify the apparatus or any part of it. Damage
or personal injury could result.
A. Power button
B. LED indicator light
C. Bluetooth®pairing button
D. Pause button
E. Volume buttons +/-
F. AUX audio port
G. USB power port
H. AC power input
I. Battery port
J. Carry handle
INTENDED USE
This DEWALT Bluetooth®speaker is designed to play/stream audio
via a wireless Bluetooth®connection or wired connection to a mobile
phone or other audio device.
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
b. Check to see if receptacle is connected to a light switch which
turns power off when you turn out the lights;
c. Move the charger and battery pack to a location where the
surrounding air temperature is approximately 65 °F– 75 °F
(18°–24°C);
d. If charging problems persist, take the apparatus, battery pack
and charger to your local service center.
5. The battery pack should be recharged when it fails to produce
sufficient power on jobs which were easily done previously. DO
NOT CONTINUE to use under these conditions. Follow the
charging procedure. You may also charge a partially used pack
whenever you desire with no adverse effect on the battery pack.
6. Foreign materials of a conductive nature such as, but not limited
to, grinding dust, metal chips, steel wool, aluminum foil, or any
buildup of metallic particles should be kept away from charger
cavities. Always unplug the charger from the power supply when
there is no battery pack in the cavity. Unplug the charger before
attempting to clean.
7. Do not freeze or immerse the charger in water or any other liquid.
WARNING: Shock hazard. Don’t allow any liquid to get inside the
charger. Electric shock may result.
WARNING: Burn hazard. Do not submerge the battery pack in
any liquid or allow any liquid to enter the battery pack. Never attempt
to open the battery pack for any reason. If the plastic housing of the
battery pack breaks or cracks, return to a service center for recycling.

Page dimensions: 8.5 x 5.5 inches
9
English
OPERATION
WARNING: To reduce the risk of serious personal injury, turn
apparatus off and unplug or remove the battery pack before
making any adjustments or removing/installing attachments or
accessories.
The speaker can operate off
of DC power (a battery pack)
or with an AC power adapter
plug. To power the speaker
using the AC adapter, plug the
adapter into the appropriate
outlet and connect it to the
speaker via the AC power
input (Fig.3, H). Battery pack
will not charge when AC
adapter is plugged in.
Installing and Removing the Battery Pack
(Fig. 4)
NOTE: For best results, make sure your
battery pack is fully charged.
To install the battery pack (L) into the
battery port (I), align the battery pack
with the rails on the sides of the port and
slide the battery in until the battery pack
is firmly seated. Be sure that it does not
disengage.
To remove the battery pack from the
apparatus, press the release button and
firmly pull the battery pack out of the port.
Insert it into the charger as described in
the charger section of this manual.
FIG. 3
H
FIG. 4
I
L
FIG. 2 A
B
CD
E
F
GH
I
J
DO NOT let children come into contact with the apparatus.
Supervision is required when inexperienced operators use this
apparatus.

Page dimensions: 8.5 x 5.5 inches
10
English
OR
OU
O
FIG. 6
F
OR
POWERING THE SPEAKER ON AND OFF (FIG. 7)
Pressing the power button (A) will turn the speaker on or off. When
turned on, the LED indicator (B) will indicate the speaker's status.
Upon initial use, the speaker will require pairing. To pair speaker to
a Bluetooth®device refer to Pairing Speaker with a Bluetooth®
Audio Device.
FUEL GAUGE BATTERY PACKS (FIG. 5)
Some DEWALT battery packs include a
fuel gauge which consists of three green
LED lights that indicate the level of charge
remaining in the battery pack.
To actuate the fuel gauge, press and hold
the fuel gauge button (K). A combination
of the three green LED lights will illuminate
designating the level of charge left. When
the level of charge in the battery is below
the usable limit, the fuel gauge will not
illuminate and the battery will need to be
recharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate apparatus functionality and is
subject to variation based on product components, temperature and
end-user application.
For more information regarding fuel gauge battery packs, please
call 1-800-4-DEWALT (1-800-433-9258) or visit our website
www.dewalt.com.
Functionality (Fig. 6, 7)
Audio can be played through the speaker via a wireless Bluetooth®
connection to a compatible Bluetooth®device or by connecting audio
device or mobile phone using a 1/8' (3.5 mm) audio cable to the
audio port (F).
K
FIG. 5

Page dimensions: 8.5 x 5.5 inches
11
English
2. Turn speaker on by pressing the power button (A). The LED (B)
will light solid for 4 seconds to indicate the apparatus powered on
successfully and then go into a half second interval blink pattern.
3. Press the Bluetooth®pairing button (C). The LED indicator light
blinks rapidly indicating the speaker is in pairing mode and is
discoverable by your Bluetooth® device.
4. Confirm pairing on your device. (Please consult your device's
instruction manual for specific pairing instructions.)
NOTE: If pairing is not confimed within 2 minutes, the LED will
stop flashing and the speaker will return to half second interval
blink pattern.
5. Once pairing is successful the LED indicator (B) will turn solid
and the speaker will emit a short tone. The speaker will now play
music from your device.
CONNECTING A PREVIOUSLY PAIRED BLUETOOTH®AUDIO
DEVICE (FIG. 1, 7)
If a Bluetooth®device has been previously paired to the speaker
it should automatically reconnect when speaker is powered on.
After 4 seconds the speaker will go into connecting mode. This is
indicated by the LED (B) blinking steady. Once the previously paired
Bluetooth®device is recognized and connected, the LED will go
solid. If connection does not occur and you are unable to stream
music please follow the instructions for Pairing Speaker with a
Bluetooth®Audio Device.
ADJUSTING THE SPEAKER VOLUME (FIG. 7)
The speaker volume can be decreased or increased by using the
corresponding volume buttons (E). Pressing the "VOL +" button
increases the volume. Pressing the "VOL-" decreases the volume.
LED SPEAKER STATUS INDICATOR
LED indicator Status/Mode
Steady blinking (half
second interval)
Speaker is unpaired or in connecting
mode.
Rapid Blinking Speaker is in pairing mode and
discoverable by your device.
Solid light Speaker is connected with a device.
No light Speaker has timed out and/or is off.
FIG. 7
C
EE
D
B
A
PAIRING SPEAKER WITH A BLUETOOTH®AUDIO DEVICE
(FIG.6, 7)
1. Place the speaker and the Bluetooth®audio source within 3.3'
(1m) of each other.

Page dimensions: 8.5 x 5.5 inches
12
English
PHONE CALL AUDIO THROUGH BLUETOOTH SPEAKER
Depending on your device it may be possible to have the audio
from a phone call play through the Bluetooth®Speaker. This
is dependent on the device and the way the device's settings
are configured. Please refer to the device's owner’s manual for
capability and settings information.
2. Due to the characteristics of Bluetooth®technology, the sound
heard through the Bluetooth®speaker is slightly delayed from the
sound played on your audio device or mobile phone while talking
on a phone call or streaming music.
MAINTENANCE
WARNING: To reduce the risk of serious personal injury, turn
apparatus off and unplug or remove the battery pack before
making any adjustments or removing/installing attachments or
accessories.
Cleaning
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the apparatus. These chemicals
may weaken the plastic materials used in these parts. Use a cloth
dampened only with water and mild soap. Never let any liquid get
inside the apparatus; never immerse any part of the apparatus into
a liquid.
Accessories
WARNING: Since accessories, other than those offered by
DEWALT, have not been tested with this product, use of such
accessories with this tool could be hazardous. To reduce the risk of
injury, only DEWALT recommended accessories should be used with
this product.
The pause button (D) can silence the speaker at any volume by being
pressed once. Pressing the pause button again will unpause the
speaker. The speaker will emit a tone when the maximum or minimum
volume is reached.
TIMEOUT FUNCTIONALITY (FIG. 1)
To conserve battery life the speaker is designed to power off
automatically after an hour of inactivity. This inactivity could be due to
the device being unpaired for an hour or in the case of the Bluetooth®
connection being broken for the same period of time. If the speaker
powers off due to inactivity of any kind refer to Connecting a
Previously Paired Bluetooth®Audio Device.
NOTE: Optimum Bluetooth®streaming range is roughly 30 ft
(9 m) (line of sight) to the speaker but distances up to 100 feet
(30 m) are possible. Physical obstacles, other wireless devices or
electromagnetic devices may affect the connection quality.
If Bluetooth®connection is lost due to exceeding time of separation,
exceeding the optimum distance, obstacles or otherwise, reconnecting
your device with the speaker may be necessary.
CHARGING A CELL PHONE OR AUDIO DEVICE VIA USB
(FIG.1)
Your audio device or mobile phone can be charged using the USB
power port (G) on the speaker. This charging is possible when unit is
on, running off of AC plug power or the battery pack.
Important Bluetooth®Speaker Notes
1. When receiving a phone call on a mobile phone which is
streaming to the Bluetooth®speaker, music playback stops. After
phone call is finished, music resumes playing.

Page dimensions: 8.5 x 5.5 inches
13
English
information, visit www.dewalt.com or call 1-800-4-DEWALT (1-800-
433-9258). This warranty does not apply to accessories or damage
caused where repairs have been made or attempted by others. This
warranty gives you specific legal rights and you may have other rights
which vary in certain states or provinces.
In addition to the warranty, DEWALT tools are covered by our:
1 YEAR FREE SERVICE
DEWALT will maintain the tool and replace worn parts caused by
normal use, for free, any time during the first year after purchase.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of your
DEWALT Power Tool, Laser, or Nailer for any reason, you can return
it within 90 days from the date of purchase with a receipt for a full
refund – no questions asked.
LATIN AMERICA: This warranty does not apply to products sold
in Latin America. For products sold in Latin America, see country
specific warranty information contained in the packaging, call the local
company or see website for warranty information.
FREE WARNING LABEL REPLACEMENT: If your warning labels
become illegible or are missing, call 1-800-4-DEWALT (1-800-433-
9258) for a free replacement.
Recommended accessories for use with your tool are available at
extra cost from your local dealer or authorized service center. If you
need assistance in locating any accessory, please contact DEWALT
Industrial Tool Co., 701 East Joppa Road, Towson, MD 21286,
call 1-800-4-DEWALT (1-800-433-9258) or visit our website: www.
dewalt.com.
Repairs
To assure product SAFETY and RELIABILITY, repairs, maintenance
and adjustment (including brush inspection and replacement) should
be performed by a DEWALT factory service center, a DEWALT
authorized service center or other qualified service personnel. Always
use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRANTY SERVICE: Registering your product will help you
obtain more efficient warranty service in case there is a problem
with your product.
• CONFIRMATION OF OWNERSHIP: In case of an insurance
loss, such as fire, flood or theft, your registration of ownership will
serve as your proof of purchase.
• FOR YOUR SAFETY: Registering your product will allow us to
contact you in the unlikely event a safety notification is required
under the Federal Consumer Safety Act.
Register online at www.dewalt.com/register.
Three Year Limited Warranty
DEWALT will repair, without charge, any defects due to faulty materials
or workmanship for three years from the date of purchase. This
warranty does not cover part failure due to normal wear or tool
abuse. For further detail of warranty coverage and warranty repair

Page dimensions: 8.5 x 5.5 inches
14
Français
Définitions: lignes directrices en
matière de sécurité
Les définitions ci-dessous décrivent le niveau de danger pour
chaque mot-indicateur employé. Lire le mode d’emploi et porter
une attention particulière à ces symboles.
DANGER: indique une situation dangereuse imminente qui,
si elle n’est pas évitée, entraînera la mort ou des blessures
graves.
AVERTISSEMENT : indique une situation potentiellement
dangereuse qui, si elle n’est pas évitée, pourrait entraîner la
mort ou des blessures graves.
ATTENTION : indique une situation potentiellement
dangereuse qui, si elle n’est pas évitée, pourrait entraîner des
blessures légères ou modérées.
AVIS : indique une pratique ne posant aucun risque de
dommages corporels mais qui par contre, si rien n’est fait pour
l’éviter, pourrait poser des risques de dommages matériels.
POUR TOUTE QUESTION OU REMARQUE AU SUJET DE CET
OUTIL OU DE TOUT AUTRE OUTIL DEWALT, COMPOSEZ LE
NUMÉRO SANS FRAIS : 1-800-4-DEWALT (1-800-433-9258).
AVERTISSEMENT : afin de réduire le risque de blessures, lire
le mode d’emploi de l’outil.
Consignes générales de sécurité
AVERTISSEMENT! lire tous les avertissements de
sécurité et toutes les directives. Le non-respect des
avertissements et des directives pourrait se solder par un
choc électrique, un incendie et/ou une blessure grave.
CONSERVER TOUS LES AVERTISSEMENTS
ET TOUTES LES DIRECTIVES POUR UN
USAGE ULTÉRIEUR
Consignes de sécurité importantes
1. Lire ces directives.
2. Conserver ces directives.
3. Respecter tous les avertissements.
4. Suivre toutes les directives.
5. Ne pas utiliser cet appareil à proximité d’eau.
6. N’utiliser qu’un chiffon sec pour le nettoyage.
7. Ne bloquer aucun orifice d’aération. Installer conformément aux
directives du fabricant.
8. Ne pas installer à proximité de sources de chaleur, tels
radiateurs, registres de chaleur, cuisinières ou tout autre appareil
(y compris les amplificateurs).
9. Ne pas annihiler le but sécuritaire de la fiche polarisée ou mise à
la terre. Une fiche polarisée possède deux lames dont l’une est
plus large que l’autre. Une fiche mise à la terre possède deux
lames et une troisième broche mise à la terre. La large lame ou
la troisième broche ont été installée pour assurer votre sécurité.
Si la fiche fournie de rentre pas dans la prise utilisée, consulter
un électricien pour faire changer cette prise désuète.
10. Protéger le cordon d’alimentation contre tout piétinement ou
constriction particulièrement au niveau des fiches, des prises, et
au point de sortie des appareils.
11. Utiliser exclusivement des accessoires recommandés par le
fabricant.
12. Débrancher l’appareil pendant les orages, ou lorsqu’il restera
inutilisé pendant une période prolongée.

Page dimensions: 8.5 x 5.5 inches
15
Français
• Cet appareil est conforme au paragraphe15 du règlement du FCC
et au(x) norme(s) RSS exempté(s) de licence d’Industrie Canada.
Son utilisation est sujette aux deux conditions suivantes:
1) Ce dispositif ne doit pas causer d’interférences nuisibles;
2) Ce dispositif doit accepter toute interférence reçue, y compris
toute interférence pouvant causer un fonctionnement
indésirable.
REMARQUE : cet équipement a été testé et jugé conforme
aux limites propres aux appareils numériques de Classe B,
conformément au Paragraphe 15 du règlement du FCC.
Ces limites sont destinées à offrir une protection raisonnable
contre les interférences nuisibles d’une installation résidentielle.
Cet équipement produit, utilise et peut émaner des ondes
radiofréquences et, s’il n’est pas installé et utilisé conformément
aux directives du fabricant, peut causer des interférences nuisibles
aux communications radio. En fonction des installations réalisées,
il n’est cependant pas garanti que toute interférence soit exclue.
Si cet équipement cause des interférences nuisibles à toute
réception radio ou télévision, ce qui peut être déterminé en
allumant et éteignant l’équipement, l’utilisateur est encouragé à
tenter de corriger ces interférences en prenant l’une ou plusieurs
des mesures suivantes:
– Réorienter l’antenne de réception ou en changer l’emplacement;
– Augmenter la distance entre l’équipement et le récepteur;
– Brancher l’équipement à une prise située sur un circuit différent
de celui sur lequel le récepteur est connecté;
– Contacter le détaillant ou consulter un technicien radio/télé
qualifié.
• Conformément aux réglementions d’Industrie Canada, cet
émetteur radio ne peut fonctionner qu’avec une antenne dont
le type et le gain maximal (ou d’une valeur moindre) sont
homologués par Industrie Canada pour cet émetteur. Pour réduire
13. Confier l’entretien de l’appareil aux soins d’un personnel
qualifié. Faire systématiquement entretenir l’appareil en cas de
dommages quelconques, tels que: le cordon électrique, ou une
fiche, a été endommagé, un liquide ou un objet a pénétré dans
l’appareil, l’appareil a été exposé à la pluie ou à l’humidité, il ne
fonctionne pas normalement ou il a fait une chute.
14. Protéger l’appareil de tout liquide, ou éclaboussure, et ne
disposer aucun objet rempli d’un liquide, (un vase par exemple)
sur l’appareil.
Le symbole de l’éclair avec une flèche au sein d’un triangle a
pour but de prévenir l’utilisateur que certaines pièces au sein du
produit posent des risques de chocs électriques pour l’individu.
Le point d’exclamation au sein d’un triangle a pour but de
prévenir l’utilisateur que des instructions importantes d’utilisation
et d’entretien sont incluses dans les documents propres à
l’appareil.
Règles de sécurité additionnelles propres
aux haut-parleurs BluetoothMD
• NE PAS éclabousser l’appareil ou l’immerger dans l’eau ou dans
tout autre liquide.
• Tout changement ou toute modification à l’appareil qui ne serait
pas expressément homologué par le tiers responsable de sa
conformité pourra annuler les droits de l’utilisateur à employer cet
équipement.
REMARQUE : le terme et les logos BluetoothMD sont des
marques déposées appartenant à BluetoothMD, SIG, Inc. et toute
utilisation de ces marques par DEWALT est autorisée par licence.
Toute autre marque de commerce et appellation commerciale
reste la propriété de leurs propriétaires respectifs.
• Cet appareil numérique de Classe B est conforme aux normes
canadiennes ICES-003.

Page dimensions: 8.5 x 5.5 inches
16
Français
Consignes importantes de sécurité
propres à tous les blocs-piles
Pour commander un bloc-piles de rechange, s’assurer d’inclure son
numéro de catalogue et sa tension. Consulter le tableau en dernière
page de ce manuel pour connaître les compatibilités entre chargeurs
et blocs-piles.
Le bloc-piles n’est pas totalement chargé d’usine. Avant d’utiliser le
bloc-piles et le chargeur, lire les consignes de sécurité ci-dessous.
Puis suivre la procédure de charge indiquée.
LIRE TOUTES LES CONSIGNES
• Ne pas recharger ou utiliser un bloc-piles en milieu
déflagrant, en présence, par exemple, de poussières, gaz
ou liquides inflammables. Le fait d’insérer ou retirer un bloc-
piles de son chargeur pourrait causer l’inflammation de poussières
ou d’émanations.
• NE JAMAIS forcer l’insertion d’un bloc-piles dans un
chargeur. NE modifier un bloc-piles d’AUCUNE façon
pour le faire rentrer dans un chargeur incompatible, car
il pourrait se briser et causer des dommages corporels
graves. Consulter le tableau en dernière page de ce manuel pour
connaître les compatibilités entre chargeurs et blocs-piles.
• Recharger les blocs-piles exclusivement dans des chargeurs
DEWALT.
• NE PAS éclabousser le bloc-piles ou l’immerger dans l’eau ou
dans tout autre liquide.
• Ne pas entreposer ou utiliser l’appareil et le bloc-piles en
présence de températures ambiantes pouvant excéder
40°C (105°F) (comme dans des hangars ou des bâtiments
métalliques l’été). Pour préserver leur durée de vie, entreposer
les blocs-piles dans un endroit frais et sec.
toute interférence radio potentielle pouvant affecter les autres
utilisateurs, le type d’antenne et ses gains devraient être choisis
de façon à ce que la puissance isotrope rayonnée équivalente ne
soit pas supérieure aux limites permettant la communication.
• Pour respecter les limites d’exposition requises par le FCC/la
RF IC pour la population générale/exposition incontrôlée, la(les)
antenne(s) utilisée(s) avec cet émetteur doit/doivent être installée(s)
de façon à préserver une distance d’au moins 20 cm avec les
individus présents et ne peut/peuvent être située(s) ou utilisée(s)
conjointement avec toute autre antenne ou émetteur.
• L’étiquette apposée sur votre outil peut inclure les symboles
suivants. La plaque signalétique se trouve sur la partie inférieure de
l'appareil. Les symboles et leur définition sont indiqués ci-après:
V................... volts A....................... ampères
Hz................. hertz W...................... watts
min ............... minutes ou AC.......... courant
ou DC... courant continu ......................... alternatif
................. classe I ou AC/DC... courant
..................... fabrication ......................... alternatif
(mis à la terre) ou continu
................. fabrication no..................... vitesse à vide
classe II n ....................... vitesse
(double isolation) ........................ nominale
…/min .......... par minute ..................... borne de terre
IPM............... impacts par ...................... symbole
minute ......................... d’avertissement
BPM ............. battements par r/min ................. tours par
minute minute
sfpm ............. pieds linéaires SPM (FPM)....... fréquence par
par minute (plpm) minute

Page dimensions: 8.5 x 5.5 inches
17
Français
blocs-piles au lithium-ion, des vapeurs et matières toxiques sont
dégagées.
• En cas de contact du liquide de la pile avec la peau, rincer
immédiatement au savon doux et à l’eau. En cas de contact
oculaire, rincer l’œil ouvert à l’eau claire une quinzaine de minutes
ou jusqu’à ce que l’irritation cesse. Si des soins médicaux
s’avéraient nécessaires, noter que l’électrolyte de la pile est
composé d’un mélange de carbonates organiques liquides et de
sels de lithium.
• Le contenu des cellules d’une pile ouverte peut causer une
irritation respiratoire. En cas d’inhalation, exposer l’individu à
l’air libre. Si les symptômes persistent, consulter un médecin.
AVERTISSEMENT: risques de brûlure. Le liquide de la pile peut
s’enflammer s’il est exposé à des étincelles ou à une flamme.
Le sceau SRPRCMC
Le sceau SRPRCMC (Société de recyclage des piles
rechargeables au Canada)apposé sur une pile au
nickel-cadmium, à hydrure métallique de nickel ou au
lithium-ion (ou un bloc-piles) indique que les coûts de
recyclage de ces derniers en fin d’utilisation ont déjà
été réglés par DEWALT. Dans certaines régions, la mise
au rebut ou aux ordures municipales des piles au
nickel-cadmium, à l’hydrure métallique de nickel ou au lithium-ion, est
illégale ; le programme de SRPRC constitue donc une solution
pratique et écologique.
La SRPRCMC, en collaboration avec DEWALT et d’autres utilisateurs
de piles, a mis sur pied des programmes aux États-Unis et au
Canada pour faciliter la collecte des piles au nickel-cadmium, à
l’hydrure métallique de nickel ou au lithium-ion usagées. Aidez-nous
à protéger l’environnement et à conserver nos ressources naturelles
en renvoyant les piles au nickel-cadmium, à l’hydrure métallique de
AVERTISSEMENT: risques d’incendie. Ne jamais tenter d’ouvrir
le bloc-piles pour quelque raison que ce soit. Si le boîtier du bloc-
piles est fissuré ou endommagé, ne pas l’insérer dans un chargeur. Ne
pas écraser, laisser tomber, ou endommager les blocs-piles. Ne pas
utiliser un bloc-piles ou un chargeur qui a reçu un choc violent, ou si
l’appareil est tombé, a été écrasé ou endommagé de quelque façon
que ce soit (p. ex. percé par un clou, frappé d’un coup de marteau,
piétiné). Les blocs-piles endommagés doivent être renvoyés à un
centre de réparation pour y être recyclés.
AVERTISSEMENT : risques d’incendie. Au moment de
ranger ou transporter le bloc-piles, s’assurer qu’aucun objet
métallique n’entre en contact avec les bornes à découvert du
bloc-piles. Par exemple, éviter de placer un bloc-piles dans un tablier,
une poche, une boîte à outils ou un tiroir, etc. contenant des objets
tels que des clous, des vis, des clés, etc. Le fait de transporter des
bloc-piles comporte des risques d’incendie, car les bornes des
piles pourraient entrer, par inadvertance, en contact avec des
objets conducteurs, tels que: clés, pièces de monnaie, outils
ou autres. La réglementation sur les produits dangereux (Hazardous
Material Regulations) du département américain des transports
interdit, en fait, le transport des piles pour le commerce ou dans
les avions (ex: dans les bagages enregistrés ou à main) À MOINS
qu’elles ne soient correctement protégées contre tout court-circuit.
Aussi lors du transport individuel de blocs-piles, s’assurer que leurs
bornes sont bien protégées et isolées de tout matériau pouvant entrer
en contact avec elles et provoquer un court-circuit.
CONSIGNES DE SÉCURITÉ PROPRES AUX PILES AU
LITHIUM-ION (Li-Ion)
• Ne pas incinérer le bloc-piles même s’il est sévèrement
endommagé ou complètement usagé, car il pourrait
exploser et causer un incendie. Pendant l’incinération des

Page dimensions: 8.5 x 5.5 inches
18
Français
AVERTISSEMENT:
•NE PAS tenter de charger de bloc-piles avec des chargeurs
autres que ceux décrits dans ce manuel. Le chargeur et son
bloc-piles ont été conçus tout spécialement pour fonctionner
ensemble.
• Ces chargeurs n’ont pas été conçus pour une utilisation
autre que recharger les blocs-piles rechargeables DEWALT.
Toute autre utilisation comporte des risques d’incendie, de chocs
électriques ou d’électrocution.
• Protéger le chargeur de la pluie ou de la neige.
• Tirer sur la fiche plutôt que sur le cordon pour débrancher
le chargeur. Cela permet de réduire les risques d’endommager
la fiche ou le cordon d’alimentation.
• S’assurer que le cordon est protégé de manière à ce que
personne ne marche ni ne trébuche dessus, ou à ce qu’il ne
soit ni endommagé ni soumis à aucune tension.
• N’utiliser une rallonge qu’en cas de nécessité absolue.
L’utilisation d’une rallonge inadéquate comporte des risques
d’incendie, de chocs électriques ou d’électrocution.
• Pour utiliser un chargeur à l’extérieur, le placer dans un
endroit sec et utiliser une rallonge conçue pour l’extérieur.
L’utilisation d’une rallonge conçue pour l’extérieur réduit les
risques de chocs électriques.
• Pour la sécurité de l’utilisateur, utiliser une rallonge de
calibre adéquat (AWG, American Wire Gauge [calibrage
américain normalisé des fils électriques]). Plus le calibre est
petit, et plus sa capacité est grande. Un calibre16, par exemple,
a une capacité supérieure à un calibre18. L’usage d’une rallonge
de calibre insuffisant causera une chute de tension qui entraînera
perte de puissance et surchauffe. Si plus d’une rallonge est utilisée
pour obtenir une certaine longueur, s’assurer que chaque rallonge
nickel ou au lithium-ion usagées à un centre de réparation autorisé
DEWALT ou chez votre détaillant afin qu’elles y soient recyclées. On
peut en outre se renseigner auprès d’un centre de recyclage local
pour connaître d’autres sites les acceptant.
SRPRCMC est une marque déposée de la Société de recyclage des
piles rechargeables au Canada.
Directives de sécurité importantes
propres à tous les chargeurs de piles
CONSERVER CES INSTRUCTIONS : ce manuel contient des
directives de sécurité et d’utilisation importantes propres aux
chargeurs de piles.
• Avant d’utiliser le chargeur, lire toute consigne et tout avertissement
apposés sur le chargeur, le bloc-piles et le produit utilisant le bloc-
piles.
AVERTISSEMENT: risques de chocs électriques. Ne laisser aucun
liquide pénétrer dans le chargeur, des chocs électriques pourraient en
résulter.
ATTENTION : risques de brûlure. Pour réduire tout risque de
dommages corporels, ne recharger que des blocs-piles rechargeables
DEWALT. Tout autre type de piles pourrait exploser et causer des
dommages corporels et matériels.
AVIS: sous certaines conditions, lorsque le chargeur est connecté au
bloc d’alimentation, des matériaux étrangers pourraient court-circuiter
le chargeur. Les corps étrangers conducteurs tels que (mais pas limité
à) poussières de rectification, débris métalliques, laine d’acier, feuilles
d’aluminium, ou toute accumulation de particules métalliques doivent
être maintenus à distance des orifices du chargeur. Débrancher
systématiquement le chargeur lorsque le bloc-piles n’y est pas inséré.
Débrancher systématiquement le chargeur avant tout entretien.
