DFI CMS100 User manual

CMS100
Mini-ITX
User’s Manual
© April 11, 2023 DFI Inc.

2
User's Manual | CMS100
Copyright
This publication contains information that is protected by copyright. No part of it may be repro-
duced in any form or by any means or used to make any transformation/adaptation without the
prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions or
changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2023. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class A
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3
User's Manual | CMS100
Table of Contents
Chapter 1 - Introduction................................................................................................................6
Specifications.........................................................................................................................6
Dimensions.............................................................................................................................9
Block Diagram ........................................................................................................................9
Chapter 2 - Hardware Installations............................................................................................10
Overview................................................................................................................................10
Top View.........................................................................................................................10
Bottom View...................................................................................................................10
Jumper Settings...................................................................................................................11
Panel Power Selection (DPJP603)...............................................................................11
Clear CMOS (JP1) .........................................................................................................11
Backlight Voltage Select (DPJP601)............................................................................12
Inverter Power Voltage Select (DPJP602)...................................................................12
AT / ATX mode select (JP26).......................................................................................13
USB Power Select (DPJP604).......................................................................................13
Pin Assignment....................................................................................................................14
Front Audio (AUJ2).......................................................................................................14
USB2_11/12 (UBJ7).......................................................................................................14
USB2_7/8 (UBJ8)...........................................................................................................15
CPU Fan (J10)................................................................................................................15
System Fan (J9)...........................................................................................................16
Battery (J5) ....................................................................................................................16
Backlight Control (DPJ601) .........................................................................................17
DIO Power (J12)............................................................................................................17
DIO (J13)........................................................................................................................18
Front Panel (J11)...........................................................................................................18
LPC Debugger (J14)......................................................................................................19
eDP (CN23)....................................................................................................................20
Expansion Slots....................................................................................................................21
Installing the M.2 Module.............................................................................................21
Installing the SO-DIMM Module ...................................................................................22
Chapter 3 - BIOS Settings...........................................................................................................23
Overview ...............................................................................................................................23
Main.......................................................................................................................................24
Advanced .............................................................................................................................24
RC ACPI Settings...........................................................................................................25
CPU Configuration.........................................................................................................25
Power & Performance...................................................................................................26
PCH-FW Configuration..................................................................................................26
Trusted Computing........................................................................................................27
PTN3460 Configuration ................................................................................................27
NCT6126D Super IO Configuration..............................................................................28
NCT6126D HW Monitor ................................................................................................29
NCT6126D HW Monitor ►Smart FAN Function .................................................29
Serial Port Console Redirection ...................................................................................30
Serial Port Console Redirection ►Console Redirection Settings........................30
USB Configuration ........................................................................................................31
Network Stack Configuration........................................................................................31
CSM Configuration........................................................................................................32
USB Power Control........................................................................................................32
Chipset..................................................................................................................................33
Graphics Configuration .................................................................................................33
PEG Port Configuration.................................................................................................34
PCH-IO Configuration....................................................................................................34
PCH-IO Configuration►PCI Express Configuration.............................................35
PCH-IO Configuration►SATA And RST Configuration.........................................36
PCH-IO Configuration►HD Audio Configuration.................................................36
Security .................................................................................................................................37
Secure Boot....................................................................................................................37
Boot.......................................................................................................................................38
Save & Exit............................................................................................................................38
Updating the BIOS................................................................................................................39
Notice: BIOS SPI ROM..........................................................................................................39

4
User's Manual | CMS100
About this Manual
This manual can be retrieved from the website.
The manual is subject to change and update without notice, and may be based on editions that
do not resemble your actual products. Please visit our website or contact our sales representa-
tives for the latest editions.
Warranty
1. Warranty does not cover damages or failures that arises from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and
product specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper
installation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether
in or out of warranty. It must be returned to the purchase point, factory or authorized
service agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequential damages to
the product that has been modified or altered.
About this Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• 1 CMS100 motherboard
• 1 Serial ATA data cable w/lock (Length: 500mm)
• 1 COM port cable (Length: 250mm, 1 x COM port)
• 1 I/O shield
- w/ icon DVI/DP/DP
- w/ icon DVI/DP/HDMI
Note: The items are subject to change in the developing stage.Note: The items are subject to change in the developing stage.
The product and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.

5
User's Manual | CMS100
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you
are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, con-
tacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or
connectors by their ends.
Safety Precautions
• Use the correct DC / AC input voltage range.
• Unplug the power cord before removing the system chassis cover for installation or
servicing. After installation or servicing, cover the system chassis before plugging in
the power cord.
• There is danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent specifications of batteries recommend by
the manufacturer.
• Dispose of used batteries according to local ordinance.
• Keep this system away from humid environments.
• Make sure the system is placed or mounted correctly and stably to prevent the chance
of dropping or falling may cause damage.
• The openings on the system shall not be blocked and shall be kept in distance from
other objects to make sure of proper air ventilation to protect the system from over-
heating.
• Dress the cables, especially the power cord, so they will not be stepped on, in contact
with high temperature surfaces, or cause any tripping hazards.
• Do not place anything on top of the power cord. Use a power cord that has been ap-
proved for use with the system and is compliant with the voltage and current ranges
required by the system’s electrical specifications.
• If the system is to be unused or stored for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
• If one of the following occurs, consult a service personnel:
- The power cord or plug is damaged.
- Liquid has penetrated the system.
- The system has been exposed to moisture.
- The system is not working properly.
- The system is physically damaged.
• The unit uses a three-wire ground cable which is equipped with a third pin to ground
the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet
does not support this kind of plug, contact your electrician to replace the outlet.
• Disconnect the system from the electricity outlet before cleaning. Use a damp cloth
for cleaning the surface. Do not use liquid or spray detergents for cleaning.
• Before connecting, make sure that the power supply voltage is correct. The device is
connected to a power outlet which should be grounded connection.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other
components. Perform the upgrade instruction procedures described at an ESD
workstation only. If such a station is not available, you can provide some ESD pro-
tection by wearing an antistatic wrist strap and attaching it to a metal part of the
system chassis. If a wrist strap is unavailable, establish and maintain contact with
the system chassis throughout any procedures requiring ESD protection.
The system may burn fingers while running.
Wait for 30 minutes to handle electronic parts after power off.

6
Chapter 1
INTRODUCTION
User's Manual | CMS100
Chapter 1 - Introduction
X Specifications
SYSTEM
Processor
10th Gen Intel®Xeon/Core™/Pentium/Celeron Processors, LGA 1200 Socket, TDP up to 125W
Intel®Xeon W-1290E Processor (Core 10; Max speed 4.8GHz; TDP 95W) (ECC memory supported) (W480E only)*
Intel®Xeon W-1270E Processor (Core 8; Max speed 4.8GHz; TDP 80W) (ECC memory supported)(W480E only)*
Intel®Xeon W-1250E Processor (Core 6; Max speed 4.7GHz; TDP 80W) (ECC memory supported)(W480E only)
Intel®Xeon W-1290TE Processor (Core 10; Max speed 4.5GHz; TDP 35W)(W480E only)
Intel®Xeon W-1270TE Processor (Core 8; Max speed 4.4GHz; TDP 35W)(W480E only)
Intel®Xeon W-1250TE Processor (Core 6; Max speed 3.8GHz; TDP 35W)(W480E only)
Intel®Core i9-10900E Processor (Core 10; Max speed 4.7GHz; TDP 65W)
Intel®Core i9-10900TE Processor (Core 10; Max speed 4.5GHz; TDP 35W)
Intel®Core i7-10700E Processor (Core 8; Max speed 4.5GHz; TDP 65W)
Intel®Core i7-10700TE Processor (Core 8; Max speed 4.4GHz; TDP 35W)
Intel®Core i5-10500E Processor (Core 6; Max speed 4.2GHz; TDP 65W)
Intel®Core i5-10500TE Processor (Core 6; Max speed 3.7GHz; TDP 35W)
Intel®Core i3-10100E Processor (Core 4; Max speed 3.8GHz; TDP 65W)
Intel®Core i3-10100TE Processor (Core 4; Max speed 3.6GHz; TDP 35W)
Intel®Pentium G6400E Processor (Core 2; Max speed 3.8GHz; TDP 65W)
Intel®Pentium G6400TE Processor (Core 2; Max speed 3.2GHz; TDP 35W)
Intel®Celeron G5900E Processor (Core 2; Max speed 3.2GHz; TDP 65W)
Intel®Celeron G5900TE Processor (Core 2; Max speed 3.0GHz; TDP 35W)
*Note: 5-year life cycle support based on Intel IOTG roadmap.
Chipset Intel®W480E/Q470E/H420E Chipset
Memory Two 260-pin SODIMM up to 64GB
Dual Channel DDR4 2933MHz (ECC supported by W480E only)
BIOS AMI SPI 256Mbit
GRAPHICS Controller Intel®HD Gen 9 Graphics
Feature OpenGL 4.5, DirectX 12, OpenCL 2.1 HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9
HW Encode: AVC/H.264, MPEG2, JPEG, HEVC/H265, VP8, VP9
Display
1 x DP++
DP++: Resolution up to 4096x2304 @60Hz
1 x HDMI 1.4b/DP++
HDMI 1.4b: Resolution up to 4096x2160 @30Hz
1 x LVDS/eDP
LVDS: resolution up to 1920x1200 @ 60Hz
eDP: resolution up to 4096x2160 @ 60Hz
1 x DVI-I (DVI-D signal)
DVI-I: resolution up to 1920x1200 @ 60Hz
Quad Displays DP++ + DP++ + DVI-I + LVDS/eDP or DP++ + HDMI + DVI-I + LVDS/eDP

7
Chapter 1
INTRODUCTION
User's Manual | CMS100
EXPANSION
Interface
1 x PCIe x16 (Gen 3)
1 x M.2 2230 E Key (PCIe x1/USB 2.0)
1 x M.2 2280 M Key (PCIe x4 Gen3 or SATA, H420E supports PCIe x4 signal only)
1 x M.2 2242/3042 B Key (W480E/Q470E: PCIe x1 Gen3 or SATA, USB 3.2 Gen1/USB 2.0)
1 x Nano SIM slot
AUDIO Audio Codec Realtek ALC888
ETHERNET
Controller
W480E/Q470E:
1 x Intel®I225LM PCIe(10/100/1000/2.5G speeds)
1 x Intel®I219LM PHY(10/100/1000 speeds), support vPro/AMT
H420E:
1 x Intel®I225LM PCIe(10/100/1000/2.5G speeds)
1 x Intel®I219V PHY(10/100/1000 speeds)
REAR I/0
Ethernet 1 x 2.5GHz (RJ-45)
2 x GbE (RJ-45)
Serial 2 x RS232/422/485 (DB-9)
USB W480E/Q470E: 6 x USB 3.2 Gen2 (dual type-A connector)
H420E: 5 x USB 3.2 Gen1 (dual type-A connector)
Display 1 x DP++ 1 x HDMI 1.4b or 1 x DP++
1 x DVI-I
INTERNAL I/O
Audio 1 x Front Audio (2.0mm pitch)
USB W480E/Q470E: 4 x USB 2.0 (2.0mm pitch)
H420E: 2 x USB 2.0 (2.0mm pitch)
Display 1 x LVDS header
1 x eDP connector
SATA 2 x SATA 3.0 (up to 6Gb/s)
RAID 0/1/5/10 (w/ M.2 Key-M/B slot + 2 SATA Conn., W480E/Q470E only)
DIO 1 x 8-bit DIO
1 x DIO Power
LPC 1 x LPC
WATCHDOG
TIMER Output & Interval System Reset, Programmable via Software from 1 to 255 Seconds
SECURITY TPM fTPM(Default); dTPM(Opt.)

8
Chapter 1
INTRODUCTION
User's Manual | CMS100
POWER
Type ATX
Connector 8-pin ATX 12V power
24-pin ATX power
Consumption
Idle: Intel Xeon W-1290E 95W: 12V @ 4.6A (55.2W)
Max: Intel Xeon W-1290E 95W: 12V @ 11.6A (139.2W)
Idle: Intel i9-10900K 125W: 12V @ 2A (24W)
Max: Intel i9-10900K 125W: 12V @ 22A (264W)
RTC Battery CR2032 Coin Cell
OS SUPPORT Microsoft Windows 10 IoT Enterprise 64-bit
Linux Linux
MECHANISM
Dimensions Mini-ITX Form Factor , 170mm (6.7") x 170mm (6.7")
Height PCB: 1.6mm Top Side: 31.51 mm
Bottom Side: 4.4 mm
ENVIRONMENT
Temperature Operating: -5 to 65°C
Storage: -40 to 85°C
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MTBF CS100-Q470: 591,713 hrs @ 25°C; 357,627 hrs @ 45°C ; 234,022 hrs @ 60°C
Calculation model: Telcordia Issue 4
Environment: GB, GC – Ground Benign, Controlled
CERTIFICATION Certification CE, FCC, RoHS

9
Chapter 1
INTRODUCTION
User's Manual | CMS100
X Dimensions X Block Diagram

10
Chapter 2
HARDWARE INSTALLATION
User's Manual | CMS100
Chapter 2 - Hardware Installations
X Overview
Top View Bottom View
DVI / HDMI (DP option)
Front
Audio 1
2
9
PCIE1
M.2-M
1
Display
Port
COM1/
COM2
LAN1/
USB1/2
LAN2/
USB3/4
USB5/6
1
2
9
1
2
9
USB2_7/8
USB2_11/12
1CPU FAN
SO_DIMM1
SO_DIMM2
1
Backlight Control
SYS FAN
1
LVDS
Backlight
Voltage Select
Inverter Power
Voltage Select
USB Power
Select
AT / ATX Mode Select
Panel Power
Selection
1
1
1
1
1
1
1
11
2
6
1
211
12
Front Panel
M.2-E
M.2-B
SPI
DIO Power
DIO
Battery
Clear
CMOS
1
1 40
12
1314
eDP
SIM1
LPC Debugger
