DFI E586-ICP User manual

E586-ICP
E586-IPE
System Board
User’s Manual
-D23540520-

vCopyright1994,byDFIInc.
All rights reserved.
No part of this document may be copied or reproduced
in any form or by any means without the prior written
consent of DFI, Inc.
DFI, Inc. makes no warranties with respect to this
documentation and disclaims any implied warranties of
merchantability, quality, or fitness for any particular
purpose. The information in this document is subject to
change without notice. DFI, Inc. reserves the right to
make revisions to this publication and to make changes
to any and/or all parts of its content, at any time,
without obligation to notify any person or entity of such
changes. Further, DFI, Inc. assumes no responsibility
for any errors that may appear in this document.
DFI is a registered trademark, and E586-ICP/E586-IPE
is a trademark of Diamond Flower, Inc. All other
product names mentioned are trademarks or registered
trademarks of their respective companies.

vFCC Statement on Class B
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential
installation. This equipment generates, uses, and can
radiate radio frequency energy and if not installed and
used in accordance with the instruction manual may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
the receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio TV
technician for help.
Notice:
1. The changes or modification not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
2. Shielded interface cables must be used in order to
comply with the emission limits.

v Table of Contentsv
Introduction .................................................................................
Features and Specifications .................................................
Package Checklist .................................................................
Installation Overview .................................................................
Preparing the Area ................................................................
Handling the System Board ..................................................
Tips in Handling the System Board ...............................
Hardware Installation.............................................................
Memory Installation .........................................................
Installing the Modules ..............................................
Board Configuration ........................................................
Jumper Settings .......................................................
Cache Configuration ................................................
Jumper Settings for Cache Memory .................
CPU Installation ..............................................................
Jumper Settings for CPU ........................................
Installing Upgrade CPUs ........................................
Installing the System Board ..................................................
Installing the PS/2 Mouse Port .............................................
Initial Setup Program .................................................................
Award BIOS CMOS Setup Utilities ......................................
Standard CMOS Setup ..................................................
BIOS Features Setup .....................................................
Chipset Features Setup .................................................
PCI Slot Configuration ...................................................
Load BIOS Defaults .......................................................
Load Setup Defaults ......................................................
Password Setting ...........................................................
IDE HDD Auto Detection ...............................................
Save & Exit Setup ..........................................................
Exit Without Saving ........................................................
1-1
1-2
1-2
2-1
2-1
2-2
2-2
2-2
2-2
2-6
2-7
2-9
2-13
2-15
2-16
2-17
2-18
2-22
2-24
3-1
3-2
3-2
3-5
3-7
3-8
3-9
3-9
3-10
3-11
3-11
3-12

EISA Configuration Utility .......................................................
Troubleshooting Checklist ......................................................
Appendix A:Types of Modules ..............................................
Appendix B:System Error Report .........................................
Appendix C:Memory & I/O Maps ...........................................
Appendix D:EISA I/O Pin Assignments ................................
Appendix E:PCI I/O Pin Assignments ..................................
Appendix F:Connector Pin Assignments ............................
Appendix G:Award BIOS Hard Disk Table ...........................
4-1
5-1
A-1
B-1
C-1
D-1
E-1
F-1
G-1

This page left intentionally blank.

Read Me First
The E586-ICP/E586-IPE system board requires the installation
of the ECU (EISA Configuration Utility), found on the
provided EISA Configuration Utility diskette, for proper
operation of this system board.
The ECU configures the EISA devices and maintains system
parameters by storing them in the Extended CMOS Memory, so
the BIOS can initialize the system and expansion boards
inserted in the EISA slots once you power up your system.
The Extended CMOS Memory is equipped with an internal
battery that needs to be constantly charged. In a small number
of cases, the internal battery may have drained and the
information stored in the Extended CMOS Memory lost during
shipment. If this happens, you will get the message "EISA
CMOS Inoperational" when you power up your system.
Simply run the ECU software, bundled with the system board,
to reconfigure the system. Save the configuration and reboot
your system. Refer to the EISA Configuration Utility section on
page 4-1 for more detailed information.

EISA/PCISystemBoard
vIntroduction
The E586-ICP/E586-IPE system board offers several
advanced features integrated into the system board. It is
designed based on the new PCI (Peripheral Component
Interconnect) local bus and EISA (Extended Industry
Standard Architecture) standards.
The E586-ICP/E586-IPE supports 273-pin Zero Inser-
tion Force socket for PentiumTM processors running at
60MHz or 66MHz bus speed. It also supports an op-
tional Flash EPROM. Flash EPROM is a memory chip
for the storage of BIOS which can be erased in bulk or
modified using a software utility.
The E586-ICP/E586-IPE comes with an EISA Configu-
ration Utility (ECU) that must be installed and run to
configure the board and the EISA expansion boards that
will be inserted in the EISA expansion slots.
The E586-ICP/E586-IPE system board is equipped with
four EISA and four PCI local bus slots. One EISA slot
and one PCI slot are shared, meaning you may use only
one or the other of these three slots. Therefore, in
accord with the PCI standard, seven slots are useable.
The E586-ICP/E586-IPE is also equipped with one
mini-DIN-6 connector for the PS/2 mouse and an op-
tional IDE disk interface, only if installed with the
Symphony SL82C101P chip.
The E586-ICP/E586-IPE can be configured to twenty-
two different sizes from 2MB to 128MB using 256Kx36,
512Kx36, 1Mx36, 2Mx36, 4Mx36 and 8Mx36 HSIM
modules.
1-1 uIntroduction

E586-ICP/E586-IPE
•Microprocessor
PentiumTM Processor
•Chipset
Intel 82430 PCI: system
Symphony SL82C101P: PCI IDE (optional)
•BIOS
Award system BIOS
•Cache Memory
256K or 512K Burst (sync) SRAM for 3-1-1-1
Level 2 cache access (E586-ICP)
256K or 512K Async SRAM for 3-2-2-2 Level 2
cache access (E586-IPE)
Supports direct map write-back or write-through
cache subsystem
Integrated cache tag RAM
•Memory Onboard
2MB to 128MB
•DRAM Type
256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and
8Mx36 SIMM
Supports single and/or double density SIMMs
Supports DRAM access time of 60ns or 70ns
Supports page mode
•ZIF Socket
273-pin ZIF socket (Intel Socket 4)
Features and Specifications
Introduction u1-2

EISA/PCISystemBoard
•Slots
Three 32-bit PCI slots
One shared - PCI/EISA slot
Three 32-bit EISA slots
•Connectors
A mini-DIN-6 connector for the PS/2 mouse
One IDE disk interface (optional; only if installed
with the Symphony SL82C101P chip)
•Tooling Holes
Baby AT form factor
•PCB
4 layers
Package Checklist
The E586-ICP/E586-IPE package contains the following
items:
•The E586-ICP/E586-IPE system board
•The E586-ICP/E586-IPE user’s manual
•One EISA Configuration Utility diskette
•One DB-25S hole cover holding the PS/2 mouse port
•One 40-pin IDE hard disk cable (optional)
If any of these items is missing or damaged, please
contact your dealer or sales representative for assistance.
1-3 uIntroduction

E586-ICP/E586-IPE
vInstallation Overview
This chapter summarizes the steps in installing the
E586-ICP/E586-IPE system board into your system unit.
It also includes a description of the area in which you
must work and directions for memory installation.
Before installing the system board, obtain the memory
you plan to install.
Preparing the Area
Before unpacking the system board, make sure the
location you have selected is relatively free of dust and
static. Excessive exposure to dust, static electricity,
direct sunlight, excessive humidity, extreme cold and
water can damage the operational capabilities of your
system board. Avoid soft surfaces such as beds and
carpeted floors which can hinder air circulation. These
areas also attract static electricity which can damage
some circuits on your system board.
Be sure that the power source has a properly grounded,
three-pronged socket. It is essential that the power
connection be properly grounded for correct functioning
of your system board. For further protection, we recom-
mend that you use a surge protection socket. This will
protect the system board from damage that may result
from a power surge on the line.
Move items that generate magnetic fields away from
your system board, since magnetic fields can also dam-
age your system board. Once you have selected the ideal
location, unpack the E586-ICP/E586-IPE system board
carefully.
InstallationOverview u2-1

EISA/PCISystemBoard
Handling the System Board
It is quite easy to inadvertently damage your system
board even before installing it to your system unit.
Static electrical discharge can damage computer compo-
nents without causing any signs of physical damage. You
must take extra care in handling the system board to
ensure that no static build-up is present.
Tips in Handling the System Board
1) To prevent electrostatic build-up, leave the board in
its anti-static bag until you are ready to install it.
2) Wear an antistatic wriststrap.
3) Do all preparation work on a static-free surface with
components facing up.
4) Hold the system board by its edges only. Be careful
not to touch any of the components, contacts or
connections, especially gold contacts on the board.
5) Avoid touching the pins or contacts on all modules
and connectors. Hold modules and connectors by
their ends.
Hardware Installation
Memory Installation
The E586-ICP/E586-IPE system board can support 2MB
to 128MB of memory using HSIMMs. HSIMM is an
acronym for High Density Single In-line Memory Mod-
ule.
2-2 uInstallation Overview

E586-ICP/E586-IPE
An HSIMM consists of several RAM chips soldered
onto a small circuit board. An HSIMM connects to the
system board via a 72-pin card-edge connector.
The HSIMM sockets are divided into two banks on the
system board. The E586-ICP/E586-IPE system board
uses 256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and
8Mx36 HSIM modules.
You will need 2 to 4 pieces of HSIM modules, depend-
ing on the amount of memory you intend to install.
Your system board can be configured with 2MB, 4MB,
6MB, 8MB, 10MB, 12MB, 16MB, 18MB, 20MB,
24MB, 32MB, 34MB, 36MB, 40MB, 48MB, 64MB,
66MB, 68MB, 72MB, 80MB, 96MB or 128MB of
onboard memory.
To install the HSIM modules, first populate Bank 1 and
then Bank 2. Failure to do so will cause the system
board to work improperly.
The following table summarizes the bank locations and
modules needed for the corresponding memory sizes.
Each bank consists of 2 HSIMM sockets.
MemorySizeBank1Bank2
2MB256Kx36-
4MB256Kx36256Kx36
4MB512Kx36-
6MB256Kx36512Kx36
6MB512Kx36256Kx36
8MB512Kx36512Kx36
8MB1Mx36-
InstallationOverview u2-3

EISA/PCISystemBoard
MemorySizeBank1Bank2
10MB256Kx361Mx36
10MB1Mx36256Kx36
12MB512Kx361Mx36
12MB1Mx36512Kx36
16MB1Mx361Mx36
16MB2Mx36-
18MB256Kx362Mx36
18MB2Mx36256Kx36
20MB512Kx362Mx36
20MB2Mx36512Kx36
24MB1Mx362Mx36
24MB2Mx361Mx36
32MB2Mx362Mx36
32MB4Mx36-
34MB256Kx364Mx36
34MB4Mx36256Kx36
36MB512Kx364Mx36
36MB4Mx36512Kx36
40MB1Mx364Mx36
40MB4Mx361Mx36
48MB2Mx364Mx36
48MB4Mx362Mx36
64MB4Mx364Mx36
64MB8Mx36-
66MB256Kx368Mx36
66MB8Mx36256Kx36
68MB512Kx368Mx36
68MB8Mx36512Kx36
72MB1Mx368Mx36
72MB8Mx361Mx36
80MB2Mx368Mx36
80MB8Mx362Mx36
96MB4Mx368Mx36
96MB8Mx364Mx36
128MB8Mx368Mx36
2-4 uInstallation Overview

E586-ICP/E586-IPE
82433LX82433LX
82434
82375
82374
SL82C101PBank 1
ZIF
Socket
Bank 2
Locations of the HSIMM Sockets on the System Board
Pin1 ofthe HSIMM socket
InstallationOverview u2-5

EISA/PCISystemBoard
Installing the Modules
HSIMMs simply snap into a socket on the system board.
Pin 1 of the HSIMM must correspond with Pin 1 of the
socket.
1. Position the HSIM module above the HSIMM
socket with the chips of the module facing the center
of the system board.
2. Seat the module at an angle into the bank. Make
sure it is completely seated. Tilt the module upright
until it locks in place in the socket.
2-6 uInstallation Overview

E586-ICP/E586-IPE
Board Configuration
The E586-ICP/E586-IPE is designed with jumpers and
connectors onboard. Make sure that the jumpers are set
correctly before installing the system board into your
system unit.
Locations of Jumpers and Connectors
on the E586-ICP System Board
J3
J7
JP1
JP2
82433LX
JP6
82433LX
82434
JP10
PL1PL2J2JP22JP23
JP24
JP12
JP15
JP16JP19-JP21
JP27JP25
JP26
JP28
JP7
JP11
JP14
82375
82374
JP3
JP5
J1
SL82C101P
JP8JP18
J4
J6
ZIF
Socket
PCI Slot - Slave
PCI Slot - Master/Slave
PCI Slot - Master/Slave
PCI Slot - Master/Slave
EISA Slot
EISA Slot
EISA Slot
EISA Slot
InstallationOverview u2-7
JP13
Flash
EPROM

EISA/PCISystemBoard
J3
J7
JP1
JP2
82433LX
JP6
82433LX
82434
JP10
PL1PL2J2JP22JP23
JP26
JP28
JP7
JP11
JP14
82375
82374
JP3
JP5
J1
SL82C101P
JP8
J4
J6
JP70JP12
JP15
JP16
JP17
JP18
ZIF
Socket
PCI Slot - Slave
PCI Slot - Master/Slave
PCI Slot - Master/Slave
PCI Slot - Master/Slave
EISA Slot
EISA Slot
EISA Slot
EISA Slot
Locations of Jumpers and Connectors
on the E586-IPE System Board
2-8 uInstallation Overview
JP13Flash
EPROM

E586-ICP/E586-IPE
Jumper Settings
Jumper JP1
PCI Edge-Triggered Interrupt
Jumper JP1 is used to select the PCI edge-triggered
interrupt of the E586-ICP/E586-IPE system board. Set
JP1 according to the table shown below.
IRQ
IRQ15
IRQ14
IRQ11
IRQ10
IRQ9
Int. A
Int. A
Int. B
Int. C
Int. D
1-2On
3-4On
5-6On
7-8On
9-10On
IRQ
10
IRQ
11
IRQ
14
IRQ
15
A A B C
IRQ
9
D
InstallationOverview u2-9
INT
JP1
2
1
10
9

EISA/PCISystemBoard
Jumpers JP3 and JP5
Built-in IDE
The E586-ICP/E586-IPE system board is equipped with
a built-in IDE disk interface, only if installed with the
Symphony SL82C101P chip. Set JP5 to On to enable the
built-in IDE. Set JP3 to On to disable the built-in IDE.
JP3JP5
2-10 uInstallation Overview
On:IDEDisabled
(Default)On:IDEEnabled
Jumpers JP6 and JP8
Parity Enable/Disable
Set Jumpers JP6 and JP8 to On to enable the SRAM’s
parity bit.
On:ParityEnabled
(Default)Off:ParityDisabled
