DGSHAPE DE-3 User manual

For the latest information regarding this machine (including manuals), see the DGSHAPE Corporation
website (http://www.dgshape.com/). R1-181210
Setup Guide
This guide describes the setup tasks and important conditions about the installation
site that must be met in order to enable use of this machine.
Read this rst

• To ensure safe use with a full understanding of this machine's performance, please be sure to read through this
manual completely.
• Store this manual in a safe place where it can be referred to when needed.
• Reproduction, citation, or translation, in whole or in part, of this manual is prohibited without the express written
consent of DGSHAPE Corporation.
• The contents of this operation manual and the specications of this product are subject to change without notice.
• DGSHAPE Corporation assumes no responsibility for any damage that may occur through use of this product,
regardless of any failure to perform on the part of this product or of any errors in this document. Damage includes
but is not limited to damage caused by the specications or performance of the product, damage caused by non-
use of the product, and damage caused by deliverables obtained through use of this product. Such damage can
be either direct or indirect.
Applicable EMC Standards: EN 61326-1 (Class A), EN 55011 (Class A, Group 1)
This product is a Class A device.
It may generate radio wave interference when used in a residential environment. In this situation,
the user may be required to implement appropriate countermeasures.
This product is a Group 1 device.
Radio frequency energies in the form of electromagnetic radiation, induction, and/or electrostatic
bonding are not used nor deliberately emitted when processing material or during examination/analysis.
This system (including the housing and safety device) is a Class 1 laser product.
Complies with IEC 60825-1 Edition 2.0 (2007-03).
Complies with FDA performance standards for laser products except for deviations pursuant to Laser
notice No.50 dated June 24, 2007.
Caution - Use of controls or adjustments or performance of procedures other than those specied herein
may result in radiation exposure.

For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
STATEMENT
Responsible Party : Roland DGA Corporation
Address : 15363 Barranca Parkway Irvine, CA 92618 U.S.A.
Telephone : [phone]
Type of Equipment : Engraving Machine
Model Name : DE-3
NOTE:
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful in-
terference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at
his own expense.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
FCC CAUTION
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
Use only I/O cables that have been designed and manufactured
specically for this device.
NOTICE Grounding Instructions
In the event of a malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk of
electric shock. This tool is equipped with an electric cord having
an equipment-grounding conductor and a grounding plug. The
plug must be plugged into a matching outlet that is properly
installed and grounded in accordance with all local codes and
ordinances.
Do not modify the plug provided - if it will not t the outlet,
have the proper outlet installed by a qualied electrician.
Improper connection of the equipment-grounding conductor
can result in a risk of electric shock. The conductor with
insulation having an outer surface that is green with or with-
out yellow stripes is the equipment-grounding conductor. If
repair or replacement of the electric cord or plug is necessary,
do not connect the equipment-grounding conductor to a live
terminal.
Check with qualied electrician or service personnel if the
grounding instructions are not completely understood, or if in
doubt as to whether the tool is properly grounded.
Use only 3-wire extension cords that have 3-prong grounding
plugs and 3-pole receptacles that accept the tool’s plug.
Repair or replace damaged or worn out cord immediately.
Operating Instructions
KEEP GUARDS IN PLACE and in working order.
MAKE WORKSHOP KID PROOF with padlocks, master
switches, or by removing starker keys.
DON’T OVERREACH. Keep proper footing and balance at all
times.
DISCONNECT TOOLS before servicing; when changing ac-
cessories,such as blades, bits, cutters, and the like.
REDUCE THE RISK OF UNINTENTIONAL STARTING.
Make sure switch is in off position before plugging in.
NEVER STAND ON TOOL. Serious injury could occur if the
tool is tipped or if the cutting tool is unintentionally contacted.
CHECK DAMAGED PARTS. Before further use of the tool,
a guard or other part that is damaged should be carefully
checked to determine that it will operate properly and perform
its intended function - check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting, and any
other conditions that may affect its operation. A guard or other
part that is damaged should be properly repaired or replaced.
NEVER LEAVE TOOL RUNNING UNATTENDED. TURN
POWER OFF. Don’t leave tool until it comes to a complete
stop.
USE POWER SUPPLY CORD WHICH IS ATTACHED
WITH PRODUCTS. Do not use other power supply cord.
For Canada
CAN ICES-3 (A)/NMB-3(A)
For EU Countries
Manufacturer:
DGSHAPE CORPORATION
1-6-4 Shinmiyakoda, Kita-ku, Hamamatsu-shi, Shizuoka-ken, 431-2103 JAPAN
The importer in the EU:
Roland DG Europe Holdings B.V.
Prof. J.H. Bavincklaan 2, 1183 AT, Amstelveen, The Netherlands
WARNING
Operation of this equipment in a residential
environment could cause radio interference.
For EU Countries
For California
WARNING : This product can expose you to chem-
icals including lead, which is known to the State of
California to cause cancer and birth defects or other
reproductive harm. For more information go to www.
P65Warnings.ca.gov.
1

Contents
Company names and product names are trademarks or registered trademarks of their respective holders.
Copyright © 2018 DGSHAPE Corporation http://www.dgshape.com/
Contents..............................................................................................................................................................................................1
To Ensure Safe Use...........................................................................................................................................................................2
Pour utiliser en toute sécurité .....................................................................................................................................................8
Important Notes on Handling and Use................................................................................................................................. 14
About the User's Manuals.......................................................................................................................................................... 15
Documentation Included with the Machine...................................................................................................... 15
Checking the Included Items.................................................................................................................................................... 16
Installation....................................................................................................................................................................................... 17
Placement and Installation....................................................................................................................................... 17
Installation Environment........................................................................................................................................... 17
Removing the Retainers ............................................................................................................................................ 18
Connecting the Power Cord..................................................................................................................................... 20
Selecting the Language Used for Text on the Display Screen..................................................................... 21
Connecting to the Computer (USB Connection)............................................................................................................... 23
Step 1: Installing the Software ................................................................................................................................ 23
Step 2: Connecting the USB Cable......................................................................................................................... 26
Step 3: Switching the Power On ............................................................................................................................. 26
Connecting to the Computer (LAN Connection)............................................................................................................... 27
Step 1: Determining the Network Addresses .................................................................................................... 27
Step 2: Setting the Computer's Network............................................................................................................. 28
Step 3: Installing the Software ................................................................................................................................ 30
Step 4: Conguring the Network Settings for This Machine ........................................................................ 33
Step 5: Connecting the LAN Cable ........................................................................................................................ 35
Before Starting Operations........................................................................................................................................................ 37
Performing Spindle Run-in (Warm-up)................................................................................................................ 37
2

Improper handling or operation of this machine may result in injury or damage to property. Points which must be
observed to prevent such injury or damage are described as follows.
About WARNING and CAUTION Notices
WARNING
Used for instructions intended to alert the user to the risk of death or severe
injury should the unit be used improperly.
CAUTION
Used for instructions intended to alert the user to the risk of injury or
material damage should the unit be used improperly.
*Material damage refers to damage or other adverse e󰀨ects caused with respect
to the home and all its furnishings, as well as to domestic animals or pets.
About the Symbols
The symbol alerts the user to important instructions or warnings.
The specic meaning of the symbol is determined by the design contained within
the symbol.
The symbol at left means "danger of electrical shock."
The symbol alerts the user to items that must never be carried out (are
forbidden).
The specic meaning of the symbol is determined by the design contained within
the symbol.
The symbol at left means the unit must never be disassembled.
The symbol alerts the user to things that must be carried out.
The specic meaning of the symbol is determined by the design contained within
the symbol.
The symbol at left means the power-cord plug must be unplugged from the outlet.
To Ensure Safe Use
3

WARNING
Always unplug the power cord when
attaching or removing parts and optional
parts and when performing cleaning or
maintenance that does not require the
machine to be connected to a power source.
Attempting such operations while the machine
is connected to a power source may result in
injury or electrical shock.
Never attempt to disassemble, repair, or
modify the machine.
Doing so may result in re, electrical shock,
or injury. Entrust repairs to a trained service
technician.
Be sure to follow the operation procedures
described in the user's manual. Never
allow anyone unfamiliar with the usage or
handling of the machine to touch it.
Incorrect usage or handling may lead to an
accident.
Conduct operations in a clean, brightly lit
location.
Working in a location that is dark or cluttered
may lead to an accident, such as becoming
caught in the machine as the result of an
inadvertent stumble.
Be careful around the cutting tool.
The cutting tool is sharp. Broken cutting tools
are also dangerous. To avoid injury, exercise
caution.
WARNING
Remove the cutting tool before performing
replacement work.
Contact with the blade may result in injury.
Keep children away from the machine.
The machine includes areas and components
that pose a hazard to children and may result
in injury, blindness, choking, or other serious
accident.
Never operate the machine while tired or
after ingesting alcohol or any medication.
Operation requires unimpaired judgment.
Operating with impaired judgment may result
in an accident.
Never use a cutting tool that has become
dull. Perform frequent maintenance to
keep the machine in good working order.
Inappropriate usage may result in re or injury.
Never operate the machine if the cover is
cracked or broken.
Doing so may result in injury. If the cover is
cracked or broken, contact your authorized
Roland DG Corporation dealer.
CAUTION
Never climb or lean on the machine.
The machine is not made to support a person.
Climbing or leaning on the machine may
dislodge components and cause a slip or fall,
resulting in injury.
Incorrect operation may cause injury
This is a heavy machine
CAUTION
Unloading and emplacement are
operations that must be performed by 2
persons or more.
Tasks that require undue e󰀨ort when
performed by a small number of persons may
result in physical injury. Also, if dropped, such
items may cause injury.
CAUTION
Install in a level and stable location.
Failure to do so may result in falling of the
machine, leading to injury.
To Ensure Safe Use
4

Cutting waste and workpieces are ammable and toxic.
WARNING
Never attempt to mill magnesium or any
other such ammable material.
Fire may occur during cutting.
Keep open ame away from the work
area.
Cutting waste may ignite. Powdered material
is extremely ammable, and even metal
material may catch re.
When using a vacuum cleaner to take up
cutting waste, exercise caution to prevent
re or dust explosion.
Taking up ne cuttings using an ordinary
vacuum cleaner may cause danger of re or
explosion. Check with the manufacturer of
the vacuum cleaner. When the safety of use
cannot be determined, clean the machine
using a brush or the like, without using a
vacuum cleaner.
CAUTION
Wear dust goggles and a mask. Wash
away any cutting waste remaining on the
hands.
Accidentally swallowing or inhaling cutting
waste may be hazardous to your health.
Danger of pinching, entanglement, and burns
WARNING
Securely fasten the cutting tool and
workpiece in place. After securing in
place, make sure no spanners or other
articles have been left behind
inadvertently.
Otherwise, such articles may be thrown from
the machine with force, posing a risk of injury.
Do not touch the spindle unit or the
surrounding areas immediately after
cutting has ended.
Doing so may result in burns.
To Ensure Safe Use
5

WARNING
Connect to an electrical outlet that
complies with this machine's ratings (for
voltage, frequency, and current).
Incorrect voltage or insu󰀩cient current may
cause re or electrical shock.
Ratings
If sparks, smoke, burning odors, unusual
sounds, or abnormal operation occur,
immediately unplug the power cord. Never
use if any component is damaged.
Continuing to use the machine may result in
re, electrical shock, or injury. Contact your
authorized Roland DG Corporation dealer.
Never use outside or in any location
where exposure to water or high humidity
may occur. Do not touch the power cord,
plug, or electrical outlet with wet hands.
Doing so may result in re or electrical shock.
Never allow any foreign object to get
inside. Never expose the machine to
liquid spills.
Inserting objects such as coins or matches
or allowing beverages to be spilled into the
ventilation ports may result in re or electrical
shock. If anything gets inside, immediately
disconnect the power cord and contact your
authorized Roland DG Corporation dealer.
Never place any ammable object nearby.
Never use a combustible aerosol spray
nearby. Never use in any location where
gases can accumulate.
Combustion or explosion could occur.
Handle the power cord, plug, and
electrical outlet correctly and with care.
Never use any article that is damaged.
Using a damaged article may result in re or
electrical shock.
WARNING
When using an extension cord or power
strip, use one that adequately satises the
machine's ratings (for voltage, frequency,
and current).
Use of multiple electrical loads on a single
electrical outlet or use of a lengthy extension
cord may cause re.
Position so that the power plug is within
immediate reach at all times.
This is to enable quick disconnection of the
power plug in the event of an emergency.
Install the machine next to an electrical outlet.
Also, provide enough empty space to allow
immediate access to the electrical outlet.
For accessories (optional and
consumable items, power cord, and the
like), use only genuine articles compatible
with this machine.
Incompatible items may lead to an accident.
Never use the machine for any purpose
for which it is not intended, or use the
machine in an excessive manner that
exceeds its capacity.
Doing so may result in injury or re.
Do not use the supplied power cord for
other products.
If the machine will not be used for a long
period, disconnect the power cord.
This prevents an accident caused by
unexpected electric leakage or unintentional
start of the machine.
Connect to ground.
This can prevent re or electrical shock due to
current leakage in the event of malfunction.
Never use cutting oil.
This machine is not designed for the ow of
cutting oil. Oil may get inside the machine and
cause re or electrical shock.
Never use a pneumatic blower.
This machine is not compatible with a
pneumatic blower. Cutting waste may get inside
the machine and cause re or electrical shock.
Danger of electrical short, electrical shock, or re
To Ensure Safe Use
6

Danger of electrical short, electrical shock, or re
Never place any object on top or
subject to damage.
Never allow to get wet. Never bend or twist with excessive
force.
Never make hot. Never pull with excessive force. Dust may cause re.
Never bundle, bind, or roll up.
To Ensure Safe Use
7

Warning labels
Warning labels are axed to make areas of danger immediately clear. The meanings of these labels are as follows.
Be sure to heed their warnings. Also, never remove the labels or allow them to become obscured.
Top
Front and Interior
Caution: Sharp Tool
The cutting tool is sharp.
Inadvertent contact may cause injury.
Never use a pneumatic blower.
This machine is not compatible
with a pneumatic blower. Cutting
waste may get inside the machine
and cause re or electrical shock.
Back
Caution: High Voltage
Removing the cover may result in
high-voltage electrical shock.
Caution: Pinching Hazard
Exercise caution to prevent ngers
from being pinched when closing
covers.
To Ensure Safe Use
8
