Diamond P6 Operating instructions

Mod: MPS18/1
Production code: P6
07/2014

GB
P6
AUTOMATIC FRESH PASTA MACHINE
User and maintenance manual
This handbook is an integral part of the machine.
Read this handbook and the attachments with attention.
Knowledge of the instructions contained is indispensable for
machine use and to carry out maintenance in safety.

P6
II

P6 I
GB
CONTENTS
CONTENTS..........................................................................................................................I
MACHINE DESCRIPTION...................................................................................................1
Machine main components...............................................................................................2
Accessories supplied........................................................................................................4
Optional accessories.........................................................................................................6
Uses provided for..............................................................................................................7
Technical specifications....................................................................................................8
Manufacturer identification data........................................................................................9
Machine identification plate / EC marking.........................................................................9
Permitted environment conditions.....................................................................................9
Noise level........................................................................................................................9
Overall dimensions .........................................................................................................10
Scrapping........................................................................................................................10
Guarantee.......................................................................................................................11
Professional qualifications of persons enabled to operate on the machine.....................12
Suggestions for pasta production ...................................................................................13
SAFETY.............................................................................................................................15
Safety information...........................................................................................................16
Safety precautions..........................................................................................................17
Safety plates and symbols..............................................................................................21
Safety devices ................................................................................................................22
Residual risks .................................................................................................................23
Directives applied ...........................................................................................................24
Harmonised technical standards.....................................................................................24
INSTALLATION ................................................................................................................25
Positioning......................................................................................................................26
Installation.......................................................................................................................27
Electrical connection.......................................................................................................29

Contents IMPERIA & MONFERRINA S.p.A.
P6
II
GB
FUNCTIONING..................................................................................................................31
Description of the controls ..............................................................................................32
Work cycle......................................................................................................................33
Changing the plate..........................................................................................................36
MAINTENANCE ................................................................................................................39
General information ........................................................................................................40
General safety rules........................................................................................................40
Cleaning..........................................................................................................................42
Maintenance on mechanical components.......................................................................42
Maintenance on electrical systems.................................................................................43
Advice regarding maintenance .......................................................................................44
Cleaning and maintenance.............................................................................................45
SPARE PARTS .................................................................................................................49
Components subject to wear and mechanical fatigue.....................................................50
List of recommended spare parts ...................................................................................50
Table 1............................................................................................................................51
Table 2............................................................................................................................53
Table 3............................................................................................................................57
WIRING DIAGRAM ...........................................................................................................59
Wiring diagram - 220 V...................................................................................................60
Wiring diagram 380 V .....................................................................................................61

Contents
P6 I
GB
CONTENTS
CONTENTS..........................................................................................................................I
MACHINE DESCRIPTION...................................................................................................1
Machine main components...............................................................................................2
Accessories supplied........................................................................................................4
Optional accessories.........................................................................................................6
Uses provided for..............................................................................................................7
Technical specifications....................................................................................................8
Manufacturer identification data........................................................................................9
Machine identification plate / EC marking.........................................................................9
Permitted environment conditions.....................................................................................9
Noise level........................................................................................................................9
Overall dimensions .........................................................................................................10
Scrapping........................................................................................................................10
Guarantee.......................................................................................................................11
Professional qualifications of persons enabled to operate on the machine.....................12
Suggestions for pasta production ...................................................................................13
SAFETY.............................................................................................................................15
Safety information...........................................................................................................16
Safety precautions..........................................................................................................17
Safety plates and symbols..............................................................................................21
Safety devices ................................................................................................................22
Residual risks .................................................................................................................23
Directives applied ...........................................................................................................24
Harmonised technical standards.....................................................................................24
INSTALLATION ................................................................................................................25
Positioning......................................................................................................................26
Installation.......................................................................................................................27
Electrical connection.......................................................................................................29

Machine description
P6
2
GB
Machine main components
The machine consists of the following units:
1 Stainless-steel shaft
2 Plexiglas safety cover
3 Mixer shaft clamp/release lever
4 Dough-cutter motor clamp/release knob
5 Plate support ring nut
6 Dough-cutter motor
7 Cooler blower
8 Stainless-steel feeder
9 Wheel block
10 Electric wire
11 Trolley
12 Electric motor
13 Plugs for electrical link with the cooler blower and optional units
14 Tank
15 Control panel

Machine description
P6 3
GB
6
5
7
8
4
3
2
1
9
10
11
12
13
14
15

Machine description
P6
4
GB
Accessories supplied
4 dough plates (the type of plate is chosen by
the customer when the order is placed).
1 plate ring nut support tightening
spanner.
1 dough-cutter motor.
1 set of blades for the dough-cutter motor.

Machine description
P6 5
GB
1 sieve.
1 reducer breather plug.
1 cooler blower.
1 adjustment rod.

Machine description
P6
6
GB
Optional accessories
Ravioli unit.
Gnocchi unit.
Attachment point, for optional units, at the
rear side of the machine.

Machine description
P6 7
GB
Uses provided for
The automatic P6 machine has been designed, built and outfitted
exclusively for the production of drawn pasta, obtained from raw materials
such as durum wheat flour or bread wheat flour with the addition of water
and/or eggs.
The pasta extruders, to obtain the different shapes, may be of two types,
in bronze or in Teflon. The pasta obtained with bronze extruders has a
rougher and more opaque surface.
With Teflon extruders, the pasta is smoother and with a more glossy
surface. These extruders are more delicate than those in bronze and the
hourly pasta production output is slightly higher.
The machine can be connected to a Ravioli and Gnocchi unit, that is
optionally available.
The technical features of the product dealt with, dimensions, weight,
cutting system etc. are only those indicated in the supply contract and
indicated in this handbook in section “Technical data”.
A different use to that specified shall be considered improper use. In any
case, the machine has been designed for professional industrial use.

Machine description
P6
8
GB
Technical specifications
Mixing tank capacity Kg 6
Dough production Kg/h 15 ÷ 18
Three-phase or single-phase motor Hp 1,5
Weight Kg 107

Machine description
P6 9
GB
Machine identification plate / EC marking
In the case of all communication with the manufacturer, always quote the
information on the machine’s ID plate.
Permitted environment conditions
To guarantee correct functioning, the machine is to be placed where it is
protected against weather and with an environment temperature ranging
between 20 °C and 30 °C and with relative humidity ranging between 40%
and 50%.
The working environment is to be clean and well lit.
Noise level
The phonometric tests carried out on this specific machine model highlight
an acoustic pressure of:
LEP,d < 70 dB (A)

Machine description
P6
10
GB
Overall dimensions
The overall dimensions are indicated in section “Technical data”.
Scrapping
Environment!
When scrapping, all the machine components are to be disposed of
in the appropriate waste dumps in accordance with the laws in force.
The machine has a pure, unalterable stainless-steel structure and
conforms to current safety regulations in Italy and abroad.
The main components of the machine are:
Single-phase electrical motor 220 V or three-phase 380 V.
Stainless-steel tank and feeder.
Stainless steel shaft that can be removed to facilitate cleaning and
maintenance.
Plates for every type of dough.
Automatic dough-cutter with speed variator and stainless-steel blades.
Cooling blower for drying the product quickly.
Stainless steel trolley on wheels.
The machine’s frame is made of steel (AC) and polycarbonate (PC).
The electric motor is made of aluminium (AL), steel (AC), copper (CU) and
polyamide (PA). Recover the used reducer oil and dispose of it at
specially – equipped collection centres.
Disconnect all power supplies before starting scrapping operations.

Machine description
P6 11
GB
Guarantee
DIAMONDprovides a warranty for 12 months
from the date of purchase for all parts, excluding those subject to normal
wear.
The warranty is annulled in the case of repairs on the machine carried out
by unauthorised persons or if equipment or accessories not supplied by
DIAMOND are used or that have not been
recommended or approved by the same, or in the case of removal or
alteration of the serial number during the warranty period.
The guarantee runs from the purchase date and the card, duly completed
in full, must be sent within ten days.
The purchase date is the one shown on the carriage note/invoice at the
time when the machine is delivered by the re-seller.
DIAMONDunder takes to repair or replace parts
which show manufacturing faults during the guarantee period, free of
charge. The warranty does not cover any cleaning of operating
components.
Defects that are not clearly due to materials or manufacturing shall be
examined at our “Technical Assistance Centre” or our works.
If the claim proves to be unjustified, all repair and/or part replacement
costs shall be borne by the customer.
The guarantee certificate and the carriage note/invoice must be shown to
the technical personnel carrying out repairs or must accompany the
machine sent for repair.
The guarantee is not extended following technical work performed on the
machine. Repairs are carried out at our “Technical Assistance Centre” at
our works and the part/s involved must arrive with carriage paid (carriage
expenses borne by the customer unless agreed differently).
The guarantee does not however cover: accidental damage, in transport,
through negligence or inappropriate treatment, incorrect use not
conforming to notes shown in the instructions booklet and anyway caused
by phenomena not depending on the regular functioning or use of the
machine.
The DIAMOND company declines all
responsibility for any harm to persons or damage to property arising from
bad or imperfect use of the machine.

Machine description
P6
12
GB
Professional qualifications of persons enabled to operate on the machine
The machine is to be used only by authorised persons who have been
instructed for the purpose; the same precaution is valid for the persons
who shall carry out the maintenance. Do not permit unauthorised persons
to approach the machine when running or during maintenance.
After receiving all the instructions necessary, only the following
professional operators are permitted to work on the machine:
Safety officer
The safety officer is responsible for protection and prevention of risks in
the company, as specified in the European Directive 89/391 EEC (Safety
in the workplace), acknowledged in Italy by D.L. Executive Order of
12/11/1994.
The safety officer shall ascertain that all the persons operating on the
machine have received all the relevant instructions contained in this
handbook.
Operator (in charge of running the machine)
Trained operator qualified to run the machine (work cycle, any
adjustments, etc.).
This operator shall only carry out the operations specifically assigned and
described in this handbook.
It is most important to avoid that the machine is not used by unskilled
persons.
Mechanical maintenance engineer
Qualified technician able to run the machine as OPERATOR and,
furthermore, able to run it with protections disabled, to intervene on
mechanical components, to carry out adjustments, maintenance and
repairs.
This engineer shall not intervene on live electrical systems.
The mechanical maintenance engineer is to have generic mechanical
experience and specific experience on this type of machine.

Machine description
P6 13
GB
Electrical maintenance engineer
Qualified technician able to run the machine as OPERATOR and
furthermore able to run it with protections disabled, to intervene on
adjustments and electrical systems for maintenance and repairs.
Able to operate with live voltage in the electric panels, control equipment,
etc.
The electrical maintenance engineer is to have generic experience on
electric panels and specific experience on the panel and electrical
components of this machine.
Manufacturer
For any other operation not specifically foreseen in this handbook or
assigned to a professional technician other than those indicated above,
contact DIAMOND
Suggestions for pasta production
Any type of flour or durum flour or flour/durum flour mixture can be used
for the dough.
The dough must be kneaded with eggs alone or an eggs/water mix.
The water can be replaced in part by finely-chopped spinach or
vegetables to obtain green pastas or tomato puree to obtain red pastas or
other ingredients: in these cases it is advisable to use hard grain durum
flour.
For good dough, around 300 ÷ 350 gr. of liquid is required for every
kilogram of flour.
This liquid may consist of eggs alone, just water or an egg/water mixture.
Since the moistness of the flour varies according to type, climate and
where it is stored, the amounts indicated must be adapted to the type of
flour being worked by adding or decreasing the quantity of liquid slightly.
The dough is just right when, at the end of kneading, it is in the form of
grains the size of coffee beans. If the dough coalesces into a even mass it
means that too much liquid has been poured in. In this case, before
extruding the dough, add a little more flour and let it mix for a bit longer.
If, however, the dough does not form little balls but remains very floury,
add a little more liquid.

Machine description
P6
14
GB
Here below we give a few recipes for different types of dough.
Remember that ingredients can at all times be modified and quantities
changed according to your experience and taste.
Preparation for pastry for ravioli:
Fine flour 70%
Hard grain durum flour 30%
5 eggs per Kg of dough + water
Knead for approximately 10 minutes
The moistness of the mixture between eggs and water must be around
32%.
Preparation of dough for tagliatelle:
Fine flour 70%
Hard grain durum flour 30%
5 eggs per Kg of dough + water
Or
Hard grain durum flour 100%
5 eggs per Kg of durum flour + water
Knead for around 15 minutes with around 33% moisture.
Preparation of durum flour pasta:
(e.g. rigatoni, fusilli, conchiglie, spaghetti, etc.).
For this type of pasta only hard-grain durum flour with 30 ÷ 33% water is
used.
When different types of flour are used it is a good idea to mix them well
before adding liquid.
To take account of the customer’s taste, salt in the rough measure of 2 gr.
per Kg of flour can be added to the dough, taking care to dilute it well in
water.

Safety
P6 15
GB
SAFETY
If in doubt do not proceed!
Telephone the DIAMOND After Sales Service immediately.
