SERVICE & REPAIR MANUAL
SINGLE SPEED
AUGER DRIVES
KOPENN ENGINEERING
PM-000150-C

2
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
PD MODEL OIL CAPACITY (LITRE)
PD12HD-21 1.45
PD22-20 2.85
PD50-20 6.4
TK25-20 7.0
LUBRICATION & MAINTENANCE
USE QUALITY EXTREME
PRESSURE GEAR OIL
(EP ISO 320 GRADE - SYNTHETIC OIL)
NOTE
It is also recommended that unit be partially disassembled to inspect gears and bearings at 2 year intervals.
Oil changes must be performed by a Authorised Service Agent. Please Contact Digga for your nearest service location.
SINGLE & DOUBLE PLANETARY AUGER DRIVES
This manual is intended to be used by persons with reasonably mechanical skills and understanding of mechanical components.
This manual will assist in the disassembly and assembly of the above model Planetary Auger Drives. Item numbers, indicated in pa-rentheses
throughout this manual, refer to the exploded parts breakdown drawing. Individual customer specications (mounting hood, output shaft etc.) may
vary from exploded drawing and standard part numbers shown. Contact Digga Australia for enquiries.
For any spare or replacement parts, contact Digga Service and Spares or a local Digga representative. For identication purposes always try to have
available the auger drive unit type and serial number. This information may be necessary for verication of any component part numbers. Component
part numbers and/or manufacturing gear set numbers may be stamped on individual parts. This information may also be helpful in identifying
replacement components.
CHANGING GEAR OIL
Change the gear oil after 6 months or 80 hours of moderate operation, then every 500 hours or 12 months whichever comes rst.
MODERATE OPERATING CONDITIONS SEVERE OPERATING CONDITIONS*
FIRST OIL CHANGE Within 3 months OR initial 50 hours of use Within the rst 30 hours of use
2ND OIL CHANGE PLUS SUBSEQUENT OIL CHANGES After 500 hours or 12 months of use After 300 hours of use thereafter (Drive requires a major
stripdown, inspection and rebuild)
GEARBOX OIL:- - CASTROL ALPHASYN ISO SP 320 (MINERAL) OR EQUIVALENT
*SEVERE OPERATING CONDITIONS:- AMBIENT TEMPERATURES BELOW 0° (32°F) & ABOVE 40°C (104°F). WORKING IN HARD GROUND.
EXTENDED AND CONTINUOUS HOURS OF OPERATION.
THE GEARBOX OIL CAPACITY IS ENGRAVED ONTO THE SERIAL TAG LOCATED ON THE TOP OF THE HOOD.
Initial (Bed-in) oil change:
• The rst oil change must be carried out within the rst 50 hours of use under MODERATE OPERATING CONDITIONS.
Thereafter, every 500 hours.
• Change the gear oil after the rst 30 hours of SEVERE OPERATING CONDITIONS*. (i.e. severe ambient temperature conditions of +40°C or
below 0°C, when augering, screw piling or core barrelling in hard ground.) Thereafter, every 300 hours.

3
TABLE OF CONTENTS
LUBRICATION & MAINTENANCE.................................................................................................................. 2
TABLE OF CONTENTS................................................................................................................................... 3
BEFORE DISASSEMBLY................................................................................................................................ 4
UNIT DISASSEMBLY PROCEDURE.............................................................................................................. 4
OUTPUT SHAFT SUBASSEMBLY ............................................................................................................... 5
PRIMARY PLANETARY SUBASSEMBLY..................................................................................................... 6
PRIMARY AND SECONDARY COMBINATION PLANETARY SUB-ASSEMBLY....................................... 7
UNIT REASSEMBLY....................................................................................................................................... 8
BEARING PRELOAD CHART......................................................................................................................... 10
PD12HD-21 EXPLODED VIEW DRAWING.................................................................................................... 11
PD22-20 EXPLODED VIEW DRAWING......................................................................................................... 14
TK25-20 EXPLODED VIEW DRAWING......................................................................................................... 16
PD50-20 EXPLODED VIEW DRAWING.......................................................................................................... 18
GB-003636 (PD50-20 MODIFIED HOOD) EXPLODED VIEW DRAWING.................................................. 20
SAFETY DECALS........................................................................................................................................... 22
CHANGING THE OIL ..................................................................................................................................... 23
CHANGING THE SHAFT SEAL .................................................................................................................... 24
CONTACT INFORMATION.............................................................................................................................. 27

4
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
In all the drive units there are primary and secondary individual gear sets.
UNIT DISASSEMBLY PROCEDURE
All parts should be inspected as they are removed from unit. Scribe or mark a line across the assembly mounting case, ring gear, and cover joints on
outside of gearbox to assure proper orientation of hood assembly, oil ll/ drain plug, motor mounting, etc., as the unit is reassembled.
1. Remove outer ring of bolts (refer to the relevant drive unit- diagram) from underside of gearbox assembly. Lift hood from gearbox assembly.
Remove drain plug and drain oil.
2. Remove hydraulic motor from gearbox assembly. On PD12HD-21 and PD22-20 and above remove 4 motor retaining bolts to remove motor then
inner ring of input housing retaining bolts.
3. The primary planetary assembly is now ready for removal. Lift outer ring gear, sun gear and gear set from the output housing.
4. For secondary planet removal, remove bolts holding interim housing, remove housing, and lift outer ring gear, sun gear and gear set from the
output housing.
5. All drive units will have a seal protector or carrier, remove this before moving to step #6.
6. Remove key steel from keyway. Loosen lock nut using the required tool and remove locknut and locking tab.
7. With output shaft down through a centre hole in hydraulic press table and unit supported by case, press shaft out by applying load to top end of
shaft (internal end) until it passes through inner shaft bearing. Outer shaft bearing will come out of unit attached to shaft.
The unit is now disassembled into groups of parts and/or subassemblies. The area requiring repair or service should be identied by thorough
inspection of the parts after they have been washed in solvent.
BEFORE DISASSEMBLY
CAUTION: RETAINING RING IS NO LONGER RETAINING OUTPUT SHAFT. TAKE PRECAUTIONS IF THE UNIT IS MOVED
BECAUSE THE SHAFT MAY FALL OUT.
CAUTION: CARE SHOULD BE TAKEN NOT TO INJURE FEET OR DAMAGE OUTPUT SHAFT DURING THIS PROCEDURE.

5
OUTPUT SHAFT SUBASSEMBLY
REFER TO APPROPIATE EXPLODED VIEW DRAWING
1. Inspect inner and outer bearing cups and cones. If either is damaged, the complete bearing assembly will need replacing.
2. Remove inner and outer bearing races from output housing with the appropriate tool.
3. Clean all foreign material from oil plug located on bottom of output housing. Add a small amount of pipe thread compound to thread on plug
before installing it back into case.
PD22-20 PD50-20
TK25-20
PD12HD-21

6
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
PRIMARY PLANETARY SUBASSEMBLY
Rotate planet gear to check for any abnormal noises or roughness in the primary planet bearings. At the same time, inspect planet gears for any
damage or worn teeth. If replacement or further inspection is required, proceed as follows. For PD15 - PD22 lift top gear set from bottom set then
proceed as follows.
1. Remove circlips from top plate and remove plate.
2. Slide planet gears from carrier.
3. Remove bottom plate.
4. Check primary planet shafts, top and bottom plates, centre thrust washer, needle rollers and gears for any abnormal wear.
5. Replace any worn items.
6. Assembly: Fit centre thrust washer, t bottom plate, t gears, insert needle rollers into gears using lubricating oil, t top washer and install
circlips to posts place gear set into ring gear and place sun gear into gear set, ensure all turns freely.
CAUTION: THE NEEDLE ROLLER BEARINGS ARE NOT CAGED THEREFORE CAN FALL FREE.
NOTE: IF THE PLANET SHAFTS ARE WORN, THE COMPLETE CARRIER ASSEMBLY MUST BE REPLACED. THE POSTS
SHOULD NOT BE REPLACED IN AN EXISTING CARRIER.

7
PRIMARY AND SECONDARY COMBINATION PLANETARY SUB-ASSEMBLY
GB-002640 GB-002790 GB-001937
GB-003121 GB-002807 GB-003507
GB-003536
GB-001937-REV B
SUIT PD12HD-21 SUIT PD22-20 SUIT TK25-20
SUIT PD50-20
SUIT PD50-20 SUIT PD50-20
GB-003536
GB-001937
GB-003223
GB-001937
FROM 26/3/14
UNTIL 8/3/17
FROM 9/3/17
UNTIL 3/8/17
FROM 04/8/14
CURRENT
REPLACE
CIRCLIP WITH
SPACER
REPLACE
CIRCLIP WITH
SPACER
SPACER
GB-003616

8
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
UNIT REASSEMBLY
1. Start with output housing assembly. Turn case upside down and position on table. Bottom seal end should be facing upward and install bearing
cup with appropriate tooling.
2. Install bottom seal or dual seals applying a smear of Loctite 243 thread locker to outside of seal and t using appropriate tooling. Ensure dual
seals oppose each other. Ensure seal is ush with the housing. Wipe off excess Loctite. Grease inner face of seal with EP grease.
3. Invert outer housing to upright position and place over securely positioned output shaft with splines facing upward. Using the appropriate
tooling, assemble the output housing onto the output shaft.
4. Install bearing race to output housing with appropriate tooling. Install bearing ensuring correct installation technique. Only drive the bearing
home via the inner cone of bearing. Hitting outer roller cage will damage the bearing.
5. While holding output shaft with one hand, rotate case to be certain it turns freely and smoothly. The slight resistance felt, if any, is due to shaft
seal load (drag) on output shaft.
6. Fit lock nut with chamfer facing downward and tension.
PD12HD-21 – 180ft/lbs (approx) PD22 – 20 nut tension – 1000ft/lbs (approx)
TK25-20 – PD50-20 nut tension – 1200ft/lbs (approx) Refer to (“Bearing Preload Chart P.12” for correct lock nut tension.)
7. Drive locking tab into the keyway of the output shaft.
8. Insert key after tensioning locking nut.
9. Clean and ensure inner section of housing and bearings are free from foreign matter.
10. For PD12HD-21 – PD22-20. Lightly grease a new o-ring and install it into o-ring groove in case. For TK25-20 and PD50-20, use gasket sealant
sparingly on mating surfaces.
11. Fit gear set and sun gear to the output housing. Line up bolt holes and t ring gear. Make sure the ring gear sits at on the
housing. Top up gear oil level to top of gear set.
12. Grease o-ring and t to interim housing and t interim housing to gear set lining up scribe mark.
NOTE: IF THE BEARINGS HAVE BEEN REPLACED, IT IS LIKELY THAT A NEW KEYWAY WILL HAVE TO BE CUT IN THE LOCKNUT.
NOTE: BE CERTAIN THAT THE O-RING STAYS SEATED IN GROOVE DURING STEP DURING ALL ASSEMBLY STAGES.

9
13. *Fit primary gear set as from step # 11.
14. *Fit o-ring to input housing and t input housing to primary gear set using sealant and aligning scribe mark as previously described.
15. *Fit the hydraulic motor using gasket sealant between motor and housing. Refer back to scribe marks made across external joints prior to
Disassembly Procedure. Line up scribe marks so that orientation of motor mount holes and oil plug are back to their original positions and
ret motor.
16. The drive unit can be lled with gear oil now or after fully assembled. If fully assembled the oil will have to be poured through the bung in the
output housing. Oil quantity is on page 2. Grease a new o-ring and install it into the groove of hydraulic motor. Refer back to scribe marks made
across external joints prior to Disassembly Procedure. Line up scribe marks so that orientation of motor mount holes and oil plug are back to
their original positions and ret motor.
17. Fit hood to gearbox assembly making sure original scribe marks are aligned. Fit all outer bolts and tension to the following setting.
Use Loctite 243 PD12HD-21 (75nm) PD22-20 - PD22 (120nm) TK25-20 – PD50-20 (170nm)
18. Attach hydraulic hoses and test operation.
19. THE AUGER DRIVE IS NOW READY FOR USE.
NOTE: BE CERTAIN O-RING STAYS SEATED IN COVER DURING STEP #12 THROUGH #16.
NOTE: THE DRIVE UNIT CAN BE FILLED WITH GEAR OIL NOW OR AFTER FULLY ASSEMBLED. IF FULLY ASSEMBLED THE
OIL WILL HAVE TO BE POURED THROUGH THE BUNG IN THE OUTPUT HOUSING. OIL QUANTITY IS ON PAGE 2.

10
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
BEARING PRELOAD CHART
PD UNIT HOUSING SHAFT DIA
(mm)
FORCE (Kg)
PD12H-21 S4 70 7
PD22-20 S5 100 30
TK25-20
TO
PD50-20
S8 120 35
S9.5 120 35
S10 150 45
S12 180 55
FORCE (in Kg)
This is the force to keep the housing spinning slowly at a
constant speed. The force required to start the spinning initially
will be greater. This is not the correct reading. To ensure an
accurate reading the force direction must be held at 90 degrees.
(As shown). Reading is to be taken from the inner bolt pattern.
FORCE (in Kg)
This is the force to keep the housing spinning slowly at a constant speed.
The force required to start the spinning initially will be greater. This is not the correct reading.
To ensure an accurate reading the force direction must be held at 90 degrees. (As shown)
Reading is to be taken from the inner bolt pattern.
BEARING PRELOAD FORCE CHART
PD UNIT Housing Shaft DIA (mm) Force (Kg)
PDD,PDX,PDX2,PDX3
,PD3 - PD5 S2 50.8 4
PD6 - PD12 S4 70 7
S4 (RME) 70/75 10
S4 75 15
PD15 - PD22 S5 100 30
S6 100 30
PD25 - PD50 S8 120 35
S9.5 120 35
S10 150 45
S12 180 55

11
PD12HD-21
6
16
14
13 15
8
9
12
10
5
11
1
17
2
23
23
21
22
3
21
23
18
22
7
4
20
19
6
16
14
13 15
8
9
12
10
5
11
1
17
2
23
23
21
22
3
21
23
18
22
7
4
20
19
34
27
26
28
24
32
31
29
33
27
26
25
30
APPLY LOCTITE 263 TO
THREADS OF FA-000734
& TORQUE TO 135Nm
ENSURE RELIEF VALVE PRESSURE
IS SET TO 2600 PSI.
36
35

12
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
PD12HD-21 PART LISTS
ITEM QTY PART NUMBER DESCRIPTION
1 2 BE-000024 BEARING TAPERED ROLLER
2 12 FA-000125 SCREW SOCKET HEAD CAP
3 8 FA-000132 SCREW SOCKET HEAD CAP
4 4 FA-000220 SCREW FLAT HEAD SOCKET
5 1 GB-000004 LOCK NUT - S4
6 1 GB-000005 KEY STEEL
7 1 GB-0 01776 SEAL PROTECTOR
8 1 GB-001848 RING GEAR
9 1 GB-001875 RING GEAR - S3
10 1 GB-002640 GEARSET - S4 - HEAVY DUTY
11 1 GB- 002714 SPACER - S4
12 1 GB-002722 INTERIM HOUSING
13 1 GB-002737 SUN GEAR - S3
14 1 GB-002819 GEARBOX - S4
15 1 GB-003121 GEARSET - S3
16 1 GB-003539 SHAFT - S4 - 70mm HEX
17 1 GB-003541 OUTPUT HOUSING - S4
18 1 GB-003583 SEAL RETAINER
19 1 HA-000129 BI-DIRECTIONAL RELIEF (55/60FT-Lb - 74/81N-m)
20 1 MO-000124 MOTOR HYD
21 3 PP-000001 PRESSURE PLUG
22 2 SE-000006 SEAL
23 4 SE-000013 O-RING

13
PD12HD-21 PART LISTS
QTY PART NUMBER DESCRIPTION
1 DE-000088 DECAL NEW GENERATION (CAUTION)
1 DE-000089 DECAL NEW GENERATION (WARNING)
1 DE-000091 DECAL NEW GENERATION (DIGGA PD) - 75MM
1 DE-000099 DECAL NEW GENERATION (1) - 35MM
1 DE-000100 DECAL NEW GENERATION (2) - 35MM
1 DE-000321 DECA L-HIGH FLOW
1 DE-000345 SWING TAG -GEARBOX OIL REPLACEMENT
1DE-000791 WARNING HIGH PRESSURE
PD12HD-21 PARTS DECALS
ITEM QTY PART NUMBER DESCRIPTION
24 1 DE-000063 SERIAL TAG - GEARBOXES
25 1 DE-000345 SWING TAG -GEARBOX OIL REPLACEMENT
26 2 FA-000046 BOLT HEX
27 2 FA-000093 NUT NYLOC
28 2 FA-000194 RIVET
29 16 FA-000734 SOCKET HEAD CAP SCREW
30 1 GB-003540 GEARBOX ASSEMBLY
31 2 HA-000131 CAP NUT
32 2 HA-000430 FITTING
33 1 HO-001542 HOOD - PD12HD - BOLT
34 1 PI-000045 PIN
35 1 PM-000149 OPERATORS MANUAL - KOPENN ENGINEERING
37 16 WA-000063 WASHER - NORDLOC

14
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
PD22-20
8
11
5
20
12
13
10
6
9
3
18
14
22
23
15
17
21
16
1
4
7
19
1
2
8
11
5
20
12
13
10
6
9
3
18
14
22
23
15
17
21
16
1
4
7
19
1
2
25
32
26
28
27
29
30 31
24
24

15
PD22-20 PARTS LIST
ITEM QTY PART NUMBER DESCRIPTION
1 2 BE-000025 BEARING TAPERED ROLLER
2 4 FA-000109 SCREW FLAT HEAD SOCKET
3 8 FA-000132 SCREW SOCKET HEAD CAP
4 2 FA-000610 SCREW SOCKET HEAD CAP
5 12 FA-100280 M12 SOCKET HEAD CAP SCREW
6 1 GB-000542 KEY STEEL
7 1 GB-001699 LOCKNUT
8 1 GB-001875 RING GEAR
9 1 G B - 0 0 2112 SPACER - S5
10 1 GB-002786 RING GEAR - S5
11 1 GB-002787 INTERIM HOUSING
12 1 GB-002790 GEARSET - S5
13 1 GB-002807 GEARSET - S3.5
14 1 GB-002819 GEARBOX - S4
15 1 GB-003407 SHAFT - TYPE 20
16 1 GB-003421 OUTPUT HOUSING
17 1 GB-003446 SEAL PROTECTOR
18 1 MO-000555 MOTOR HYD
19 1 PP-000001 PRESSURE PLUG
20 2 SE-000013 O-RING
21 1 SE-000050 SEAL
22 2 SE-000114 SEAL
23 4 SP-000006 SPRING PIN
24 1PM-000149 OPERATORS MANUAL - KOPENN ENGINEERING

16
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
TK25-20
DETAIL A
( 1 : 1 )

16
6
10
12
6
1
15
1
11
713.8
460.0 
2
4
7
22
21
8
8
8
5
14
13
20
20
3
17
9
8
18
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES
&IN BETWEEN SEALS.
23
19
DETAIL A
( 1 : 1 )

16
6
10
12
6
1
15
1
11
713.8
460.0 
2
4
7
22
21
8
8
8
5
14
13
20
20
3
17
9
8
18
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES
&IN BETWEEN SEALS.
23
19
DETAIL A
( 1 : 1 )

16
6
10
12
6
1
15
1
11
713.8
460.0 
2
4
7
22
21
8
8
8
5
14
13
20
20
3
17
9
8
18
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES
&IN BETWEEN SEALS.
23
19
DETAIL A
( 1 : 1 )

16
6
10
12
6
1
15
1
11
713.8
460.0 
2
4
7
22
21
8
8
8
5
14
13
20
20
3
17
9
8
18
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES
&IN BETWEEN SEALS.
23
19
29
31
28
24
27
30
32
26
25
33

17
ITEM QTY PART NUMBER DESCRIPTION
1 2 BE-000029 BEARING TAPERED ROLLER
2 12 FA-000079 BOLT HE X
3 6 FA-000144 SCREW SOCKET HEAD CAP
4 9 FA-000432 SCREW SOCKET HEAD CAP
5 6 FA-000480 SCREW FLAT HEAD SOCKET
6 2 GB-000539 RING GEAR - S8
7 1 GB-001467 KEY - LOCK
8 4 GB-001469 O-RING
9 1 GB-001697 LOCKNUT - S9.5
10 1 GB-001937 GEARSET - S8
11 1 GB-003185 OUTPUT SHAFT - S9.5
12 1 GB-003225 INTERIM HOUSING - SERIES 6-8 INTERIM
13 1 GB-003273 SEAL PROTECTOR
14 1 GB - 0 0 3274 SHAFT SEAL COVER
15 1 GB-003316 OUTPUT HOUSING
16 1 GB-003483 INPUT HOUSING
17 1 GB-003507 GEARSET - S8
18 2 PP-000003 PRESSURE PLUG
19 1 PP-000005 PRESSURE PLUG
20 2 SE-000039 SEAL
21 1 SE-000114 SEAL
22 12 WA-100031 WASHER HIGH TENSILE 9/16
23 1MO-002821 MOTOR COMPLETE
24 8 FA-000026 BOLT HEX
25 2 FA-000401 GREASE NIPPLE
26 24 FA-100064 BOLT HE X
27 1 GB-003501 GEABOX ASSEMBLY
28 2 HO-000087 HOOD COVER
29 1 HO-001203 HOOD ASSEMBLY
30 1 MO-002821 MOTOR COMPLETE WITH RELIEF MANIFOLD
31 1 PI-000055 PIN
32 24 WA-000065 WASHER - NORDLOC
33 1 PM-000149 OPERATORS MANUAL - KOPENN ENGINEERING
TK25-20 PARTS LIST

18
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
PD50-20
DETAIL A
190.0
460.0 
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
DETAIL A
190.0
460.0 
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
DETAIL A
190.0
460.0
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
29
23
30
26
28
24
25
27
31

19
ITEM QTY PART NUMBER DESCRIPTION
1 2 BE-000029 BEARING TAPERED ROLLER
2 12 FA-000079 BOLT HEX
3 1 GB-001937 GEARSET - S8
4 1 GB-003536 GEARSET - S8
5 1 GB-003225 INTERIM HOUSING
6 1 GB -001467 KEY - LOCK
7 1 GB-001697 LOCKNUT - S9.5
8 3 GB- 001469 O-RING
9 1 GB-003316 OUTPUT HOUSING
10 1 GB-003185 OUTPUT SHAFT
11 1 PP-000005 PRESSURE PLUG
12 2 PP-000003 PRESSURE PLUG
13 2 GB-000539 RING GEAR - S8
14 1 GB-003483 INPUT HOUSING
15 9 FA-000432 SCREW SOCKET HEAD CAP
16 6 FA-000150 SCREW SOCKET HEAD CAP
17 6 FA-000144 SCREW SOCKET HEAD CAP
18 1 SE-000114 SEAL (NOT SHOWN)
19 2 SE-000039 SEAL
20 1 GB-003457 SEAL PROTECTOR
21 1 GB-003584 SEAL PROTECTOR
22 12 WA-100031 WASHER HIGH TENSILE
23 24 FA-100064 BOLT HEX
24 1 FA-000188 NUT HEX NYLOC
25 1 FA-000412 BOLT HE X
26 1 GB-003317 GEABOX ASSEMBLY
27 1 HO-001548 HOOD ASSEMBLY
28 1 MO-000631 MOTOR COMPLETE WITH RELIEF MANIFOLD
29 1 PI-000261 PIN
30 24 WA-000065 WASHER - NORDLOC
31 1 PM-000149 OPERATORS MANUAL - KOPENN ENGINEERING
PD50-20 PARTS LIST

20
PM-000150-C Kopenn Auger Drive Service and Repair Manual - March 2018
GB-003636 (PD50-20)
DETAIL A
190.0
460.0
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
DETAIL A
190.0
460.0 
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
DETAIL A
190.0
460.0 
12
714
19
20
17
19
10
1
2
22
9
5
1
6
8
7
13
3
8
12
4
14
11
OPEN SIDE
OF SEAL
OPEN SIDE
OF SEAL
APPLY GREASE TO SEAL FACES &
IN BETWEEN SEALS.
15
28
18
16
21
31
