Digi TX54 User manual

TX54
User Guide
Firmware version 22.2

Revision history—90002357
Revision Date Description
FMarch 2021 Release of Digi TX54 firmware version 21.2:
nEnhancements to the location service:
lThe ability to define a static latitude and longitude
as a location for the device.
lReporting location information as health metrics to
Digi Remote Manager.
lGeo-fencing: Allow you to define one or more
circular or polygonal geo-fence areas and then
perform a set of actions when the device enters or
leaves that area.
lPython support for location information through
the digidevice.location python module.
nCellular modem carrier scanning and locking:
lNew modem scan CLI command for listing available
carriers for the current modem and SIM.
lManual carrier selection option to allow you to lock
the SIM to a specific carrier.
nEnhanced serial support:
lCertificate management control for TCP and
autoconnect serial port setups.
lAutoconnect.
nEnhanced Wi-Fi support:
lSupport 5GHz DFS Wi-Fi channels in client mode.
Only available for devices with 5GHz Wi-Fi radio
support.
lAdded 5GHz frequencies to the list of channels that
can be scanned for client-mode Wi-Fi background
scanning.
nLocal RESTAPI for automated configuration of the
device.
nSupport for remote CLI commands through Digi
Remote Manager.
nSupport for automatically checking for device and
modem firmware updates.
GJune 2021 Release of Digi TX54 firmware version 21.5:
nWi-Fi enhancements:
lAdded support for WPA3 Wi-Fi encryption:
TX54 User Guide 2

Revision Date Description
oWPA2/WPA3 Personal
oWPA3 Enhanced Open
oWPA3 Personal
lAdded support for WPA and WPA/WPA2 mised
mode with TKIP.
nCellular enhancements:
lAdded support for modem firmware update to the
Admin CLI.
lAdded support for over-the-air (OTA) modem
firmware update to check, list, and update to new
modem firmware from the Digi firmware server.
lAdded the ability to scan for cellular carriers on the
Modem status page and the ability select a
particular PLMN/network to use.
nAdded commands for over-the-air (OTA) system
firmware update to check, list, and update to new
firmware from the Digi firmware server.
nAdded a show dns command to the Admin CLI to
display active DNS servers and their associated
interface.
nAdded a show ntp command to the Admin CLI to
display the status of the NTP service.
nExpanded Port forwarding option to support a range of
ports, including one-to-one and many-to-one port
mappings.
nAdded options to control packet filtering for the
network analyzer.
nVPN enhancements:
lIPsec enhancements:
oAdded support for multiple remote endpoints
and the ability to use round-robin or to randomly
select an endpoint to establish a tunnel to.
oAdded configurable options to control IKE
transmit interval, tunnel retry interval, and
tunnel retry timeout.
lLDAP enhancements:
oAdded a login attribute to provide the ability to
match the attribute set on an Active Directory
server.
nSureLink enhancements
lAdded the ability to configure how many times a
SureLink test must run, and must fail, before the
TX54 User Guide 3

Revision Date Description
interface is restarted or the device is rebooted.
lAdded the ability to configure how many times a
SureLink test must pass before an interface is
considered to be working.
lAdded the ability to test another interface's status.
nSNMPv2 supported added.
nUpdated python to version 3.6.13.
nAdded the default digi.device local domain.
HSeptember 2021 Release of Digi TX54 firmware version 21.8:
nAdded LXC container support for running localized
containers on the device.
nAdded support for maintenance windows triggers to
control when a device is available for Digi Remote
Manager maintenance activity.
nWi-Fi enhancements:
lRemoved requirement to set a Wi-Fi SSID and
passphrase to initially configure the device.
lAdded support for 40Mhz channel bandwidth on
2.4GHz.
nVPNenhancements:
lAdded support for L2TPv3 tunneling.
lNew option to enable, disable, or force IPsec IKE
fragmentation.
nImproved options for creating a custom default
configuration:
lsystem backup CLI commands for generating a
custom default config file based on the active
config settings on the device.
lNew section on the File System page of the Web UI
for loading a configuration backup file as the
custom default config
lNew persistent files folder accessible through Digi
Remote Manager where users can upload a
configuration backup.
lAdded ability to clear a custom default
configuration by performing by pressing the RESET
button, waiting for the device to reboot, then
pressing the RESET again.
nAdded ability to override or edit SSH server options.
nAdded options for filtering Wi-Fi scanner results based
off of MAC addresses or RSSI signal strength.
TX54 User Guide 4

Revision Date Description
nAdded options for sending local device event logs to
Digi Remote Manager.
nNew system time CLI command for manually setting
the local date and time.
nNew firewall packet filter options to allow/deny packets
based off of a range of source or destination MAC
addresses.
nNew monitoring metrics upload CLI command to send
on-demand health metrics to Digi Remote Manager.
nAdded support for the configuration of custom scripts
that will be run manually, and a new system script
start CLI command to run manual scripts.
nNew "Find me" feature that flashes cellular-related
LEDs to help locate the device onsite and a new system
find-me command.
nAdded datapoint.upload_multiple function to
digidevice python module for uploading multiple
datapoints to DigiRM at once.
nAdded clear dhcp-lease command to remove all
dynamic DHCP leases or certain DHCP leases based on
MAC address or IP address.
nAdded speedtest command for performing on-demand
iPerf or nuttcp speedtests.
nLocal users are now required to be assigned to an
authentication group.
nNew Network → Advanced → Sequential DHCP address
allocation configuration setting for controlling if DHCP
addresses are assigned sequentially or randomly
(disabled by default).
nAdded ability to control if DHCP addresses are assigned
sequentially or randomly (disabled by default).
nAdded 802.1x port-based network access control,
configurable per network interface.
JDecember 2021 Release of Digi TX54 firmware version 21.11:
nConfiguration option to allow for automatic update of
new firmware (disabled by default).
nUser authentication enhancements:
lAdded TACACS+ command authorization and
accounting for Admin CLI commands.
lAdded a new username alias to provide an
alternate username that allows for special
characters in the username.
TX54 User Guide 5

Revision Date Description
nWi-Fi enhancements:
lPKI certificate-based authentication for
WPA2/WPA3 Enterprise Wi-Fi client connections,
including options for SCEP client integration for
automatic certificate generation.
lImproved Wi-Fi scanning tool on the Status page to
automatically setup the underlying basic client-
mode settings so the device can scan for nearby
APs without requiring the user to first configure the
client-mode settings.
nVPNenhancements:
lAdded support for PPP-over-L2TP tunnels.
lChanged default IPsec IKE DH group to 14 for
enhanced compatibility with industry standard
settings.
nLocation services enhancements:
lNew option for Location service to specify the
talker ID used in NMEA mesage strings.
lInclude the mode indicator field in NMEA messages
constructed when a GPS fix isn’t obtained.
nSureLink enhancments:
lAdded new settings under cellular Surelink options
to have the device reset the cellular modem if a
specified number of Surelink tests fail
lAdded show surelink Admin CLI command.
nSerial port enhancements:
lNew option to add and configure an external USB-
to-serial adapter.
lDisable serial history in remote access mode by
default.
nSupport for sending analog and digial I/O health
metrics to Digi Remote Manager.
nAdded show containers Admin CLI command.
KMarch 2022 Release of Digi TX54 firmware version 22.2:
nVPNenhancements:
lRenamed VPN >IPsec >Tunnels >Policies >Local
network setting to Local traffic selector and
added Remote traffic selector.
lAdded a Dynamic option to the Local traffic
selector to configuration of a local network by
protocol and/or port instead of a network address
TX54 User Guide 6

Revision Date Description
range.
lAdded Protocol and Port match criteria for Local
traffic selector and Remote traffic selector.
lAdded VPN >IPsec >Advanced >Debug level to
specify the logging verbosity of IPsec messages in
the device system logs.
nAdded the ability to use the on-board GNSS module as
a time source.
nEnhancements to communications with Digi Remote
Manager:
lEnhanced security for communications with Digi
Remote Manager by using client-side certificates.
lThe default URL for the device's Remote Manager
connection is now edp12.devicecloud.com. This
URL is required to utilize the client-side certificate
support.
nNew Switch SIM SureLink action for WWAN interfaces,
which allows SureLink to be configured to switch to the
alternate SIM if the modem is connected but SureLink
test are failing.
lNew Switch SIM fail count option to determine
how many SureLink failures are required prior to
switching to the alternate SIM.
nNew Socket ID string option to send the configured
text to the remote server(s) when a TCP socket
connection is opened to the serial port.
nNew system power ignition off_delay CLI command
for manually adjusting the power off delay from
ignition sensors without having to adjust the
configuration settings of the Digi device
nNew cat Admin CLI command for displaying file
contents.
Trademarks and copyright
Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States
and other countries worldwide. All other trademarks mentioned in this document are the property of
their respective owners.
© 2022 Digi International Inc. All rights reserved.
Disclaimers
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International. Digi provides this document “as is,” without warranty of
any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or
TX54 User Guide 7

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual
or in the product(s) and/or the program(s) described in this manual at any time.
Warranty
To view product warranty information, go to the following website:
www.digi.com/howtobuy/terms
Customer support
Gather support information: Before contacting Digi technical support for help, gather the following
information:
Product name and model
Product serial number (s)
Firmware version
Operating system/browser (if applicable)
Logs (from time of reported issue)
Trace (if possible)
Description of issue
Steps to reproduce
Contact Digi technical support: Digi offers multiple technical support plans and service packages.
Contact us at +1 952.912.3444 or visit us at www.digi.com/support.
Feedback
To provide feedback on this document, email your comments to
[email protected]
Include the document title and part number (TX54 User Guide, 90002357 H) in the subject line of your
email.
TX54 User Guide 8

Contents
Revision history—90002357 2
What's new in Digi TX54 version 22.2
Digi TX54 Quick Start
Step 1: Connect your device 23
Step 2: Connect DC power 24
Step 3: Set up access to Digi Remote Manager 25
Step 4: Register your device 25
Step 5: Complete setup 25
Step 6: Configure cellular APN 25
Digi TX54 hardware reference
Digi TX54 features and specifications 27
TX54 accessories 27
TX54 front view 27
TX54 LEDs 28
Single cellular models 28
Dual cellular models 28
Dual Wi-Fi models 28
Power 28
GNSS Service 29
Wi-Fi Service (single Wi-Fi models) 29
Wi-Fi1 Service (dual Wi-Fi models) 29
Wi-Fi2 Service (dual Wi-Fi models) 29
WWAN Signal 29
WWAN Service 29
Ethernet 1-4 Link and Activity (on rear panel) 29
Power sensor and button behavior 30
TX54 back view 30
Digi TX54 serial connector pinout 30
QR code definition 31
Hardware setup
Install SIM cards 33
Apply Dielectric Grease over SIMContacts 33
Tips for improving cellular signal strength 34
TX54 User Guide 9

TX54 User Guide 10
Connect data cables 34
Connect antennas 34
Mount the TX54 to a mounting surface 34
Connect power 35
Mount and ground chassis 35
TX54 electrical rating 36
TX54 power connector 37
Battery power management 37
Configuration and management
Review TX54 default settings 39
Local WebUI 39
Digi Remote Manager 39
Default interface configuration 39
Other default configuration settings 43
Change the default password for the admin user 43
Reset default SSIDs and pre-shared keys for the preconfigured Wi-Fi access points 45
Configuration methods 47
Using Digi Remote Manager 49
Access Digi Remote Manager 49
Using the web interface 49
Log out of the web interface 50
Use the local RESTAPI to configure the TX54 device 50
Use the GETmethod to return device configuration information 50
Use the POST method to modify device configuration parameters and list arrays 52
Use the DELETE method to remove items from a list array 53
Using the command line 55
Access the command line interface 55
Log in to the command line interface 55
Exit the command line interface 56
Interfaces
Wide Area Networks (WANs) 58
Wide Area Networks (WANs) and Wireless Wide Area Networks (WWANs) 60
Configure WAN/WWAN priority and default route metrics 60
WAN/WWAN failover 63
Configure SureLink active recovery to detect WAN/WWAN failures 64
Configure the device to reboot when a failure is detected 75
Disable SureLink 83
Example: Use a ping test for WAN failover from Ethernet to cellular 87
Using Ethernet devices in a WAN 91
Using cellular modems in a Wireless WAN (WWAN) 92
Configure a Wide Area Network (WAN) 116
Configure a Wireless Wide Area Network (WWAN) 125
Show WAN and WWAN status and statistics 135
Delete a WAN or WWAN 137
Default outbound WAN/WWAN ports 139
Local Area Networks (LANs) 140
About Local Area Networks (LANs) 141
Configure a LAN 141
Example: Configure two LANs 149
Show LAN status and statistics 159

TX54 User Guide 11
Delete a LAN 161
DHCP servers 163
Create a Virtual LAN (VLAN) route 179
Default services listening on LANports 182
Bridging 183
Edit the preconfigured LAN1 bridge 185
Configure a bridge 188
Show Surelink status and statistics 192
Show Surelink status for all interfaces 192
Show Surelink status for a specific interface 193
Show Surelink status for all IPsec tunnels 193
Show Surelink status for a specific IPsec tunnel 194
Show Surelink status for all OpenVPN clients 194
Show Surelink status for a specific OpenVPN client 195
Serial port
Default serial port configuration 196
Serial mode options 196
Add a USBserial port 196
View serial port information 196
Default serial port configuration 196
Configure Login mode 197
Configure Remote Access mode 199
Configure Application mode 204
Configure UDP serial mode 206
Configure Modbus mode 211
Add a USB serial port 215
Show serial status and statistics 229
Log serial port messages 230
Wi-Fi
Wi-Fi configuration 232
Default access point SSID and password 232
Default Wi-Fi configuration 232
Configure the Wi-Fi radio's channel 234
Configure the Wi-Fi radio to support DFS channels in client mode 236
Required configuration items 236
Configure the Wi-Fi radio's band and protocol 238
Configure the Wi-Fi radio's transmit power 241
Configure an open Wi-Fi access point 242
Configure a Wi-Fi access point with personal security 249
Configure a Wi-Fi access point with enterprise security 256
Isolate Wi-Fi clients 265
Isolate clients connected to the same access point 265
Isolate clients connected to different access points 266
Configure a Wi-Fi client and add client networks 273
Show Wi-Fi access point status and statistics 282
Show Wi-Fi client status and statistics 284

TX54 User Guide 12
Hotspot
Hotspot authentication modes 287
Hotspot DHCP server 288
Hotspot security 288
Hotspot configuration 289
Enable hotspot using the default configuration 290
Change the default hotspot SSID 295
Change the default hotspot IP address and subnet 297
Change the default hotspot bandwidth limits 300
Add an Ethernet port to the default hotspot 302
Use policy routes with hotspot 304
Create a new hotspot 305
Configure the hotspot to use local shared password authentication 318
Configure the hotspot to use RADIUSshared password authentication 320
Configure the hotspot to use RADIUS users authentication 324
Configure the hotspot to use HotspotSystem authentication 328
Show hotspot status and statistics 331
Customize the hotspot login page 334
Edit sample hotspot HTML pages 335
Upload custom hotspot HTML pages 336
Restore hotspot default sample pages 338
Hotspot RADIUS attributes 339
Routing
IP routing 341
Configure a static route 342
Delete a static route 345
Policy-based routing 347
Configure a routing policy 347
Example: Dual WAN policy-based routing 356
Example: Route traffic to a specific WAN interface based on the client MACaddress 359
Routing services 364
Configure routing services 365
Show the routing table 367
Dynamic DNS 369
Configure dynamic DNS 370
Virtual Router Redundancy Protocol (VRRP) 375
VRRP+ 375
Configure VRRP 375
Configure VRRP+ 379
Example: VRRP/VRRP+ configuration 387
Configure device one (master device) 388
Configure device two (backup device) 392
Show VRRP status and statistics 398
Virtual Private Networks (VPN)
IPsec 401
IPsec data protection 401
IPsec mode 401
IPsec modes 401
Internet Key Exchange (IKE) settings 401

TX54 User Guide 13
Authentication 402
Configure an IPsec tunnel 402
Configure IPsec failover 429
Configure SureLink active recovery for IPsec 432
Show IPsec status and statistics 439
Debug an IPsec configuration 440
Configure a Simple Certificate Enrollment Protocol client 442
Example: SCEP client configuration with Fortinet SCEP server 447
Disable hardware cryptographic acceleration 451
Disable hardware cryptographic acceleration 453
OpenVPN 455
Configure an OpenVPN server 456
Configure an OpenVPN Authentication Group and User 465
Configure an OpenVPN client by using an .ovpn file 469
Configure an OpenVPN client without using an .ovpn file 472
Configure SureLink active recovery for OpenVPN 476
Show OpenVPN server status and statistics 484
Show OpenVPN client status and statistics 485
Generic Routing Encapsulation (GRE) 487
Configuring a GREtunnel 487
Show GRE tunnels 492
Example: GRE tunnel over an IPSec tunnel 493
L2TP 508
Configure a PPP-over-L2TP tunnel 508
Configure SureLink active recovery for PPP-over-L2TP 518
L2TP with IPsec 526
Show L2TP tunnel status 526
L2TPv3 Ethernet 528
Configure an L2TPv3 tunnel 528
Show L2TPV3 tunnel status 533
NEMO 534
Configure a NEMO tunnel 534
Show NEMO status 540
Services
Allow remote access for web administration and SSH 543
Configure the web administration service 546
Configure SSHaccess 556
Use SSH with key authentication 563
Generating SSH key pairs 563
Configure telnet access 566
Configure DNS 571
Show DNS server 577
Simple Network Management Protocol (SNMP) 578
SNMP Security 578
Configure Simple Network Management Protocol (SNMP) 578
Download MIBs 583
Location information 585
Configure the location service 586
Configure the internal GNSS module 588
Use a dead reckoning external USB GNSS receiver 591
Configure the device to use a user-defined static location 593
Configure the device to accept location messages from external sources 595
Forward location information to a remote host 599

TX54 User Guide 14
Configure geofencing 606
Show location information 618
Modbus gateway 619
Configure the Modbus gateway 620
Show Modbus gateway status and statistics 633
System time 636
Configure the system time 636
Manually set the system date and time 640
Network Time Protocol 640
Configure the device as an NTP server 641
Show status and statistics of the NTP server 646
Configure a multicast route 647
Ethernet network bonding 651
Enable service discovery (mDNS) 653
Use the iPerf service 657
Example performance test using iPerf3 661
Configure the ping responder service 662
Example performance test using iPerf3 666
Applications
Configure scripts to run automatically 668
Task one: Upload the application 668
Task two: Configure the application to run automatically 670
Configure scripts to run manually 674
Task one: Upload the application 675
Task two: Configure the application to run automatically 676
Start a manual script 679
Stop a script that is currently running 680
Show script information 681
Run a Python application at the shell prompt 682
Start an interactive Python session 684
Digidevice module 686
Use digidevice.cli to execute CLI commands 687
Use digidevice.datapoint to upload custom datapoints to Digi Remote Manager 688
Use digidevice.config for device configuration 691
Use Python to respond to Digi Remote Manager SCI requests 693
Use digidevice runtime to access the runtime database 702
Use Python to upload the device name to Digi Remote Manager 704
Use Python to access the device location data 706
Use Python to set the maintenance window 710
The digidevice led submodule 712
Use Python to send and receive SMS messages 714
Use the Human Interface Device (HID) module 716
Help for the hid module 717
Use Python to access serial ports 718
Use the Paho MQTTpython library 719
User authentication
TX54 user authentication 724
User authentication methods 724
Add a new authentication method 726
Delete an authentication method 728

TX54 User Guide 15
Rearrange the position of authentication methods 730
Authentication groups 732
Change the access rights for a predefined group 733
Add an authentication group 735
Delete an authentication group 739
Local users 742
Change a local user's password 743
Configure a local user 745
Delete a local user 753
Terminal Access Controller Access-Control System Plus (TACACS+) 755
TACACS+ user configuration 756
TACACS+ server failover and fallback to local authentication 757
Configure your TX54 device to use a TACACS+ server 757
Remote Authentication Dial-In User Service (RADIUS) 762
RADIUS user configuration 763
RADIUS server failover and fallback to local configuration 763
Configure your TX54 device to use a RADIUS server 764
LDAP 767
LDAP user configuration 769
LDAP server failover and fallback to local configuration 770
Configure your TX54 device to use an LDAP server 770
Configure serial authentication 775
Disable shell access 777
Set the idle timeout for TX54 users 779
Example user configuration 782
Example 1: Administrator user with local authentication 782
Example 2: RADIUS, TACACS+, and local authentication for one user 784
Firewall
Firewall configuration 792
Create a custom firewall zone 792
Configure the firewall zone for a network interface 794
Delete a custom firewall zone 796
Port forwarding rules 797
Configure port forwarding 797
Delete a port forwarding rule 802
Packet filtering 805
Configure packet filtering 805
Enable or disable a packet filtering rule 809
Delete a packet filtering rule 811
Configure custom firewall rules 813
Configure captive portals 815
Delete captive portals 819
Configure Quality of Service options 820
Web filtering 831
Configure web filtering with Cisco Umbrella 831
Configure web filtering with manual DNS servers 834
Verify your web filtering configuration 837
Show web filter service information 839
Containers
Upload a newLXCcontainer 841

TX54 User Guide 16
Configure a container 842
Starting and stopping the container 845
Starting the container 845
Stopping the container 846
View the status of containers 846
Show status of all containers 847
Show status of a specific container 847
Schedule a script to run in the container 848
Create a custom container 850
Create the custom container file 850
Test the custom container file 851
System administration
Review device status 854
Configure system information 855
Update system firmware 857
Manage firmware updates using Digi Remote Manager 857
Certificate management for firmware images 858
Downgrading 858
Dual boot behavior 862
How to recover a TX54 that will not boot 863
Update cellular module firmware 864
Update modem firmware over the air (OTA) 865
Update modem firmware by using a local firmware file 870
Reboot your TX54 device 873
Reboot your device immediately 873
Schedule reboots of your device 874
Erase device configuration and reset to factory defaults 875
Configure the TX54 device to use custom factory default settings 879
Locate the device by using the Find Me feature 881
Configure power button behavior 882
Configure power input voltage 883
Power ignition sensor 885
Configure power delays for power ignition sensor 886
Temporarily set the ignition power delay 888
Configure automatic reboot behavior for temporary power drop 888
Configuration files 890
Save configuration changes 890
Save configuration to a file 891
Restore the device configuration 892
Schedule system maintenance tasks 895
Disable device encryption 900
Re-enable cryptography after it has been disabled. 901
Configure the speed of your Ethernet ports 902
Monitoring
intelliFlow 906
Enable intelliFlow 906
Use intelliFlow to display average CPU and RAMusage 909
Use intelliFlow to display top data usage information 910
Use intelliFlow to display data usage by host over time 912
Configure NetFlow Probe 913

TX54 User Guide 17
Enable the Bluetooth scanner 918
Display the output of the Bluetooth scanner. 923
Enable the Wi-Fi scanner 925
Required configuration 925
Additional configuration 925
Display the output of the Wi-Fi scanner. 933
Central management
Digi Remote Manager support 938
Certificate-based enhanced security 938
Configure Digi Remote Manager 938
Collect device health data and set the sample interval 945
Enable event log upload to Digi Remote Manager 948
Log into Digi Remote Manager 950
Use Digi Remote Manager to view and manage your device 951
Add a device to Digi Remote Manager 952
View Digi Remote Manager connection status 952
Configure multiple devices using profiles 953
Learn more 954
File system
The TX54 local file system 956
Display directory contents 956
Create a directory 957
Display file contents 958
Copy a file or directory 958
Move or rename a file or directory 959
Delete a file or directory 960
Upload and download files 961
Upload and download files by using the WebUI 961
Upload and download files by using the Secure Copy command 962
Upload and download files using SFTP 963
Diagnostics
Perform a speedtest 966
Generate a support report 966
View system and event logs 968
View System Logs 968
View Event Logs 970
Configure syslog servers 972
Configure options for the event and system logs 974
Analyze network traffic 979
Configure packet capture for the network analyzer 980
Example filters for capturing data traffic 989
Capture packets from the command line 990
Stop capturing packets 991
Show captured traffic data 992
Save captured data traffic to a file 993
Download captured data to your PC 994
Clear captured data 995

TX54 User Guide 18
Use the ping command to troubleshoot network connections 997
Ping to check internet connection 997
Stop ping commands 997
Use the traceroute command to diagnose IProuting problems 997
Digi TX54 regulatory and safety statements
RF exposure statement 999
Federal Communication (FCC) Part 15 Class B 999
Radio Frequency Interference (RFI) (FCC 15.105) 999
European Community - CE Mark Declaration of Conformity (DoC) 999
ANATEL (Brazil) 1001
Maximum transmit power for radio frequencies 1002
Innovation, Science, and Economic Development Canada (IC) certifications 1002
RoHS compliance statement 1003
Special safety notes for wireless routers 1003
Product disposal instructions 1004
Safety warnings
English 1006
Bulgarian--б ъ л га р с ки 1007
Croatian--Hrvatski 1008
French--Français 1009
Greek--Ε λληνικά 1010
Hungarian--Magyar 1011
Italian--Italiano 1012
Latvian--Latvietis 1013
Lithuanian--Lietuvis 1014
Polish--Polskie 1015
Portuguese--Português 1016
Slovak--Slovák 1017
Slovenian--Esloveno 1018
Spanish--Español 1019
DigiTX54 Certifications
International EMC (Electromagnetic Compatibility) and safety standards 1020
Command line interface
Access the command line interface 1022
Log in to the command line interface 1022
Exit the command line interface 1023
Execute a command from the web interface 1023
Display help for commands and parameters 1024
The help command 1024
The question mark (?) command 1024
Display help for individual commands 1025
Use the Tab key or the space bar to display abbreviated help 1026
Auto-complete commands and parameters 1026
Available commands 1028
Use the scp command 1029

TX54 User Guide 19
Display status and statistics using the show command 1030
show config 1030
show system 1031
show network 1031
Device configuration using the command line interface 1032
Execute configuration commands at the root Admin CLI prompt 1032
Display help for the config command from the root Admin CLI prompt 1032
Configuration mode 1034
Enable configuration mode 1034
Enter configuration commands in configuration mode 1034
Save changes and exit configuration mode 1035
Exit configuration mode without saving changes 1035
Configuration actions 1035
Display command line help in configuration mode 1036
Move within the configuration schema 1039
Manage elements in lists 1040
The revert command 1042
Enter strings in configuration commands 1044
Example: Create a new user by using the command line 1044
Example: Configure multiple WANs and LANs by using the command line 1046
Command line reference 1056
analyzer clear 1057
analyzer save 1058
analyzer start 1058
analyzer stop 1058
clear dhcp-lease ip-address 1058
clear dhcp-lease mac 1059
container create 1059
container delete 1059
cp 1059
help 1060
ls 1061
mkdir 1062
modem at 1062
modem at-interactive 1062
modem firmware check 1062
modem firmware list 1062
modem firmware ota check 1063
modem firmware ota list 1063
modem firmware ota update 1063
modem firmware update 1063
modem pin change 1064
modem pin disable 1064
modem pin enable 1064
modem pin status 1065
modem pin unlock 1065
modem puk status 1065
modem puk unlock 1065
modem reset 1066
modem scan 1066
modem sim-slot 1066
monitoring 1066
monitoring metrics upload 1067
more 1067
mv 1067

TX54 User Guide 20
ping 1067
reboot 1069
rm 1070
scp 1071
show analyzer 1071
show arp 1071
show cloud 1071
show config 1072
show containers 1072
show dhcp-lease 1072
show dns 1072
show event 1072
show hotspot 1073
show ipsec 1073
show l2tp lac 1073
show l2tp lns 1073
show l2tpeth 1074
show location 1074
show log 1074
show manufacture 1074
show modbus-gateway 1074
show modem 1075
show nemo 1075
show network 1075
show ntp 1075
show openvpn client 1076
show openvpn server 1076
show route 1076
show serial 1076
show scripts 1077
show surelink interface 1077
show surelink ipsec 1077
show surelink openvpn 1077
show system 1078
show usb 1078
show version 1078
show vrrp 1078
show web-filter 1078
show wifi ap 1079
show wifi client 1079
show wifi-scanner 1079
show wifi-scanner blocklist 1080
show wifi-scanner candidates 1080
show wifi-scanner log 1080
speedtest 1080
ssh 1081
system backup 1081
system disable-cryptography 1081
system duplicate-firmware 1081
system factory-erase 1082
system find-me 1082
system firmware ota check 1082
system firmware ota list 1082
system firmware ota update 1083
system firmware update 1083
