Digi Connect WAN Sync Edge 10 User manual

Connect WAN Sync Edge 10
© Digi International Inc., 2005.
Digi, Digi International, the Digi logo, the Making Device Networking Easy logo, Digi Connect, and RealPort
are trademarks or registered trademarks of Digi International, Inc. in the United States and other countries worldwide.
All other trademarks are the property of their respective owners.
Quick Start Guide
What you will need
A SIM card must be supplied and activated
by a Cellular Service Provider for device
operation.
Digi Connectware
Manager CD
Antenna
Digi Connect WAN Sync
SIM
1234
5678
9101
1121
AT&TSIM
*SIM card not included
HARDWARE
Connect Hardware
The Link LED will
remain on steady
and the Active
LED will blink
when connection
is active.
cross-over Ethernet
cable
PN:(1P)
A 90000735-88
Power (green)
steady blinking;
seeking or waiting
for an IP address
ACT (yellow)
on - network
traffic detected
(off when no
traffic detected)
Diagnostic (yellow)
flashes 3 times
during startup or
reset indicating
successful startup.
Reset
Network Link
(green) on
Ethernet activity or
access point engaged
1234
5678
9101
1121
Orient SIM card* with metal
side down and short corner to
the outside. Use caution to
insure card is properly seated
in SIM socket.
SIM
2
CONFIGURE
DB-25M to DB-9F
Connect
power supply.
Connect
antenna.
1
!Warning: Do not over-tighten the antenna. Over-tightening may
damage internal connections. Loosen antenna before adjusting
antenna angles.
Connect
Ethernet cable
to your laptop.
4
Open your web browser and enter
the IP 192.168.1.1 into the URL address
bar.
From the web
interface, under
Configuration click
Mobile. Enter your
service provider name
and connection
parameters and click
Apply.
1
The ConnectPort WAN has DHCP server enabled by default.
In order to discover your Digi device, make sure your host
computer is setup to obtain IP addresses automatically.
Also ensure all firewall software is temporarily disabled.
!
Under Management click Connections to verify your
device has been properly provisioned. To test your
configuration and verify proper Ethernet to cellular
routing, see the back of this guide.
3
Configure Cellular Settings
VERIFY
Verify Cellular Connection
2

Test the Configuration
The following test scenario will prove proper routing of the
cellular to Ethernet interface.
Hub/
Switch
TCP
socket
2001
Connect the Digi Connect WAN IA to your network.
If your device is not registered, verify you have
entered the proper provisioning information
on the Configuation > Mobile page. If your device
shows poor signal strength move the device
and/or antenna to a different location.
Internet
Cellular
Network
1
23
4
Test Your Digi Connect WAN Sync Edge 10
Discover device using Digi Discovery Utility, click on
IP address
Check your connection across the celluar network - Click
Status Info > Diagnostics
www.digi.com Select PING
