Digiop NT1000 User manual

1
www.digiop.com
DO_NT1000_CoQ
Congratulations on your new DIGIOP® Video and Data Management System
This guide provides setup instructions for your server hardware.
For more information, contact DIGIOP® Support at
877.972.2522 Toll Free • [e-mail] • www.digiop.com
DIGIOP® NT1000 Chassis
Hardware Quick Start Guide
Video and Data Management Systems

2
1. Getting Started
Unpacking the Contents
The following are included with your system. Please inspect these and the
other system components while unpacking.
• Quick Start Guide
• Surge Protection Notice
• MS Windows Disk
• Driver Disk
• Application DVD
• External Power Supply
Choose a Proper Location
Select a location for the system that meets the following requirements.
Notice: Excessive heat can shorten the life of electronics.
• Adequate ventilation to avoid excessive heat (climate-controlled environment)
• Uninterrupted Power Supply (UPS)
• Moisture-free environment
• A place away from direct sunlight
• An area with minimal dust or debris
Site Installation
Hardware Setup – Connect all input devices and external peripherals to the system. Follow the order of connections displayed in Step 3.
• IP Camera(s)
• VGA Monitor
• Ethernet
• Mouse
• Keyboard
• Power Adapter
• PTZ Camera(s) - Optional
• Audio in (microphone) - Optional
• Powered Speakers - Optional
Notice: For proper indoor and outdoor cameras an in-line surge suppressor or equivalent should be used to reduce exposure to surges and lightning strikes.
2. About Your System
Drive Bay
(Not Used)
USB 2.0 Port
Vertical Stand
Power Button
Power Status
LED
HDD Status
LED
4-in-1 Card
Reader
Kensington
Lock
LAN Port
VGA Port
Power
Connector
(DC IN)
Headphone/
Line Out
USB 2.0
Ports (4)
Front Back
www.digiop.com

3
www.digiop.com
3. Setting Up Your System
1. Connect your monitor to the VGA port. 2. Connect your keyboard and mouse. You can use any of the available USB ports.
3. Connect the network cable. 4. Connect the power adapter to the computer, then plug it into a standard 120 VAC outlet.
5. Power on the computer and monitor.
Press

4
Notes
