Digital Equipment MicroVAX 3100 90 Guide

MicroVAX3100
Model90
Troubleshooting and Diagnostic
Information
Order Number: EK–A0607–TI. B01
December 1993
This manual describes the troubleshooting procedures and diagnostic com-
mands that you can use to solve basic problems with the MicroVAX 3100
Model 90 system.
Revision Information: This manual supersedes EK–A0607–TI. A01
Digital Equipment Corporation
Maynard, Massachusetts

December 1993
Digital Equipment Corporation makes no representations that the use of its products in the
manner described in this publication will not infringe on existing or future patent rights, nor do
the descriptions contained in this publication imply the granting of licenses to make, use, or sell
equipment or software in accordance with the description.
Possession, use, or copying of the software described in this publication is authorized only
pursuant to a valid written license from Digital or an authorized sublicensor.
© Digital Equipment Corporation 1993. All Rights Reserved.
The postpaid Reader’s Comments forms at the end of this document request your critical
evaluation to assist in preparing future documentation.
The following are trademarks of Digital Equipment Corporation: Digital, MicroVAX, OpenVMS,
RX, ThinWire, VAX, VAX DOCUMENT, and the DIGITAL logo.
S2452
This document was prepared using VAX DOCUMENT Version 2.1.

Contents
Preface ..................................................... v
1 Troubleshooting and Diagnosing Problems
1.1 Troubleshooting ...................................... 1–1
1.2 Using the Troubleshooting Table . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1.3 Diagnostic Tests and Commands . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
1.3.1 Power-UpTests ................................... 1–10
1.3.2 Diagnostic Tests and Utilities . . . . . . . . . . . . . . . . . . . . . . . . 1–13
1.3.3 Power-Up Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
1.3.4 ConfigurationDisplay .............................. 1–21
1.3.5 ErrorDisplay..................................... 1–23
1.4 Contacting Digital Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–24
Index
Figures
1–1 Successful Power-Up Test Display . . . . . . . . . . . . . . . . . . . . . 1–10
1–2 DiagnosticTests................................... 1–13
1–3 StatusLEDDisplay................................ 1–25
Tables
1–1 Basic Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
1–2 OptionCardTests ................................. 1–15
1–3 MicroVAX 4000-100A Tests . . . . . . . . . . . . . . . . . . . . . . . . . . 1–16
iii

Preface
This manual describes the troubleshooting procedures and diagnostic
commands that you can use to solve basic problems with the MicroVAX™ 3100
Model 90 system.
Audience
This manual is intended for people who have some experience with computers.
Structure of This Manual
This manual has one chapter and an index.
Additional Information
See the MicroVAX 3100 Model 90 Operator Information manual for the list of
associated and related documents.
v

Conventions
The following conventions are used in this manual:
Convention Description
MONOSPACE Text displayed on the screen is shown in monospace type.
italic type Italic type emphasizes important information and indicates the
complete titles of manuals.
boldface type Boldface type in examples indicates user input. Boldface type in text
indicates the first instance of terms defined in the text.
Note A note contains information that is of special importance to the user.
Warning A warning contains information to prevent personal injury.
vi

1
Troubleshooting and Diagnosing Problems
This chapter describes the troubleshooting procedures and diagnostic commands that
you can use to solve basic problems with the MicroVAX 3100 Model 90 system. It
contains information on the following:
• Troubleshooting
• Diagnostic tests and commands
• Contacting Digital™ Services
It also lists the information that you must give to your Digital Services
representative and where to find this information.
1.1 Troubleshooting
If a problem occurs, you must first make sure that all the cables, loopback
connectors, and terminators are correctly connected and that the connectors
are not damaged, for example, the pins may be broken or short-circuited.
Follow these steps:
1. Shut down the operating system following the procedures described in the
operating system documentation.
2. Turn off the console terminal and all the peripheral devices, such as
printers and modems.
3. Turn off all the expansion boxes.
4. Turn off the system unit.
5. Check that the following cables, if installed, are correctly connected at both
ends and that the connectors are not damaged:
• Console terminal cable (linking the console terminal to the system unit)
• Console terminal power cord
• System unit power cord
Troubleshooting and Diagnosing Problems 1–1

• Expansion box SCSI cables
• Expansion box power cords
• ThinWire™ Ethernet cable or standard Ethernet cable
6. Check that the following terminators, if installed, are correctly connected
and are not damaged:
• SCSI terminators
• ThinWire Ethernet terminator (T-connector and two terminators)
• Standard Ethernet loopback connector
If you have correctly followed steps 1 to 5, the on/off switches on all
the components are set to the off (O) position, and you have solved any
problems caused by incorrectly connected cables or terminators.
7. Set the on/off switches on the following equipment to the on (| ) position in
the following order:
a. Expansion boxes
b. Peripherals
c. Console terminal
d. System unit
The system responds with the power-up test display. If it does not, see
Section 1.2.
1.2 Using the Troubleshooting Table
Table 1–1 suggests the corrective actions for certain system problems. If you
have a problem with the system, follow these steps:
1. Write down the symptoms of the problem.
2. Check the Symptom column in Table 1–1 for a match.
3. Check the causes of the symptom in the Possible Cause column. If the
column lists more than one possible cause, check the possible causes and
their suggested solutions in the order listed.
4. Follow the advice in the Suggested Solution column.
5. See Section 1.4 if the problem persists.
1–2 Troubleshooting and Diagnosing Problems

Table 1–1 Basic Troubleshooting
Symptom Possible Cause Suggested Solution
System Problems
The system unit fan is off
or the power light is off. The power cord is not
connected. The power cord
may be faulty. The power
socket may not be working.
The system breaker or wall
outlet may have blown.
Make sure that all the power cords
are connected correctly at both
ends. Try a known good power cord
or test the power socket with an
appliance that works.
The overload protection
circuitry of the power
supply may have shut down
because of an abnormal
condition on the power line.
Turn the system off and then turn
it back on.
The power supply unit
(PSU) is faulty. Contact your Digital Services
representative.
The power-up display does
not show after 20 seconds. The terminal cable is not correctly connected. Make sure that all the cables are connected at both ends.
The terminal cable is not
connected to the correct
MMJ port.
Check the MMJ port to which the
terminal cable is connected. If this
port is not MMJ port 3, remove the
terminal cable and connect it to
MMJ port 3.
The power cord is not
connected. The power cord
may be faulty. The wall
outlet may not be working.
Make sure that all the power cords
are connected correctly at both
ends. Try a known good power cord
or test the power socket with an
appliance that works.
The terminal fuse may have
blown. Replace the blown terminal fuse.
See the terminal documentation.
The terminal settings may
be incorrect. See the MicroVAX 3100 Model 90 Operator Information manual for
the list of correct terminal settings.
See the terminal documentation for
information on how to set up the
terminal.
(continued on next page)
Troubleshooting and Diagnosing Problems 1–3

Table 1–1 (Cont.) Basic Troubleshooting
Symptom Possible Cause Suggested Solution
System Problems
The port to which the
terminal connects may be
faulty.
Try connecting the terminal to
another system. If this solution
works, the port to which the
terminal was connected is faulty.
If the terminal still does not
operate, it is faulty. In either
case, contact your Digital Services
representative.
The terminal cable may be
faulty. Connect the terminal cable and
the terminal to another system.
If the connected terminal works,
the DZ circuitry or MMJ connector
is faulty. Otherwise, the cable
is faulty. Contact your Digital
Services representative.
The power-up display
contains question marks. A diagnostic error has
occurred. See Section 1.4.
The power-up test display
contains unexpected
characters.
The terminal settings are
incorrect or the DZ circuitry
is faulty.
Make sure the terminal settings
are correct, then run the power-
up test again. If the terminal is
set correctly, contact your Digital
Services representative.
The system fails to boot the
operating system. The system defaults are
incorrectly set. Set the system defaults as described in the OpenVMS Factory
Installed Software User Information
document, then try to boot the
system again. If the system still
fails to boot, contact your Digital
Services representative.
(continued on next page)
1–4 Troubleshooting and Diagnosing Problems

Table 1–1 (Cont.) Basic Troubleshooting
Symptom Possible Cause Suggested Solution
RRD42 Compact Disc Drive Problems
The drive does not accept
the caddy. The disc is upside-down in
the caddy or it is not placed
correctly in the caddy.
Remove the disc from the caddy
and reinsert it properly.
A caddy is already present. Eject the caddy and replace it with
a new one.
The eject button fails to
eject the caddy. The eject button is disabled by software. Reenable the eject button or
manually eject the caddy.
The system does not have
power. Set the system unit on/off switch to the on ( |) position and press the
eject button again.
The RRD42 compact disc
drive is faulty. If you want to eject the caddy
manually, see MicroVAX 3100
Model 90 Operator Information
for instructions. If the problem
persists, contact your Digital
services representative.
(continued on next page)
Troubleshooting and Diagnosing Problems 1–5

Table 1–1 (Cont.) Basic Troubleshooting
Symptom Possible Cause Suggested Solution
TZ30 Tape Drive Problems
The TZ30 green LED
flashes rapidly. The drive mechanism is
faulty or the tape cartridge
is damaged.
Press and release the unload button
to clear the fault. If the LED
continues to flash, do not try to
remove the tape cartridge or use
the tape drive. Contact your Digital
Services representative.
The TZ30 does not operate. The drive does not contain
a tape cartridge. Insert the tape cartridge and slide the lever from the UNLOCK to the
LOCK position.
The operate lever does not
slide. The tape cartridge is in use. Wait for the green LED to turn
on and try again. If the problem
persists, do not use the drive.
Contact your Digital Services
representative.
The operate lever does not
lock. The tape cartridge is not
inserted correctly. Reinsert the tape cartridge. If
the problem persists, contact your
Digital Services representative.
The tape does not load. Press and release the unload
button. Wait for the green LED
to turn on before sliding the lever
and removing the tape. If the
LED flashes, contact your Digital
Services representative.
The system cannot write to
the tape. The write-protect switch
is in the write-protect
position.
If the write-protect LED is on,
remove the tape, reset the switch
and try writing to the tape again. If
the problem persists, contact your
Digital Services representative.
The data read from the tape
cartridge is corrupted. The tape drive head may be
dirty. See the MicroVAX 3100 Model 90
Operator Information manual for
information on how to clean the
drive head.
The tape does not eject. The tape is not rewound.
The operate lever is in the
lock position.
Follow the procedure for removing a
tape from the TZ30 described in the
MicroVAX 3100 Model 90 Operator
Information manual.
(continued on next page)
1–6 Troubleshooting and Diagnosing Problems

Table 1–1 (Cont.) Basic Troubleshooting
Symptom Possible Cause Suggested Solution
TLZ06 Cassette Tape Drive Problems
The system cannot write to
the cassette tape. The write-protect switch
is in the write-protect
position.
If the write-protect LED is on,
remove the tape, reset the switch
and try writing to the tape again. If
the problem persists, contact your
Digital Services representative.
The cassette tape is not
loaded. Load the cassette tape.
The write-protect LED
flashes. The tape drive heads are dirty or the tape is worn. Clean the drive heads (see the MicroVAX 3100 Model 90 Operator
Information manual). If the
problem persists, use a new tape.
The data read from the
cassette tape is corrupted. The tape drive heads may
be dirty. See the MicroVAX 3100 Model 90
Operator Information manual for
information on how to clean the
drive heads.
TZK10/TZK11 Quarter Inch Cartridge (QIC) Tape Drive Problems
The data read from the QIC
tape is corrupted. The drive head is dirty. Clean the drive head. See the MicroVAX 3100 Model 90 Operator
Information manual.
The system cannot write to
the QIC tape. The write-protect switch is in the write-protect
position.
Remove the QIC tape, reset the
switch and try to write to the
QIC tape again. If the problem
persists, contact your Digital
Services representative.
The system cannot read
from or write to the QIC
tape.
The QIC tape may be faulty. Remove the QIC tape. If the amber
LED turns off when you remove
the QIC tape, the tape is probably
faulty. Try a different QIC tape.
If the amber LED stays on or if
the problem persists, contact your
Digital Services representative.
(continued on next page)
Troubleshooting and Diagnosing Problems 1–7

Table 1–1 (Cont.) Basic Troubleshooting
Symptom Possible Cause Suggested Solution
RX™26 Diskette Drive Problems
The system cannot read
from or write to the
diskette.
The diskette is not
formatted. Format the diskette.
The diskette is not correctly
inserted. Eject the diskette. Try to insert the
diskette again.
The diskette is faulty. Try a different diskette.
The diskette drive is faulty. Contact your Digital Services
representative.
The diskette density is
incorrect. The RX26 accepts only high-
density (HD) or extra-density (ED)
diskettes.
The diskette drive head
may be dirty. See the MicroVAX 3100 Model 90
Operator Information manual for
information on how to clean the
diskette drive head.
The system can read
from but cannot write to
a diskette.
The write-protect switch
is in the write-protect
position.
Eject the diskette and reset the
switch. Try writing to the diskette
again.
The diskette does not eject. The diskette is incorrectly
positioned in the drive. Gently press the diskette with your
finger and reposition it. Press the
eject button again.
RZ-Series SCSI Disk Drive Problems
An installed drive does not
work. Two SCSI identifiers are set to the same number. Reset each SCSI ID to a unique number.
Drive cables not properly
connected. Check the cable connections.
The Configuration display
does not show a SCSI
device.
SCSI device is not properly
terminated. Check for a SCSI 50-pin terminator.
Two SCSI identifiers are set
to the same number. Reset each SCSI ID to a unique
number.
1–8 Troubleshooting and Diagnosing Problems

1.3 Diagnostic Tests and Commands
There are a number of diagnostic tests and commands that can help you to
isolate a problem with the system unit. These tests and commands are as
follows:
• Power-up tests
• Diagnostic tests and utilities1
• Configuration display1
• Error display1
The following sections describe these tests and commands.
1You can use these tests and commands in privileged console mode only if the console
security feature is enabled and the password is set. See the MicroVAX 3100 Model 90
Customer Technical Information manual for information on the console security
feature.
Troubleshooting and Diagnosing Problems 1–9

1.3.1 Power-Up Tests
The system runs the power-up tests each time you turn on the system. After
successful completion of tests, the system will either enter Console mode or
proceed to automatic bootstrap, depending on the HALT action selected by
the user. If HALT action is Default, Halt, or Restart, then the system enters
console mode. If HALT action is Reboot or Restart_reboot, then the system
proceeds to boot. The following example shows a typical display for a system
that passes all tests and then enters console mode.
Figure 1–1 Successful Power-Up Test Display
KA50-A V2.3, VMB 2.14

Performing normal system tests.
74..73..72..71..70..69..68..67..66..65..64..63..62..61..60..59..
58..57..56..55..54..53..52..51..50..49..48..47..46..45..44..43..

42..41..40..39..38..37..36..35..34..33..32..31..30..29..28..27..
26..25..24..23..22..21..20..19..18..17..16..15..14..13..12..11..
10..09..08..07..06..05..04..03..
Tests completed.

>>>


Central Processing Unit (CPU) Name, Firmware Version Number, and
Virtual Memory Boot (VMB) Version Number

Read-Only Memory (ROM) Based Diagnostics Countdown

Status Message

Console Prompt
The following example shows a typical display for a system that passes all
tests and then enters automatic bootstrap.
KA50-A V2.3, VMB 2.14
Performing normal system tests.
74..73..72..71..70..69..68..67..66..65..64..63..62..61..60..59..
58..57..56..55..54..53..52..51..50..49..48..47..46..45..44..43..
42..41..40..39..38..37..36..35..34..33..32..31..30..29..28..27..
26..25..24..23..22..21..20..19..18..17..16..15..14..13..12..11..
10..09..08..07..06..05..04..03..
Tests completed.
Loading system software.
(BOOT/R5:0 EZA0)
2..
-EZA0
1..0..
1–10 Troubleshooting and Diagnosing Problems

Note
The operating system messages start here, i.e. VMS ..........
If the power-up tests encounter an error, one of the following actions occurs:
For minor errors:
• If HALT action is set to a boot condition (that is reboot or
restart_reboot), and if a minor error occurs, the system displays an
abbreviated error message and continues to boot as normal.
• If HALT action is set to Default, Halt or Restart, then the system
enters console mode.
• The only errors defined as minor are errors in memory that cause pages
to be marked bad in the memory bitmap. There must be enough good
memory left to allow an attempt to bootstrap.
For severe errors:
• The system always enters console mode regardless of HALT action after
it attempts to complete all tests possible.
The following example shows a system with a memory error that only affected
one set of memory out of two sets. Because some memory is still usable, the
system proceeds to automatic bootstrap if the HALT action is set to a boot
condition.
KA50-A V2.3, VMB 2.14
Performing normal system tests.
74..73..72..71..70..69..68..67..66..65..64..63..62..61..60..59..
58..57..56..55..54..53..52..51..50..49..48..47..46..45..44..43..
42..41..40..39..38..37..36..35..34..33..32..
? Test_Subtest_40_06 Loop_Subtest=00 Err_Type=FF DE_Memory_count_pages.lis
31..30..29..28..27..26..25..24..23..22..21..20..19..18..17..16..
15..14..13..12..11..10..09..08..07..06..05..04..03..
16 MB RAM, SIMM Set (0A,0B,0C,0D) present
Memory Set 0: 04000000 to 04FFFFFF, 16MB, 0 good pages, 32768 bad pages
64 MB RAM, SIMM Set (1E,1F,1G,1H) present
Memory Set 1: 00000000 to 03FFFFFF, 64MB, 131072 good pages, 0 bad pages
Total of 80MB, 131072 good pages, 32768 bad pages, 136 reserved pages
Troubleshooting and Diagnosing Problems 1–11

Tests completed.
Loading system software.
(BOOT/R5:0 EZA0)
2..
-EZA0
1..0..

? Test_Subtest_40_06 Loop_Subtest=00 Err_Type=FF DE_Memory_count_pages.lis

16 MB RAM, SIMM Set (0A,0B,0C,0D) present
Memory Set 0: 04000000 to 04FFFFFF, 16MB, 0 good pages, 32768 bad pages
64 MB RAM, SIMM Set (1E,1F,1G,1H) present
Memory Set 1: 00000000 to 03FFFFFF, 64MB, 131072 good pages, 0 bad pages
Total of 80MB, 131072 good pages, 32768 bad pages, 136 reserved pages

Operating system messages start here; i.e. VMS ......

Abbreviated error message for memory error
Memory errors normally cause the results of a SHOW MEMORY display to
occur after the tests are completed and before continuing. SHOW MEMORY is
the most useful command to determine which memory SIMMs are bad when
memory errors occur.
1–12 Troubleshooting and Diagnosing Problems

1.3.2 Diagnostic Tests and Utilities
The diagnostic tests and utilities are similar to the power-up tests except that
the power-up tests enable you to test all the devices in the system, whereas the
diagnostic tests and utilities enable you to test single devices and the functions
of single devices.
Figure 1–2 shows a list of diagnostic tests obtained by entering the following
command:
>>> T 9E
Figure 1–2 Diagnostic Tests
Test
# Address Name Parameters
___________________________________________________________________________
20052200 SCB
20055850 De_executive
30 2006A53C Memory_Init_Bitmap *** mark_Hard_SBEs ******
31 2006AB34 Memory_Setup_CSRs *********
32 2005D148 NMC_registers **********
33 2005D324 NMC_powerup **
34 2005E6D8 SSC_ROM ***
35 2005FB90 B_Cache_diag_mode bypass_test_mask *********
37 20061590 Cache_w_Memory bypass_test_mask *********
40 2006B5E0 Memory_count_pages SIMM_set0 SIMM_set1 Soft_errs_allowed *****
41 20068CEC Board_Reset *
42 20061880 Chk_for_Interrupts **********
46 200610C4 P_Cache_diag_mode bypass_test_mask *********
47 2006AD04 Memory_Refresh start_a end incr cont_on_err time_seconds *****
48 2006B028 Memory_Addr_shorts start_add end_add * cont_on_err pat2 pat3 ****
4A 2006A23C Memory_ECC_SBEs start_add end_add add_incr cont_on_err ******
4B 2006940C Memory_Byte_Errors start_add end_add add_incr cont_on_err ******
4C 20069BA0 Memory_ECC_Logic start_add end_add add_incr cont_on_err ******
4D 20068FE8 Memory_Address start_add end_add add_incr cont_on_err ******
4E 20069188 Memory_Byte start_add end_add add_incr cont_on_err ******
4F 2006B7F4 Memory_Data start_add end_add add_incr cont_on_err ******
51 2005803C FPA **********
52 20058530 SSC_Prog_timers which_timer wait_time_us ***
53 20058818 SSC_TOY_Clock repeat_test_250ms_ea Tolerance ***
54 20057C18 Virtual_Mode ********
55 20058E6C Interval_Timer *****
56 2006507C SHAC_LPBCK From_bus To_bus passes *******
58 20065D24 SHAC_RESET dssi_bus port_number time_secs not_pres *
59 20062778 SGEC_LPBCK_ASSIST time_secs **
(continued on next page)
Troubleshooting and Diagnosing Problems 1–13

Figure 1–2 (Cont.) Diagnostic Tests
5C 20062D10 SHAC SHAC_number *********
5F 200619B8 SGEC loopback_type no_ram_tests ******
62 20058B1C console_QDSS mark_not_present selftest_r0 selftest_r1 *****
63 20058CA4 QDSS_any input_csr selftest_r0 selftest_r1 ******
80 2005D3C0 CQBIC_memory bypass_test_mask *********
81 200596CC Qbus_MSCP IP_csr ******
82 200598AC Qbus_DELQA device_num_addr ****
83 2005A85C QZA_Intlpbck1 controller_number ********
84 2005BF1C QZA_Intlpbck2 controller_number *********
85 20059A9C QZA_memory incr test_pattern controller_number *******
86 20059F44 QZA_DMA Controller_number main_mem_buf ********
90 20058494 CQBIC_registers *
91 20058410 CQBIC_powerup **
99 2005DC4C Flush_Ena_Caches dis_flush_VIC dis_flush_BC dis_flush_PC
9A 20063FB0 INTERACTION pass_count disable_device *******
9B 20068E48 Init_memory **
9C 2006631C List_CPU_registers *
9D 2006C250 Utility Flags *********
9E 2005903C List_diagnostics script_number *
9F 200681CC Create_A0_Script **********
C1 20057888 SSC_RAM_Data *
C2 20057A78 SSC_RAM_Data_Addr *
C5 200589E8 SSC_registers *
D0 20060C70 V_Cache_diag_mode bypass_test_mask *********
D2 2005DE90 O_Bit_diag_mode bypass_test_mask *********
DA 2006139C PB_Flush_Cache **********
DB 2005E850 Speed print_speed *********
DC 2006C060 NO_Memory_present *
DD 2005F0DC B_Cache_Data_debug start_add end_add add_incr *******
DE 2005EC64 B_Cache_Tag_Debug start_add end_add add_incr *******
DF 2005E2A8 O_BIT_DEBUG start_add end_add add_incr seg_incr ******
E0 2006D4D4 SCSI environment reset_bus time_s *******
E1 2006D7CC SCSI_Utility environment util_nbr target_ID lun ******
E2 2006DA2C SCSI_MAP bypass_test addr_incr_data_tst ********
E4 2006DFC8 DZ environment *********
E8 2006E1DC SYNC environment *********
E9 2006E2B4 SYNC_Utility environment *********
EC 2006E398 ASYNC environment *********
F0 2006D638 SCSI_option environment reset_bus time_s *******
F1 2006D900 SCSI_Opt_Utility environment util_nbr target_ID lun ******
F2 2006DA40 SCSI_MAP_Option bypass_test addr_incr_data_tst ********
Scripts
# Description
(continued on next page)
1–14 Troubleshooting and Diagnosing Problems
