Digital Watchdog D2252DIR SERIES User manual

D2252DIR, D2262DIR Series
About manual
INSTRUCTION MANUAL
Before installing and using the camera, please read this
manual carefully.
Be sure to keep it handy for future reference.
5436 W Crenshaw St.
Tampa, FL 33634
www. digital-watchdog.com
Technical Support : 1-866-446-3595 / 813-888-9555
Before installing and using the camera, please read this
manual carefully.
Be sure to keep it handy for future reference.
5436 W Crenshaw St.
Tampa, FL 33634
www. digital-watchdog.com
Technical Support : 1-866-446-3595 / 813-888-9555

PRECAUTIONS
■Do not open or modify
Do not open the case except during maintenance and installation,
as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances
get inside the camera. It could cause fire, short-circuits or damages.
■Be careful when handling the unit
To prevent damage, do not drop the camera or subject it to
strong shock or vibration.
■Install away from electric or magnetic fields
■Protect from humidity and dust
■Protect from high temperature
Be careful when installing close to the ceiling , in a kitchen or boiler
room, as the temperature may rise to high levels.
■Do not open or modify
Do not open the case except during maintenance and installation,
as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances
get inside the camera. It could cause fire, short-circuits or damages.
■Be careful when handling the unit
To prevent damage, do not drop the camera or subject it to
strong shock or vibration.
■Install away from electric or magnetic fields
■Protect from humidity and dust
■Protect from high temperature
Be careful when installing close to the ceiling , in a kitchen or boiler
room, as the temperature may rise to high levels.
■Cleaning
Dirt can be removed from the case only by wiping it with a soft cloth
moistened with a soft detergent solution.
■Mounting Surface
The mounting surface material must be strong enough to support
the camera.

TROUBLESHOOTING
Before sending the camera out for repair, check the items below.
If the problem persists after checking these items, contact your service
center.
■If no image appears
Is the coaxial cable attached securely?
Are the power and voltage normal?
Has the iris of the lens inside the camera been
adjusted correctly (with the level volume) ?
Is there adequate illumination?
■If the image is unclear
Is the lens in focus?
Is the lens dirty?
Dirt or fingerprints on the lens can adversely affect the
images. Gently wipe any dirt or fingerprints off the lens
with a soft cloth or lens cleaning paper and cleaning
fluid (commercially available).
Before sending the camera out for repair, check the items below.
If the problem persists after checking these items, contact your service
center.
■If no image appears
Is the coaxial cable attached securely?
Are the power and voltage normal?
Has the iris of the lens inside the camera been
adjusted correctly (with the level volume) ?
Is there adequate illumination?
■If the image is unclear
Is the lens in focus?
Is the lens dirty?
Dirt or fingerprints on the lens can adversely affect the
images. Gently wipe any dirt or fingerprints off the lens
with a soft cloth or lens cleaning paper and cleaning
fluid (commercially available).
Is the monitor adjusted correctly?
WARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

DIMENSION (mm)
D2252DIR, D2262DIR series

INSTALLATION
E
D
C
F
C
D
E
F
E
A
B
D
C
F
A
B
C
D
E
F

INSTALLATION (cont.)
A. Loosen the fixing screw using the L-wrench that came with the camera
B. Separate the upper case and the base case.
C. Cut a hole in the ceiling for routing the cables.
D. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
E. Pass the power cable and video cable from the camera
unit through the cable hole in the ceiling.
F. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
G. Install and adjust the camera unit.
H. Adjust the dome liner to show the lens through the camera
window
and attach it
to the base
A. Loosen the fixing screw using the L-wrench that came with the camera
B. Separate the upper case and the base case.
C. Cut a hole in the ceiling for routing the cables.
D. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
E. Pass the power cable and video cable from the camera
unit through the cable hole in the ceiling.
F. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
G. Install and adjust the camera unit.
H. Adjust the dome liner to show the lens through the camera
window and attach it to the base.
I. Put the upper case and the base together.
J. Tighten the screws with the L-wrench for the upper and base not to be
separated .

CONNECTION
DC12
V
DC12V / AC24V
CAUTION :
Check for polarity when using a DC 12V power supply.
DC12
V
DC12V / AC24V

■LENS ADJUSTMENT
CAMERA SETTINGS
B. Focus lever
A. Zoom Lever
A. Set the zoom lever to the desired position by moving the Zoom lever.
B. Set the Focus lever as the image is focused by moving the Focus lever.
B. Focus lever
A. Zoom Lever

D2252DIR, D2262DIR Series
(1)
Adj ti l l l (VR)
2'nd Video
Joy Stick Key
VR
(1) Adjusting level volume (VR
)
If the entire image is too dark or bright, or the backlight compensation is not correct
even after LENS is set to "DC", you need to adjust the level volume.
CCW (Low) Closes the lens iris, making the entire image darker
CW(High) Opens the lens iris, making the entire image brighter
(2) SECOND VIDEO OUT CONNECTOR (2ND VIDEO)
If installer uses a portable monitor, this connector should be connected.
2'nd Video
Joy Stick Key
VR

OSD MENU SETTINGS - D2252DIR, D2262DIR
SETUP FUNCTION SUMMARY
LENS MANUAL.DC - DC : bright level
SHUTTER FIXED,MANUAL,FLK - MANUAL : Manual shutter adjust.
- BLC AREA
- BLC RA TIO
AGC ON,OFF - AGC GAIN: Min~ Max
- MA NUA L : RED,BLUE
- FIXED : MODE 1,2,3,4
- CONTRA ST adjus t.
- SHARPNESS adjust.
- CB_GAIN adjust.
- CR_GAIN adjust.
FUNCTION ☜
- CA MERA ID
- POSITION
MIRROR ON,OFF - Mirror image on/off
- AUTO: DELAY
START LEVELDA Y NIGHT A UTO,B/W,COLOR
ADJUST CONTRA ST,SHA RPNESS
CB_GA IN,CR_GA IN
CAMERA ID ON,OFF
BLC ON,OFF
WHITE BAL ATW,A WB,FIXED,MANUAL
SETUP FUNCTION SUMMARY
LENS MANUAL.DC - DC : bright level
SHUTTER FIXED,MANUAL,FLK - MANUAL : Manual shutter adjust.
- BLC AREA
- BLC RA TIO
AGC ON,OFF - AGC GAIN: Min~ Max
- MA NUA L : RED,BLUE
- FIXED : MODE 1,2,3,4
- CONTRA ST adjus t.
- SHARPNESS adjust.
- CB_GAIN adjust.
- CR_GAIN adjust.
FUNCTION ☜
- CA MERA ID
- POSITION
MIRROR ON,OFF - Mirror image on/off
- AUTO: DELAY
START LEVEL
END LEVEL
- AREA
- MOTION TH
- MOTION TRA CE ON/OFF
- AREA SEL
- AREA STATE
GAMMA USER, 0.05~1.0 - GAMMA set.
LA NGUA GE ENGLISH,Korean,Chinese1,Chinese
2,日本語 - Language set.
RESET YES,NO - Returns to the level
EXIT - Save out
PRIVACY ON.OFF
DA Y NIGHT A UTO,B/W,COLOR
MOTION ON,OFF
ADJUST CONTRA ST,SHA RPNESS
CB_GA IN,CR_GA IN
CAMERA ID ON,OFF
BLC ON,OFF
WHITE BAL ATW,A WB,FIXED,MANUAL
