Digital Watchdog DWC-D2252DIR User manual

Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
ABOUT MANUAL
12232010
User Manual
Indoor Dome Camera
DWC-D2252DIR, D2262DIR, D2362DIR
DWC-D2363D, D2363TIR
DWC-D2367WD, D2367WTIR

GGDonot open or modify.
GGDonot open the case except during maintenanceand installation,
for it may bedangerous and can cause damages.
GDonot put objects into the unit.
GGGG
or other damages.
GGGBe careful when handling the unit.
Toprevent damages, do not drop the camera or subjectit to shockor vibration.

Protectfrom humidity and dust.
Protectfrom high temperature.

Be careful when installing near the ceiling of akitchen or aboiler room,as the temperature may rise to
high levels.
Cleaning
Toremovedirt from the case, moisten asoft cloth with asoft detergent solution and wipe.
Mounting Surface
The material of the mounting surfacemust bestrong enough to support the camera. GGGGGGGGGGGGGGGGGGGGGGGGGGG
PRECAUTIONS
This equipment has been tested and found to complywith the limits for aClass Bdigital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonableprotection against harmful
interference, when the equipment is operated in aresidential environment. This equipment generates, uses,
and radiates radio frequencyenergy; and if it is not installed and used in accordancewith the instruction
manual,it may cause harmful interferenceto radio communications.
WARNING
:Changes or modications are not expresslyapproved bythe manufacturer.
FCC COMPLIANCE
2

Before sending your camera for repair, checkthe following or contactour technical specialist.
No Video
Checkthe coaxial cableand make sure it is connected securely.
Checkthe lens’ iris adjustment at the menu setup of the camera.
Checkthe power supplyand make sure the camera has the proper voltage and current.
Out-of-Focus Video
Checkthe lens manual focal and zoom adjustment. Fieldtest monitor is recommended.
TROUBSHOOTING
3

4
1/3” Sony Super HAD II CCD
420 TV Lines
3.6mm Fixed Lens (D2252DIR)
3.3 ~ 12m Varifocal Auto Iris Lens (D2262DIR)
100ft Range IR with Intelligent Camera Sync
Electronic Day and Night
DRC (Dynamic Range Compressor)
HME (Highlight Masking Exposure)
SLC (Side Light Compensation)
AGC / BLC / AWB
NegativeImaging
Mirror Image Control
ProgrammablePrivacyZone (4) & Motion Detection
Easy Icon Driven OSD Menu with Built-in Joystick
Auto Sensing 12VDC/24VAC with Line Lock
12VDC Transformer Included
Secondary Video-BNC Output
FEATURES*-D2252DIR, D2262DIR

5
FEATURES*-D2362DIR
1/3” Sony Super HAD II CCD
540TV Lines
3.3 ~ 12mm Varifocal Auto Iris Lens
100ft Range IR with Intelligent Camera Sync
Electronic Day and Night
DRC (Dynamic Range Compressor)
HME (Highlight Masking Exposure)
SLC (Side Light Compensation)
AGC / BLC / AWB
NegativeImaging
Mirror Image Control
12VDC Transformer Included
ProgrammablePrivacyZone (4) & Motion Detection
Easy Icon Driven OSD Menu with Built-InJoystick
Secondary Video-BNC Output
FEATURES*-D2363D
1/3" Sony Super HAD II CCD560TV Lines
3.3~12mm Varifocal Auto Iris Lens
Electronic Day and Night
Star-Light (Super Low Light Technology)
DRC (Dynamic Range Compressor)
3D-DNR (3D Digital Noise Reduction)
HME (Highlight Masking Exposure)

6
FEATURES*-D2363TIR
1/3” Sony Super HAD II CCD
High Resolution 560TV Lines
3.3 ~ 12mm Varifocal Auto Iris Lens
100ft Range IR with Intelligent Camera Sync
True Day and Night / TDN5
Star-Light (Super Low Light Technology)
DRC (Dynamic Range Compressor)
3D-DNR (3D Digital Noise Reduction)
HME (Highlight Masking Exposure)
AGC / BLC / AWB
ProgrammablePrivacyZone (8) & Motion Detection
Easy Icon Driven OSD Menu with Built-in Joystick
Auto Sensing 12VDC/24VAC with Line Lock
Secondary Video-BNC Output
BLC (BackLight Compensation)
ProgrammablePrivacyZone (8) & Motion Detection
Easy Icon Driven OSD Menu with Built-in Joystick
Auto Sensing 12VDC/24VAC with Line Lock
Secondary Video-BNC Output

7
FEATURES*-D2367WD
1/3”Sony Super HAD II CCD
560 TVLines
3.3 ~12mm Varifocal Auto Iris Lens
Electronic Day and Night
EWDR (Electronic Wide Dynamic Range)
Star-Light (Super LowLight Technology)
DSS (Digital SlowShutter)
3D-DNR (3DDigital Noise Reduction)
DIS (Digital Image Stabilizer)
HME (Highlight Masking Exposure)
AGC /BLC /AWB
Programmable Privacy Zone (6) &Motion Detection
Easy Icon Driven OSD Menu with Built-in Joystick
Auto Sensing 12VDC/24VAC with Line Lock
Secondary Video-BNC Output

8
FEATURES*-D2367WTIR
1/3”Sony Super HAD II CCD
560 TVLines
3.3 ~12mm Varifocal Auto Iris Lens
100ft Range IR with Intelligent Camera Sync
True Day and Night /TDN5
EWDR (Electronic Wide Dynamic Range)
Star-Light (Super LowLight Technology)
DSS (Digital SlowShutter)
3D-DNR (3DDigital Noise Reduction)
DIS (Digital Image Stabilizer)
HME (Highlight Masking Exposure)
AGC /BLC /AWB
Programmable Privacy Zone (6) &Motion Detection
Easy Icon Driven OSD Menu with Built-in Joystick
Auto Sensing 12VDC/24VAC with Line Lock
Secondary Video-BNC Output

9
DIMENSION (mm)*
109.6
103.1
41.3
6.5145
117.0
125.0
5.0
4.5
91.0
91.0
85.0
85.0
L= 300mm
RS485 (Black+ & White -)
VIDEO (YELLOW)
BNC JACK
DC 12V or AC24V
5mm TWIST SOLDERING
RED
BLACK

10
Power Requirement *
Power Wire Maximum Distance
Wire Gauge 12VDC 24VAC
24 AWG 80ft 323ft
22 AWG 128ft 513ft
20 AWG 203ft 815ft
18 AWG 323ft 1295ft
16 AWG 514ft 2056ft
14 AWG 816ft 3264ft
12AWG 1295ft 5183ft
10AWG 2057ft 8228ft
Coaxial Cable Type Maximum Distance
RG59/U 750ft
RG6/U 1,000feet
RG11/U 1,500feet
Power Requirement
12VDC at 1A
24VAC at 500mA

11
INSTALLATION*
Included with Digital Watchdog Camera:
1.User Manual
2. Mounting Template
3. Security L-Key
4.SingleSided Hex Key
5.Secondary BNC Cablefor aFieldMonitor
6.Four (4) Screwsand Four (4) Dry Wall
Anchors
X
Z
Y
[
\
^
]
Camera Installation
Use the Mounting Template (2) when mounting the camera.
Use the Security L-Key (3) to loosen the Four Screwsthat secure the vandal-proof dome cover.
Removethe cover; then, removethe inner screw holes to mount the camera.
NOTE

12
INSTALLATION*
A.Loosen the Screws(A) with the Security L-Key
included with your camera.
B. Separate the Upper Case (B) from the Base (F).
C.Cut aholein the ceiling for routing the cables.
D.Use the Mounting Template to drill the four
screw holes on the surfaceof the ceiling.
E.Pass the Power Cable(C) and the Video Cable(E)
from the camera unit through the holein the
ceiling.
F.Align the screw holes of the camera unit with
the holes in the ceiling. Secure the four screws.
G.Install and adjust the camera unit.
H.Assemblethe Upper Case (B) and the Base (F).
I.Put the upper case and the base together.
J.Tighten the outer Screws(A) using the Security
L-Key.

13
CONNECTION*
Video Output BNC Cable
Main Monitor
Field Test Monitor
Spot Monitor Cable
DC12V/AC24V

14
LENSADJUSTMENT*
A. Move the Zoom Lever until you get the desired position.
B. Move the Focus Lever until you get the desired focus.
A. Zoom Lever
B.Focus Lever

15
D2252DIR, D2262DIR, D2362DIR, D2363D, D2363TIR, D2367WD, D2367WTIR
CAMERASETTING & ON-SCREENDISPLAY*
Field Test Monitor Video Output
RS485 Connector
Dip Switch for the IR Remote Controller
Mini Joystick for the Menu Setup
LEFT
UP DOWN
RIGHT

16
MODULEOSD MENU*(D2252DIR, D2262DIR, D2362DIR)
EXPOSURE COLORDAY&NIGHT
BRIGHTNESS
SHUTTER
BLC
AGC
WB MODE D&N MODE
FUNCTION MOTION PRIVACY
MIRROR
SHARPNESS
GAMMA
SLC
HME
DRC
ALARM MASK 1
MASK 2
MASK 3
MASK 4
COLOR SET
SYNCSETUPEXIT
SYNC CAMERA ID
TITLE EDIT
TITLE RESET
TITLE POSITION
DPC SET
LANGUAGE
PC CONT.
EXIT
SAVE &EXIT
FACTORY RESET

17
EXPOSURE
BRIGHTNESS MANUAL (ELC LEVEL : 0~ 100) / DC (DC LEVEL : 0~ 31)
SHUTTER 1/60, 1/100FLC,1/120 ~ 1/100000
BLCOFF / ON
BLC (BackLight Compensation)
AGC OFF / 12dB ~ 36dB
AGC (Auto Gain Control)
COLOR
WBMODE AWC / ATW / MANUAL / PUSHLOCK (AWC is recommended.)
R-Y GAIN0~ 255
B-Y GAIN0~ 255
DAY & NIGHT
Day & Night Mode
AUTO / COLOR / BW
COLOR --> BW: Switching from COLOR to BW; Ifthe number is higher, the camera will only
switchduring asuper low light condition.
BW --> COLOR: nahtrewolsyawlaebdluohsre
bmunsihT;ROLOCotWBmorfgnihctiwS
COLOR --> BW
Read Time: Time interval to switchfrom COLOR to BW
COLOR:
BW: BURST (OFF/ON); When the burst is OFF,the picture will haveless noise.
OSD MENU*(D2252DIR, D2262DIR, D2362DIR)
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET

18
FUNCTION
MIRROROFF/ MIRROR
SHARPNESS 0~ 49
GAMMA USER / 0.45 / 0.6 / 1.00
SLCOFF / ON (0~ 50)
SLC (Side Light Compensation)
HMEOFF / ON (0~ 55)
HME (Highlight Masking Exposure)
DIS OFF /ON
DIS (Digital Image Stabilizer)
MOTION (OMNI-Plus Cameras Only)
MOTION
OFF / ON
SET WINDOW
ALL SET (Set the Entire Screen)
ALL CLEAR (Clear the Entire Screen)
SENSITIVITY (0~ 55)
SHOW INDICATOR (OFF / ICON / TRACE)
DELAY OUT(1 ~ 15)
Motion Alarm Zoom-InDelay
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET

19
PRIVACY
MASK 1 OFF / ON
MASK 2 OFF / ON
MASK 3 OFF / ON
MASK 4 OFF / ON
COLOR SETBLACK / GRAY / COLOR 1~ 6
SYNC
SYNC MODE INTERNAL / AUTO
V-PHASE 0~ 199
SETUP
CAMERAID 0~ 255
TITLE EDIT
TITLE RESET
TITLE POS.
DPC OFF / AUTO
DPC ( Dead Pixel Cancellation)
LANGUAGE English / Chinese
PC CONT. OFF / ON
EXIT
EXITExit the menu
SAVE&EXITExit the menu and savethe setting
FACTORY SETReset the menu setting to factory default
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET
EXITJUMPEXIT / SAVE&EXIT / FACTORY SET

20
MODULEOSD MENU*(D2363D, D2363TIR)
EXPOSURE COLORDAY&NIGHT
BRIGHTNESS
SHUTTER
BLC /HME
AGC
STARLIGHT
WB MODE
R-Y GAIN
B-Y GAIN
D&N MODE
C_SUP
A_SUP
FUNCTION MOTION PRIVACY
MIRROR
SHARPNESS
GAMMA
FREEZE
NEGATIVE
D-ZOOM
3DDNR
DRC
MOTION PRIVACY
SYNCSETUPEXIT
SYNC TITLE EDIT
PC CONTROL
LANGUAGE
MONITOR
OSD COLOR
OMNI LENS
EXIT
SAVE &EXIT
FACTORY RESET
