USB-C™ UNIVERSAL
DOCKING STATION, 8 PORT
Quick Installation Guide
DA-70884

Description
The DIGITUS® USB-C™ docking station extends your notebook by 8
additional interfaces. Among other things, 2 HDMI® interfaces with
resolutions of up to 4K / 30 Hz are integrated. When connecting 2
monitors simultaneously, a resolution of Full HD 1080P / 60 Hz is
supported. While the docking station is in use, you can charge the
connected notebook via the existing USB-C™ Power Delivery Port.
The maximum charging capacity is 100 W. 2 x USB 3.0 connections
are also included to which according periphery devices such as a
keyboard, mouse or an external hard drive / USB stick can be
connected. With Battery Charge (BC 1.2), they also offer the
possibility of charging devices such as smartphones or tablets. You
can connect the existing Gigabit RJ45 connection with your router
and, thus, the Internet. This then allows you to access your
connected notebook. Two card slots for SD and Micro SC cards round
off the docking station. Memory cards of up to 2 TB are supported.
The compact housing with a brushed aluminum finish boasts a stylish
and elegant look and is easily portable. Thanks to Plug and Play, a
driver installation is not required. This way, the docking station can
also be connected to external systems quickly.
Instant Expansion with comprehensive functional ports:
•2x USB 3.0 port
•2x 4K HDMI
•1x Gigabit
•1x USB-C for PD Charging
•1x Micro SD
•1x SD
Note: The 2 charts below list the resolutions of the 2 video ports
under SST and MST mode

Under SST Mode
HDMI
Single Port Connected
4K/30Hz
Dual Ports Connected
1080P/60Hz
Under MST Mode
HDMI
Single Port Connected
4K/30Hz
Dual Ports Connected
1080P/60Hz
•Supported devices (for example):
2016/2017/2018 MacBook Pro, 2015/2016/2017 MacBook,
ChromeBook, ASUS Transformer 3 Pro, Dell XPS 12 9365 and
newer, HP Elite X2, Spectre x360 13, 15, Pro Convertible, Huawei
Matebook, Lenovo IdeaPad 720s, ThinkPad T470, T570, X1 Yoga,
720, 920, Microsoft Surface Book 2 and Pro, Razer Blade Stealth,
Samsung Galaxy Tab Pro S and many more USB-C devices with
Power Delivery and DP Alternate mode support
•Features 2 USB 3.0 ports and Type-C pass-through charging port,
2 port USB3.0 data transfer speed reach up to 5Gbps. 2-ports USB
allow you connect various appliances like keyboards, mouse,
USB flash drives, etc. to your type C devices
•2 USB3.0 ports support BC 1.2 charging function, with an auto
switching mode
•2x HDMI supports up to 4K resolution video at 30Hz and
1920 x 1080 (1080p) at 60Hz. Delivering crystal clear, high quality
video and audio. 2xHDMI support MST function under Window
system. Mirror or extend two displays with the USB C adapter
HDMI ports simultaneously. Perfect for presentations, movie
nights and more.
•1 Gigabit Ethernet port gives access to super fast network speed,
backward compatible with 10/100 ethernet.

•Quickly charge your Type-C laptop while simultaneously using
other USB ports.
•Brushed aluminum finish complements your Apple accessories
for a timeless and modern desk set up.
•Supported Systems: Macbook (USB Type-C™) - Mac OS X (Mac OS
doesn’t support MST), Chromebook Pixel - Chrome OS, Windows
10/8.1/8/7
How to Connect
Connect the adapter directly to your computer.
Connect your USB devices to any of the USB ports.
2x HDMI Port - Transmits high-definition audio and video from
computer or tablet to HDMI display for streaming and gaming
with resolution up to full 4K@30Hz, also supports 1080p, 720p,
480p and other.
Easy to use and carry, hot swap supportable.
No extra driver required.
Product Feature
1) Chipset:VL102/VM3332/PS176/VL817/GL3224/RTL8153B
2) Material:Aluminium
3) Cable Length:20 cm
4) Weight:78 g
5) Operating Temperature: 0℃to 40℃(35°F to 100°F)
6) Operating Humidity: 20% RH to 80% RH
Package Content:
1x USB-C Universal Docking Station, 8 Port
1x QIG (Quick Installation Guide)

Hereby Assmann Electronic GmbH, declares that the Declaration of
Conformity is part of the shipping content. If the Declaration of
Conformity is missing, you can request it by post under the below
mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
