Digitus DisplayPort DA-70472 User manual

DisplayPort – HDMI Converter
(4K2K/60Hz)
Manual
DA-70472
The Digitus DisplayPort - HDMI Converter converts a DisplayPort signal to output to
HDMI monitors in a brilliant UHD resolution (4K2K/60Hz). Supports HDR10, Dolby
Vision HDR/HDCP 2.2, 1.4. Use DisplayPort output to connect your HDMI screens/TVs
to your PC/laptop quickly and easily, whether for private or business applications
such as presentations, etc.

Features
A. DisplayPort1.4 Receiver
Up to 5.4Gbps link rate supporting HBR2/HBR/RBR modes
1, 2 or 4 lanes configuration
Up to 600MHz dual pixel path and 16bits.
RGB/YCbCr 4:4:4 or 4:2:2 or 4:2:- pixel format.
Supports DP to HDMI Stereoscopic 3D transport
Supports LPCM and Compressed Audio encoding formats, max
audio sample rate of 192 KHz x 8 Channel or 768 KHz x
2 Channel.
B. HDMI Transmitter
600MHz maximum TMDS character color.
Deep color up to 16 bits per color.
High Dynamic Range support (Static and Dynamic HDR)
3D video timings.
CEC Support- snooping, tunneling.
SCDC read request handling, polling enabled for HDMI sinks,
not supporting read requests.
Max video resolution and color depth on HDMI TX output
4K60Hz, RGB/YCbCr 4:4:4, 8bits
4K60Hz, YCbCr 4:2:2 up to 12bits
4K60Hz, YCbCr 4:2:0 up to 16bits
4K30Hz, RGB/YCbCr 4:4:4 up to 16bits
C. Audio stream forwarding form DP Receiver to HDMI Transmitter
Up to 8CH, 192 kHz, 24bits LPCM audio, AC3, DTS, Dolby-HD
2CH, 768 kHz 24 bits HBR audio
D. Support: HDCP1.4 /2.2 repeater function
E. Support: HDMI HDR10/Dolby Vision HDR/HLG
Package Content
•DisplayPort to HDMI converter
•Manual

Application Diagram:
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity
is part of the shipping content. If the Declaration of Conformity is missing, you
can request it by post under the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
HDMI 2.0 Cable
4K Monitor/T
V
PC
