1.Log into the Switch Web Interface
The default management address of the switch is 192.168.10.12/24, when logging
into the web management page of the switch, you need to set the IP address of the
local network card and the IP address of the switch are in the same segment, as
shown in the following screen: the IP address of the local network card is set to
192.168.10.222/24.
Enter the management address of the switch in the search bar of the browser, screen
as below:
Confirm to enter the web verification page of the switch.
User Name: admin
Password: admin.
Click login to login to the web interface of the switch.

4
2.Switch Information
This module is used to view the internal data of the switch when it is running,
including the flow rate of the port, the working mode, and the log information of the
switch.
2.1 Global Information
The following functions are in included:
○1View the current port status, port working mode and port speed of the switch.
Move the mouse to the icon and he port name, status, bandwidth, duplex
mode, and rate will be displayed.

5
Indicates that the port has been enabled and the connection has been
established, indicates that the port is not enabled, and indicates the
optical port.
○2View the switch property information, click in the page to
synchronize the local computer time with the system time of the switch.
○3To check the CPU and memory usage of the switch.
2.2 Statistical Information
To check the message data received and sent by various ports, including Basic Packet
Statistics, Detailed Packet Statistics, MAC Frame Length Statistics and MAC Frame
Error Statistics.

6
2.3 Log Information
Log is used to view simple switch log, and can view switch startup and port startup
data, screen as blew:
2.4 Alarm List
This page is used to view the alarm information of the switch;

7
3.Port Management
3.1 Port Configuration
In this page, you can set the port rate, duplex mode, the max frame length (the value
range is 1518-10240), flow control and switch port.
In the link status, indicates that the port is not connected, or the port has been
manually down. When the link status is or , it indicates that the port is
working normally, the color is the port working mode (green is Gigabit, yellow is
100MB).
On this page, you can not only view the port link status and port working mode, but
also set the port working mode, such as "100MB full / half duplex", "Gigabit full / half
duplex" and "adaptive". You can also close the specified port through this page, which
is the same as the command “shut down”.
For the frame size setting, the default is basic frame 1522, which can be modified to
super long frame 9600. The value range of this item is 1518-10240.
3.2 Port Isolation
This page is used to configure the port isolated. The isolated ports cannot
communicate with each other, and the isolated ports can communicate with other
non-isolated ports.

8
3.3 Mirroring Port
This page is used to configure the mirror port, is
used to configure to accept mirror data；is used
to configure all port mirroring properties in one step.
The configuration representative in the following page mirrors the sent message data
of port 4 to port 1, screen as blew:
3.4 Rate Limited
This page is used to limit the upper limit of port rate;

9
3.5 Storm Control
This page is used to limit the packet rate of port broadcast, multicast and unicast,
3.6 Port Energy Saving
This function is used to open the energy saving mode of switch port, screen as blew:

10
4.PoE
4.1 PoE Port Configuration
You can view the working status of the port PoE and the current voltage and current
data provided, screen as blew:
In the link column of the page, indicates that the port has no data transmission,
indicates that the port is in forwarding state, in the power supply status
column indicates that the port is not PoE powered, and indicates that the port is
in PoE power supply state. The voltage, current, and power columns respectively
display the voltage, current and power provided by the POE power supply port. The
priority column is used to change the PoE power supply priority of the switch port.
When the overall power is insufficient, the port with higher priority will give priority
to power supply. The startup bar is used to enable the port PoE function.
4.2 Devices Power Supply
This page is used to set the total output power of the switch, with a value range of 60
~ 300W. It can also be used to view the total output power and chip temperature of
the current switch.

11
4.3 Timing Power Supply Configuration
Configure the periodic outage period or specific outage time of the switch.
Apply the set power-off time to the port, and turn on this function by default for all
ports.

12
4.4 Intelligent Power Supply Configuration
Set PoE port to automatically disconnect power supply when there is no data
transmission within a certain period of time. The default value is that when there is
no data transmission in 120 seconds, the POE port will disconnect the power supply,
and the value range is 60 ~ 600 seconds.
Open the port intelligent power supply function, which is all on by default.

13
5.L2 Management
5.1 MAC address table
Check the MAC address of the device mounted on the switch
5.2 VLAN Configuration
This page includes viewing VLAN State, VLAN Configuration, Voice VLAN Configuration,
MAC VLAN configuration and IP VLAN configuration.
Screen as blew:
The screen below shows the configuration of port VLAN;
Port properties that can be set:
Access：
Access ports are normally used to connect to end stations. Dynamic features like
voice VLAN may add the port to more VLANs behind the scenes. Access ports have
the following characteristics:
Member of exactly one VLAN, the Port VLAN (Access VLAN), which by default is 1.
Accepts untagged and C-tagged frames.
Discards all frames that are not classified to the Access VLAN
On egress all frames classified to the Access VLAN are transmitted untagged.
The access port is usually used to connect to the terminal station. For example,

14
the dynamic characteristics of voice VLAN can add ports to multiple VLANs behind
the scenes. The access port has the following characteristics:
There is only one VLAN, port VLAN (also known as access VLAN), which is a
member of 1 by default.
accept unlabeled frames and C-labeled frames,
Drop all frames in unclassified access VLAN,
All frames to the exit are sent unmarked.
Trunk：
The trunk port can traffic multiple VLANs at the same time and is usually used to
connect to other switches. The trunk port has the following features:
By default, the trunk port is a member of all existing VLANs. This can be achieved
by using a limited number of VLANs.
Unless enabled on the port of VLAN relay, divided into different VLANs, and the
frame of that the port is not a member will be discarded.
By default, all frames, but VLAN (also known as local VLAN) frame tags classified
into ports get about exits. The frames classified to the port VLAN do not get the
exit of c-tag,
The exit marker can change all frames of the marker, in which case only the entry
of the marked frame is accepted,
VLAN trunking may be enabled.
Hybrid：
The hybrid port is similar to the trunk port in many ways, but adds additional port
configuration capabilities. In addition to the characteristics described for the relay
port, the hybrid port also has the following capabilities:
It can be configured as VLAN tag or unknown, C-tag all, S tag all, or S-custom tag
all.
The inlet filtration can be controlled.
The exit annotation and configuration of the access frame can be configured
independently.

15
Port VLAN: Determine the VLAN ID (also known as PVID) of the port. The allowable
VLAN range is 1 to 4095, and the default is 1.
Voice VLAN configuration’s screen as blew:
Enable Voice VLAN, the Access port will carry the IP voice traffic from the IP phone.
When the switch is connected to Cisco IP phone (such as Cisco 7960 IP phone), the
voice traffic sent by IP phone has three layers of IP priority and two layers of CoS
value, which are set to 5 by default. For IEEE 802.1Q or IEEE 802.1p tagged traffic, the
default cos value is untrusted.
Configure VLAN based on MAC address, screen as blew:
Configure VLAN based on IP, screen as blew:

16
5.3 GVRP
Enable the GVRP function, screen as blew:
The enabled GVRP function is applied to the designated port and configure its timer.
Used to view the operation information of GVRP.
5.4 Link Aggregation
On this page, you can configure static aggregation groups, dynamic aggregation
groups, and view link aggregation information;
Static aggregation configuration: click create static aggregation group TID value range
is (1-4), that is, up to 4 static aggregation groups can be created.
Port Member: Port join aggregation must be the same speed and full duplex
This switch supports 32 groups of aggregation, each group supports up to 8 ports. To
configure an aggregation group, just select the convergence port to the same line

17
group number, as shown in Figure 21: 1-2 ports converge in a group; 3-4 ports in a
group. Please keep configuration consistency for the ports of aggregation group
members, such as port rate mode, VLAN information, etc.
Link aggregation load balancing mode supports:
"Source MAC address" (load balancing calculation based on source MAC address of
message)
"Destination MAC address" (load balancing calculation based on the destination MAC
address of the message),”
"IP address" (the source IP address and the destination IP address of the message are
XOR, and then the load balancing calculation is performed)
"TCP / UDP port number" (load balancing calculation is based on the TCP / UDP port
number of the message).
Four modes can be selected and combined. The assignment of equalization algorithm
is global.
If LACP dynamic aggregation protocol is enabled on some ports, static aggregation
cannot be configured manually.
Note:
Static aggregation on the same port cannot be configured simultaneously with
dynamic LACP aggregation.

18
Configure dynamic aggregation port as blew:
Link aggregation information: view switch aggregation port information.
The switch supports port dynamic aggregation. After enable the dynamic protocol of
the port, the devices on both sides of the convergence exchange information through
the protocol. According to the parameters and status of both sides, the matching links
are automatically gathered together to send and receive data. After the convergence
is formed, the switching equipment maintains the convergence link state, and
automatically adjusts or disbands the aggregation link when the configuration of both
sides changes.
The configuration parameters of dynamic protocol include protocol switch state, key
negotiation and active / passive mode selection. Only when the dynamic protocol is
turned on can the dynamic negotiation be carried out, which may lead to the
formation of aggregation links. The key is the basis of negotiation. Only the ports with
the same key can negotiate to form an aggregation link. The negotiation mode is
"active | passive". When "active" is selected, the device will actively initiate
aggregation negotiation; when "passive" is selected, the device will passively accept
the aggregation negotiation initiated by other devices. If some ports have been
converged statically, the dynamic convergence of LACP cannot be realized.
Note: dynamic LACP aggregation and static convergence on the same port cannot be
configured at the same time

19
5.5 MSTP Configuration
Global configuration: select the spanning tree protocol version (STP / RSTP / MSTP is
optional), MSTP protocol is selected by default.
An example of configuring MSTP:
Set the mapping VLAN of multi spanning tree.
Configuration name: identifies the name of the VLAN to MSTI mapping, the bridge
must share the name and revision (see below), and the VLAN-to-MSTI mapping
configuration in order to share the MSTI spanning tree. (Within region) the name is
up to 32 characters.
Configuration version: revision of MSTI configuration above. It must be an integer
between 0 and 65535.
Mapped VLANs: a list of VLANs mapped to MSTI. VLANs must be separated by
commas and / or spaces. VLAN can only be mapped to one MSTI. An unused MSTI
should remain empty. (That is, no VLAN is mapped to it).

20
Interface instance configuration: configure the enable of the instance on the port.
Screen as blew:
Interface configuration: configure the enabled port of spanning tree protocol and the
enabled port of BPDU message. Screen as blew:
5.6 Loop Protection
Global Configuration: enable and set loop protection, screen as blew:
Port Configuration: enable the loop protection function on the port.
The loop protection includes double fiber ring protection and four fiber ring
protection.
