Digitus DN-95351 User manual

GIGABIT MANAGED
PoE SWITCH
DN-95351 (16 Port)
DN-95352 (24 Port)
Quick Start Guide

2
Introduction
Gigabit managed switch designed and developed solely for the purpose of
building high-performance gigabit network requirements. Provide a
comprehensive security protection system Perfect QoS strategy and rich
VLAN function Management and maintenance are simple and can be
applied to small and medium enterprises Core layer of community and
school.
Parameter
 Support Port/MAC/IP/VLAN ID four Yuan intelligent scanning binding
 Quickly locate user information, simplify operation and simplify network
management.
 The CPU frequency of 500Mhz, 128M flash, 4M cache, 128M RAM.
 Support IEEE 802.1Q VLAN, Voice VLAN and other rich VLAN function.
 The comprehensive security system, tackling the problem, ensure long
term stable operation of the network.
 The rich QoS strategy and control function of ACL multi-service access,
efficient integration of operation.
 Support multiple spanning tree protocol and port aggregation; improve
the ability to link redundancy backup.
 Support STP, RSTP, MSTP fast spanning tree protocol; support EPPS, EAPS
ring network protocol.
 The visual interface of POE, standard POE duty management
 Support the CLI command line, Web network, SNMP SSH, a variety of
management methods.
 The multiple timing restart function.
 We provide network diagnosis, cable detection, system log function.

3
Item list:
Please open the switch package carefully, confirm the packing box should
be as follows:
 1*Managed Switch
 1*power cable
 1*User Manual
 2*mounting brackets
 4*mats
 6*brackets screw
Product Display
Front panel sketch map
1. DN-95351: 16*10/100/1000M PoE Port+2*1000M SFP+1*Console,
Rackmount, 19-inch steel case.
2. DN-95352: 24*10/100/1000M PoE Port+2*1000M SFP+1*Console,
Rackmount, 19-inch steel case
PWR: The indicator lights up to indicate that the switch is
connected to the power supply.
SYS: CPU state indicator light, after the initialization is completed,
per-second flicker once.
PoE: The indicator lights up, corresponding port is supplying
power to the connecting device
Giga/1000M: The transmission rate of the corresponding port is 1000M
Link: Data transmission on the corresponding port

4
Back panel sketch map
1. The 19-inch steel case, back panel sketch map
Power adapter interface: The power supply of the switch is inserted into
the port, insert additional adapter
Single phase three wire socket: The power supply of the switch is inserted
into the port, and the input voltage of AC terminal is 100-240V 50/60Hz
Grounding: Make the equipment ground
Product mounting
Attention
In order to avoid improper use of equipment damage and personal injury,
please note the following:
1. During the installation, the power supply remains closed, while wearing
anti-static wrist, and ensure that anti-static wrist and skin good contact,
to avoid potential safety hidden danger;
2. The switch can work normally under the correct power supply. Please
confirm that the supply voltage is consistent with the voltage indicated
by the switch;
3. Before the switch is switched on, please confirm that it will not cause
overload of the power circuit, so as not to affect the normal operation of
the switch or even cause unnecessary damage;
4. In order to avoid the risk of electric shock, switch work should not open
the shell, even in the case of no electricity, do not open on its own;
5. Before cleaning the switch, the switch power plug should be pulled out,
please do not wipe with wet fabric, please don't use liquid cleaning;
6. Install the equipment rack generally from the bottom, avoid overload
installation;
7. The switch surface to avoid placing other heavy objects, so as to avoid
accidents.

5
Mounting Switch
Rack Mounting
1. Check the grounding and stability of the rack.
2. Secure the supplied rack-mounting brackets to each side of the device
with supplied screws, as illustrated in the following figure.
3. After the brackets are attached to the device, use suitable screws (not
provided) to secure the brackets to the rack, as illustrated in the
following figure.
Figure 2-1 Bracket Installation
Figure 2-2 Rack Installation
Desktop mounting
1. To install the device on the desktop, please follow the steps:
2. Set the device on a flat surface strong enough to support the entire
weight of the device with all fittings.
3. Remove the adhesive backing papers from the rubber feet.
4. Turnover the device and attach the supplied rubber feet to the recessed
areas on the bottom at each corner of the device.

6
Connect Port
Connect Ethernet port
Connect an Ethernet port of the switch to the device by RJ45 cable as the
following figure shows
Figure 3-1 Connect Ethernet port
Connect SFP port
The optical fiber module is grabbed from the side and inserted smoothly
along the switch SFP slot until the optical module is in close contact with
the switch.
Note: to avoid improper operation cause damage to equipment or personal
injury, please pay attention to the following matters
 Excessive bending of optical fibers is not allowed, and the radius of
curvature should not be less than 10cm.
 Ensure the cleanliness at the end of the fiber.
 Please do not look directly at the optical fiber connector; otherwise it
may cause damage to your eyes.
Remarks: it is recommended to adopt straight line -568B international
standard connection method, as the following figure shows
Power supply socket specification
Switch power line single-phase three wire power socket, the middle foot to
ground, and the left foot on the right foot for the zero line and FireWire,
please check before the operation.

7
Figure 4-1 Single phase three wire power outlet
Connect the power cord
The Rackmount direct access to AC100~240V, 50~60Hz city electricity
Figure 4-2 Power core connect
Connecting to the Ground
The grounding cable is important to protect the switch from electrical
interference. It is advised to use the grounding cable; if your power is
ungrounded which could damage the switch or its functionality
Figure 4-4 Connecting Grounding Terminal
Note: The grounding bar and the ground cable are not provided with our
product. If needed, please self-purchase them.
1
2
Grounding Terminal

8
Check after installation
Please check the following items after installation:
 check whether there is enough space for heat exchange, air circulation is
smooth
 check the power supply socket power supply switch is in accordance
with the specifications
 check the power supply, switchboard, rack and other equipment have
been properly grounded
Login the Device
The machine-default IP address is 192.168.2.11, subnet mask is
255.255.255.0. So when you log on to the switch, make sure the IP address
of the computer network card and the IP of the switch in the same network
segment: 192.168.2. *** (1 <*** <255, *** is not equal to 11).
Please enter user name: guest, password: guest, then you can use the web
browser-based configuration to manage switch.

9
Managed PoE Switch Hardware Parameters
Type
DN-95351
DN-95352
Port
16*10/100/1000M
24*10/100/1000M
2*SFP
2*SFP
1*Console
1*Console
PoE standards
IEEE802.3af/at, single port PoE power 30W
PoE Port
16
24
PoE Budget
380W
Reset
1
Bandwidth
56Gbps
56Gbps
Packet forwarding
40.32Mpps
40.32 Mpps
CPU
500Mhz
RAM
128M
MAC
8K
Buffer
4.1M
FLASH
128M
Transmission
Store and forward
Working
temperature
0°C ~50°C
Storage temperature
-40°C ~70°C
Operating humidity
10%~90% Non-coagulation
Storage humidity
5%~95% Non-coagulation
Product size
440*290*45mm
Packing size
497*313*97mm
Power in
AC 100-240V, 50/60Hz
Power Supply
400W

10
Management switch WEB software function
Standards
IEEE 802.3x
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z IEEE
802.3ad
IEEE 802.3q, IEEE 802.3q/p
IEEE 802.1w, IEEE 802.1d, IEEE 802.1S, IEEE802.1X
MAC Address
16K MAC addresses; MAC address learning and aging
VLAN
STP (Spanning Tree Protocol) Up to 4095 VLAN
Voice VLAN, can configure QoS for voice data 4k VLANS;
Port-based VLANs；802.1Q VLAN
Spanning Tree
STP (Spanning Tree Protocol)
RSTP/MSTP (Rapid Spanning Tree Protocol) EPPS ring
network protocol 802.1x argumentation agreement
Link
Aggregation
Max 8 aggregation groups TRUNK, each supports
8 ports Static aggregation and dynamic aggregation
Port Mirror
Many-to-one port mirroring
Loop Guard
Loop protection function, real-time detection, rapid
alarm, accurate positioning, intelligent blocking,
automatic recovery
Isolation
Support downlink ports isolated from each other and
communicate with upstream port
Port flow
control
Half duplex based back pressure control Full duplex
based on PAUSE frames
Line rate
Support port-based input / output bandwidth
management
IP binding
Support static ARP
Static routing
Support static routing
IGMP Snooping
Support 256 layers of set table capacity IGMPv1/2/3
and MLDv1/2 Snooping GMRP protocol registration
Multicast address management, multicast VLAN,
multicast routing ports, static multicast addresses
DHCP
DHCP Snooping
Storm
suppression
Unknown unicast, multicast, unknown multicast, storm
suppression of broadcast type Storm suppression based
on bandwidth tuning and storm filtering

11
Security
Support 256 groups of ACL
Teams that support 4 different priorities per port
User port + IP address + MAC ACL based on IP and MAC
Security properties of port-based MAC address
quantities Support system CPU self-protection
QOS
802.1p port queue priority algorithm
Teams that support 4 different priorities per port
Cos/Tos, QOS sign
WRR (Weighted Round Robin),
Weighted priority rotation algorithm WRR, SP, WFQ,
3 priority scheduling models
Support based on port, MAC, 802.1Q, DSCP
classification
Port
Auto-MDIX; Auto negotiation
System
maintenance
Upgrade package upload system log view
Support to upload / download configuration files
through WEB Support multiuser management
WEB restore factory configuration
PoE
Management
Open or close port
Standard POE scheduling management
Power and current display
Automatic restarting function of equipment dead
machine
Timing reactivation Support IP bindings restarting
Management
& maintenance
WEB NMS
CLI Telnet, TFTIP Console, management based on
Remote configuration and maintenance using
Telnet SNMP V1/V2/V3; SSH V1/V2; RMON V1/V1
Hereby Assmann Electronic GmbH, declares that the Declaration of
Conformity is part of the shipping content. If the Declaration of Conformity
is missing, you can request it by post under the below mentioned
manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
