Velleman HPG1MK2 Quick setup guide

Velleman HPG1MK2 - User manual and info
INFO
Features:

DDS type generator (Direct Digital Synthesis)

sweep function with bi-direction option

OLED screen

operates on 4 x 1.5V AAA batteries (not included)

signature white back casing
Specifications:

DAC resolutions: 10 bits

frequency range: from 1 Hz to 1.000.000 Hz (± 0.01 %)

frequency steps: 1 Hz, 10 Hz, 100 Hz, 1 kHz and 10 kHz

waveforms: sine, square and triangle

output voltage: max. 8 Vpp

real output level measurement: dBm / Vrms or Vpp readout (± 3 %)

typical sine wave distortion (THD): < 0.1% @ 1 kHz / 0dB / 600 Ohm

square wave rise/fall time: typ. 0.2 µs

output impedance: 50 Ohm

dimensions: 114 x 68 x 22mm / 4.48 x 2.67 x 0.86"

power consumption: 70 mA max

battery life: about 15 hours on quality alkaline batteries

What's in the box

handheld pocket generator

getting started manual

BNC male to RCA female

BNC male to 2x4mm banana plug
Option:
Optional Velleman instruments protective pouch (HPSP1)

CONNECTIONS AND CONTROLS
1. on/Off switch
2. BNC output connector
3. calibration output
4. signal and menu display
5. output level indicator
6. up and down set buttons
7. menu button / menu selection up
8. settings menu button / menu selection down

CHANGING THE BATTERIES
Use 4 x AAA 1,5V batteries and note the polarity!

FUNCTION GENERATOR SETUP
Access the setup menu by keeping the settings button pressed in.
You can:

change the user interface language

adjust the display contrast or reverse the display (white with black dots)

change the way the frequency is changed if you keep the up/down button pressed ( Log. will make the
frequency change faster)

start or Stop the DEMO mode (useful for demonstration or testing)

press and hold the setting menu button (8) or the menu button (7) to leave the menu and store the
settings

WAVEFORM MENU
This view is shown when sweep is off (check the next chapter).
SWEEP MENU
A sweep generator generates a frequency which changes with respect to time and is a practical device for
recording frequency characteristics, or to make automated measurements.
