Dimplex DCFF50MBK User manual

For domestic household use only.
INSTRUCTION MANUAL
50cm HV Floor Fan
Model: DCFF50MBK

IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR
FUTURE REFERENCE. Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/
OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your dehumidifier
for the first time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate surroundings of a bath,
a shower or a swimming pool.
• Never immerse the appliance in water or other liquids.
• Operate this unit only on a firm, flat surface.
• Do not place on soft, unstable or non-horizontal/angled surfaces.
• Never operate the appliance if a cable or connector has been damaged,
after appliance malfunction or if the appliance was dropped or is otherwise
damaged.
• If the mains lead is damaged it must only be replaced by the manufacturers
service agent or a similarly qualified person in order to avoid a hazard.
• Please ask a professional service agent to repair the product. Improper repair
may cause danger to users.
• Disconnect the appliance from mains power whenever it is not in use, before
relocating it, and before cleaning.
• Operate the appliance only at the voltage specified on the rating label.
• Only connect the unit to a properly installed and easily accessible socket so
that you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension lead.
• This fan is only intended for INDOOR RESIDENTIAL applications. This fan
should not be used for commercial or industrial or leisure applications or in
small enclosed spaces.
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a fire or electrocution hazard, NEVER put the cord near heat registers,
radiator, stoves or heaters.
• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.
• DO NOT route cord under furniture or appliances. Take care to position the
cord away from traffic areas and where it will not be a tripping hazard.
• DO NOT use the unit near windows or where water collects. Rain and water
collection may lead to a risk of fire or electric shock.
• Only operate this appliance with a minimum of 50cm clearance all around i.e.
away from walls, furniture and overhanging objects such as curtains or a shelf.
2

• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
• WARNING: To avoid danger of suffocation please remove all packaging
materials particularly plastic and EPS and keep these away from vulnerable
people, children and babies.
• NEVER drop or insert any object or fingers into any openings.
• Do not use the appliance in locations where paint, petrol or other flammable
liquids are used or stored.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
• Do not use bug sprays or other flammable cleansers/vapour sprays on or
around the unit.
• Always switch off the unit and take the plug out of the socket:
• If you are not using the unit
• Before you clean or carry out maintenance on the unit
• If a fault occurs
• In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away from
electrical appliances such as televisions & radios.
3

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
No extension leads or
power boards
Where there is risk
of fire or close to
a naked flame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
4

Model no. DCFF50MBK
Colour
Matte Black
Power supply
220-240V~ 50-60Hz
Rated power 120W
Speed settings 3
Modes -
Timer -
Air volume 126m
3
/min
Adjustable height -
Tilt adjustable head Y
Horizontal oscillation Y
Noise level 66dB(A)
Weight (net) 4.8kg
Dimensions (w x d x h) 500 x 290 x 625mm
Specification
• For greater precision, please always refer to the rating label placed on the product.
5

Parts
2. Front grille
3. Blade
4. Front grille
screw
5. Front
grille nut
6. Motor housing
screws
7. Rear grille
8. Motor
9. Oscillation
knob
10. Power
cord
12. Lock nut
11. Neck
13. Stand
1. Logo ring
6

Assembly
This fan has been partially assembled to reduce wastage of packaging material,
paper cartons and weight. To assemble the fan grilles, blades and base, please follow
the instructions below:
1. Remove the protective sleeve (if any) from the motor shaft (8).
2. Remove the four rear guard retaining screws (6) from the motor housing (8).
3. Using a Phillips head screwdriver (not supplied), attach the rear grille (7) to the
motor housing (8) using the four screws (6), you just removed.
Ensure the handle is at the top.
4. Place the fan blade (3) over the motor shaft (8) so that the blade retaining screw
on the fan blade shaft sits behind the blade. Tighten the screw securely against
the flat part of the motor shaft (8).
5. Remove the front grille rim screw (4) and nut (5) from the front grille (2) and
open the clips around the outside edge of the front grille (2), turning them
outwards.
6. Hang the front grille (2) by its hook over the top of the rear grille (7), making sure
the holes for the front grille rim screw (4) and nut (5) are aligned. Bring the front
grille (2) down to meet the rear grille (7) and push the clips inwards until the
front grille (2) is fastened to the rear grille (7). Finally fit the front grille rim screw
(4) and nut (5) through the holes in the bottom edge of the guard and tighten
with a small Phillips head screwdriver (not supplied).
7. Place the stand base (13) on the floor in front of you with the long part of the
stand tube (13) at the front so that the end of the tube stand points to the back.
8. Take the fan head assembly (with the front towards you) and push the opening of
the fan neck firmly onto the top of the stand base (13) as far as it will go.
9. Tighten the lock nut (12) to secure the parts together.
CAUTION: If you install the fan head assembly the wrong way onto the stand tube,
the fan could turn over when tilting the fan head.
7

Cleaning
Over time, dust can accumulate on the grille covers and fan blades, which can affect
the fans performance. It is recommended to clean the fan at least once a month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Lightly run a vacuum cleaner nozzle (soft brush) over the front and rear grilles to
remove any dust or dirt that may have accumulated inside or on the unit.
3. Remove any dust build up with a soft brush or cloth.
4. To remove stains from the blades, or for thorough cleaning before storage, open
the clips at the edge of the grilles, remove the tiny screw and nut at the bottom
of the grille edge and take off the grilles. Remove the blades cautiously for
cleaning, taking care not to drop them, then refit. Make sure all grille clips are
securely closed and the screw and nut tightened before reuse.
Do NOT use abrasive sponges, scouring pads, or a stiff brush to clean the unit.
IMPORTANT
The control panel and other parts must not come into contact with water or any
other liquids.
Operation
1. Connect the plug to a power supply and switch on the power.
2. Switch the fan ON by rotating the speed switch knob at the rear in clockwise
direction. This switch is also used to adjust the fan SPEED.
3. The airflow direction can be adjusted upward/downward by simply lifting the
motor unit or rear guard UP or DOWN.
NOTE: Only adjust the fan head when the unit is OFF. Be careful not to insert your
fingers through the guard.
4. Turn the speed control switch to your desired fan speed by selecting HIGH (III),
MEDIUM (II) or LOW (I).
5. Oscillation - To activate the oscillation function, push down the oscillation knob
(9). Pull the oscillation knob (9) up to stop oscillation at the desired direction of
airflow.
6. Turn the dial to the (0) position to switch the fan OFF.
8

If the unit fails to operate efficiently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landlls or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
If you do not use the unit for an extended period of time. After cleaning please:
• Turn the unit off, unplug and take care of the mains lead & plug.
•
Cover the unit and store it upright in a location where it will not receive direct
sunlight. Note: Prolonged exposure to direct sunlight will discolour the enclosure.
Storage
Maintenance
9

Customer Care: 1300 556 816
[e-mail]
www.dimplex.com.au
Supplied by Glen Dimplex Australia
8 Lakeview Drive, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
DCFF50MKB REV 2
