Dimplex BLF7451 User manual

Owner’s Manual
Model
BLF7451
7214000100R03
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com

2 www.dimplex.com
Table of Contents
Always use a qualied technician or
service agency to repair this replace.
!NOTE: Procedures and
techniques that are considered
important enough to emphasize.
CAUTION: Procedures and
techniques which, if not carefully
followed, will result in damage to
the equipment.
WARNING: Procedures and
techniques which, if not carefully
followed, will expose the user to
the risk of re, serious injury, or
death.
Welcome & Congratulations ...................3
IMPORTANT INSTRUCTIONS .................4
Quick Reference Guide ......................6
Fireplace Installation ........................7
Site Selection ................................. 7
For Bathroom Use .............................. 7
Wiring ....................................... 8
Surface Mount Installation .......................10
Flush Mounted Installation - 2x8 Framing ............12
Front Glass Installation ......................... 13
Operation ................................14
Maintenance ..............................17
Warranty .................................18
Technical Support ..........................20

3
Welcome & Congratulations
Thank you and congratulations for purchasing an electric replace from
Dimplex. Please use our convenient online registration page to record
your model and serial numbers for future reference at
www.dimplex.com/register
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
for Troubleshooting and Technical Support
OR Toll-Free 1-888-346-7539
Please visit our website for operating hours
In order to better serve you, please have your model and serial number
ready or register your product online before calling (See above)
Serial Number
Label Rating Label with
Model Number
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in
a possible electric shock, re hazard and will void the warranty.

4 www.dimplex.com
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before
installing or using this electric
replace.
② This replace is hot when in
use. To avoid burns, do not let
bare skin touch hot surfaces.
The trim around the heater
outlet becomes hot during
heater operation.
DANGER: High temperatures
may be generated under
certain abnormal conditions.
Do not partially or fully cover
or obstruct the front of this
heater.
③Extreme caution is necessary
when any heater is used by
or near children or invalids
and whenever the unit is left
operating and unattended.
④Young children should be
supervised to ensure that they
do not play with the appliance.
IMPORTANT INSTRUCTIONS
⑤ The appliance is not intended
for use by young children
or inrmed persons without
supervision.
⑥Do not operate the unit after
it malfunctions. Disconnect
power at the service panel
and contact Dimplex Technical
Service for service
1-888-346-7539.
⑦ Do not use outdoors.
⑧Never locate replace where it
may fall into a bathtub or other
water container.
⑨ To disconnect the replace,
turn the controls o󰀨, then
disconnect the circuit at the
main disconnect panel.
⑩ Do not locate the heater
immediately below a xed
socket-outlet.
⑪Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this
may cause an electric shock
or re, or damage to the
heater.
⑫ To prevent a possible fire,
do not block air intakes or
exhaust in any manner.

5
SAVE THESE INSTRUCTIONS
⑬ All electrical heaters have hot
and arcing or sparking parts
inside. Do not use in areas
where gasoline, paint, or
ammable liquids are used or
stored.
⑭Use this heater only as
described in this manual. Any
other use not recommended
by the manufacturer may
cause re, electric shock or
injury to persons.
⑮Do not burn wood or other
materials in the electric
replace.
⑯ Do not strike the replace
glass.
⑰ Always use a certied
electrician should new circuits
or outlets be required.
⑱ Disconnect all power supply
before performing any
cleaning, maintenance or
relocation of the unit.
⑲When transporting or storing
the unit and cord, keep in a
dry place, free from excessive
vibration and store so as to
avoid damage.
WARNING: Remote control
contains small batteries.
Keep away from children.
If swallowed, seek medical
attention immediately.
WARNING: Do not install
battery backwards, charge, put
in re or mix with used or other
battery types - may explode or
leak causing injury.
!NOTE: Changes or
modications not expressly
approved by the party
responsible for compliance
could void user's authority to
operate the equipment.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
IMPORTANTINSTRUCTIONS

6 www.dimplex.com
Quick Reference Guide
Figure 1
1. The electrical information
regarding your electric replace
can be found on the rating label
located on the front of the unit,
behind the glass.
Please use our convenient online
registration page to record your
model and serial numbers for future
reference at
www.dimplex.com/register
2. If you have any technical
questions or concerns regarding
the operation of your electric
replace, or require service
contact customer service at
1-888-346-7539.
3. For dimensions of your replace,
refer to Figure 1.
[7.1 in.]
467 mm
[18.4 in.]
1883 mm [74.1 in.]
493 mm
[19.4 in.]
187 mm
[7.3 in.]
1844 mm [72.6 in.]

7
Site Selection
Review and consider all of the
following conditions before installation:
• Dimensions of the unit: 74.1 in.
(1883 mm) x 19.4 in. (494 mm)
• For surface installation, the unit
requires a minimum of 2 wall
studs in order to ensure secure
installation. For other installation
methods, suitable framing is
required.
There are two possible mounting
methods:
• Surface mount (pg. 10);
• Flush mount (pg. 11).
WARNING: The top of the
replace is to be installed at least
4" (10.2 cm) from the ceiling.
CAUTION: Ensure installation
does not allow replace to be in
direct contact with building vapor
barrier or insulation and meets all
local building code.
!NOTE: A dedicated, properly
fused 15 Amp circuit is required,
rated for the appropriate voltage
(120V, 240V).
WARNING: Construction and
electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
Fireplace Installation
WARNING: To reduce the risk of
re, do not store or use gasoline
or other ammable vapors or
liquids in the vicinity of the heater.
1. Select a location that is not
susceptible to moisture and is
away from drapes, furniture and
high tra󰀩c.
2. Unpack the replace, front glass
and hardware from the box and
remove all packaging materials
before installation.
3. Store the replace in a safe, dry
and dust free location until you
are ready to install the replace.
For Bathroom Use
If this unit is installed in a bathroom
it must be protected by a GFI
receptacle or circuit. If receptacle is
used it must be readily accessible.
To prevent electrical shock this unit
is an electrical appliance that is NOT
watertight and must be installed as to
prevent water from entering unit. This
must be installed away from showers,
tubs, etc. Never locate replace
where it may fall into a bathtub or
other water container.

8 www.dimplex.com
Fireplace Installation
Wiring
WARNING: To reduce the risk
of re, electric shock or injury to
persons, always use a licensed
electrician.
WARNING: Ensure that the circuit
on which the replace is to be
installed has the power cut o󰀨 at
the service panel until installation
is complete.
1. Carefully remove the electrical
cover bracket from the back of the
replace by removing the three
retaining screws. (Figure 2)
2. Leaving a minimum of 3 in. (7.6
cm) of slack, route the power
supply through a cable clamp
(not included) and the hole in the
electrical cover bracket.
3. Remove the two covers o󰀨 of the
unit at the front to access the wire
connections. (Figure 3)
Wiring Diagram
AC/DC
ADAPTER
RELAY BOARD
SWITCH BOARD
DISPLAY / CONTROL BOARD
THERMISTOR
LED STRIPS
(RGB) - MEDIA
FLAME LED STRIPS (AMBER)
CUTOUT
THERMAL
FLICKER MOTOR
BLOWER MOTOR
LED STRIPS
(RGB) - FLAME
M
M
ELEMENTS
LED DRIVER
BOARDS
Figure 2
Screws
Electrical Cover Bracket

9
Fireplace Installation
For 120V Installations
Use two conductor, non-metallic
sheath cable with ground wire (3
wires total) for the incoming power
supply.
CAUTION: Use the appropriate
wire to meet local and national
electrical codes for rated power
consumption.
• Connect the L1 wire from the unit
to the live wire from the power
supply.
• Connect the N and H1 wires from
the unit to the neutral wire from
the power supply.
• Connect the L2 and H2 wires
together, with a wire connector
and leave them disconnected
from everything.
• Attach the grounding wire to
the cover with the provided
grounding screw. Place wire in-
between screw and lock washer
and tighten (Figure 4).
• Reposition the electrical cover
brackets over the wires and
connectors and attach to
replace chassis using the screw
removed in step 1 and step 3.
Figure 4
Hole for
Ground Screw
Figure 3

10 www.dimplex.com
Fireplace Installation
For 240V Installations
Use three conductor, non-metallic
sheath cable with ground wire (4
wires total) for the incoming power
supply on replace inserts.
CAUTION: Use the appropriate
wire to meet local and national
electrical codes for rated power
consumption.
• Connect the L1 wire from the unit
to the L1 wire from the power
supply.
• Connect the L2 wire from the unit
to the L2 wire from the power
supply.
• Connect the N wire from the unit
to the neutral wire from the power
supply.
• Connect the H1 and H2 wires
together, with a wire connector
and leave them disconnected
from everything.
• Attach the grounding wire to
the cover with the provided
grounding screw. Place wire in-
between screw and lock washer
and tighten (Figure 4).
• Reposition the electrical cover
brackets over the wires and
connectors and attach to
replace chassis using the screw
removed in step 1 and step 3.
Surface Mount Installation
CAUTION: Two people will be
required for various steps of this
procedure.
WARNING: Ensure that the circuit
on which the replace is to be
installed has the power cut o󰀨 at
the service panel until installation
is complete.
1. Determine the mounting location
of the unit so that the wall-
mounting bracket can be installed
into 3 wall studs.
!NOTE: It is recommended that
the mounting bracket be installed
56 in. (142 cm) o󰀨 of the ground
to maintain an optimized viewing
angle of the ame.
2. Hold the wall mounting bracket,
with the bubble level on the top,
on the wall so that the bubble on
the level is centered between the
two black lines.
3. Mark the 4 mounting screw
locations, on the wall, ensuring
that the wall bracket stays level.
(Figure 5)
4. In locations where the screws are
being installed only into drywall,
install the supplied wall anchors
before installing the screw (predrill
if required).

11
Fireplace Installation
5. Secure the wall bracket to the wall
using the supplied 1½ in. (3.8 cm)
mounting screws and washers
into the wall and/or wall anchors.
6. Install the bottom support bracket
to the wall centered with the
wall mounting bracket, using the
appropriate mounting hardware,
13 ¾" (350 mm) below the wall
mounting bracket. (Figure 5)
7. Remove the center screw from
the bottom of the replace.
(Figure 6)
8. Hang the replace from the
bracket.
9. Install the removed screw through
the bottom support bracket into
the replace.
10. Refer to Front Glass Installation
section nal installation
procedures.
Figure 5
Figure 6

12 www.dimplex.com
Fireplace Installation
Flush Mounted Installation -
2x8 Framing
CAUTION: Two people will be
required for various steps of this
procedure.
1. Prepare a wall with a framed
opening of 73 in. (185.4 cm) wide
x 18 ½ in. (47 cm) high (Figure 7).
!NOTE: It is recommended that the
bottom of the unit not be mounted
higher than 40 in.
(102 cm) from the ground to
maintain an optimized viewing
angle of the ame.
WARNING: Do not attempt to wire
your own new outlets or circuits. To
reduce the risk of re, electric shock
or injury to persons, always use a
licensed electrician.
WARNING: Ensure that the circuit
on which the replace is to be
installed has the power cut o󰀨 at
the service panel until installation
is complete.
2. Lift replace and insert into
opening. The replace's mounting
trim should be ush against the
wall (Figure 7).
3. Use the supplied bubble level
to level the replace within the
framing, adjust as required.
4. Drive four supplied mounting
screws through the four mounting
holes located on the inside surface
of the replace chassis, into wall
studs (Figure 8).
5. Refer to Front Glass Installation
section for nal installation
procedures.
Figure 7 2 x 8 Framing
Mounting hole
Mounting hole
Wall
surface
Figure 8

13
Figure 9
Front tray
Front glass
assembly
Figure10 Tab
Hooks (4)
Mounts (4)
Front Glass Installation
1. Pour and evenly distribute the
supplied media in the Media tray
of the firebox (Figure 9).
2. Carefully mount front glass
assembly so that the front glass
hooks hang on the front glass
mounts on the fireplace (Figure
9).
3. Use the supplied four Phillips
sheet metal screws to fasten
the glass assembly tabs to the
fireplace (Figure 10).

14 www.dimplex.com
Operation
!NOTE: When any button is
pressed the intake temperature
will be displayed on the Floating
DisplayTM for 5 seconds.
B. Flame E󰀨ects
Turns the ame e󰀨ect On and O󰀨.
→ Activated by pressing the
button on the remote.
C. Heat ON/OFF
Turns the heater On and O󰀨.
→ Activated by pressing the
button on the unit or the remote.
• Indicated by the icon and the
intake temperature being displayed
on the Floating DisplayTM, for 5
seconds before turning off.
!NOTE: After the heater is
switched o󰀨, there is a 60 second
fan delay, where the fan will
WARNING: This electric rebox
must be properly installed before it
is used.
The unit can be controlled by either
the manual controls which are located
on the upper right of the replace or
the remote (Figure 11 & 12).
The replace is supplied with an IR
multifunction remote control.
!NOTE: To operate correctly, the
remote control must be pointed
towards the Floating DisplayTM.
A. Standby
Turns the unit On and O󰀨.
→ Activated by pressing the Standby
button on the remote or the unit.
• The unit will turn on with the same
functions that it was set to when
it was turned O󰀨 and the intake
temperature will be indicated on
the Floating DisplayTM.
Figure 11 A C DEF
Floating
DisplayTM
Figure 12
A
D
BC
E
G
H
F

15
Operation
continue running before turning
o󰀨.
!NOTE: The unit can be operated
in Heat Only Mode. When the unit
is only running with the heater,
the icon will continuously
be displayed on the Floating
DisplayTM.
!NOTE: The heater may emit a
slight, harmless odor when rst
used. This odor is a normal
condition caused by initial heating
of internal heater parts and will
not occur again.
D & E. Thermostat Controls
Adjusts the temperature set point
to your individual requirements.
Once the desired set temperature
is reached the heater will turn off.
The heater will cycle on and off to
maintain the desired set temperature.
The default temperature setting is
72°F (22°C).
→ Adjusted by pressing the to
decrease the setpoint and the
to increase the setpoint on the unit
or the remote.
• The Floating DisplayTM will indicate
the temperature setpoint as it is
adjusted.
!NOTE: Holding the and
the buttons down for two
seconds, on the manual controls,
will change the temperature from
°C to °F, or vice versa.
Disable Heat
If desired, depending on the season,
the heater on the unit can be
disabled. The unit will operate in the
same fashion, with remainder of the
controls.
Pressing the and buttons
on the manual controls at the same
time and holding for 2 seconds will
disable and enable the heater.
!NOTE: When the heater has been
disabled and either the or
the is pressed the Floating
DisplayTM will indicate "--".
F. Color Themes
Di󰀨erent presets of ambient lighting
color combinations contained in the
unit.
→ Changed by repeatedly pressing
the corresponding button on the
remote or the unit.
• Cycles through the di󰀨erent
preset ambient lighting settings
of the unit, this includes di󰀨erent
combinations of colours of the
ame base and media lighting.
!NOTE: The last theme of the cycle
is a prism where the unit cycles
through a variety of colours.
Pressing the button stops the

16 www.dimplex.com
Resetting the Temperature
Cuto󰀨 Switch
Should the heater overheat, an
automatic cut out will turn the whole
unit o󰀨 and it will not come back
on without being reset. It can be
reset by turning the unit o󰀨 at the
main disconnect panel and waiting 5
minutes before turning the unit back
on.
CAUTION: If you need to
continuously reset the heater,
unplug the unit and call technical
support at 1-888-346-7539.
Remote Control Battery
Replacement
To replace the battery:
1. Slide battery cover open on the
remote control.
2. Correctly install one 3 Volt
(CR2032 [longer life] or CR2025)
battery in the battery holder.
3. Close the battery cover.
Battery must be recycled or
disposed of properly. Check
with your Local
Authority or Retailer for recycling
advice in your area
cycling and holds the unit on the
preferred color, indicated by a "U"
- Unfreeze or a "F" - Freeze on
the display.
G. Brightness
Changes the brightness of the lights
in the unit.
→ Adjusted by repeatedly pressing
the corresponding button on the
remote.
• Indicated by the second digit on
the Floating Display™ changing to
show: "H" (high), and "L" (low).
H. Sleep Timer
The Sleep Timer can be set to
automatically shut o󰀨 the replace
after a preset time (from 30 minutes
to 8 hours).
→ To set the timer press the timer
button on the remote, repeatedly,
until the desired time is displayed.
• The Floating DisplayTM will display
the di󰀨erent times as it is adjusted.
Once the timer has begun,
pressing the button will display
the time remaining before the unit
turns O󰀨.
!NOTE: The Sleep Timer can be
cancelled at any time by pressing
the button repeatedly until the
sleep timer displays nothing.
Operation

17
Maintenance
WARNING: Disconnect power
and allow heater to cool before
attempting any maintenance or
cleaning to reduce the risk of
re, electric shock or damage to
persons.
!NOTE: The replace should not
be operated with an accumulation
of dust or dirt on or in the unit,
as this can cause a build up of
heat and eventual damage. For
this reason the heater must be
inspected regularly, depending
upon conditions and at least at
yearly intervals.
Partially Reective Glass
Cleaning
The partially reective glass is
cleaned in the factory during the
assembly operation. During shipment,
installation, handling, etc., the
partially reective glass may collect
dust particles; these can be removed
by dusting lightly with a clean dry
cloth.
To remove ngerprints or other
marks, the partially reective glass
can be cleaned with a damp cloth.
The partially reective glass should
be completely dried with a lint
free cloth to prevent water spots.
To prevent scratching, do not use
abrasive cleaners.
Fireplace Surface Cleaning
Use only a damp cloth to clean
painted surfaces of the replace. Do
not use abrasive cleaners.
Servicing
Except for installation and cleaning
described in this manual, an
authorized service representative
should perform any other servicing.

18 www.dimplex.com
Products to which this limited warranty
applies
This limited warranty applies to your newly
purchased Dimplex electric replace. This
limited warranty applies only to purchases
made in any province of Canada except
for Yukon Territory, Nunavut, or Northwest
Territories or in any of the 50 States of the
USA (and the District of Columbia) except
for Hawaii and Alaska. This limited war-
ranty applies to the original purchaser of
the product only and is not transferable.
Products excluded from this limited war-
ranty
Products purchased in Yukon Territory,
Nunavut, Northwest Territories, Hawaii, or
Alaska are not covered by this limited war-
ranty. Products purchased in these States,
provinces, or territories are sold AS IS
without warranty or condition of any kind
(including, without limitation, any implied
warranties or conditions of merchant-
ability or tness for a particular purpose)
and the entire risk of as to the quality and
performance of the products is with the
purchaser, and in the event of a defect the
purchaser assumes the entire cost of all
necessary servicing or repair.
What this limited warranty covers and for
how long
Products, other than replace surrounds
(mantels) and trims, covered by this
limited warranty have been tested and
inspected prior to shipment and, subject to
the provisions of this warranty, Glen
Dimplex Americas warrants such prod-
ucts to be free from defects in material
and workmanship for a period of 2 years
from the date of the rst purchase of such
products.
Dimplex replace surrounds (mantels) and
trims covered by this limited warranty have
been tested and inspected prior to ship-
ment and, subject to the provisions of this
warranty, Glen Dimplex Americas warrants
such products to be free from defects in
material and workmanship for a period of
1 year from the date of rst purchase of
such products.
The limited 2 year warranty period for
products other than replace surrounds
(mantels) and trims and the limited 1 year
warranty period for replace surrounds
(mantels) and trims also applies to any
implied warranties that may exist under
applicable law. Some jurisdictions do not
allow limitations on how long an implied
warranty lasts, so the above limitation may
not apply to the purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Glen Dimplex Americas or its autho-
rized service representatives) or otherwise
altered. This limited warranty does further
not apply to defects resulting from misuse,
abuse, accident, neglect, incorrect installa-
tion, improper maintenance or handling, or
operation with an incorrect power source.
What you must do to get service under
this limited warranty
Defects must be brought to the attention of
Glen Dimplex Americas Technical Service
by contacting Glen Dimplex Americas at
1-888-346-7539, or 1367 Industrial Road,
Cambridge Ontario, Canada
N1R 7G8. Please have proof of purchase,
catalogue/model and serial numbers
available when calling. Limited warranty
service requires a proof of purchase of the
product.
What Glen Dimplex Americas will do in the
event of a defect
In the event a product or part covered by
this limited warranty is proven to be defec-
tive in material or workmanship during (i)
the 2 year limited warranty period for prod-
ucts other than replace surrounds (man-
tels) and trims, and (ii) the 1 year limited
warranty period for surrounds (mantels)
and trims, you have the following rights:
• Glen Dimplex Americas will in its sole
discretion either repair or replace such
defective product or part without charge.
If Glen Dimplex Americas is unable to
Warranty

19
repair or replace such product or part,
or if repair or replacement is not com-
mercially practicable or cannot be timely
made, Glen Dimplex Americas may, in
lieu of repair or replacement, choose to
refund the purchase price for such prod-
uct or part.
• Limited warranty service will be per-
formed solely by dealers or service
agents of Glen Dimplex Americas
authorized to provide limited warranty
services.
• For products other than surrounds
(mantels) and trims, this 2 year limited
warranty entitles the purchaser to on-
site or in-home warranty services. Ac-
cordingly, Glen Dimplex Americas will
be responsible for all labour and trans-
portation associated with repairing or
replacing the product or part except as
follows: (i) charges which may be levied
for travel costs incurred to travel to the
purchaser’s site where the product is
located if the purchaser’s site is beyond
30 miles (48 km) from the closest ser-
vice depot of Glen Dimplex Americas’s
dealer or service agent; and (ii) the pur-
chaser is solely responsible for provid-
ing clear access to all serviceable parts
of the product.
• For surrounds (mantels) and trims, this
1 year limited warranty does not entitle
the purchaser to on-site or in-house
warranty services. The purchaser is
responsible for removal and transpor-
tation of the surrounds (mantels) and
trims (and any repaired or replacement
product or part) to and from the autho-
rized dealer’s or service agent’s place
of business. On-site or in-home services
for surrounds (mantels) and trims may
be performed at the purchaser’s specic
request and expense at Glen Dimplex
Americas’s then current rates for such
services. Glen Dimplex Americas will
not be responsible for, and this limited
warranty shall not include, any expense
incurred for installation or removal of the
surrounds (mantels) or trims or any part
thereof (or any replacement product
or part) including, without limitation, all
shipping costs and transportation costs
to and from the authorized dealer’s or
service agent’s place of business and
all labour costs. Such costs shall be the
purchaser’s responsibility.
What Glen Dimplex Americas and its
dealers and service agents are also not
responsible for:
IN NO EVENT WILL GLEN DIMPLEX
AMERICAS, OR ITS DIRECTORS, OFFI-
CERS, OR AGENTS, BE LIABLE TO THE
PURCHASER OR ANY THIRD PARTY.
WHETHER IN CONTRACT, IN TORT, OR
ON ANY OTHER BASIS, FOR ANY INDI-
RECT, SPECIAL, PUNITIVE, EXEMPLA-
RY, CONSEQUENTIAL, OR INCIDENTAL
LOSS, COST, OR DAMAGE ARISING
OUT OF OR IN CONNECTION WITH THE
SALE, MAINTENANCE, USE, OR IN-
ABILITY TO USE THE PRODUCT, EVEN
IF GLEN DIMPLEX AMERICAS OR ITS
DIRECTORS, OFFICERS, OR AGENTS
HAVE BEEN ADVISED OF THE POS-
SIBILITY OF SUCH LOSSES, COSTS
OR DAMAGES, OR IF SUCH LOSSES,
COSTS, OR DAMAGES ARE FORESEE-
ABLE. IN NO EVENT WILL GLEN DIM-
PLEX AMERICAS, OR ITS OFFICERS,
DIRECTORS, OR AGENTS BE LIABLE
FOR ANY DIRECT LOSSES, COSTS, OR
DAMAGES THAT EXCEED THE PUR-
CHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF IN-
CIDENTAL OR CONSEQUENTIAL DAM-
AGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO THE
PURCHASER.
How State and Provincial law apply
This limited warranty gives you specic
legal rights, and you may also have other
rights which vary from jurisdiction to juris-
diction. The provisions of the United Na-
tions Convention on Contracts for the Sale
of Goods shall not apply to this limited
warranty or the sale of products covered
by this limited warranty.
Warranty

1-888-346-7539 | www.dimplex.com
In keeping with our policy of continuous product
improvement, we reserve the right to make
changes without notice.
© 2019 Glen Dimplex Americas
Technical Support
Technical and troubleshooting support, as well as a list of
replacement parts can be found on
www.dimplex.com/customer_support.
Scan for a quick link
for customer support
