Dimplex SUTP Mid Range User manual

SUTP Mid Range
Unvented Hot Water Heaters
Installation Manual
30,50 & 75 Litres

Important -This Manual Should Be Left With The Unit After Installation
Table of Contents
1. Introduction.......................................................................................................................................2
2. Component Check List .....................................................................................................................3
3. General requirements........................................................................................................................3
4. Plumbing Installation........................................................................................................................5
7. Electrical installation.........................................................................................................................9
8. Filling and commissioning- ............................................................................................................10
9. Servicing and maintenance. ............................................................................................................11
10. Fault finding..................................................................................................................................12
11. Users instructions..........................................................................................................................13
12. Warranty........................................................................................................................................13
13. Installation, Commissioning and Service Record.........................................................................14
1. Introduction
The “SUTP Mid Range” is a high quality unvented stainless steel domestic hot water cylinder
suitable for domestic hot water systems where the cold mains water supply is between 3bar and 12bar.
Reduced performance is available at lower pressures but the units are not suitable for pressures lower
than 1.5bar and flow rate of 20 litres per minute. The unit comes complete with all the necessary safety
equipment to comply with legislation governing the installation of such systems.
2

Technical Specification
Model Number SUTP30 SUTP50 SUTP75
Storage capacity (litres) 30 50 75
depth (mm) 400 400 400
width (mm) 400 400 400
Overall height incl t&p valve 665 860 1175
Height excl t&p valve 586 781 1093
Weight when full (kg) 47 71 100
Cold feed/hot draw off connections (mm) 22 22 22
Maximum water supply pressure (bar) 12 12 12
System operating pressure (pre-set) (bar) 333
Expansion vessel charge pressure (bar) 333
Expansion relief valve set pressure (bar) 666
Temperature and pressure relief valve settings:
Lift pressure (bar) 777
Lift temperature (ºC) 90 90 90
Package includes*:
Expansion vessel ltr 555
3bar pressure reducing valve, non return valve, 6 bar expansion relief valve,
tundish •••
T/P valve 7bar 90degC factory fitted
•
•
•
15mm to 22mm Tundish
•
•
•
Cylinder with 3kW immersion, thermostat, and manual reset thermal cut-out •••
Installation Manual
•
•
•
Performance:
Heat up time 15 to 65 ºC (min) 36 55 85
Reheat time for 70% of contents (min) 25 38 60
2. Component Check List
The SUTP water heater comes complete with all necessary safety equipment, please check through the
components supplied and ensure that all parts are present:
a. Water Heater
b. 5 litre Expansion Vessel
c. Pressure reducing valve
d. Expansion relief valve
e. Isolation valve
f. Tundish
g. Expansion vessel bracket
Please contact our customer service department immediately should any part be missing.
3. General requirements
3.1. The “SUTP Mid Range” domestic hot water cylinder MUST be installed by a competent person
in accordance with section G3 of the current Building Regulations.
3.2. Important - It is important that the installer reads and understands these instructions, unpacks and
familiarises themselves with the equipment before commencing the installation. Failure to observe
these installation instructions could invalidate the warranty.
3

3.3. Water supply – The water supply to the cylinder should be potable water direct from a public
mains water supply with any water treatment equipment functioning correctly.
For optimum performance the unit should be fed via a 15 mm diameter supply pipe direct from the
mains water entry point to the property with supplies between 3bar and 12bar, however, the the unit
can operate with a minimum supply pressure of 1.5 bar and a flow rate of at least 20 litres per minute,
but flow from the outlets will be low if several outlets are used simultaneously. The cylinder control
equipment is factory set to limit the system operating pressure to 3 bar. The maximum supply pressure
into the pressure-reducing valve is 12 bar.
3.4. Taps and fittings -All taps and fittings incorporated in the unvented system should have a rated
operating pressure of 7 bar or above.
3.5. Location – The unit is designed to be vertically wall mounted, indoors, in a frost-free
environment. When choosing a suitable location for the cylinder, consideration should be given to the
routing of the discharge pipe to a convenient point and also the availability of an adequate power
supply for connecting the immersion heater.
The wall onto which the cylinder is mounted should be of good sound masonry construction capable of
holding the weight of the cylinder when full of water (See Technical specifications for weights).
min 300mm
min 100mm
Unit should be mounted on or near external wall
The position of the cylinder should be such that easy access is provided for servicing the controls and
replacing the immersion heater should the need arise.
Pipe runs should be made as short as possible and lagged to prevent heat loss.
To allow for servicing and repairs the unit must be mounted at least 300mm
above any surface or object, so that access can be gained to electric
connectors and the heating element may be removed.
The unit should be mounted close to an external wall so that the discharge
pipe D2 can be routed to a safe visible place.
The tundish should be mounted in a visible location so that it may easily be
inspected.
3.6. Storage and handling – If the cylinder is not being installed immediately, it should remain in its
carton with all pipe end protective caps in situ to prevent damage. We recommend that the cylinder be
transported to its installation position with the outer carton in place.
3.7. Pipework connections –All Pipework connections to the cylinder MUST be made in accordance
with Fig1.
4

4. Plumbing Installation
4.1. Connections. Connections MUST be made to the cylinder in accordance with Fig 1, and Fig 2.
A drain cock (not supplied) should be fitted in the position shown in Fig 1 to facilitate draining of the
cylinder.
4.2. Cold water supply – For best results, the cylinder should be fed by an uninterrupted 15mm
supply pipe into the pressure reducing valve (PRV) with a supply pressure of between 3 and 12 bar
maximum. The cylinder should not be used on any system with a supply pressure below 1.5 bar and a
flow rate of less than 20 litres per minute.
4.3. Temperature and pressure relief valve – The temperature and pressure relief valve (T&P Valve)
is supplied factory fitted to the cylinder. The T&P Valve must not be removed from the cylinder or
tampered with in any way. The valve is pre calibrated to lift at 7 bar or 90 degrees centigrade and any
attempt to adjust it will invalidate the warranty and could affect the safety performance of the unit.
The outlet of the T&P valve should be routed in 15mm copper piping in a downward direction
alongside the water heating unit to the tundish. The outlet of the expansion relief valve must be T’d
into this pipe before the tundish so that any water exiting either valve can be seen draining through the
tundish– see fig 2
4.4. Pressure Reducing Valve – The pressure relief valve should be installed in the cold water supply
to the water heating unit with the arrow pointing in the direction of water flow as shown in figure 5.
This can be connected to a supply pressure of between 1.5 and 12 bar.
4.5 Expansion Relief Valve this must be installed between the pressure reducing valve and the water
heating unit in accordance with Figure 1. No other valve should be fitted between this valve and the
cylinder. The expansion relief valve contains a non return valve.
4.6. Expansion vessel – A suitable expansion vessel with a pre-charge pressure of 3 bar is supplied for
fitting to all water heating units in the range. The expansion vessel MUST be fitted between the
expansion relief valve and the cylinder. The expansion vessel MUST be positioned with the entry
point at the bottom.
IMPORTANT: Regular checks must be carried out to ensure that the expansion vessel is correctly
pressurised to 3 bar at all times. The expansion vessel should be installed using a standard t-connector
between the expansion relief valve and the cylinder – see Figure 1.
4.7. Tundish – The tundish must not be positioned above or in close proximity of any electrical
current carrying devices or wiring. The installation should conform with the requirements of item 7
below.
5

4.8 Connection arrangement for SUTP Mid Range Cylinder
Fig 1
1 MAINS COLD WATER SUPPLY (15mm)
2 STOP COCK (NOT SUPPLIED)
3 PRESSURE REDUCING VALVE
4 CHECK VALVE if supplied separately (included in RWC expansion relief valve)
5 EXPANSION RELIEF VALVE - SET 6 BAR
6 DISCHARGE PIPE 22mm DIA (SEE SECTION 7)
7 DRAIN COCK (Not Supplied)
8 TUNDISH
9 EXPANSION VESSEL
4.9. Discharge arrangement.
The Tundish must be installed in a position so that it is clearly visible by the user. In addition, the
discharge pipe from the Tundish should terminate in a safe place where there is no risk to persons in
the vicinity of the discharge, be of metal and:
(a) Be at least one pipe size larger than the normal outlet size of the safety device unless its total
equipment hydraulic resistance exceeds that of a straight pipe 9 m long, i.e. discharge pipes between 9
m and 18 m equivalent resistance length should be at least two sizes larger then the normal outlet size
of the safety device, between 18 m and 27 m at least three sizes larger and so on. Bends must be taken
into account in calculating the flow resistance. Refer to the diagram, tables and worked example
detailed in Fig 2.
6

(b) Have a vertical section of pipe at least 300 mm long below the Tundish before any elbows or bends
in the Pipework.
(c) Be installed with a continuous fall
(d) Have discharges visible at both Tundish and the final point of discharge, but where this is not
possible or practically difficult, examples of acceptable discharge arrangements are:
-Ideally below a fixed grating and above the water seal in a trapped gully
-Downward discharge at low level, i.e. up to 100 mm above external surfaces such as car
parks, hard standings, grassed areas, etc. are acceptable providing that where children play
or otherwise come into contact with discharges, a wire cage or similar guard is positioned
to prevent contact whilst maintaining visibility.
-Discharge at high level, e.g. into a metal hopper and metal down pipe with the end of the
discharge pipe clearly visible (Tundish visible or not) or onto a roof capable of
withstanding high temperature discharges of water and 3 m from any plastic guttering
system that would collect such discharges (Tundish visible).
-Where a single pipe serves a number of discharges such as in blocks of flats, the number
served should be limited to not more than six systems so that any installation discharging
can be traced reasonably easily. The single common discharge pipe should be at least one
pipe size larger than the largest individual discharge pipe to be connected. If unvented hot
water stored systems are installed where discharges from safety devices may not be
apparent i.e. in dwellings occupied by blind, or disabled people, consideration should be
given to the installation of an electrically operated device to warn when discharge takes
place.
Warning Notice – The discharge will consist of scalding water and steam. Asphalt, roofing felt and
non-metallic rainwater goods may be damaged by such discharges.
Typical discharge pipe arrangement.
Fig 2
7

8
Sizing of copper discharge pipe “D2” for common temperature relief valve outlet sizes
Valve outlet Min size of Min size of Max resistance Resistance
size, diameter discharge pipe discharge pipe allowed, expressed created by
(inches) D1 in (mm) D2 from tundish as a length of each elbow
in (mm) straight pipe, i.e. or bend
no elbows or (m)
bends.
22 up to 9 0.8
1/2 15 28 up to 18 1.0
35 up to 27 1.4
___________________________________________________________________________
28 up to 9 ----
3/4 22 35 up to 18 ----
42 up to 27 1.7
35 up to 9 1.4
1 28 42 up to 18 1.7
54 up to 27 2.3
___________________________________________________________________________
Worked example
The example below is for a ½”diameter temperature relief valve with a discharge pipe (D2) having 4
22mm elbows and a length of 7 m from the tundish to the point of discharge.
From
Maximum resistance allowed for a straight length of 22mm copper discharge pipe (D2) from a
½”diameter temperature relief valve is: 9.0 m.
Subtract the resistance for 4 No 22mm elbows at 0.8 m each = 3.2 m.
Therefore, the maximum permitted length equates to: 5.8 m.
5.8 m is less than the actual length of 7 m, therefore, calculate the next largest size.
Maximum resistance allowed for a straight length of 28mm pipe (D2) from a ½”diameter temperature
relief valve equates to: 18 m.
Subtract the resistance for 4 No 28mm elbows at 1.0 each = 4 m.
Therefore the maximum permitted length equates to 14 m.
As the actual length is 7 m, a 28mm diameter copper pipe will be satisfactory.

4.10 Secondary Return
Where required the hot water outlet to the taps may be returned to the cold water inlet of the cylinder
using a circulating pump. The secondary return should be connected as per Figure 3. Note the 5litre
vessel included with the water heater is suitable for pipe lengths of up to 180m. For longer pipe runs
the cylinder should be increased in size accordingly.
Figure 3
7. Electrical installation
WARNING: THIS EQUIPMENT MUST BE EARTHED.
All electrical wiring must be carried out by a competent person and in accordance with the current
I.E.E. Wiring Regulations. All pipework should be earthed!
7.1.The immersion heater - A 3kW 230v 50Hz immersion heater is pre fitted to the cylinder at the
factory. It should be wired in accordance with the instructions given in Fig 4. The cable should be
routed through the strain relief bush.
7.2. Wiring instructions
a) The power supply to the heater must be via a double pole isolator switch or controller, having
contact separation of at least 3 mm, using 1.5mm sq. flexible cable, 85°C rubber insulated HOFR
sheathed, to comply with BS 6141 table 8 and must be fully earthed. Wire the water heater in
accordance with the wiring diagram below:
i. Connect the Earth wire to the terminal on the cylinder marked with the earth symbol.
ii. Connect the Live wire to the high temperature cut-out terminal A1
iii. Connect the Neutral wire to the high temperature cut-out terminal B1
WARNING: DO NOT SWITCH ON THE ELECTRICITY SUPPLY UNTIL INSTRUCTED TO DO SO IN
THE COMMISSIONING PROCEDURE AND THE UNIT IS FULL OF WATER.
9

Fig 4
WARNING: THIS APPLIANCE MUST BE EARTHED.
8. Filling and commissioning-
8.1. Check that the expansion vessel charge pressure is 3 bar.
8.2. Check that all water and electric connections are tight and correctly configured.
8.3. Open the main stopcock and fill the unit. Open successive hot taps starting with the tap furthest
from the heater. Leave each tap open for a few moments to allow all air and debris from the system to
exit. Close all of the taps.
8.4 Turn off the mains water supply to the cylinder and drain the system through the drain cock.
8.5 Refill the cylinder with hot taps open and close when water flows freely.
8.6 Manually lift (by rotating the knob) both the expansion relief and the temperature and pressure
relief valves for a short period to remove trapped air from behind the valve seating and to prove the
correct function of the discharge arrangement.
8.7. Check all joints for leaks and rectify as necessary.
8.8. With the heater full of water, turn the thermostat to a point just below its mid point setting and
switch on the electricity supply. Check that the cylinder heats the water and the thermostat operates
when the set temperature is reached. Turn on the hot taps to check that warm water is delivered to the
8.9 Check that while the unit is heating up, no water exits from either the expansion relief or the
temperature and pressure relief valve. If water does exit through the valves check the expansion vessel
pressure and installation.
8.10 Increase the temperature to maximum and allow the unit to heat and the temperature to stabilise.
Check that no water discharges from the valves. Turn on the hot taps to drain the heater of hot water.
Set the thermostat to the required temperature and allow the heater to reheat ready for use.
10

9. Servicing and maintenance.
9.1. Servicing and maintenance must only be carried out by a competent unvented hot water installer
or by Glen Dimplex UK Limited authorised personnel.
9.2. Before any work whatsoever is carried out on the installation, it MUST first be isolated from the
mains electricity supply.
9.3 Only use spare parts authorised by Glen Dimplex UK Limited. The use of other parts will
invalidate the warranty.
9.4. Drain the cylinder – When draining the cylinder, always switch off the boiler and the immersion
heater first. Turn off the water supply at the stopcock (see Fig 1). Connect a hosepipe to the drain cock
(see Fig 1) and route it to a convenient gully. Open the drain cock and all hot taps that are served by
the cylinder. The cylinder may take several minutes to empty completely.
9.5. In hard water areas it may be necessary from time to time to remove and de-scale the immersion
heater element. Replace the gasket each time it is removed.
9.6. Remove the cartridge from the pressure reducing valve. Check the strainer and if necessary
remove any debris from in front of it. Replace the cartridge.
9.7 .Check the charge pressure in the expansion vessel and top up as necessary. The charge pressure
should be 3.0 bar.
9.8. Close the drain cock, disconnect the hose, refit the immersion heater and close all hot water taps
before reopening the stopcock. Allow the cylinder time to fill whilst checking for any leaks. Release
any air from the system by opening each hot water tap individually, starting with the one furthest from
the cylinder.
9.9. Manually lift the expansion relief and temperature and pressure relief valve one at a time, every 12
months (more frequently in hard water areas) to prevent debris from building up behind the valve seat.
Whilst carrying out this operation, check that the discharge to waste is unobstructed. Check that each
valve seals correctly when released. As the valves are pre-calibrated, they require no further
maintenance.
9.10. Finally, when the heater is full of water switch on the mains electricity supply to the immersion
heater and the boiler. As the system heats up, check again for any leaks and rectify as necessary.
9.11 In the event of the manual reset cut-out operating, isolate the heater from the mains supply,
investigate and identify the cause of the operation of this cut-out, rectify the fault before manually
resetting the cut-out via the reset button on the cut-out. Finally switch the mains electricity supply back
on.
11

10. Fault finding.
Notice: Disconnect electrical supply before removing any electrical equipment cover.
Fault Possible cause Remedy
No hot water 1. Mains supply off
2. Strainer in Pressure reducing valve
blocked
3. Pressure reducing valve
incorrectly fitted
1. Open stopcock
2. Turn water supply off, remove
strainer and clean.
3. Re-fit correctly
Water from hot taps is cold 1. Programmer if fitted is not switched
on.
2. High limit thermostat has tripped
1. Set programmer to call
3. Check and re-set
Intermittent water discharge
through tundish on warm-up 1. Expansion vessel has lost its
charge pressure 1. Turn off stopcock open a hot water tap check vessel charge pressure and
recharge to 3 bar
Continuous water discharge 1. Pressure reducing valve (PRV) not
working
2. Expansion relief valve not seating
correctly
3. Temperature and pressure relief
valve not seating correctly
1. Check pressure from Pressure
reducing valve if greater than 3 bar
replace cartridge
2. Manually lift the valve once or twice
to clear any debris from the seat
otherwise replace valve
3. Manually lift the valve once or twice
to clear any debris from the seat
otherwise replace valve
12

11. Users instructions.
11.1 Your “SUTP Mid Range” unvented hot water cylinder has been designed to give many years of
trouble free service and is made from hygienic high grade stainless steel.
11.2. When a hot tap is turned on there may be a short surge of water, this is quite normal with
unvented systems and does not mean there is a fault.
11.4. When you first fill a basin the water may sometimes appear milky. This is due to very tiny air
bubbles in the water which will clear very quickly.
11.5. If water is seen dripping through the tundish at any time switch off the electricity supply
immediately and call the installer or the Dimplex customer service department on the number listed at
the end of this guide.
12. Warranty
12.1. Glen Dimplex UK Limited guarantee all electrical and mechanical controls supplied with the
cylinder for a period of 2 years from the date of purchase provided that they have been installed for
their intended use by a competent person and have not been modified in any way.
12.2. In addition Glen Dimplex UK Limited also guarantees the stainless steel hot water cylinder for a
period of 10 years from the date of purchase against faulty material or manufacture provided that:
(a) It has been installed by a competent person in accordance with this installation manual and all
current regulations and codes of practice at the time of installation.
(b) It has been used solely for the purpose of heating potable water that complies with current (at
the time of installation) EU standards and is not fed with water from a private source.
(c) It has not been modified in any way.
(d) It has not been subjected to excessive pressure or electrolytic action from dissimilar materials,
or attack from any salt deposits.
(e) It has been installed indoors in a frost-free environment.
(f) The warranty card is completed and returned to Dimplex UK Limited within 90 days of
installation.
This warranty is not transferable. This warranty does not include claims due to frost or lime scale
damage. Proof of purchase will be required against any claim. This guarantee does not affect your
statutory rights.
For help about the SUTP Mid Range please contact the Dimplex Customer Services Department:
Glen Dimplex UK: Millbrook House, Grange Drive, Hedge End, SO30 2DF
Tel [phone] Fax [phone]
13

13. Installation, Commissioning and Service Record
CUSTOMER DETAILS
NAME
ADDRESS
TEL No.
INSTALLER DETAILS
COMPANY NAME DATE
ADDRESS
TEL No.
INSTALLER NAME REGISTRATION No.
COMMISSIONING ENGINEER (IF DIFFERENT)
COMPANY NAME DATE
ADDRESS
TEL No.
INSTALLER NAME REGISTRATION No.
CYLINDER DETAILS
MODEL
CAPACITY LITRES SERIAL NO.
SERVICE RECORD DETAILS
Before completing the appropriate Service Interval Record below, please ensure you have carried out the service as
described in the manufacturer’s instructions and in compliance with all relevant codes of practice.
It is recommended that your hot water system is serviced regularly and that your service engineer completes the
appropriate Service Interval Record below.
SERVICE 1 DATE:
SERVICE 2 DATE:
SERVICE ENGINEER SERVICE ENGINEER
TEL NO. TEL NO.
REGISTRATION NO. REGISTRATION NO.
SIGNATURE SIGNATURE
SERVICE 3 DATE:
SERVICE 4 DATE:
SERVICE ENGINEER SERVICE ENGINEER
TEL NO. TEL NO.
REGISTRATION NO. REGISTRATION NO.
SIGNATURE SIGNATURE
SERVICE 5 DATE:
SERVICE 6 DATE:
SERVICE ENGINEER SERVICE ENGINEER
TEL NO. TEL NO.
REGISTRATION NO. REGISTRATION NO.
SIGNATURE SIGNATURE
SERVICE 7 DATE:
SERVICE 8 DATE:
SERVICE ENGINEER SERVICE ENGINEER
TEL NO. TEL NO.
REGISTRATION NO. REGISTRATION NO.
SIGNATURE SIGNATURE
SERVICE 9 DATE:
SERVICE 10 DATE:
SERVICE ENGINEER SERVICE ENGINEER
TEL NO. TEL NO.
REGISTRATION NO. REGISTRATION NO.
SIGNATURE SIGNATURE
14
