Dini Argeo TPW Series Operating instructions

www.diniargeo.com
TPW
Pallet truck with integrated scale
ENGLISH
USER, INSTALLATION, MAINTENANCE INSTRUCTIONS - v4

TPW 3
IDENTIFICATION 8
Identification of the Manufacturer 8
Machine identification 8
Identification plate 8
EC Declaration of Conformity 9
Reference directives 10
PRELIMINARY INFORMATION 11
Recipients 11
Supply and storage 11
Updates 11
Language 12
Operators 12
Symbols used inside the manual 12
Personal protective equipment 13
Warranty 14
SAFETY DEVICES 15
Noise 15
Vibrations 15
Residual risks 15
Safety pictograms applied to the machine 16
DESCRIPTION 17
Intended use (correct) 17
Reasonably foreseeable misuse 17
Obligations and prohibitions 18
Operator obligations 18
Operator prohibitions 18
Technical data 19
Environmental conditions permitted 22
Main components 23
Rechargeable battery 24
Optional components 25
USER_MAN_ENG_TPW_v4
ContentsContents

TPW 4
PACKAGING AND HANDLING 27
Packaging and handling warnings 27
Packaging 28
Packaging handling 28
Packaging removal 29
Packaging disposal 29
ASSEMBLY 30
Assembly warnings 30
Assembly procedure 31
Descent adjustment 35
COMMANDS 36
Tiller commands 36
Display 37
Keyboard types 38
USE 40
General warnings for correct use 40
Pallet truck conditions 42
Checks before use 43
Display switch-on 43
Pallet truck positioning 44
Load lifting and weight reading 44
How to replace the roll 45
Customisable printouts 45
BASIC SCALE FUNCTIONS 46
Start-up - On 46
Shutdown - O 46
Zero 46
Display brightness adjustment 47
Automatic tare 47
Tare deletion 48
USER_MAN_ENG_TPW_v4
Contents

TPW 5
Set a known tare value (PT) 48
Print 49
Metrics 50
ADDITIONAL FUNCTIONS FOR MODELS WITH NUMBER KEYPAD 51
30-tare log 51
Automatic tare deletion 52
Number IDs 53
Date and time 54
Print (and reprint of last receipt) 55
Metrics 56
ADVANCED SCALE FUNCTIONS 57
How to access the function menu 57
Horizontal accumulator 58
Mixing several components 60
Piece count 62
Weight check 65
Exchange between net weight and gross weight 69
Percentage weighing 70
Unit of measurement conversion 73
METROLOGICAL SCALE INFORMATION 75
MAINTENANCE 76
Maintenance warnings 76
Scheduled maintenance 77
Scheduled maintenance table 77
Oil level top-up 78
Tank top-up for models with pump with plug 78
Tank top-up by means of syringe for models with mono-block pump 79
Unscheduled maintenance 80
USER_MAN_ENG_TPW_v4
Contents

TPW 6
TROUBLESHOOTING CASES 81
Error messages 83
USER_MAN_ENG_TPW_v4
Contents

TPW 7
i
Introduction
USER_MAN_ENG_TPW_v4
Dear Customer, Thank you for choosing a DINI ARGEO product.
The manual weighing pallet truck that you have purchased is ideal for handling and weighing pallets or standardised
containers directly where they are located, saving you time and money.
It is equipped with high performance weighing electronics, precise and durable, and features a multifunctional
program that can help you perform your daily tasks. Before using the instrument, please read this instruction manual
carefully in order to be able to use it in complete safety and to learn about all of the functions it oers.
Safety information - Warnings
• Read this manual carefully before carrying out any handling operations or lifting any loads.
• This pallet truck is designed to weigh exclusively on standardised pallets.
• With approved scale, you can perform weighing on EUR-EPAL pallet 800x1200mm (ref. Standards UIC
435-2 and UIC 435-4).
• NEVER load the scale beyond the maximum capacity stated on the plate of the weight readout instrument.
 IT IS forbidden to use the scale in environments where there is the danger of fire or explosion.
• Do not load the forks when they are raised, not even partially.
• Before using the pallet truck ensure it is in perfect working order.
• To achieve a correct weighing result, the forks need to be raised by at least 5-10 cm (Paragraph “Load
lifting and weight reading” ref.).
• Do not expose the pallet truck to atmospheric agents (sun, rain, etc.).
• Use the pallet truck in non-condensing environments with moderate temperature and humidity levels
• Use the pallet truck where there are no vibrations.
• Carefully read and apply the aforementioned description of the weight indicator.
• To clean the pallet truck, avoid the use of solvents or aggressive substances.
• It is forbidden to make any modifications to the truck if not authorised by the manufacturer.
• It is forbidden to use the pallet truck when it no longer fulfils the safety criteria.
• It is forbidden to use flammable products to clean the truck.
• Except with specific models, it is forbidden to wash the pallet truck with direct jets of water.
• Do not pour liquids on the indicator.
• Anything not specifically described in this manual is to be considered improper use of the equipment.
• The crossed out wheelie bin symbol on the product shows that it must be brought to appropriate
separate waste collection centres at the end of its life cycle or returned to the dealer when pur-
chasing a new equivalent product.
• Proper separate collection to then send the product to recycling contributes to preventing possible
negative effects on the environment and to health and promotes recycling. Users who dispose of
the product illegally shall face administrative sanctions as provided for by law.
The safety precautions described in this manual, marked with the symbol, must be followed during all installation,
use, maintenance or repair stages of the weighing system.
Any use other than that reported in this manual, as well as not following the safety precautions, relieves the
manufacturer from any responsibility and will void the product warranty.

TPW 8
Mod.
Sn
TPWLKP-5
0100574294
Dini Argeo - v. Fisica, 20 - 41042 Fiorano (MO) Italy
UK 2945
6V DC
Max
Min
e =
B1W1 B1W2 B1W3
500 kg 1000 kg 2000 kg
4 kg 10 kg 20 kg
0.2 kg 0.5 kg 1 kg
Identification
USER_MAN_ENG_TPW_v4
IDENTIFICATION
Identification of the Manufacturer
Manufacturer DINI ARGEO s.r.l.
Address Via della Fisica, 20
41042 Spezzano di Fiorano Mod.se (MO) - Italy
Tel. [phone] Fax [phone]
[email protected]om
Machine identification
Machine PALLET TRUCK WITH INTEGRATED SCALE
Model TPWXX
Identification plate
The machine is equipped with an identification plate positioned in the upper part of the column.
The identification details of the machine, to be cited to the Support Centre if required, are provided on the plate.
WARNING!
It is strictly forbidden to remove the CE identification plate and/or replace it with other plates.
If, for accidental reasons, the plate is damaged or removed, the customer must inform the Manufacturer.

TPW 9
Identification
USER_MAN_ENG_TPW_v4
DICHIARAZIONE DI CONFORMITA’
DECLARATION OF CONFORMITY
KONFORMITÄTSERKLÄRUNG
DÉCLARATION DE CONFORMITÉ
DECLARACIÓN DE CONFORMIDAD
Fabbricante:
Manufacturer:
Hersteller:
Fabricant:
Fabricante:
DINI ARGEO srl
Via della Fisica,20
Fiorano Modenese (MO) Italy
Modello:
Model:
Modell:
Modèle:
Modelo:
TPW20APM-2
Anno di costruzione:
Manufacturing year:
Herstellungsjahr:
Année de fabrication:
Año de construcción:
2018
Numero di serie:
Serial number:
Seriennummer:
Numéro
de série:
Número de serie:
0100611649
E’ conforme alle direttive:
-Conforms to the directives: / Konform mit folgenden richtlinien ist: / Est conforme aux directives: / Es conforme a las directivas:
2014/30/EU - Compatibilità Elettromagnetica
-Elecrtomagnetic Compatibility / Elektromagnetische Kompatibilität / La compatibilità Electromagnétique / Compatibilidad
Electromagnética
-Con riferimento alle norme armonizzate:
-With reference to these harmonised norms: / Mit Bezug auf die Normen: / En référence aux normes harmonisées: / Con referencia
a las normas armonizadas:
EN 61000-6-2 / 2005; EN 61000-6-4 / 2007 / A1:2011; EN 61326-1 / 2013; EN 55011 /
2009)
2006/42/CE - Macchine
-Machines / Maschinen / Machines / Máquinas
UNI EN 13155 / 2009 ; UNI EN 13889
-Only for / Nur für / Seulemen pour / Solo per MCW/TPW
Dichiara inoltre che:
Declares also that: / Der Hersteller erklärt auβerdem, dass: / Déclare également que: / Declara también que:
-La persona autorizzata a costituire il fascicolo tecnico presso la sede del fabbricante è la
Direzione Tecnica.
The person authorised to compose the technical file at the premises of the manufacturer is the Technical Management. / Die
autorisierte Person, die die technischen Dokumente im Firmensitz des Herstellers verwaltet, ist das technische Management. / La
personne autorisée à constituer le dossier technique chez la siége du fabricant est le directeur technique. / La persona autorizada a
constituir el expediente técnico en la sede del fabricante es la Dirección Técnica.
Fiorano Mod.se (MO) Italy, 14/03/2018
Firma/Signature/Unterschrift
President
Rev. 2
EC Declaration of Conformity
The EC Declaration of Conformity is available on: www.diniargeo.com
FAC-SIMILE

TPW 10
Identification
USER_MAN_ENG_TPW_v4
Reference directives
The machine supplied by DINI ARGEO does not fall within one of the categories of machines listed in Annex IV
of the Directive; therefore, for the purposes of certifying conformity of the machinery with the provisions of this
Directive, DINI ARGEO shall apply the conformity assessment procedure with internal check on the manufacture of
the machinery, as set out in Annex VIII.
To certify the conformity of the machine with the provisions of the Directive, DINI ARGEO before placing it on
the market, has carried out the risk assessment in order to verify compliance with the essential health and safety
requirements of the Directive as well as the tests and the checks required by the reference standards applied.
The technical construction file has been compiled in compliance with the provisions of Annex VII of Directive
2006/42/EC and is available for inspection by supervisory authorities upon a reasoned request, as required by the
laws in force on the matter.
DINI ARGEO s.r.l. then places the machine on the market, constituting it with:
• CE Marking
• EC Declaration of Conformity
• Instruction manual for use, installation and maintenance (Documentation drawn up according to section 1.7.4 of
the Machinery Directive 2006/42/EC)
please note that the machine has been designed according to the following Directives:
• 2006/42/EC Machinery Directive
• 2014/30/EU Electromagnetic Compatibility Directive
And that the following harmonised standards have been applied:
• EN 61000-6-2 / 2005
• EN 61000-6-4 / 2007 / A1:2011
• EN 61326-1 / 2013
• EN 55011 / 2009
• UNI EN 13155 / 2009
• UNI EN 13889

TPW 11
Preliminary information
USER_MAN_ENG_TPW_v4
PRELIMINARY INFORMATION
Recipients
The manual is intended for operators responsible for using and managing the machine throughout all its technical
lifespan stages. It contains the topics referring to the correct use of the machine, in order to maintain its functional
and qualitative characteristics unchanged over time. All information and warnings for correct use in complete safety
are also provided.
The manual, similarly to the EC compliance certificate, is an integral part of the machine and must always accompany
it if moved or resold. It is the responsibility of the user to keep this documentation intact, to allow consultation,
throughout the lifespan of the machine itself.
Supply and storage
The manual is available in electronic format on: www.diniargeo.com
Store this manual supplied with the machine, in order for it to be easily consulted by the operator.
The manual is an integral part for safety purposes, therefore:
• it must be kept intact (in all its parts). Should it be lost or damaged, it is required to request a copy immediately.
• it must follow the machine until demolition (even in case of movements, sale, lease, rental, etc....);
DINI ARGEO declines any liability for improper use of the machine and/or damage caused as a result of operations
not covered by the technical documentation.
Updates
Should the machine require functional modifications or replacements, the revision or update of the manual is the
responsibility of the Manufacturer. The Manufacturer is responsible for the delivery of the update of the manual.
The user is also responsible for ensuring that, if the present document is modified by the Manufacturer, only the
updated versions of the manual are actually present in the points of use.

TPW 12
Preliminary information
USER_MAN_ENG_TPW_v4
Language
The original manual has been drawn up in Italian.
Any translations into additional languages must be carried out starting from the original instructions.
The Manufacturer considers himself responsible for the information contained in the original instructions; translations
in dierent languages cannot be fully verified, therefore if an incongruity is detected, it is required to follow the
original text or contact the Support Centre.
Operators
In order to establish with certainty what are the skills and qualifications of the operators involved in the various tasks
(commissioning, cleaning, scheduled maintenance), refer to the following table:
Qualification Description
OPERATOR Personnel of the user trained and qualified to use and run the machine for production purposes for
the activities for which it was built and supplied.
They must be able to perform all the operations required for proper functioning of the machine
and for the safety of themselves or of any collaborators. They must have proven experience in the
correct use of these types of machines and be trained, informed and instructed in this regard. In
case of doubt, they must report any anomaly to their superior.
Note: they are not authorised to carry out any maintenance operation.
MECHANICAL
MAINTENANCE
TECHNICIAN
Qualified technician able to perform preventive/corrective maintenance on all mechanical parts of
the machine subject to maintenance or repair.
Qualified technician able to access all machine parts for visual analysis, checking the equipment
status, adjustments and calibrations.
Note: they are not authorised to operate on live electrical systems (if any).
MANUFACTURER’S
TECHNICIAN
Technician qualified by the Manufacturer and/or their distributor for complex operations, as they
are aware of the production cycle of the machine.
This person operates according to the user's requests.
Symbols used inside the manual
Symbol Description
Symbol used to identify important warnings for the safety of the operator and/or machine.
Symbol used to identify information of particular importance within the manual. The information
also concerns the safety of personnel involved in using the machine.

TPW 13
Preliminary information
USER_MAN_ENG_TPW_v4
Personal protective equipment
When working near the machine, both for assembly operations and for maintenance and/or adjustment, it is strictly
required to comply with the general accident-prevention regulations, therefore it will be important to use the personal
protective equipment (PPE) required for each individual operation.
The complete list of personal protective equipment (PPE) that may be required for the dierent procedures is
provided below:
Symbol Description
Obligation to use safety or insulating gloves.
Indicates a requirement for the personnel to use safety or insulating gloves.
Obligation to use safety goggles.
Indicates a requirement for the personnel to use safety goggles.
Obligation to use safety footwear.
Indicates a requirement for the personnel to use safety footwear.
Obligation to use noise protection devices.
Indicates a requirement for the personnel to use earplugs or earmus for hearing protection.
Obligation to use safety clothing.
Indicates a requirement for the personnel to wear the specific safety clothing.
The clothing of those operating or maintaining the line must comply with the essential safety requirements defined
by the EU Reg.2016/425 and with the laws in force in the country where the line is installed.

TPW 14
Preliminary information
USER_MAN_ENG_TPW_v4
Warranty
IMPORTANT!
The complete warranty terms are set out in the sales contract.
The conditions foreseen in the commercial contract (if different) have priority over what is provided in
this section.
The warranty is subject to the following general conditions:
• the machine must be used within the limits stated in the contract and provided in the technical documentation.
• maintenance must be carried out in the times and in the ways required by the manual, using original DINI ARGEO
spare parts and entrusting the operations to qualified personnel.
The warranty is void in case of:
• failure to comply with the safety regulations;
• removal or tampering with control and safety devices;
• improper use of the machine;
• use of the machine by untrained and/or unauthorised personnel or failure to comply with the skills of the various
operators, as indicated in the manual;
• modifications or repairs made by the user without the Manufacturer's written authorisation;
• partial or total failure to comply with the instructions;
• lack of maintenance;
• use of non-original spare parts;
• exceptional events such as flooding, fires (if not caused by the machines).

TPW 15
Safety devices
USER_MAN_ENG_TPW_v4
SAFETY DEVICES
Noise
Noise measurements have been carried out in accordance with the provisions of standards UNI EN 11200 and UNI
EN ISO 3746.
During the operating cycles, under conditions of perfect functioning and maintenance and on a smooth industrial
surface, noise exposure of the personnel is less than 70 dB .
It is the user's responsibility to apply the resulting preventive and protective measures, in compliance with the
legislation of the country where the machine is installed and used.
Vibrations
The vibrations produced by the machine, according to its mode of operation, are not dangerous to the health of the
operators.
WARNING!
Excessive vibration can only be caused by a mechanical fault that must be immediately reported and
eliminated, in order not to compromise the safety of the line and of the operators.
Residual risks
The machine has been designed to assure the essential safety requirements for the operator.
Safety has been integrated into the design and construction of the machine as far as possible; however, risks from
which operators must be protected remain.
For each residual risk, a description of the risk and of the zone or part of the machine subject to the residual risk is
provided (unless it is a risk valid for the entire machine). Procedural information on how to avoid the risk and on the
correct use of the personal protection devices provided and required by the Manufacturer is also provided.
Risk Description and procedural information
Risk of crushing The risk of crushing lower limbs under the load during its descent remains.
Risk of load
falling The risk of load falling and crushing during handling operations remains.

TPW 16
2
1
4
3
Safety devices
USER_MAN_ENG_TPW_v4
Safety pictograms applied to the machine
Stickers and safety plates are applied to the machine, as shown in the following table. Refer to the image for positioning.
Pos. Pictogram Description
1
Mod.
Sn
TPWLKP-5
0100574294
Dini Argeo - v. Fisica, 20 - 41042 Fiorano (MO) Italy
UK 2945
6V DC
Max
Min
e =
B1W1 B1W2 B1W3
500 kg 1000 kg 2000 kg
4 kg 10 kg 20 kg
0.2 kg 0.5 kg 1 kg
CE IDENTIFICATION PLATES
2
WARNING PLATE:
• load lowering;
• load transport;
• load lifting;
• oil filling;
• do not use on slopes.
3MANUFACTURER DATA STICKER
4BATTERY INDICATIONS STICKER

TPW 17
Description
USER_MAN_ENG_TPW_v4
DESCRIPTION
Intended use (correct)
The machine in question is intended for industrial use for:
• the weighing and handling of objects placed on Europallet.
Max Europallet capacity permitted:
MODEL CAPACITY
TPWN 2000 kg
TPWP 2500 kg
TPWLK 2000 kg
TPWA 2000 kg
TPWI 2000 kg
TPWLKI 2000 kg
The machine has been designed to:
• meet the specific needs mentioned in the sales contract;
• be used according to the instructions and limits of use provided in this manual.
The machine has been designed and built to operate safely if:
• it is used within the limits stated on the contract and in this manual;
• the user manual procedures are followed;
• scheduled maintenance is carried out in the times and in the ways indicated;
• unscheduled maintenance is promptly carried out if required.
Reasonably foreseeable misuse
The reasonably foreseeable misuses, which are to be intended as strictly forbidden, are listed below:
• transporting people;
• transporting unstable or incorrectly stacked loads or fluids;
• using the machine as a support point;
• using the machine on a slope;
• using the machine in poorly lit areas;
• using the machine in order to obtain production values above the required limits;
• using the machine dierently than described in paragraph “Intended use (correct)”.
Any other use of the machine with respect to that required must be previously authorised in writing by the Manufacturer.
In the absence of said written authorisation, the use is to be considered “improper use”; therefore the Manufacturer
declines any responsibility in regards to damage caused to property or people and deems any type of warranty on
the machine expired.
IMPORTANT!
An improper use of the machine relieves the Manufacturer from any responsibility.

TPW 18
Description
USER_MAN_ENG_TPW_v4
Obligations and prohibitions
Operator obligations
The operator must:
• Perform maintenance operations always with the machine switched o. Not lubricate moving parts.
• When the machine is running, not operate nearby while wearing chains, bracelets, ties or other clothing that may
get caught in the mechanisms.
• Operators with long hair must tie them up in order to prevent them from getting entangled.
• During operation, pay the utmost attention that no person is able to directly access moving parts.
• Use the protective devices made available by the employer in an appropriate manner.
• Immediately report any deficiencies of the safety devices to the employer, the manager or the person in charge.
Operator prohibitions
Specifically, operators must not:
• use the machine improperly, i.e. for uses other than those indicated in the paragraph “Intended use (correct)”;
• remove or modify safety or warning devices without authorisation;
• carry out operations or manoeuvres that are not within their competence or that may compromise their own
safety or that of other workers on their own initiative;
• wear bracelets, rings or chains that can dangle and be dragged by moving parts, creating a hazard for the
operator;
• replace or modify the speed of the components of the machine without being authorised by a manager;
• use the machine if it has not been installed according to the regulations in force;
• use the machine as a support point even if it is not running (under risk of falling and/or the risk of damaging the
machine itself);
• use the machine outside the environmental conditions permitted (consult the paragraph “Environmental
conditions permitted”).
WARNING!
DINI ARGEO is not liable for damage to things or people if it is ascertained that the machine has been
used in a non permitted environment.

TPW 19
Description
USER_MAN_ENG_TPW_v4
Technical data
TPWN
Material PAINTED STEEL
Fork dimensions 1150 x 550 x 87 mm *
Weight 110 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2000 kg
IP Degree -
Power supply BATTERY, 4 “AA” TYPE
Printer -
Keyboard 5 KEYS
Operating life 40 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.
TPWLK
Material PAINTED STEEL
Fork dimensions 1150 x 550 x 85 mm *
Weight 125 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2000 kg
IP Degree 65 (ONLY VERSIONS WITHOUT PRINTER)
Power supply WITH REMOVABLE BATTERY
Printer OPTIONAL
Keyboard 17 KEYS
Operating life 80 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.
TPWA
Material PAINTED STEEL
Fork dimensions 1150 x 550 x 85 mm *
Weight 125 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2000 kg
IP Degree -
Power supply WITH REMOVABLE BATTERY
Printer AS PER STANDARD
Keyboard 17 KEYS
Operating life 80 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.

TPW 20
Description
USER_MAN_ENG_TPW_v4
TPWET
Material PAINTED STEEL
Fork dimensions 1150 x 550 x 85 mm *
Weight 125 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2000 kg
IP Degree 65 (ONLY VERSIONS WITHOUT PRINTER)
Power supply WITH REMOVABLE BATTERY
Printer OPTIONAL
Keyboard TOUCHSCREEN
Operating life 10 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.
WARNING!
For the functions of the models with touchscreen keypad, refer to the specific manual of the weight
indicator software.
TPWP
Material PAINTED STEEL
Fork dimensions 1150 x 550 x 85 mm *
Weight 125 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2500 kg
IP Degree 65 (ONLY VERSIONS WITHOUT PRINTER)
Power supply WITH REMOVABLE BATTERY
Printer OPTIONAL
Keyboard 17 KEYS
Operating life 80 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.
TPWLKW
Material PAINTED STEEL
Fork dimensions 1240 x 680 x 85 mm *
Weight 134 kg
Wheels GUIDE WHEELS AND DOUBLE LOADING WHEELS IN POLYURETHANE *
Max capacity 2000 kg
IP Degree 65 (ONLY VERSIONS WITHOUT PRINTER)
Power supply WITH REMOVABLE BATTERY
Printer OPTIONAL
Keyboard 17 KEYS
Operating life 80 hrs
* Dierent sizes and materials are available at the specific request of the purchaser.
