Diono monterey 5 iST FixSafe User manual

monterey 5 iST FixSafe
booster seat
instruction manual
asiento elevador
manual de instrucciones
READ INSTRUCTION MANUAL
before using this child restraint
LEA LAS INSTRUCCIONES
antes de usar este asiento de seguridad para niños
40–120 lb (18–54 kg)
38–63” in./po (97–160 cm)
siège d’appoint
manuel d’instructions
LIRE LE MODE D’EMPLOI
avant d’utiliser ce dispositif de retenuepour enfant

diono.commonterey 5
2 3
CONTENTS
Français
Español
Register This Car Seat
Our Story
Safe Use Guide
Warnings & Safe Practices
Vehicle Seat Belt Systems
Car Seat Use After a Collision
Parts Listing
Installation & Removal
Securing the Child
Cup Holder
Carry Strap
Care & Maintenance
Warranty
28
54
4
5
6
7–10
11
12–13
14–15
16–17
18–19
20
21
22–23
24–27
BEFORE YOU BEGIN
WE LOVE TO HELP
Hello there, Welcome to the Diono Family!
We’ve created this lovingly engineered car seat
to help keep your child comfortable and safe
with all of the goods and none of the gimmicks.
We look forward to lending a helping hand each
and every day :)
Any questions?
Diono U.S.: 1-855-463-4666
Diono Canada: 1-866-954-9786

diono.commonterey 5
4 5
REGISTER THIS CAR SEAT
Time. It goes so fast…
Who would have thought that nearly two decades have passed since
we first stepped out into the world and started a business dedicated
to family travel.
Well the world has changed a lot, but we’re proud to say that we
haven’t,(sure we’ve grown up), but we’re still as passionate about
what we do today as we were back then.
Our story is ‘Made of Seattle’, a city like no other. This is a place where
creative minds and innovators rub shoulders within a landscape of
adventure; a place, where being ‘a little dierent’, is the everyday
norm.
With a love for design and an understanding of modern parenting, we
strive to create amazing products, so that you and your little ones can
celebrate the joy in every journey.
People who own Diono products can be found in all four corners of
the big blue green ball, we all call home. Some are fans and followers,
some are supporters, tweeters, social media magicians, miracle moms
and devoted dads.
Without your passion, pictures, words and stories, we would never
hear your voice.So tell us about your patch of grass, and join in the
hustle and bustle at diono.com.
share your journey @diono social or find the latest news.
OUR STORY
For future reference, in the case of a change of address. Please take
a moment to fill out the following information:
This information can be found either on the registration card or on
the manufacturing label located on the seat.
For U.S. recall information, call the U.S. Government’s Vehicle Safety
Hotline at 1-888-327-4236 (TTY: 1-800-424-9153), or go to
http://www.NHTSA.gov.
Diono U.S.
PO Box 77129
Seattle, WA 98177
or call 1-855-463-4666
or register online at:
diono.com/us/product-registration/
Diono Canada ULC
2160 S. Service Rd., W.
Oakville, ON L6L 9Z9 Canada
or call 1-866-954-9786
or register online at:
diono.com/ca/product-registration/
Please take a moment to fill out the prepaid registration card
attached to the seat and mail it in today or register online at:
Diono U.S.: diono.com/us/product-registration
Diono Canada: diono.com/ca/product-registration/
Child restraints could be recalled for safety reasons. You must register
this restraint to be reached in a recall. Send your name, address,
e-mail address if available, and the restraint’s model number and
manufacturing date to:
DO NOT SCALE - ART CANNOT BE SCALED
118 mm
35 mm
Model Name / Nom de modéle / Nombre de modelo:
Model Number / Numéro de modè / Número de Modelo:
Serial Number / Numéro de serie / Número de Serie:
Manufacture Date / Date de fabrication /
Fecha de fabricacion:
Diono | Designed & Engineered in Seattle,WA | Conçu et développer à Seattle,WA | Diseñado y Desarrollado en Seattle,WA
Made in China | Fabriqué en Chine | Hecho de China
Diono US LLC, 14810 Puyallup St E, Suite 200, Sumner,WA 98390, United States
year/année/año month/mois/mes day/jour/día
BLACK
6 C
WHITE
PANTONE CALLOUTS:
PROJECT NAME: Manufacturing STICKER – NA
PROJECT:
SCALE: TO SCALE 1:1
DRAWN BY: Technical Compliance — S Staub
DATE: 01/23/2020 © Diono LLC 2020
Car Seats, Booster Seats
QUALITY: VINYL WITH HI TAC ADHESIVE
(MUST BE PERMANENT WHEN APPLIED)

diono.commonterey 5
6 7
SAFE USE GUIDE
WARNING  Carefully read and understand all instructions
and warnings in this manual, and those labeled on your Child
Restraint. Failure to do so can result in SERIOUS INJURY or
DEATH of your child.
SAFE USE REQUIREMENTS:
This Child Restraint is designed for use ONLY with children who weigh
40—120 lb (18—54 kg) AND whose height is 38—63 in. (97—160 cm).
Use ONLY the vehicle lap and shoulder belt system when restraining
the child in this booster seat. DO NOT use a lap belt only!
UseUse ONLY with children whose ears are below the top of eitherwith children whose ears are below the top of either
the fully raised booster seat head support or the fully raised vehiclethe fully raised booster seat head support or the fully raised vehicle
headrest.headrest.
CERTIFICATIONS:
This Child Restraint System conforms to all applicable
Federal Motor Vehicle Safety Standards (FMVSS 213) and
Canadian Motor Vehicle Safety Standards (CMVSS 213.2).
This child restraint is certified for use in passenger cars,
multi-purpose passenger vehicles, and trucks ONLY.
THIS RESTRAINT IS NOT CERTIFIED FOR USE IN AIRCRAFT.
Aircraft seats do not have shoulder belts which are required for use
with this booster seat.
!
DO NOT PLACE A CHILD RESTRAINT IN THE
FRONT SEAT OF A VEHICLE WITH A PASSENGER
AIR BAG. DEATH OR SERIOUS INJURY MAY OCCUR.
If an air bag inates, it can hit the child or
child restraint with enough force to cause
serious injury or death to your child.
The back seat is the safest place for children 12 and
under. Refer to your vehicle owner’s manual for
information on your child restraint installation.
WARNING!
According to accident statistics, children are safer when properly
restrained in the rear seating positions than in the front seating
positions.

diono.commonterey 5
8 9
• Read all instructions before using this child restraint. Keep
instructions stored underneath the booster seat base for future use.
• Before installing this child restraint in a vehicle, be sure to also check
the vehicle owner’s manual for information on proper installation.
• DO NOT use child restraint in any configuration not shown in the
instructions.
• Use ONLY with children who weigh 40—120 lb (18—54 kg) AND
whose height is 38—63 in. (97—160 cm).
• Use ONLY the vehicle lap and shoulder belt system when
restraining the child in this booster seat.
• NEVER use with vehicle lap belt ONLY to restrain a child. This
could result in serious injury or death.
• ALWAYS make sure the vehicle seat belt can properly retract
before each use.
• NEVER leave your child unattended.
• NEVER install in rear-facing, side-facing or on the back of a
folded down vehicle seat.
• ALWAYS install this booster seat in the rear vehicle seat.
• DO NOT use this booster seat with any other backrest or cushions.
• ALWAYS secure the booster seat using the vehicle belt or ISOFIX
connectors even when it is unoccupied. It could injure other
occupants in a sudden stop or crash.
• DO NOT use any accessories, inserts or products not included
with this booster seat, unless approved by Diono. Items not
tested with this booster seat could injure your child.
• DO NOT modify your booster seat.
• NEVER provide this booster seat to another person without also
providing them with the instruction manual.
• Unsecured objects can become flying hazards and can cause
serious injury in an accident.
WARNING!
DEATH or SERIOUS INJURY can occur.
WARNING!
DEATH or SERIOUS INJURY can occur.
