Direct Healthcare Group GATE Bure Double 2.0 User manual

A DIRECT HEALTHCARE GROUP COMPANY
GATERD.SE
Bure Double 2.0
User Manual

BURE DOUBLE 2.0
GATERD.SE2

USER MANUAL
3
GATERD.SE
The new Bure Double is equipped with twin electric drives for raising and lowering the walker and widening the
walking frame. The new version has a signicantly lower height above the walking frame for better access and
a higher user weight (150 kg) compared to the earlier version.
Contents
1. Raising/lowering the frame 04
2. Adjusting the handles 04
3. Left and right adjustment of armrests 04
4. Locking castors/Unlocking castors 04
5. Control box wiring 04
6. Battery charging 05
7. LED on controlbox and battery 05
8. Maintanance 06
9. General maintenance advice 07
10. Technical specications 07
Bure Double 2.0

BURE DOUBLE 2.0
GATERD.SE4
1. Höjning/Sänkning av sits
Preferred height; adjust using <UP> arrow or <DOWN> arrow.
Adjust bottom frame using <WIDER> arrow or <NARROWER> arrow.
2. Adjusting the handles
To adjust handles to the desired position; loosen screw, adjust handle, tighten
screw.
3. Left and right adjustment of armrests
The handles are adjusted to the desired position by: Loosening the knob of the
handles adjustable locks.
4. Locking castors/Unlocking castors
Bure Double is tted with braked casters with directional locking (green pedal).
Depress the foot brake to set it and lock the castor. To unlock, press down on the
protruding part of the brake. Locking affects rolling and swiveling.
5. Control box wiring
Remove the control box cover to make the connections as described below. Use
a screwdriver or similar; refer to the special labels on the control box.
NOTE: Make sure plugs are connected to the correct
sockets otherwise the actuators can be damaged.
1. Socket for the height adjustment actuator.
2. Socket for the width adjustment actuator.
3. Remote control socket.
4. Battery terminal socket.
5. Plug socket (NOTE: Plugs must ALWAYS be connected to the control box for
IP classication to be valid).
1 2
3
4
5

USER MANUAL
5
GATERD.SE
6. Battery charging
• Connect plug to 230V wall socket. Charging begins automatically and the
battery LED ashes green.
• Make sure the battery is fully charged before using for the rst time. It takes
around 25 h to fully charge the battery.
• We recommend that the battery plug be removed from the control box if the
product will be out of use for an extended period (more than one week) or if
the battery is switched off by means of the ON/OFF switch. This eliminates
the risk of disabling the battery as the control box always uses a small
quantity of electricity even when the walker is not in use.
7. LED on controlbox and battery
Control box – green light when power is available from battery/mains socket.
Battery:
• The LED ashes green during charging.
• ON/OFF: To use the product, press ON.
• The green lamp will begin to ash.
• Use the OFF button (hold down for 5 s) to switch off the battery if the product
will not be used for an extended period.
• The LED will shows a constant green light when the battery is fully charged.
• When the battery is in normal state/in operation, the LED lashes green at
REGULAR intervals, namely 0.5 s ON, 4 s OFF.
• When the battery requires charging (remaining charge <25%) the LED will
ash orange/red at REGULAR intervals, namely 0.5 s ON, 4 s OFF.
NOTE: The battery has an in-built device that automatically switches it off when
remaining charge is <20%. The LED is then extinguished. The battery must now
be fully charged before the electronics can be used again.

BURE DOUBLE 2.0
GATERD.SE6
8. Maintanance
recommended at least once per year
Check that Action
General
The walker feels rm/does not feel loose.
The walker does not rattle during manoeuvres.
The walker is level and all of its castors are in contact with
the oor.
The walker is not dirty.
Clean with lukewarm soap solution or alcohol-based
cleaning agent (no petroleum products).
Arm rests
Arm rests are intact and clean.
Arm rest widening is functional.
Clean; replace if damaged.
Replace lock knob.
Handle
Grips are not damaged/dirty.
Handle adjustment is functional.
Clean with lukewarm soap solution (no petroleum
products).
Replace handle grips.
Fit lock knobs/plates as required.
Battery
Check that the charging cable is connected to the control
box.
Check that the remote control is connected to
the control box.
Connect or t new remote control as required.
Check that the battery, actuators and control box
are not loose.
Fit new cable; this must always be connected to the
control box (IP65 classication).
Connect; replace with new remote control as required.
Refer to the wiring diagram in the Technical manual.
Tighten; replace with new fasteners as required.
Height/width adjustment
Raising and lowering are functional.
The walker feels stable at maximum settings.
There is no looseness between the vertical frame and
bottom frame.
Height adjustment clamps lock.
The electric actuator must not feel loose.
Height adjustment via remote control is functional. The
electric actuator must run smoothly at a constant speed.
Fit new guide sleeves (in frame) or end plugs
(in chrome tubes) as required.
The technical manual shows the design and which
fasteners must be checked. Contact the distributor if the
parts cannot be tightened.
Replace clamps.
Tighten the attachment tting concerned; replace bolts/
lock nuts as necessary.
Check that the battery/remote control/actuator are
connected in accordance with the wiring diagram.
Charge the battery. Contact customer services.
Frame parts
There is no mechanical damage.
There are no scratches.
End plugs/lower frame tted.
If damage is present, contact GATE’s customer services.
Touch up as necessary.
Fit new end plugs.
Castors/brakes
Castors roll easily/tread not damaged.
The castors are tightly fastened to the lower frame.
Castor brakes functional on all castors.
Handbrake functional.
Clean or replace castors (NOTE: Castors are always xed
to the lower frame with thread locker or lock nuts. The
castors are sealed and we do not recommend their
dismantling; instead, replace the whole castor assembly).
Tighten the castor bolt and t locking nut or use thread
locker (depends on model).
Replace castor assembly.
Adjust the brake or t new castors.

USER MANUAL
7
GATERD.SE
9. General maintenance advice
• Clean the walker and its armrests clean as necessary - Wipe using a soap solution/surface disinfectant.
• The product may be cleaned in a tunnel washer or similar as electrical systems have IP65 protection.
However, the product is not corrosion proof which means washing by machine may reduce its lifetime.
• Replace damaged parts immediately; must be done by experienced personnel.
• The product is only intended for indoor use.
10. Tekniska specikationer
Mått anges för bord med 125 mm hjul.
Part No. Width Max user
weight
Length Height Weight Armrest/
Internal
dimension
56-303 64-95cm 150kg 87cm 90-130cm 40kg 25-50cm

GATERD.SE
Gate Rehab Development AB
Industrigatan 2
Reftele, Sverige
S-330 21
T: 0371-318 00
F: 0371-318 01
E: [email protected]
LIT-00056 Issue 1
Date: January 2020
