Mover Aqua
User & Service Manual

MOVER AQUA
DIRECTHEALTHCAREGROUP.COM2

DIRECTHEALTHCAREGROUP.COM
USER & SERVICE MANUAL
3
Mover is a transfer platform developed to provide smooth, convenient transfer transfer indoor/at surfaces. It’s
easy to use and helps transfer patients safely and conveniently. Mover has a narrow base frame and double
castors for easy manoeuvrability even in conned spaces. Mover has a stable platform and comfortable seat
cushions, and thanks to constant eye contact with the carer, the user always feels comfortable and condent.
The new MoverAqua is specially designed to be used also in showers. PU cushions together with stainless
solutions makes this possible. Hygiene management is improved as well.
Contents
1. General information 04
2. Foreword 04
3. Servicing and support 04
4. Manufacturer 04
5. Intended use 04
6. Expected lifespan 05
7. Identication of the product 05
8. Policy on the number of persons required for moving a care recipient 05
9. ID labelling 05
10. Safety instructions 05
11. Product description 06
12. How to use the “Mover” 07
13. Cleaning 08
14. Care and maintenance 08
15. Recycling/Scrapping 09
16. Technical Specications 09
17. Dimensions 11
Mover Aqua

MOVER AQUA
DIRECTHEALTHCAREGROUP.COM4
1. General information
Thank you for purchasing this transfer platform from GATE. Please read these operating instructions carefully
and contact us if you have any questions about the use or maintenance of the “Mover – Transfer Platform”.
2. Foreword
Please read the full instructions before using the product. It is important to understand the information in the
operating instructions so the product can be correctly used and maintained.
Keep the operating instructions with the product so they can be used as a reference whenever necessary.
Ensure that everyone who uses the product receives regular training in how to use the product. The product
may not be modied without the producer’s permission.
The product is CE marked according to MDD 93/42/EEC.
This product has been tested according to SS EN ISO 12182:2012. (Cushions have been re tested according
to SS EN ISO 597-1/-2).
3. Servicing and support
The product must always be checked before use. We also recommend a general overhaul once a year.
Also see the section entitled “Care and maintenance”.
4. Manufacturer
GATE Rehab Development AB
Box 2
S-33021 Reftele
tel [phone]
[email protected]
5. Intended use
The Mover – Transfer Platform is a mobile transfer platform with a safe working load of 180 kg. The product is
intended for indoor use on at surfaces for moving care recipients and residents at hospitals, nursing homes or
in home healthcare.
The product is only intended to be used for care recipients who are able to stand up without assistance or who
can stand with minimal assistance.
The product is not intended for long periods of sitting or moving.
The product is intended for moving a care recipient to/from a chair, bed, wheelchair or toilet. In this context,
“care recipient” means the person being moved.
The Mover Aqua model is also constructed in such a way that it can be used in the shower.
References to directions in this document (left/right, forwards/backwards) are always based on the carer’s
pushing position/facing the care recipient.

DIRECTHEALTHCAREGROUP.COM
USER & SERVICE MANUAL
5
6. Expected lifespan
The expected lifespan of the product is at least 10 years if regular maintenance is carried out and any broken
parts are replaced as necessary. Contact the distributor if any part needs to be replaced.
7. Identication of the product
The unique serial number is displayed on a sticker located on the inside of the frame at the bottom/left.
8. Policy on the number of persons required for moving a care recipient
This product is designed to be safely used by one carer. There may be circumstances involving a care recipient
who must be moved that make it necessary for two carers to carry out the move. Each professional carer is
individually responsible at all times for assessing whether the product is suitable for use and whether a move/
transfer needs to be carried out by one or two carers.
9. ID LABEL
1. Article number
2. Product name
3. Date of manufacture
4. Maximum user weight
5. Serial number
6. EAN code
10. Safety instructions
• This product is only intended for moving care recipients. No other use is permitted.
• This product has been constructed and tested to safely move/transfer care recipients with a body weight
of up to 180 kg.
• Always carry out recommended daily maintenance before using the product.
• Always move the product using the handlebars.
• Before using the product, a clinical assessment must be carried out as to whether the care recipient can
be moved using this product and, if so, whether the move/transfer should be carried out by one or two
carers.
• Do not move a loaded product over obstacles that the castors cannot easily get over (thick carpet edges,
thresholds, etc.).
• Mover Aqua can also be used in a shower. Repair any paint damage as soon as possible to avoid a shorter
lifespan due to corrosion.
• Do not allow the Mover Aqua to stand in direct sunlight since dark surfaces can become extremely hot.
180kg
53-301
Mover Aqua
1
2
3
4
5
5

MOVER AQUA
DIRECTHEALTHCAREGROUP.COM6
11. Product description
1. Handlebars/handles for manoeuvring
2a. Upper crossbar/handle
2b. Middle crossbar/handle
2c. Lower crossbar/handle
3. Hinged half-seats/seat cushions
4. Shin suppor
5. Leg
6. Front castors with no brake
7. Step
8. Rear castors with full brake
1
2a
3
4
5
6
7
2b
8
2c

DIRECTHEALTHCAREGROUP.COM
USER & SERVICE MANUAL
7
12. How to use the “Mover”
Turn the cushions
1. Hold the half-seat by the handle in the upper corner.
2. Turn the half-seat either away from the moving area or to a position
underneath the care recipient.
Pull and release the brakes on the rear castors
Lock the brakes Release the brakes
How to carry out a move/transfer
1. The steps shown below are for a transfer from one chair/wheelchair/bed/toilet to another, but it is done in
the same way regardless of whether the movement/transfer is carried out from a chair, bed, wheelchair or
toilet.
1. Fold up the two
half-seats.
3. Lock the brakes
2. Manoeuvre up to
the care recipient.
4. Place the Mover so the care
recipient can easily place his or
her feet on the step and his or
her knees/ shins against the shin
support. Let the care recipient
take hold of the crossbars/han-
dles however he or she wishes.

MOVER AQUA
DIRECTHEALTHCAREGROUP.COM8
How to carry out a move/transfer, continued
5. Fold down the two half-seats. 6. Ask the care recipient to sit down.
Release the brakes and move the care recipient.
NOTE: The care recipient should be seated during movement.
2. To carry out a transfer to a chair/wheelchair/bed/toilet, you carry out the above steps in reverse order.
3. When moving to a toilet:
• When the care recipient is in position, the rear castor brakes are applied and the care recipient stands up.
• Remove the care recipient’s clothing if necessary then fold up the half-seats so the care recipient can sit on
the toilet him or herself. The product can now act as a support frame to make it easier for the care recipient
during the toilet visit.
13. Cleaning
The product must be regularly cleaned/disinfected – after every use if necessary or at least once a day.
Clean the product by wiping with a damp cloth moistened with warm water and disinfectant detergent.
Dry thoroughly to effectively disinfect all surfaces. Do not use chlorine, phenols, pentanols or other strong
detergents that could damage the surface/dry out the cushions or cause premature cracking.
14. Care and maintenance
Preventive maintenance schedule
If the product, when checked, has faulty/broken parts, do not be use until the faulty parts have been replaced.
Åtgärd/Kontroll Före varje användning Årlig översyn
Carry out a general inspection -test the product’s
functions. Check that there are no broken or cracked
parts. Check that the product feels stable.
x x
Check that the half-seats can be folded up/down x
Check that the rear castors can be rotated and that the
brakes can be applied. x
Check that the step is xed. x x
Check that the castors are securely xed to the frame. x
Inspect exposed parts for cracks or sharp edges (these
may become unhygienic or injure the care recipient) x
Check that there are no loose bolted joints x
Repair any damage to the paint to prevent surface
corrosion – this applies particularly to Mover Aqua. x

DIRECTHEALTHCAREGROUP.COM
USER & SERVICE MANUAL
9
15. Recycling/Scrapping
When the product can no longer be used, it should be recycled in accordance with the law/regulations for
waste management in each country. All electrical parts including batteries must be removed and recycled as
electrical components. (Consult your local recycling facility for more information on how the various materials in
the product (metal, plastic, electronics) must be recycled).
16. Technical Specications
Pos. No. Part Number Description
1 53-341 End screw M10, Ø30 mm
2 53-342 Screw, Knee support plate (x4)
3 53-344 Rubber handle, L=92 mm (x2)
4 53-311 Step Aqua
5 53-336 Screw, Seat plate (x3)
6 53-337 Screw, step (x4)
7 53-338 Washer, seat plate (x3)
8 53-339 Locknut, M10
9 53-340 Washer M10
10 53-312 Double castor with no brake Ø75 mm
11 57-096 Double castor with full brake “diameter” 100mm (Aqua)
12 53-343-L Bracket, seat plate left
13 53-343-R Bracket, seat plate right
14, 15 57-394 Seat/Knee support PUR (Aqua)
16 53-334 Washer/Knee support plate (x4)
17 53-330 Cap/Screw. grey
18 53-331 Washer

MOVER AQUA
DIRECTHEALTHCAREGROUP.COM10
3
7, 5
6, 4
17, 18
2, 15, 16
12
14
13
10
11
8, 9, 1

DIRECTHEALTHCAREGROUP.COM
USER & SERVICE MANUAL
11
17. Dimensions
Product weight = 28 kg
94cm
107cm
63.5cm
96cm
38cm
80cm
62cm
