Direct Healthcare Group SystemRoMedic BureDouble 2.0 User manual

IFU no: 924 rev. 2 211020
SWL: 150 kg / 330 lbs
Instructions for use – English
Bruksanvisning – Svenska
Brugsvejledning - Dansk
BureDouble 2.0

Table of contents
English............................................................................................... 3
Svenska............................................................................................18
Danske..............................................................................................32

Product Overview
56-303
56-303-AUS
56-303-B/0-FKHW_R
56-303-B/0-FKHW_R-PU
56-303-B/0-PU
56-303-B/1-PU
56-303/75
56-303/75-B/0
56-303/75-B/0-FKNW_R-PLUS
56-303/75-B/0-PU
56-303/75-UK
56-303/75-TKN_R
56-303/100
56-303/100-PU
56-303-PLUS
56-303-PLUS-PU
56-303-PU
56-303-PU-AUS
56-303-UK
56-303-TKN_R
3
IFU

1. Intended use
2. Contraindications, Precautions and Warnings
Walkers are to be used as indoor, movable and portable assistive aids, which together with approved accessories
are intended to be used for transfer from sitting to standing positions, and walking training. Walkers are to be
used by persons with reduced muscular strength, who shall be able to stand and perform simple leg movements.
Walkers are to be used for leaning on when walking and standing during early mobilisation training. Walkers and
accessories are intended for indoor use only in Home Healthcare environment and Professional Healthcare facility
environment.
Contradictions
The device may not be used by patients above the maximum weight indicated on the label of the device.
Precautions
Check that the device is used on flat surface.
Check the device is correctly mounted/assembled before its first use.
Check the device after every folding after any transport.
Check height adjustment and leg spreading motions and inspect the actuators’ or gas pistons’ full ranges.
Activate the brakes whenever the device is not in use.
Check the function of the brakes before use.
Inspect the device regularly to detect any signs of damage. If there are any visible signs of damage, contact
Direct Healthcare Group Customer Service.
In case of an electrical model of the device, check that the hand control does not show signs of wear before
every use.
Check that the hand control markings are in accordance with the lifting functions.
Check the battery status of an electrically operated model, before using the device.
It is important to never leave the user alone during the transfer.
Warranty applies only if repairs or alterations are made by personnel who are authorized by Direct Healthcare
Group.
Ensure that there are no obstacles or people in the way of the device, when moving.
Handle batteries with care. Do not drop.
Use only batteries and cables that are intended for the device as instructed by the manufacturer.
Verify that potential accessories that might be used are properly attached to the device before use.
Low speed is recommended when moving with the device.
Take care not to drive the device over thresholds with high speed or force. Approach the threshold with lower
speed and communicate the coming threshold to the user.
Keep the instructions for use together with the product so that it can be used as a reference if necessary.
Beware of moving parts during usage.
Peform a risk assessment on the user before using the Walker to ensure they can stand and peform simple
movements.
Instructions for use - English
BureDouble 2.0
The Bure Double 2.0 is equipped with twin electric drives for raising and lowering the Walker and widening the
walking frame. The new version has a significantly lower height above the walking frame for better access and a
higher user weight (150 kg) compared to the earlier version.
4IFU

5
IFU
Warnings
The caregiver must be able to read and understand the Manual/IFU of the product.
It is important to use only approved accessories to prevent unintended detachment of components and
subsequently a fall that may lead to patient injury.
Use careful and gentle maneuvers when moving the device.
Perform maintenance/service of the device, according to the instructions in the manual/IFU, at least once every
12 months.
Accessories must be properly fitted and tested in relation to the user’s needs and functional ability.
Special care must be taken when using strong electrical power sources such as diathermy and the like so that
diathermy cables are not placed on or near the device. In case of doubt consult with a Direct Healthcare Group
representative.
When lifting the device, only use the denoted handholds. At least two people are required for lifting the device.
Do not leave a user or patient unattended when the device is being used.
Never move the lift by pulling on the actuator or gas piston.
The device must not be lowered into water.
The device must not be cleaned using steam.
The device must not be left or stored in a damp or humid environment.
The device must not be charged in a wet room.
The device must not be used outdoors, only indoors.
To avoid the risk of electric shock, this equipment must only be conected to a supply mains with protective
earth.
No modification of this equipment is allowed
Do not modify this equipment without authorisation of the manfacturer
If this equipment is modified, appropriate inspection and testing must be conducted to ensure continued safe
use of this equipment.
Before use:
• Inspect the packaging for any damage.
• Check for correct product being delivered.
• Check to ensure that the device is free from damage.
• Check if all the parts/components are included in the packaging.
• Check if all approved accessories are included in the package.
• Check if Product Quality Approval document is included in the packaging. Save this document for future contact
with manufacturer.
• Make certain the device is properly assembled.
• Check lifting function and bottom-frame adjustment function.
• Check if it is possible to move the device in all directions.

6IFU
4. Using Bure Walker with Gait training Kit 56-388
Top view
Front
Back
• The gait support harness has four blue straps with a plastic buckle allowing for adjustments in length, having
steel carabiner clips at the ends to be fasten to the gait walker. The carabiner clips on to the metal mounts
placed under the table of the Gait walker.
• Apply the gait walker support harness by clipping on the two front carabiners to the front mounters, one on
each side of the table.
• Place the user standing up in the Gait walker. Pull back the harness in between the legs and clip on the
carabiners to the back mounters, one on each side of the table. Adjust the harness to the user by pulling in
the back strap loops.
• Observe! Intended use of the Gait trainer support harness is to practise walking. It is not a sitting or lifting aid.
3. Standing Up Using the Bure Double
1. Ask the user to sit on the edge of the bed or chair. Bring out the walking table and place it in front of the user.
Lock the brakes on the wheels.
2. Ask the user to place their arms on the armrests. If necessary, ask the user to move forward on the seat base
so that the user reaches the handles.
3. Ask the user to lean forward. To start raising the walking table, press the UP button on the controller. Raise
the walking table to a desired height.
4. Unlock the brakes. Assist the user while walking.

7
IFU
8. Locking Castors/Unlocking Castors
Remove the control box cover to make the connections as described
below. Use a screwdriver or similar; refer to the special labels on the
control box.
NOTE: Make sure that plugs are connected to the correct sockets
otherwise the actuators can be damaged.
1. Socket for the height adjustment actuator.
2. Socket for the width adjustment actuator.
3. Hand control socket.
4. Battery terminal socket.
5. Plug socket (NOTE: Plugs must ALWAYS be connected to the
control box for IP classification to be valid).
Bure Double is fitted with braked casters with directional locking
(green pedal). Depress the foot brake to set it and lock the castor.
To unlock, press down on the protruding part of the brake. Locking
affects rolling and swiveling.
9. Control Box Wiring
12
3
4
5
6. Adjusting the Handles
To adjust handles to the desired position; loosen screw, adjust handle,
tighten screw.
7. Left and Right Adjustment of Armrests
The handles are adjusted to the desired position by:
Loosening the knob of the handles adjustable locks.
5. Raising/Lowering the Frame
The desired height is adjusted with Arrow <UP> or Arrow <DOWN>.
Adjust bottom frame using <WIDER> arrow or <NARROWER> arrow.
Handset from Plus also have charge indicator / battery (low, medium, high) and Ser-
vice indicator (see further under “16 Hand Control Plus”).

11. LEDs on Control Box and Battery
Control box – green light when power is available from battery/mains socket.
Battery:
• The LED flashes green during charging.
• ON/OFF: To use the product, press ON.
• The green lamp will begin to flash.
• Use the OFF button (hold down for 5 s) to switch off the battery if the product will not
be used for an extended period.
• The LED will shows a constant green light when the battery is fully charged.
• When the battery is in normal state/in operation, the LED flashes green at
REGULAR intervals, namely 0.5 s ON, 4 s OFF.
• When the battery requires charging (remaining charge <25%) the LED will flash
orange/red at REGULAR intervals, namely 0.5 s ON, 4 s OFF.
NOTE: The battery has an in-built device that automatically switches it off when
remaining charge is <20%. The LED is then extinguished. The battery must now be
fully charged before the electronics can be used again.
10. Battery Charging
• Plug needs to connect to 230V wall socket. Charging starts automatically.
o LED / battery flashes green.
• The battery is of the LiOn type and insensitive to how long / how often you charge the battery. Full charge on
discharged battery takes about 24 hours.
• We recommend that the battery plug be removed from the control box if the product will be out of use for an
extended period (more than one week) or if the battery is switched off by means of the ON/OFF switch. This
eliminates the risk of disabling the battery as the control box always uses a small quantity of electricity even
when the Walker is not in use.
8IFU

9
IFU
12. Maintenance
Check that everything is clean and working before using.
Recommended at least once per year
Check that Action
General
The Walker feels firm/does not feel loose.
The Walker does not rattle during manoeuvres.
The Walker is level and all of its castors are in
contact with the floor.
The Walker is not dirty.
Clean with lukewarm soap solution or alcohol-based cleaning
agent (no petroleum products).
Arm rests
Armrests are intact and clean.
Armrest widening is functional. Clean; replace if damaged. Replace lock knob.
Handle
Grips are not damaged/dirty.
Handle adjustment is functional. Clean with lukewarm soap solution (no petroleum products). Replace handle grips.
Fit lock screws/plates as required.
Battery
Check that the charging cable is connected to
the control box.
Check that the hand control is connected to
the control box.
Connect or fit new hand control as required.
Check that the battery, actuators and control
box are not loose.
Fit new charging cable; this must always be connected to the
control box (IP65 protection).
Connect or fit new hand control as required.
Refer to the wiring diagram in the control box wiring section.
Tighten; replace with new fasteners as required.
Height adjustment
Raising and lowering are functional.
The Walker feels stable at maximum settings.
There is no play between the vertical frame
and bottom frame.
Height adjustment clamps lock.
The electric actuator must not feel loose.
Height adjustment via hand control is
functional.
The electric actuator must run
smoothly at a constant speed.
Fit new guide sleeves (in frame) or end plugs (in chrome tubes)
as required.
The part list shows the design and which fasteners must be
checked. Contact the DHG if the parts cannot be tightened.
Replace clamps.
Tighten the attachment fitting concerned; replace bolts/lock
nuts as necessary.
Check that the battery/hand control/ actuator are connected in
accordance as in hte control box wiring section.
Charge the battery. Contact customer services.
Frame parts
There is no mechanical damage.
There are no scratches.
End plugs/lower frame fitted.
If damage is present, contact DHG customer services.
Touch up as necessary.
Fit new end plugs.
Castors/brakes
Castors roll easily/tread not damaged.
The castors are firmly fastened to the lower
frame.
Castor brakes functional on all castors.
Handbrake functional.
Clean or replace castors. NOTE: Castors are always fixed to
the lower frame with thread locker or lock
nuts.
The castors are sealed and we do not recommend their
dismantling; instead, replace the whole castor assembly).
Tighten the castor bolt and fit locking nut or use thread locker
(depends on model).
Replace castor assembly.
Adjust the brake or fit new castors.
DHG can provide upon request neccessary technical information in order to assist maintenace and repair of the
device.

13. General Maintenance Advice & Cleaning of Walker
• Clean the walker armrests and handles after every use. Wipe using a mild soap solution/surface disinfectant.
However, the product is not corrosion proof.
• With enviroments with high risk of infections use the walker with PU-cushions (Accessory number 57-361-L
and 57-361-R)
• Replace damaged parts immediately; must be done by experienced personnel.
• The product is only intended for indoor use.
14. General Maintence for gait training Sling:
Read the product label.
Do not use rinsing agent.
To prolong product life,
avoid tumble-drying.
15. Storage and transportation
If the walker is not to be used for some time or e.g., during transport, we recommend that the emergency stop
button be pressed in. The walker should be transported and stored in -10 ° C to + 50 ° C and in normal humidity,
20% to 80% non-condensing. The air pressure should be between 700 and 1060 hPa. Leftmost symbol indicates
storage and transportation. Let the walker reach room temperature before the batteries are charged or the walker is
used. The walker should not be stored so that it is exposed to dust, or so that the battery or gas piston is exposed
to direct sunlight.
Operation
The operating environment should be 5 °C to 40°C, relative humidity 20% to 80% non-condensing, and atmo-
spheric pressure 700 to 1060 hPa. See also Technical Information below. Leftmost symbol indicates operating
condition.
40°C
5°C
50°C
-10°C
1060
hPa
700
hPa
1060
hPa
700
hPa
%
80%
20%
%
80%
20%
40°C
5°C
50°C
-10°C
1060
hPa
700
hPa
1060
hPa
700
hPa
%
80%
20%
%
80%
20%
10 IFU

16. Technical Specifications
Dimensions apply to Walkers with 125 mm castors.
Product
Nr.
Width Max user
weight
Length Height Weight Armrest/
Internal
dimension
56-303 64-95cm 150kg 87cm 90-130cm 40kg 25-50cm
11
IFU

19. Electrical System - Technical Data
Actuator Lift Widening
Producer TiMOTION TiMOTION
Voltage 12V 24V
Push 2000N/1500N 1000N
Pull 2000N/1500N 1000N
Self-locking push 1000N 1000N
Current 6.6 (+/-1,0)A 2.6 (+/-0,4)A
Colour Black Aluminium
Stroke 400mm 55mm
Mounting dim 605mm 167mm
Encapsulation IP66 UIP
IEC60601-1 3rd revision
12 IFU
17. Recycling/Disposal
When the product is no longer usable it should be recycled in accordance with legislation and regulations in the
country concerned. All electrical parts including batteries must be removed and recycled as electrical components.
(Ask your local recycling station for further information about how the different materials in the product (metals,
plastics, electronics) should be recycled).
18. Warranty
We provide two years’ warranty for manufacturing faults (does not apply to wear parts).
For further information or enquiries please contact:
Direct Healthcare Group Sverige AB
Torshamnsgatan 35,
SE-164 40 Kista, Sweden
Tel: [phone]
[e-mail]
www.directhealthcaregroup.com

Control box + Battery
Producer TiMOTION
Voltage 24V
Capacity 2.0AH
Encapsulation IP66
Colour Black
Electrical safety Class II
IEC60601-1 3rd revision
13
IFU
20. Hand Control Plus
**1. Service indicator – flashes red after 11 months’ operation.
Constant light (red) after 12 months’ operation.
The indicator is a reminder to review the maintenance instruction (see Maintenance
Instructions). This should be done at least once every 12 months.
Reset: hold down buttons <2a> + <2b> for at least 30 seconds.
**The indicator will go out around 30 seconds after the hand control is
activated (battery conservation function).
2a 2b
1
21. Expected lifetime:
The life expectancy of the product is 8 years.

14 IFU
22. Parts List
1 57-306
57-305
Armrestpad left
Armrestpad right
12 58-364 Circular plate
2 58-365 Frame/Armrest 13 58-352 Cross section
357-041-3 Holder, Hand control (TH7) 14 58-302 Bearing (x2) Cross section
4 57-369
57-370
Clamp/Battery (alu)
Plate Clamp/Battery (alu)
15 58-353 Turn axle, beam
5 58-376 Battery, TiMOTION 16 57-776
57-775
Cover, Wheel
Washer, wheel
6 58-377 Actuator, TiMOTION 17 58-360 Cover, Wheelplate (PA)
7 58-373
58-373-1
Controlbox 220V, TiMOTION
Controlbox 110V, TiMOTION
18 58-354 Wheel mount beam
8 58-366
58-335
Vertical frame
Telescopic Innertube
incl. Bronzebearing
19 57-051
57-319
57-049
Wheel 75mm
Wheel 100mm
Wheel 125mm
9 58-358 Sideplate (2x) alu 20 58-379-L
58-379-R
Bottom beam, left
Bottom beam, right
10 58-356 Aluprofile, widening 21 Linking arm, right
11 58-378 Actuator, widening (TiMOTION) 22 Linking arm, left

15
IFU

16 IFU
Art. Nr. Description
56-339-2-0 Manual brake, 2 handles
56-339-2-1 Manual brake, 1 handle
56-333-DB Standing plate, Short
56-383-DB Standing plate, Long
56-334 Dripstand, Chromed
56-335 Holder for Dripstand
56-336 Oxygen tubeholder
56-337 Side support
56-338 Dripstand holder, Complete
56-387 Wheel w brake 75 mm
56-358 Wheel w brake 100 mm
56-361 Wheel w brake 125 mm
57-361-L Armrestpad PUR left
57-361-R Armrestpad PUR right
58-374-2 Hand Control (TH7) TiMOTION
56-062 Hand Control PLUS, DB (TH10) TiMOTION
58-326 (-1, -2, -3) Coiled Cable/EUR (-UK, -US, -AUS) TiMOTION
56-388-KIT Kit/Gait training for Belt Multi
56-388 Gait training kit
23. Accessories

24. Table of Symbols
17
IFU
This product complies with the require-
ments of the Medical Device Regulation
2017/745
Visual Inspection
Medical Device Read the manual
Caution Product Code
Manufacturer information Batch Code
Type BF, according to the degree of pro-
tection against electric shock
The device is intended for indoor use
WEEE Symbol
May not be discarded in domestic waste
Class II Equipment
Duty Cycle:
2 min in active (ON) mode.
18 min in rest (OFF) mode.
Wash at 75 degrees
Do not iron Do not dry clean
Do not bleach

1. Avsedd Användning
2. Kontraindikationer, Försiktighetsåtgärder och Varningar
Gåbord ska enbart användas inomhus och på plant underlag. Gåbord är ett hjälpmedel, som tillsammans med
godkända tillbehör är avsedda att användas för förflyttning från sittande till stående positioner och gångträning.
Gåbord ska användas av personer med nedsatt muskelstyrka, som ska kunna stå och utföra enkla benrörelser.
Gåbord ska användas för att luta sig mot när brukaren går och står under tidig mobiliseringsträning. Gåbord och
tillbehör är avsedda att användas i hemsjukvårdsmiljö och professionell vårdinrättning.
Kontraindikationer
Produkten får inte användas av en brukare vars vikt överstiger den maximala brukarvikt som anges på
produktens etikett.
Försiktighetsåtgärder
Kontrollera att produkten används på en torr och plan yta.
Kontrollera att produkten är korrekt monterad/ihopsatt före den första användningen.
Kontrollera produkten efter att den har varit ihopfälld /demonterad efter transport.
Kontrollera höjdjustering och benspridningsrörelser och inspektera ställdonens eller gasfjäderns fulla
rörelseomfång.
Aktivera bromsarna när produkten inte används.
Kontrollera bromsarna före användning.
IInspektera produkten regelbundet för att upptäcka tecken på skada. Om det finns några synliga tecken på
skada, kontakta Direct Healthcare Groups kundtjänst.
Före varje användning av en elektrisk modell av produkten, kontrollera att handkontrollen inte visar tecken på
slitage.
Kontrollera att markeringarna på handkontrollen överensstämmer med lyftfunktionerna.
Före varje användning av en elektrisk modell av produkten, kontrollera batteristatus.
Det är viktigt att aldrig lämna brukaren ensam under förflyttningen.
Garantin gäller endast om reparationer eller ändringar görs av personal som är auktoriserad av Direct Healthcare
Group.
Se till att det inte finns några hinder eller människor i vägen för produkten när brukaren förflyttar sig med hjälp av
produkten.
Hantera batterier varsamt. Tappa inte.
Använd endast batterier och kablar som är avsedda för produkten enligt tillverkarens anvisningar.
Kontrollera att potentiella tillbehör som kan användas är korrekt anslutna till enheten före användning.
Låg hastighet rekommendera s när du använder produkten.
Var försiktig så att du inte kör produkten över en tröskel med hög hastighet eller kraft. Närma dig trösklar med
lägre hastighet och uppmärksamma brukaren när ni närmar er en tröskel.
BureDouble 2.0
Bure Double 2.0 är utrustad med dubbel eldrift, dels med eldriven höj- och sänkning och dels med eldriven bredd-
ning av benstativen. Den nya versionen har en väsentligt lägre höjd över benstativen – för bättre åtkomst samt en
högre brukarvikt (150kg) jämfört med tidigare version.
Bruksanvisning - Svenska
18 IFU

19
IFU
Förvara bruksanvisningen tillsammans med produkten så att den kan användas som referens vid behov.
Se upp för rörliga delar under anvädning.
Genomför en riskbedömning med en brukare innan ni använder ett gåbord. Säkerställ att brukaren kan stå och
göra enkla rörelser med ben.
Varningar
Vårdgivaren måste kunna läsa och förstå produktens bruksanvisning och användarinstruktioner.
Det är viktigt att endast använda godkända tillbehör listade i bruksanvisningen för att förhindra att komponenter
lossnar oavsiktligt, då detta medföra ett fall och patientskada.
Manövrera mjukt och försiktigt när du jobbar med produkten.
Utför underhåll/service av enheten enligt instruktionerna i bruksanvisningen, minst en gång var 12:e månad.
Tillbehören måste vara ordentligt fastsatta. De bör testas i förhållande till användarens behov och funktionsnivå.
Särskild försiktighet måste vidtas vid användning av starka elektriska kraftkällor som används vid till exempel
diatermi och liknande så att diatermikablar inte placeras på eller i närheten av enheten. Vid tvivel, rådgör med en
representant för Direct Healthcare Group.
När du lyfter produkten ska du endast använda de angivna handfästena. Minst två personer krävs för att lyfta
produkten.
Lämna aldrig brukaren utan uppsikt när produkten används.
Flytta aldrig produkten genom att dra i ställdonet eller gasfjädern.
Produkten får inte sänkas ner i vatten.
Produkten får inte lämnas eller förvaras i miljö med hög luftfuktighet.
Produkten får inte rengöras med ånga.
Produkten får inte laddas i ett våtrum.
Produkten får inte användas utomhus, endast inomhus.
För att undvika risk av en elektrisk chock, gåbord kan endast kopplas mot elektrisk källa med jord.
Ingen modifiering av denna utrustning är tillåten.
Ändra inte denna utrustning utan tillstånd från tillverkaren.
Om denna utrustning modifieras måste lämplig inspektion och testning utföras för att säkerställa fortsatt säker
användning av denna utrustning.
Före användning
• Inspektera förpackningen för att upptäcka eventuella skador.
• Kontrollera att rätt produkt har levererats.
• Kontrollera att materialet är fritt från skador.
• Kontrollera att alla delar/komponenter finns med i förpackningen.
• Kontrollera att alla godkända tillbehör finns med i förpackningen.
• Kontrollera att kvalitetsgarantidokumentet finns med i förpackningen. Spara det här dokumentet för eventuella
framtida kontakter med tillverkaren.
• Kontrollera att gåbordet är korrekt monterat.
• Kontrollera lyftfunktionen och funktionen för att justera benbreddningen.
• Kontrollera körfunktionen i alla riktningar.

20 IFU
4. Användning av Bure Double med Gåträningskit 56-388
Top view
Front
Back
• Gångstödsselen har fyra blå remmar med plastspänne som möjliggör längdjusteringar. Karbinhakar av stål
ska fästas på i metallfästena vid ändarna av gåbordet.
• Sätt fast gåträningsele med två karabinhakar mot främre delen av gåbordet, en på varje sida.
• Placera användaren stående i gåbordet. Dra tillbaka selen mellan benen och sätt fast de bakre karabinhakar
mot de bakre metallfästena, en på varje sida av bordet. Justera selen till användaren genom att dra in
remsorna.
• Observera! Den avsedda anvädningen av gåträningsselen är att träna gå. Detta är inte ett sitt- eller lyfthjälpmedel.
3. Uppresning och gåträning med Bure Double
1. Be brukaren att sitta på kanten av sängen eller stolen. För fram gåbordet och ställ det framför brukaren. Lås
bromsarna på hjulen.
2. Be brukaren placera armarna på armstöden. Eventuellt be brukaren flytta fram på sittunderlaget så brukaren
når handtagen.
3. Be brukaren att luta sig framåt. Börja höja gåbordet genom att trycka på UPP-knappen på handkontrollen.
Höja gåbordet till en önskad höjd
4. Lås upp bromsarna. Assistera brukaren vid gång.
