Direct Healthcare Group SystemRoMedic Rowalker400 User manual

Manual no.: 658 Ver. 2 EN 200819
Service manual - English
Visual inspection
Check the condition and function of the product regularly. Check to ensure that material is free from damage. If there are
signs of wear, the product must be inspected and serviced.
Always read the manuals for all assistive devices used during a transfer.
Keep the manual where it is accessible to users of the product.
Do not leave the patient unattended during a transfer situation.
The product should be inspected yearly, and otherwise as required, by a qualified technician. Service must be performed
by a qualified technician.
Functional inspection
Always read the manual
RoWalker400
SystemRoMedicTM
SWL: 180 kg / 400 lbs
20101010
REF

Table of contents
Exploded view ......................................................................................... 3
Component list ....................................................................................... 4
Spare part list ...................................................................................... 5-6
Detail descriptions for Periodic inspection.................................................. 7
Periodic inspection, instruction .............................................................8-10
Change of spareparts.........................................................................11-13
Care of the product .................................................................................13
General .................................................................................................13
Dimensions............................................................................................14
Technical information .............................................................................15
2SystemRoMedicTM

Exploded view
3
SystemRoMedicTM
1
1
15
1 9
1 5A
1
23
D
1
24
E
14
1
3 1
2
1 1
1
10
22
2
F
4
SCALE 1 : 3
2
DETAIL A
6
10
2
7
7
10
DETAIL D
SCALE 2 : 5
8
2
1
17
1 4
13
1
18
19
1
16
1
20
DETAIL E
SCALE 1 : 3
1
21
19
1
13
4
11
2SCALE 1 : 3
12
2
DETAIL F13
4
BRAKO
Q.A
MFG
APPV'D CHK'D
D E F C
12 3 4
B A
321 5
C D
4
ANGULAR:
6 87
B A
RoWo-0-000-B
N. Jovanovski
WEIGHT:
A3
SHEET 1 OF 2SCALE:1:20
DWG NO.
TITLE:
REVISION
DO NOT SCALE DRAWING
EDGES DEBUR AND
DATE
BREAK SHARP
MATERIAL:
NAME SIGNATURE
UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIM ETERS SURFACE FINISH: TOLERANCES: LINEAR:
DRAWN

Number Name Size
1 Frame
2 Front fork
3 Leg Left
4 Axial Plain bearing 26x44x1,5
5 Centre piece
6 Bronze plain bearing 35x25x50
7 Screw M6x12 Fzb
8 Threaded rod M8 - DIN 975
9 Seat kit right
10 Seat kit left
11 Off-center adjuster
12 Screw M8x30/8.8 - DIN 931
13 Plastic nut cover M8
14 Arm support
15 Tube for gas spring
16 Release head gas spring
17 Plate holder
18 Releasing pin
19 Screw M8x40/8.8 - DIN931
20 Locking nut M8 - DIN985
21 Screw M5x10/8.8 - DIN 914
22 Locking clamp
23 Gas spring 205 615 (207N)
24 Cable for gas spring
Component list
4SystemRoMedicTM

Spare part list
Articleno Product Unit Components Parts
80100084 Seat kit left 1 set 1 x Seat left
2 x Screw
80100085 Seat kit right 1 set 1 x Seat right
2 x Screw
80200023 Castor with direction lock 1 set 2 x Castor
kit 80mm 2 x Screw
2 x Locking nut
80100073 Castor kit with brake 1 set 2 x Castor
80mm 2 x Screw
2 x Locking nut
80200024 Knee pad 1 pce 1 x Knee pad holder
80200025 Handles RW 1 set 2 x Handle
2 x Cover
2 x Locking handle
2 x Washer
80200026 Gas spring RW 1 set 1 x Gas spring
1 x Locking nut
1 x Screw M8x40
1 x Plastic cover
1 x Pin to release the buffer
1 x Screw M5x10
1 x Release head
1 x Plate holder
5
SystemRoMedicTM
80200024
80100084
80100085
80200023
80100073
80200025
80200026

Articleno Product Unit Components Parts
80200022 Release head gas spring 1 set 1 x Locking nut
1 x Screw
2 x Plastic cover
1 x Releasing pin
1 x Socket set Screw cone point
1 x Release head
1 x Plate holder
80200027 Cabel for gas spring RW 1 pce 1 x Cable
80200028 Control for hight adjustment 1 pce 1 x Handle
80200029 Arm support right 1 set 1 x Armsupport right
1 x Screw
1 x Plastic cover
1 x Washer (M10)
80200030 Arm support Left 1 set 1 x Armsupport left
1 x Screw
1 x Plastic cover
1 x Washer (M10)
80200031 Locking clamp 1 pair 2 x Locking clamp aluminum
80200032 Star knob set for 1 set 2 x Star Knob
2 x Plate
2 x Holder rotation plate
6 x Screw
80200033 Star knob set for oxygen 1 set 4 x Star knob
tank holder
80200034 Locking handle 1 set 2 x Locking handle
2 x Washer
6SystemRoMedicTM
80200030
80200031
80200032
80200033
80200034
x 2
x 2
x 2
x 2
80200029
80200028
80200027
80200022

Detail descriptions for Periodic inspection
1. Frame Page 8
2. Castors with brake Page 8
3. Castors with direction lock Page 8
4. Footpedal for leg spread adjustment Page 8
5. Leg support Page 9
6. Gas spring Page 9
7. Control for hight adjustment Page 9
8. Seat support Page 9
9. Handles Page 10
10. Locking clamp Page 10
11. Locking handle Page 10
12. Arm support Page 10
13. Star knob for arm support Page 10
7
SystemRoMedicTM
1
23
8
4
5
6
7
9
10
11
12
13

Periodic inspection, instruction
Frame
Check screws, nuts and bolts.
Check the frame for visible damage to the surfaces, finish, etc.
Castors with brake
Lock the brakes. Check that the castors do not turn when the RoWalker is pushed.
Castors with direction lock
Roll the RoWalker unloaded on the floor, check that the castors roll and turn freely.
Check that the castor fasteners are tight and if necessary, remove dirt and hair from
wheels.
Footpedal for leg spread adjustment
Check the footpedal for adjusting the leg spread in and out.
8SystemRoMedicTM

Seat support
Check the seat supports for visible damage to the surfaces, finish, etc.
Check that both of them swings away and flip-ups easily.
Leg support
Check the kneepad for visible damage to the surfaces, finish, etc. Make sure it is
correctly assembled.
Check that the control for hight adjustment is activating the gas springs.
Control for hight adjustment
Check that the gas springs are moving smooth and soft.
Gas spring
9
SystemRoMedicTM

Arm support / Star knob for arm support
Check the arm support for visible damage to the surfaces, finish, etc. Make sure it
is correctly assembled.
Handles
Check the handles for visible damage to the surfaces, finish, etc. Make sure it is
correctly assembled.
Check that the handles can be adjusted.
Locking handle
Open the locking clamps on both sides and make sure that the hight adjustment is
moving smooth and soft.
Locking clamp
10 SystemRoMedicTM

Change of spareparts
Seat support
Disassemble and change the seat support by unlocking the two screws according to
picture. Use the attached screws to assemble the new seat support and please note
that there is a left and right seat support.
Castors
Disassemble and change the castors by unlocking the underneath mounted screw
according to picture. Use the attached screw to assemble the new castor and
ensure correct tightening.
Disassemble and change the handles by unlocking the underneath mounted locking
handles according to picture.
Handles
Arm support / Star knob for arm support
Disassemble and change the arm support by unlocking the star knob
and screws according to picture.
11
SystemRoMedicTM

Gas spring cabel set for gas spring
Disconnect the cable set by first loosen the adjustment screw on the cable and
secondly unhook the cable from the bracket. Attach the new cable set to the old
one, while still mounted in the frame, and change the old cable by pulling the cable
through the frame. Ensure correct mounting and adjustment by function control.
Disconnect the cable set.
Disassemble and change control for hight adjustment by unlocking the two screws.
Control for hight adjustment
Gas spring
Ensure that the arm supports are raised to the maximum height, that the gas spring is fully extended and that the locking
clamps (1) are locked before removing the gas spring.
Lower mount (2): Release the pin, and then remove the gas spring from the ball joint.
Upper mount (3): Remove the screw cover and unscrew the gas spring.
12 SystemRoMedicTM
2
31

Care of the product:
• Use a soft cloth and mild cleaning agent such as dishwashing liquid or car shampoo to clean the RoWalker. Do not use
abrasive cloths or brushes.
• Do not use solvents.
• To disinfect, use 70% alcohol.
General
Before the product is used, check to ensure that the screws are securely tightened. The product must be inspected
regularly by an authorized technician. The product must be inspected thoroughly at least once each year, or more
regularly if it is used very frequently. Inspection and service must be performed by an authorized technician.
The gas spring release head is removed and the gas spring can then be removed
from the gas spring tube and replaced.
Replace the gas spring release head, secure the lower mount to the gas spring
and, finally, reinstall the gas spring assembly on the RoWalker.
Use an Allen key to release the adjustment cable from the gas spring release
head.
13
SystemRoMedicTM

Dimensions
14 SystemRoMedicTM
1013
1172
906
N. Jovanovski
MFG
APPV'D
CHK'D
D
E
F
C
12 3 4
B
A
321 5
C
D
4 6
Q.A
78
B
A
RoWo-0-000 collected
Minimum height
BRAKO
WEIGHT: 47.17
A3
SHEET 1 OF 1SCALE:1:20
DWG NO.
TITLE:
REVISION
DO NOT SCALE DRAWING
MATERIAL:
ANGULAR:
EDGES
SIGNATURE
BREAK SHARP
DATE
DEBUR AND
NAME
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
DRAWN
1013
1379
BRAKO
Q.A
MFG
APPV'D
CHK'D
D
E
F
C
12 3 4
B
A
321 5
C
D
4
ANGULAR:
67
A
8
Maximum height
B
RoWo-0-000 elongated
N. Jovanovski
WEIGHT: 47.17
A3
SHEET 1 OF 1SCALE:1:20
DWG NO.
TITLE:
REVISION
DO NOT SCALE DRAWING
EDGES
DEBUR AND
DATE
BREAK SHARP
MATERIAL:
NAME SIGNATURE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
DRAWN
906
987
1379
694
N. Jovanovski
MFG
APPV'D
CHK'D
D
E
F
C
12 3 4
B
A
321 5
C
D
4 6
Q.A
BRAKO
7
B
8
RoWo-0-000 without holders
A
Maximum height
WEIGHT: 42.01
A3
SHEET 1 OF 1SCALE:1:20
DWG NO.
TITLE:
REVISION
DO NOT SCALE DRAWING
MATERIAL:
ANGULAR:
EDGES
SIGNATURE
BREAK SHARP
DATE
DEBUR AND
NAME
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
DRAWN
(mm)

Technical information
Seat width: 480 mm 18.8”
Seat depth: 265 mm 10.4”
Castor Ø Ø80 mm Ø3”
Weight: 37,5 kg 82,67 lbs
Weight incl. OxygenTankHolder: 43,5 kg 95.9 lbs
SWL: 180 kg 400 lbs
15
SystemRoMedicTM

Simple solutions for great results
SystemRoMedic™ is the name of Direct Healthcare Group’s unique easy transfer concept, the market’s widest and most
comprehensive range of clever, easy-to-use and safe transfer and lifting aids designed to make life easier, both for the
user and for the caregiver. SystemRoMedic™ is a complete solution that provides for the majority of patient transfer or
manual handling requirements. From the simplest to the most complex scenarios, from the lightest to the heaviest. The
concept encompasses assistive devices for four different categories of transfers:
• Transfer, assistive devices for manual transfers of users between two locations.
• Positioning, assistive devices for manual repositioning of users within the same location.
• Support, assistive devices for mobility support e.g., during sit-to-stand or gait training.
• Lifting, assistive devices for manual and mechanical lifting of users.
Improved work environment, improved quality of care and cost savings
The philosophy behind SystemRoMedic™ is focused on the prevention and reduction of occupational injuries while
allowing users to experience a greater sense of independence and dignity. Through a unique combination of training and
a complete range of efficient transfer aids, SystemRoMedic™ offers improvement of both work environment and quality
of care and, at the same time, achieves significant cost savings.
Always make sure that you have the correct version of the manual
The most recent version of all manuals are available for downloading at/from our website;
www.directhealthcaregroup.com
For questions about the product and its use
Please contact your local Direct Healthcare Group and SystemRoMedic™ representative. A complete list of all our
partners with their contact details can be found on our website; www.directhealthcaregroup.com.
SystemRoMedicTM
Direct Healthcare Group is quality and environmentcertified in
accordance with ISO 9001, ISO 13485 and ISO 14001.
Direct Healthcare Group Sverige AB
Torshamnsgatan 35,
SE-164 40 Kista, Sweden
Tel: [phone]
[email protected]
www.directhealthcaregroup.com
