Direct Supply Panacea DS-CX418ADDA-ELR User manual

Model # DS-CX418ADDA-ELR
• WARNING: Weight capacity is 300 lbs.
Customer Service
Our promise to you is that you will have a convenient and easy
ordering experience, receive a quality Panacea wheelchair, and enjoy
outrageous customer service. If you have any questions about the
wheelchair you have purchased or would like to request warranty
service, please contact:
Direct Supply Equipment & Furnishings at 1-800-634-7328,
6767 N. Industrial Road, Milwaukee, WI 53223,
[e-mail].
Limited Warranty
We, Direct Supply Manufacturing, Inc., offer to you, as the original
purchaser, a warranty for the Panacea XLT Lightweight Wheelchair.
Our warranty applies for the limited warranty period stated below.
If any device or device part listed below is defective in material or
workmanship during the applicable limited warranty period, we
will repair or replace it at our cost. Please note that the decision to
repair or replace a device or device part will be at our discretion.
Our warranty applies only if the device is properly maintained by
the original purchaser for normal, indoor use and does not cover
normal wear and tear, modification of the device or damage caused
by abuse, improper use, failure to maintain, use which exceeds the
published device limitations, or the combination of any device with
another device. In addition, our warranty does not cover fading,
colorfastness, stains, spills or exposure to chemicals, odors, heat
or light. In certain cases, we may provide you repair or adjustment
instructions and/or replacement parts, and ask you to perform a
repair or adjustment or replace a defective part. Our warranty gives
you specific legal rights, and you may also have other rights, which
vary from state to state. Please note that our limited warranty period
begins when we ship the device to you.The limited warranty period and our
obligations under the warranty end once you transfer the device to someone
else or at the end of the applicable limited warranty period identified below,
whichever is earlier.
Product
Warranty Period
(Parts)
Anticipated Usable
Device Life
Panacea®
XLT Lightweight Wheelchair Limited Lifetime 5 years
Nondurable Components 60 days 60 days
The anticipated usable device life for this device is 5 years. Anticipated Usable
Device Life is based on normal use with proper maintenance, cleaning and
storage. You should still inspect, monitor and care for the device as described
in this guide, as the device may need to be replaced sooner than anticipated
in particular situations.
DIRECT SUPPLY MANUFACTURING, INC. MAKES NO IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE; THESE AND ALL OTHER IMPLIED WARRANTIES ARE
SPECIFICALLY DISCLAIMED. TO THE FULLEST EXTENT ALLOWED BY LAW,
DIRECT SUPPLY MANUFACTURING, INC. WILL NOT BE LIABLE FOR ANY
INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, OR
LOST PROFITSTHAT MAY RESULT FROMTHE DEVICE OR YOUR USE OF
OR INABILITYTO USE THE DEVICE EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. OURTOTAL LIABILITYTO YOU, IF ANY, IS LIMITEDTO
THE PRICE OF THE DEVICE OR SERVICE GIVING RISE TO YOUR CLAIM.
Some states do not allow an exclusion or limitation of incidental or
consequential damages, or how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you. If implied warranties are
not excluded, and to the extent allowed by law, we limit any and all implied
warranties to the applicable warranty period identified above. Except for rights
under any applicable state law, the remedies provided under this warranty are
your sole and exclusive remedy for any breach of our warranty and state the
entire limit of our responsibilities.
• WARNING: The items and packaging in this shipment contain chemicals
known to the state of California to cause cancer, birth defects or other
reproductive harm.*
*This product meets or exceeds all mandatory federal safety and
environmental regulations.
Panacea®products are available to purchase exclusively through Direct Supply
Equipment & Furnishings®, a division of Direct Supply®, Inc. Distributed by Direct Supply®
Manufacturing™, Inc. 6699 N. Industrial Road, Milwaukee, WI 53223.
© 2012-15 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply®,
Panacea®, and all associated logos are the registered trademarks of Direct Supply, Inc.,
used under license.
#5908
Date of Printing: December 2015
Panacea®
XLT LighTweighT
wheeLchair
Please keep and refer to this Owner’s Manual.
Owner’s Manual
Thank you for purchasing a Panacea®XLT Lightweight Wheelchair from Direct
Supply Equipment & Furnishings®, distributed by Direct Supply®Manufacturing™,
Inc. Please read this entire guide carefully and keep it for future reference. This
guide will provide you with instructions, warnings, warranty information and
other important information about your Panacea XLT Lightweight Wheelchair.
Share this information with your housekeeping, nursing and maintenance staff
to help ensure this wheelchair is cared for properly.
1-800-634-7328 DirectSupply.com

Introduction
Thank you for purchasing this Panacea XLT Lightweight Wheelchair from
Direct Supply Equipment & Furnishings, a division of Direct Supply, Inc.
In this owner’s manual, you’ll find important information you should read
before assembling and using this device. Please keep this manual available
for future reference. Should you have any questions, please contact your
Direct Supply account manager or Direct Supply Manufacturing, Inc.
Definitions and Symbols
The Panacea XLT Lightweight Wheelchair is distributed by Direct Supply
Manufacturing, Inc. (“We,” “Us” or “Our”). “You” are the facility,
community or other entity that has purchased the product.
• WARNING: Calls your attention to a potential danger that requires
correct procedures or practices in order to prevent personal injury or death.
• CAUTION: Correct operating or maintenance procedures must be
followed in order to prevent damage to or destruction of the product or
other property.
Warnings and Cautions
Carefully read all directions and warnings before using this device. Do not
operate this device without first reading and understanding the contents of
this manual. Death or injury may result from the improper use of this device or
failure to follow all directions and warnings. This device is intended for use by
or under the supervision of trained and licensed healthcare providers in normal,
indoor conditions.
• WARNING: This wheelchair has not been approved as a seat that can
be used within vehicles of any kind. Always transfer wheelchair user to a
vehicle manufacturer-approved seat and use available safety restraints.
• WARNING: Do not operate this wheelchair on roadways, streets or any
surfaces with vehicular traffic.
• WARNING: Do not attempt to operate on inclines 10 degrees or greater
without proper assistance.
• WARNING: Be sure to completely engage wheel locks when getting in
and out of wheelchair or when in elevator or wheelchair lift.
• WARNING: Wheelchair locks should be used only when the wheelchair
is at a complete stop. The locks are not intended to be used when the
wheelchair is moving. Do not use locks as brakes to slow down.
• WARNING: Wheelchair should be on a smooth, stable and level area
with wheel locks engaged before transferring user in or out of wheelchair.
• WARNING: Do not adjust footrests any lower than 21⁄2" from floor.
• WARNING: When getting in or out of wheelchair, do not stand on or
apply weight to footrests.
• WARNING: Before reaching or leaning forward, rotate casters to front
of the wheelchair and engage wheel locks to help prevent wheelchair from
tipping over.
• WARNING: Do not lean out of the chair or apply weight to the
top of wheelchair back. This can cause wheelchair to tip over. When
trying to extend arms over back, only allow residents to reach as far as
their arm can extend without having to alter their seating position.
• WARNING: Do not stand on wheelchair.
• WARNING: Abruptly stopping or changing directions while going up or
down an incline could cause instability or possible tipping over.
• WARNING: A skilled caregiver should assess the appropriateness of
removing footrests or legrests on a case-by-case basis.
• WARNING: Always provide assistance to residents transferring into
and out of this device.
• WARNING: Do not make any modifications to this device or use
non-Panacea parts. Doing so may void the warranty and pose a risk to
the resident.
• CAUTION: State and local codes and regulations may prohibit
the removal of footrests. Check with your local authorities to ensure
compliance with all applicable regulations.
• WARNING: This device may not be suitable for all individuals. A skilled
caregiver should always assess the appropriateness of this device for a
resident on a case-by-case basis.
Directions for Use
Wheel locks: Engage both wheel locks before getting in or out of chair,
leaning forward in chair, or while in an elevator or wheelchair lift. Proper
adjustment of wheel lock is at least 1⁄8" when locked. Locks are engaged
by pushing handle completely forward. Adjustments to locks are made
by loosening or tightening nut on the carriage bolt. Embed lock to show
at least 1⁄8" by sliding clamp toward rear wheel while handle is in locked
position. Test for correct locking action and the resident’s ability to engage
wheel locks before each use.
Tires: The solid rubber tires on your Panacea wheelchair need minimal
maintenance but should be cleaned occasionally with a damp cloth.
Replace if tires become severely worn or if cracking appears.
Front casters: Casters should be checked periodically and lubricated
occasionally. Lubricate by removing fork and greasing caster stem
bearings. Lubricate wheel bearings by removing wheel from fork.
Reassemble fork and wheel by tightening nuts until no play remains but
wheels roll freely. If nut is too loose, caster will shimmy. If nut is too tight,
the chair will be difficult to steer.
Removal of swingaway footrests/legrests: Release lock by pushing
on the front rigging lever. Swing footrest/legrest out and sideways. Lift
to remove.
Adjusting length of footrest/legrest: When adjusting length of
footrests or legrests, user should be sitting in wheelchair with feet on
the footplates. Loosen bolt on the clamp around support assembly.
Raise or lower footplate to desired position, taking into account
the support of thighs. Front rigging should not be so low that
it causes uncomfortable pressure to thighs at front of seat
upholstery. Footrests should not be lower than 21⁄2" from the
ground to ensure clearance.
Adjusting/elevating legrest: Lift footplate on legrest assembly to
desired position. Release legrest assembly and it will automatically
lock into place. To lower, push out on legrest lever and lower
footplate to desired position.
Wheels: Large rear wheels should be inspected at least once a
month to ensure proper tightness. If wheel wobbles or is loose,
release lock nut and tighten axle bolt slightly. Test for proper
tightness by leaning chair to one side and spinning adjusted wheel.
General care: Wipe chrome parts with a clean, soft cloth at least
once a week. All metal parts can be cleaned with auto wax or similar
devices. If exposed to moisture, dry immediately. Do not use an
abrasive cleanser that will scratch the finish.
To open chair: Open wheelchair by tilting to one side and pushing
down on seat rail until fully opened.
To close/fold chair: First fold footplates to vertical position. Grab
seat with both hands at front and back edge and lift. Or, tilt chair to
one side and lift up on seat rail.
To remove arms: Remove arms by depressing spring button and
lifting arms out of front and rear sockets.
Seat Extension Instructions
Your Panacea wheelchair comes with an adjustable-depth seat that
has been factory set at the shortest position. Follow the instructions
below to extend the seat depth of your chair:
1. Lay wheelchair on its back. Open seat two-
thirds of the way so seat posts do not rest on
chair frame. Unfold seat extension by pulling
upward on end of seat to release hook-and-loop
closure (Fig. 1).
2. Pull outward on hook-and-loop closures to
free them from underside of seat (Fig. 2).
3. The seat extension post is located inside the
seat frame. To access it, turn screw counter-
clockwise and remove it (Fig. 3).
4. Pull upward on seat extension post until
the second hole on the seat post lines
up with the hole on seat frame. Reinsert
screw into bottom hole and turn clockwise
to secure in place (Fig. 4).
5. Fold hook-and-loop closure over extended seat
post to secure seat upholstery to the frame
(Fig. 5).
6. Repeat process for opposite side (Fig. 5).
7. Return chair to upright position and push down
on seat to secure it to the frame (Fig. 6).
1-800-634-7328 DirectSupply.com
Fig. 1
Fig. 2
Fig. 3 Fig. 4
Fig. 5
Fig. 6
