Directed Directechs DB3 User manual

Designed by Installers for Installers
INSTALLATION GUIDE
DB3
2016 Buick Verano (Smart Key). 403.GM9 2.38
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 4
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Wiring diagram 5
Locating components in the vehicle 7
Keyport location 8
Vehicle connections 10
Key2GO 12
Connecting the module 12
Module programming 13
LED diagnostics and troubleshooting 14
Soft reset 16
Hard reset 16
Feature programming 17
Feature and option list 18
Limited one year consumer warranty 19
Quick reference guide 20
Contents

3403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote controls to assure that the system does not unintentionally remote start the vehicle.
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.

4403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to <ConnectImportant> for more information.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
* Fuel Level
Key2GO
* Odometer
Immobilizer Bypass-Data No Key Req'd
OEM Remote Start Activation using XL-202 or RF kit
RAP Shut Down (Retained ACC Power)
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
E-Brake Status
Ignition Status

5403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible Keys required for
programming 1Keys required for
operation 0
Important! The following settings must be made for the 2016 - 2019 Chevrolet Malibu Hybrid (Smart Key). The Remote
Starters tachometer setting set Engine Checking Mode to OFF and Cranking Time (in seconds) to 4.0 seconds or similar.
Important! Wait 10 seconds after remote start shutdown before remote starting the vehicle again.
Key2GO is mandatory to control the immobilizer override in this firmware.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[2] Hook up brake for automatic transmission vehicles or clutch for manual transmission vehicles.

6403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
D2D Port
(-) Ground (-) Ground
(+) Ignition Input
(+) 12V Input
HS CAN High: Tan/Black: 3
HS CAN Low: Tan : 4
1412
10 42
(-) Parking Lights Output
XKD2D65
1
8
10 11 12 13 14
17
23
15
21
18
24
19 20
25
23 4 5 6 7
Immo Data Interr. (conn. side): Yellow: 8
Immo. Data Interr. (veh. side): Orange/Yellow: 9
Single Wire CAN: Lt. Green: 1
(+) Ignition Status Output: Gray/Black: 7
(MUX) Brake Activation Output: Violet/Brown: 9
Immo. Data (conn. side): Yellow/Black: 10
1 2 3 4
5
8 9
10 11 12 13 14
15 17 19
23 25
16
22
18 20
24 26
6 7
21
Cut
Immo. Data:
Green/Violet or
Lt. Blue, pin 2
1 2 3 4
5 6 78
9
10
17
23
16
22
11 12
18
24
13
19
25
14
20
26
15
21
27
(+) 12V: Pin 4
(MUX)
Brake: Pin 7
HS CAN Low:
Pin 23
Single Wire
CAN: Pin 22
HS CAN High:
Pin 24
(-) Parking Lights:
Pin 22
(AC) Tach Output: Violet/White: 5
(AC) Tach Intput
(MUX) Clutch: pin B
BCM (blue conn. under
driver-side dash or in center
console passenger side)
BCM
(green conn.
under driver-side
dash or in center
console passenger side)
BCM
(white conn. under
driver-side dash
or in center console
passenger side)
ABC
Clutch Switch
(black 3-pin
connector)
Clutch: Brown/Red: 12
(MUX) Clutch Output: Yellow/Red: 11
180 Ohms Resistor

8403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Keyport location
Vehicle Keyport location Reference
Buick Enclave (Smart Key) 2018 - 2020 Remove the cupholder from the center console storage area. Place
transmitter in the pocket with the buttons facing up. B
Buick Encore (Smart Key) 2017 - 2021 Place transmitter in the cupholder with the buttons facing up. D
Buick Encore GX (Smart Key) 2020 - 2021 Place the RKE transmitter in the storage bin with the buttons facing up. F
Buick Envision (Smart Key) 2016 - 2020 Place transmitter in the cupholder with the buttons facing up. D
Buick LaCrosse (Smart Key) 2014 - 2019 Place the transmitter in the transmitter pocket inside the armrest storage
area. A
Buick LaCrosse (Smart Key) 2010 - 2013 Remove the cupholder from the center console storage area. Place
transmitter in the pocket with the buttons facing up. B
Buick Regal (Smart Key) 2011 - 2017 Remove the cupholder liner from the center console cupholder. Place
transmitter in the pocket with the buttons facing up. B
Buick Regal Sportback (Smart
Key)
2018 - 2020 Place the RKE transmitter in the storage bin with the buttons facing up. F
Buick Regal Tour X (Smart Key) 2018 - 2020 Place the RKE transmitter in the storage bin with the buttons facing up. F
Buick Verano (Smart Key) 2012 - 2017 Remove the cupholder liner from the center console cupholder. Place
transmitter in the pocket with the buttons facing up. D
Cadillac ATS (Smart Key) 2013 - 2018 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Cadillac ATS-V (Smart Key) 2016 - 2018 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Cadillac CTS Sedan (Smart
Key)
2014 - 2017 Open the center console storage area and remove the rubber mat. Place
the transmitter in the transmitter pocket. A
Cadillac CTS-V (Smart Key) 2016 - 2017 Open the center console storage area and remove the rubber mat. Place
the transmitter in the transmitter pocket. A
Cadillac Escalade (Smart Key) 2015 - 2020 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Cadillac SRX (Smart Key) 2010 - 2017 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Cadillac XT4 (Smart Key) 2019 - 2020 Open the center console and place the transmitter in the transmitter
pocket. A or B
Cadillac XT5 (Smart Key) 2017 - 2020 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Cadillac XT6 (Smart Key) 2020 Open the center console and place the transmitter in the transmitter
pocket. A or B
Cadillac XTS (Smart Key) 2013 - 2018 Open the center console storage area and the storage tray. Place the
transmitter in the transmitter pocket. A
Chevrolet Blazer (Smart Key) 2019 - 2021 Place the transmitter in the front cupholder. D
Chevrolet Camaro (Smart Key) 2016 - 2019 Place transmitter in the pocket with the buttons facing up. C
Chevrolet Cruze (Smart Key) 2012 - 2016
Remove the plastic trim piece from the small storage area next to the
accessory power outlet toward the front of the console. Push the button on
the transmitter to extend the blade, insert the key blade into the transmitter
slot.
E
Chevrolet Corvette (Smart Key) 2019 - 2020
Place the transmitter in the steering column transmitter pocket with the
buttons facing up and the bottom of the transmitter facing the passenger
side.
G
Chevrolet Cruze (Smart Key) 2017 - 2018 Place transmitter in the cupholder with the buttons facing up. D
Chevrolet Equinox (Smart Key) 2018 - 2021 Place the transmitter in the front cupholder. D
Chevrolet Impala (Smart Key) 2014 - 2019 Open the center console and place the transmitter in the transmitter
pocket. A or B
Chevrolet Malibu (Smart Key) 2013 - 2020 Open the center console and place the transmitter in the transmitter
pocket. A or B
Chevrolet Malibu Hybrid (Smart
Key)
2016 - 2019 Open the center console and place the transmitter in the transmitter
pocket. A or B

9403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Vehicle Keyport location Reference
Chevrolet Silverado 1500
(Smart Key) 2019 - 2021
With bucket seats - Open the center console and place the transmitter in
the transmitter pocket with the buttons facing the front of the vehicle. D
Without bucket seats - Place transmitter in the transmitter pocket between
the cupholders. B
Chevrolet Silverado
2500/3500 (Smart Key) 2020 - 2021
With bucket seats - Open the center console and place the transmitter in
the transmitter pocket. D
Without bucket seats - Place transmitter in the transmitter pocket between
the cupholders. B
Chevrolet Spark (Smart Key) 2016 - 2021 Open the center console and place the transmitter in the transmitter
pocket. B
Chevrolet Suburban (Smart Key) 2015 - 2020 Open the center console and place the transmitter in the transmitter
pocket. A
Chevrolet Tahoe (Smart Key) 2015 - 2020 Open the center console and place the transmitter in the transmitter
pocket. A
Chevrolet TrailBlazer (Smart Key)
2021 Open the center console and place the transmitter in the transmitter
pocket. B
Chevrolet Traverse (Smart Key) 2018 - 2021 Open the center console and place the transmitter in the transmitter
pocket. B
Chevrolet Trax (Smart Key) 2017 - 2021 Place the transmitter in the front cupholder of the center console storage
area. F
GMC Acadia (Smart Key) 2017 - 2020 Open the center console and place the transmitter in the transmitter
pocket. B
GMC Sierra 1500 (Smart Key) 2019 - 2021
With bucket seats - Open the center console and place the transmitter in
the transmitter pocket with the buttons facing the front of the vehicle. D
Without bucket seats - Place transmitter in the transmitter pocket between
the cupholders. B
GMC Sierra 2500/3500
(Smart Key) 2020 -2021
With bucket seats - Open the center console and place the transmitter in
the transmitter pocket. D
Without bucket seats - Place transmitter in the transmitter pocket between
the cupholders. B
GMC Terrain (Smart Key) 2018 - 2021 Place the transmitter in the front cupholder. D
GMC Yukon (Smart Key) 2015 - 2020 Open the center console and place the transmitter in the transmitter
pocket. A
Center Console
Cupholder
Front
B
C
D
E
G
F
A

10 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2016 Buick Verano (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green (DATA) Single Wire CAN BCM on passenger side of center dash, blue 27 pin plug, pin 22 data green
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN High BCM on passenger side of center dash, blue 27 pin plug, pin 24 data blue
H1/4 Tan (DATA) HS CAN Low BCM on passenger side of center dash, blue 27 pin plug, pin 23 data white
H1/5 Orange/Green No Connection No Connection
H1/6 Orange/Brown No Connection No Connection
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM Immo. Data Interrupt (conn. side) BCM on passenger side of center dash, green 25 pin plug, pin 2 data green/violet
H1/9 Orange/Yellow Relay N.C. Immo. Data Interrupt (vehicle side) BCM on passenger side of center dash, green 25 pin plug, pin 2 data green/violet
H1/10 Orange/Red Relay N.C. No Connection No Connection
H1/11 Yellow/Red Relay COM (MUX) Clutch Output [2] clutch switch, black 3 pin plug, pin B resistor
s
yellow
H1/12 Brown/Red Relay N.O. (-) Ground [2] Must use a resistor. (chassis ground)
H1/13 Red (+) W2W Only - 12 Volt BCM on passenger side of center dash, blue 27 pin plug, pin 4 + red/brown (30A)
H1/14 Black (-) W2W Only - Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black No Connection No Connection
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black No Connection No Connection
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - (+) Brake Status Output Remote Starter
H2/7 Gray/Black (+) Ignition Output Remote Starter
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown (MUX) Brake Activation Output [2] BCM on passenger side of center dash, blue 27 pin plug, pin 7 MUX blue/yellow
H2/10 Yellow/Black Immo. Data BCM on passenger side of center dash, green 25 pin plug, pin 2 data green/violet
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color

11 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet (-) W2W Only - Aux1 Input Remote Starter
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White No Connection No Connection
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink (+) W2W Only - Ignition Input Remote Starter
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Green (Data) TX
H4/2 Black (-) Ground
H4/3 Blue (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts BCM on passenger side of center dash, blue 27 pin
plug, pin 4
+ red/brown (30A)
Ground (chassis ground)
Ignition BCM on passenger side of center dash, green 25 pin
plug, pin 6
+ violet/black
Parking Lights - hdlt sw or BCM on pass side of cntr dash, white 26
pin plug, pin 22
- green/gray
Tachometer top front of engine, black 12 pin plug, pins 1, 2, 3, or
4
ac brown, blue, green, or lt. blue

12 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Key2GO
This feature is mandatory to control the immobilizer override in this firmware.
Key2GO has been designed and developed to bypass the advanced encryption layers found in modern vehicles. It uses an array
of servers to generate a duplicate of the original key, allowing the installation of a remote starter without having to give up a key.
The advantage is that this feature allows you to use one original key and the server to configure the bypass in the vehicle.
All Key2GO-compatible firmware are clearly indicated in the function list of each vehicle search result page and will also appear
on the flash page. Any first-time user must re-register to gain access to Key2GO, and some additional information will be required
to complete the registration process, such as your Directed account number and store name.
Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application.
Refer to “Module programming” of this guide for instructions on how to program features using Key2GO.
Connecting the module
Important!
Make all the required connections to the vehicle, as described in this guide, and double check to ensure everything is correct prior
to moving onto programming.
Warning! To take advantage of advanced features, you must use DirectLink 4.5 (and higher) or the Directechs Mobile application.
Flashing a module using your computer:
1. Connect the interface module to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and select the Flash Module button.
3. Follow the instructions to select your vehicle, installation type, and configure your options.
4. Once you have configured the firmware options, click on the FLASH button.
Flashing a module using your smartphone or tablet:
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs Mobile app on your smartphone or tablet.
3. Select FLASH YOUR MODULE and follow the on screen instructions.
When the flashing operation is successful, you can proceed with the instructions below.
D2D installation
Recommended: Connect the 10-pin, 12-pin and 14-pin harnesses to the module, then
connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
4th
(D2D)
2nd
(12-pin)
OR
W2W installation
If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin
harness to the module. 3rd
(14-pin)
1st
(10-pin)
2nd
(12-pin)

13 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
1
Wait until the LED turns ON solid red.
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. When the LED turns ON solid orange, proceed to
step 4.
2Remove battery from one key fob, and make sure that the other key fob is located
more than 10 feet away from vehicle.
3Put the key fob (with battery removed) in the keyport. (Refer to Keyport location).
4
Press and hold the Push-to-Start (PTS) button until the ignition turns ON, then release.
The LEDflashes orange then green.
Note: If the LED starts flashing 2x red, press and hold the Push-to-Start (PTS) button with
the brake pedal applied. When the engine begins cranking, let go of the button. The
LED flashes orange then green, proceed to step 5.
Note: If the transponder programming was skipped, the LED turns ON solid orange for
3 seconds then shuts OFF when programming is done.
5Press the PTS button once to turn the ignition OFF. The LED willflash orange slowly.
6Remove the module from the vehicle and reconnect it to your computer. The web site
will automatically recognize that you are moving onto the second phase of the
programming sequence.
7Click on Submit Key2GO Request.
8Once the configuration is completed, reconnect the module. The LED turns ON solid
green for 3 seconds, then turns OFF.
You have successfully completed the module programming sequence.

14 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
LED diagnostics and troubleshooting
This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation.
Module Programming
LED Description Troubleshooting
Off Module has no power. Make sure the D2D harness is connected and that 12 Volt is present between the red and black
wires. If 12 Volt is present, the module may be defective.
Solid red
Waiting to begin the programming
sequence. Ensure the correct programming procedure is being followed.
Flashes green &
red
Initialization failed. Reset the module and complete the programming again. If the issue persists, please contact
Technical Support.
Solid orange Transponder functions were skipped. (If compatible) when RXT mode is not desired or convenience features are needed, please reset
the and reprogram the module.
Flashes green
All required CAN networks has been
detected. Normal operation.
Flashes orange 1 of 2 CAN networks has been detected. Normal operation.
Flashes orange
slowly
Key2GO initiated. Please follow the steps indicated in “Module programming” to complete the Key2GO
programming.
Solid green x 3
secs
Module was successfully programmed
with all functions. Normal operation.
Solid orange x 3
secs
Module was successfully programmed
without transponder functions. Normal operation.
Module Programming - Error codes
LED Description Troubleshooting
Flashes red x 1 CAN2 not detected.
Check the CAN2 Orange/Green and Orange/Brown wire connections. Wake up the data bus
by turning the ignition on and try again. If your installation does not require this connection, skip
this step by pressing the programming button 5 times.
Flashes red x 1 J1850 not detected. Check the J1850 wire connection. Wake up the data bus by turning the ignition on and try
again.
Flashes red x 2 CAN1 not detected.
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the
ignition on and try again. If your installation does not require this connection, skip this step by
pressing the programming button 5 times.
Flashes red x 3 Bypass data not detected. Check the bypass line connection. If more than one wire is used, make sure they are not inverted.
Ensure the vehicle still operates correctly using the factory key.
Flashes red x 4 Bypass processing error. The bypass calculation failed. Reset the module and try again. If the condition persists, please
contact Technical Support.
Flashes red x 5 ISO 1 not detected. The Yellow/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams
& vehicle wiring reference charts)” to check the connections.
Flashes red x 6 ISO 2 not detected. The Orange/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams
& vehicle wiring reference charts)” to check the connections.
Flashes red x 7 MUX not detected. The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to
“Installation (wiring diagrams & vehicle wiring reference charts)” to check the connections.
External Module Synchronization
LED Description Troubleshooting
(Flashes red, red,
then orange) x 10
OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited.

15 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Active Ground When Running (Status)
LED Description Troubleshooting
Flashes green
Ground When Running (Status) command
received. The module has initialized the remote start sequence.
Flashes red &
orange
Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence.
Flashes green
quickly
Start ON command received. The module has received the Start ON command and is processing the remote start sequence.
Flashes red x 10 PTS shutdown error. The PTS output from the module was not activated due to safety protection.
Flashes red x 21 CAN bus incorrectly detected. Verify the CAN1 and CAN2 connections. Refer to “Installation (wiring diagrams & vehicle wiring
reference charts)” to check the connections.
Commands
LED Description Troubleshooting
Flashes orange x 1 LOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 2 UNLOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 3 TRUNK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 4 AUX1 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 5 AUX2 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 6 AUX3 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Shutdown Codes
LED Description Troubleshooting
Flashes green x 1 Takeover successful. Normal operation.
Flashes red x 1 Runsafe was not disabled. No UNLOCK command was received prior to opening the door, or the 45 second timer expired
in takeover mode.
Flashes red x 2 Brake was not detected. The brakes were not detected, which prevents the system from shutting down the vehicle.
Flashes red x 3 Smart key was not detected. The smart key was not detected, which prevents the system from shutting down the vehicle.
Flashes red x 4 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down.

16 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Soft reset
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange then release the programming button.
The LED turns ON solid red. &&
Solid SolidRelease
A module reset will only erase the steps perfomed in “Module programming”. The firmware and settings flashed to the module
will not be affected.
Hard reset
Warning Against Executing a Hard Reset!
1
D2D installation
Connect the 10-pin, 12-pin & 14-pin harnesses to the module. Press and hold the
programming button, then connect the 4-pin D2D harness. 3rd
(14-pin)
1st
(10-pin)
5th
(D2D)
2nd
(12-pin)
4th
(Button)
OR
W2W installation
Connect the 10-pin & 12-pin harnesses to the module. Press and hold the
programming button, then connect the 14-pin harness to the module. 4th
(14-pin)
3rd
(Button)
1st
(10-pin)
2nd
(12-pin)
2Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the
LED starts to flash orange and red. Solid Flashes
&
3Release the programming button. The LED turns ON solid red. &
Release Solid
A hard reset will revert the flashed firmware back to its default factory settings. Depending on the installation, some settings (such
as RFTD and D2D options) may have to be reconfigured. Refer to “Feature and option list”.

17 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Feature programming
To enter feature programming routine:
1. Turn the ignition ON, then OFF.
2. Within 5 seconds, press and hold the programming button until the LED turns ON orange (after 3 seconds).
3. Release the Programming button.
4. The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to
indicate the current option of feature 1 (e.g. 1 x green followed by 1 x red indicates feature 1 is set to option 1). The flashing
sequence will repeat until a new command is entered.
Changing feature options:
1. Press the lock/arm or unlock/disarm button on aftermarket transmitter to change the option of the selected feature.
2. The LED flashes red rapidly the number of times equal to the current option number. After a short delay, the LED flashes green
slowly the number of times to indicate the current feature. The flashing sequence will repeat until a new command is entered.
Accessing another feature:
1. Press and release the programming button a number of times to advance from the current feature to the next desired feature.
2. The LED flashes green slowly the number of times equal to the feature number. After a short delay, the LED flashes red rapidly
to indicate the current option of the current feature. The flashing sequence will repeat until a new command is entered.
When the maximum number of features or options is reached, the LED will start flashing again from the first feature or option.
Exiting feature programming:
To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface
for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence.

18 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Feature and option list
It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing
page at www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the
information on this page.
* Default option
Feat. Operation Flashes / Option Description
1 RFTD Output
Type
1. No RF Output* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (when available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
2 Unlock Driver
Priority
1. Driver priority* Unlocks only the driver door when the button is first pressed, and unlocks all doors
when it is pressed a second time within 5 seconds.
2. All Unlocks all doors when the button is first pressed.
3 Trunk 1. Trunk* Will pop the trunk if available.
4 Aux1 1. Trunk Will pop the trunk if available.
2. Electric Rear
Hatch* Will open the rear hatch if available.
5 Smart OEM
Alarm Control 1. Disabled
The OEM alarm will not be controlled by the interface upon remote start. No disarm
or arm command will be executed at the beginning or end of the sequence; it must
be controlled by the Remote Starter.
2. Safelock
Smart OEM Alarm Control will behave like a standard Safelock feature on a remote
starter. It will unlock at the beginning of the sequence, and relock after start and
shutdown.
3. Enabled*
Smart OEM Alarm Control will synchronize with the OEM alarm so that it will
disarm and rearm the vehicle in the remote start sequence, only when required.
Smart OEM Alarm Control will monitor the alarm and door lock status to detect if
the disarm or rearm is required. If the vehicle is unlocked or is not equipped with
factory alarm, the disarm/rearm will not be executed.

19 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Limited one year consumer warranty
For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed
Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the
security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material under
normal use, provided the following conditions are met: the Part was purchased from an authorized DIRECTED dealer; and the
Part is returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale bearing the following
information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete product and Part
description.
This warranty is nontransferable and is automatically void if the Part has been modified or used in a manner contrary to its
intended purpose or the Part has been damaged by accident, unreasonable use, neglect, improper service, installation or other
causes not arising out of defect in materials or construction.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, EXCEPT AS STATED ABOVE, ALL WARRANTIES, INCLUDING BUT NOT
LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR
PURPOSE AND WARRANTY OF NONINFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND
DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION
OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED HEREBY DISCLAIMS AND HAS ABSOLUTELY NO
LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING DEALERS OR INSTALLERS. DIRECTED IS NOT OFFERING
A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE, OR THEFT OF THE AUTOMOBILE, ITS PARTS OR
CONTENTS, AND DIRECTED HEREBY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIMITATION,
LIABILITY FOR THEFT, DAMAGE, OR VANDALISM. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR
ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE
LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER
ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE
OF THE PART. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE,
THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR AT DIRECTED’S OPTION THE PART AS
DESCRIBED ABOVE.
This warranty only covers Parts sold within the United States of America and Canada. Parts sold outside of the United States of
America or Canada are sold “AS-IS” and shall have NO WARRANTY, express or implied. Some states do not allow limitations
on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights and you may also have other rights that vary from State to State. DIRECTED does not and has not
authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this Part.
For further details relating to warranty information of Directed products, please visit the support section of DIRECTED’s website at:
www.directed.com
920-10012-01 2013-07
This Interface kit / Data Bus Interface part has been tested on the listed vehicles. Other vehicles will be added to the select
vehicle list upon completion of compatibility testing. Visit website for latest vehicle application guide. DISCLAIMER: Under
no circumstances shall the manufacturer or the distributors of the bypass kit / data bus interface part(s) be held liable for any
consequential damages sustained in connection with the part(s) installation. The manufacturer and it’s distributors will not, nor will
they authorize any representative or any other individual to assume obligation or liability in relation to the interface kit / data bus
interface part(s) other than its replacement. N.B.: Under no circumstances shall the manufacturer and distributors of this product be
liable for consequential damages sustained in connection with this product and neither assumes nor authorizes any representative
or other person to assume for it any obligation or liability other than the replacement of this product only.
Protected by U.S. Patents: 5,719,551; 6,011,460 B1 *; 6,243,004 B1; 6,249,216 B1; 6,275,147 B1; 6,297,731 B1; 6,346,876 B1; 6,392,534
B1; 6,529,124 B2; 6,696,927 B2; 6,756,885 B1; 6,756,886 B2; 6,771,167 B1; 6,812,829 B1; 6,924,750 B1; 7,010,402 B1; 7,015,830
B1; 7,031,826 B1; 7,046,126 B1; 7,061,137 B1; 7,068,153 B1; 7,205,679 B1; Cdn. Patent: 2,320,248; 2,414,991; 2,415,011; 2,415,023;
2,415,027; 2,415,038; 2,415,041; 2,420,947; 2,426,670; 2,454,089; European Patent: 1,053,128; Pat. Pending: 2,291,306. Made in Canada.

20 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Quick Reference Guide
Pit stop/idle mode
1Stop the vehicle in a safe parking spot and put the
gear in Park (P).
Put
gear in
Park
2
Press the Remote Start button on the transmitter.*
The parking lights will flash once to indicate the
vehicle is now in Pit Stop Mode. Parking lights flash x1
14:36
Press Remote
Start button*
&
3
It is safe to leave the engine running and exit the
vehicle with the factory remote in hand.
Note: We recommend that you always lock the
doors of your vehicle when leaving it unattended.
14:36
Exit vehicle
with remote
* Icon and remote appearance may differ depending on the model purchased.
List of available commands
Note that the information below is for many Viper, Clifford, Python, Avital, Automate,
Autostart and AstroStart models. Icons and commands may differ depending on the
model and options purchased. Refer to your authorized installation center for more
specific information.
Button(s) Actions
Press & hold for 1 second to lock.
Press & hold for 1 second to unlock.
* Press & hold for 1 second to remote start.
* Press & hold for 5 seconds to activate the trunk release (optional).
* Icon and remote appearance may differ depending on the model purchased.
Sending commands to your vehicle
Whether you want to remote start the engine, lock/unlock the doors or pop the trunk,
there are 3 possible ways you can send commands to your vehicle, using the:
• Factory remote.
• Aftermarket remote.
• Directed SmartStart application via your smartphone.
If applicable, you can also start the engine remotely by pressing the Lock button 3
times quickly on your factory remote.
Vehicle takeover with Get In and Go
1
Close the vehicle doors, hood and trunk, then press
the Remote Start button on the transmitter to start the
vehicle.*
14:36
Press Remote
Start button*
2Press the Unlock button on the factory or aftermarket
remote.*
14:36
Press Unlock on
either remote*
Complete the following steps within 45 seconds or the vehicle will shut down.
3Enter the vehicle, while making sure the factory
remote is inside with you. Close all vehicle doors.
14:36
Enter vehicle
with remote
4Depress the brake pedal for a minimum of 3 seconds
then put the car in gear and drive off.
Ready to
drive off
* Icon and remote appearance may differ depending on the model purchased.
Get In and Go
Get In and Go is designed to provide users with easy takeover when entering their
Push-to-Start (PTS) equipped vehicle, once it has been remote started.
Typically, users would have to remote start their vehicle, then get inside and press
the PTS button to perform a takeover. There is therefore a physical action required
to drive away. With Get In and Go, you simply remote start the vehicle, unlock the
doors, get in and go... All that's left to do is put the gear in drive and drive off.
Other manuals for Directechs DB3
82
This manual suits for next models
1
Table of contents
Other Directed Door Lock manuals
Popular Door Lock manuals by other brands

RCI
RCI F1114 installation instructions

CEStronics
CEStronics OMEGA ACTIVE IES Fitting and operating instructions

Assa Abloy
Assa Abloy Emtek Modern Keypad Entryset Installation & programming guide

Best
Best IDH Max 1300 installation instructions

Schlage
Schlage Omnia quick start guide

Weiser
Weiser kevo convert 66102/01 Installation and user guide
