Installation Instructions
Spider Rear Netting
DD-N-JK4-07RS
Jeep JK unlimited 2007-up
-Thank you for purchasing a Dirtydog 4x4 netting system.
Please read these instructions fully to familiarize yourself with
the installation. You should have 3 main pieces. Right side, left
side, and backside. Set aside 30 minutes for the first time you
install your netting. Installation is done easiest with the hard
Step 1
Start with the back piece first.
Install the short straps on the
side roll bars first. For correct
positioning the fifth strap from
the bottom attaches at the top
of the roll bar. Each additional
strap installs down the roll bar.
The last strap connects to the
rear fender with the strap in
the lower photo. This strap
connect to the under side of
the fender lip using the longer
bolts provided. These will
thread into the hardtop nut if
you have them or you can use
the nut and washer we have
VIDEO INSTALLATION INSTRUCTIONS AVAILABLE AT:
WWW.DIRTYDOG4X4.COM OR WWW.FACEBOOK.COM/DIRTYDOG4X4

The strap at the very top of
the rear piece wraps around
the top of the vertical roll bar
comes toward the outside
wraps back around and
connects into the ladderloc
clip. See photo
Slide each half of the aluminum tailgate bar in the last row as
shown in the photo. This bar will connect at the center of the net
and then the whole bar is clipped into soft-top tailgate clips.
(Clips can be purchased form us or your local dealer.) This last
row is optional and can be cut off if not needed.

Next is to install is the
attaching strap with the nut
and washer provided. This is
the strap that has a single ring
on one end. This attaches to
the existing bolt stud that you
will find under the carpet
directly behind the rear door
STEP 2
Start with either side. There are
4 rings that attach with straps.
2 rings attach sharing the
straps you already installed on
the rear section (white arrows)
and 2 rings that attach with
additional straps provided
(black arrows). The bottom
The side straps can now be
installed on the loop in the
order shown in the photo.
Tighten straps 1 and 2 evenly so
net is pulling equally in both
directions. Followed by straps 3
and 4.
1
2
3
4

Dirtydog 4x4
3045 Southcreek Road
Mississauga, ON
Canada
1.855-704-0708
Question? Call or email [email protected]
Any excess straps that hang out can be tucked in under itself. Adjust and
tighten straps as needed to even out the net so it is positioned properly.
Your net comes with a 3 year warranty against manufacturing defects.
Cuts, abrasions, sun faded items are not covered under the warranty.
The last strap at the bottom
can now be installed using the
loop at the rear strap that you
installed at the beginning.
Inside view

Buckle with
grommet
Buckle with
grommet
Buckle with
roll bar Wrap
Buckle with
roll bar Wrap
