HAUL MASTER 69650 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ols required for assembly and se rv ic e m ay n ot b e i nc lu de d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 69650
Specifications
Load Capacity 350 lb.
Dimensions 52-3/4"L (extended) x 12-3/4"H
Crossbar Width 49"
Hitch Receiver Size Fits 2" Square Receivers
Note: A class 3 truck hitch is required.
IMPORTANT SAFETY INFORMATION
General Safety
1. Make sure the area in which
the Extender is assembled is
clean and well lit. Cluttered or
dark areas invite accidents.
2. Keep children and bystanders away
while assembling the Extender.
3. Stay alert, watch what you are
doing and use common sense when
using the Extender. Do not use the
Extender while you are tired or under
the influence of drugs, alcohol or
medication. A moment of inattention
while using the Extender may
result in serious personal injury.
Extender Use and Care
1. Use the correct Extender for your
application. The correct Extender
will do the job better and safer at the
rate for which it was designed.
2. Store the Extender out of reach of
children and do not allow people
unfamiliar with the Extender or
these instructions to use the
Extender. Use of Extender by
untrained people may not be safe.
3. Maintain the Extender. Check for
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
Extender’s operation. If damaged,
have the Extender repaired before
use. Many accidents are caused
by poorly maintained equipment.
4. Use this Extender in accordance with
these instructions and in the manner
intended for this particular type of
product, taking into account the area
conditions and the task to be performed.
Use of this Extender for operations
different from those intended could
result in a hazardous situation.
Service
Have this Extender serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the Extender is maintained.

Page 3For technical questions, please call 1-888-866-5797.Item 69650
Specific Safety Rules
1. Follow DOT guidelines for
installation and use.
2. Do not exceed 350 lb. capacity,
evenly distributed. Be aware of
dynamic loading! Sudden load
movement may briefly create excess
load causing product failure.
3. Secure load before moving.
4. Tie warning flag to the end
of extended loads.
5. Turn vehicle’s ignition OFF, set parking
brake, and chock wheels before
installing, loading, or unloading.
6. Use as intended only.
7. Inspect before use; do not use
if parts loose or damaged.
8. Wear ANSI-approved safety goggles
and heavy-duty work gloves during
installation, loading, and unloading.
9. Maintain labels and nameplates
on the Extender. These carry
important safety information. If
unreadable or missing, contact
Harbor Freight Tools for a replacement.
10. Keep Extender clean and dry.
11. This product is not a toy. Keep
it out of reach of children.
12. Make sure to secure load with ropes,
and/or tie-downs before transporting.
13. Load heaviest items toward
the center of the Extender.
14. Only use Extender with a properly
installed Class III 2 inch hitch
receiver capable of supporting
the Extender and its load.
15. The warnings, cautions, and instructions
discussed in this instruction manual
cannot cover all possible conditions
and situations that may occur. It must
be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
SAVE THESE INSTRUCTIONS.

Page 4 For technical questions, please call 1-888-866-5797. Item 69650
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Assembly Diagram on page 7.
Turn vehicle’s ignition OFF, set parking brake, and chock wheels before assembly.
Assembly
1. With the short end of the L-Extension
(4) facing up, slide the long end into
the receiver hitch (not included).
2. Insert an Angled Pin (2) through
the hitch and L-Extension (4).
3. Secure with a R-Pin (3) through
the hole in the Angled Pin (2).
4. Slide the Warning Flag (5) onto
the remaining Angled Pin (2).
5. The T-Support (1) has five holes
to change the height. Line up the
hole on the T-Support (1) with the
desired hole on the L-Extension (4).
6. Insert the Angled Pin (2) with
the Warning Flag through
T-Support and L-Extension.
7. Secure with the remaining R-Pin (3).
8. Pull out on the L-Extension and
T-Support to make sure they
are properly locked in place.
Functions
Note: Lowest setting shown.
Note:
Lowest setting shown.
Figure A: Components
L-Extension
T-Support
Receiver Hitch hole
Height holes
Angled Pin
R-Pin

Page 5For technical questions, please call 1-888-866-5797.Item 69650
Operation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
TO PREVENT SERIOUS INJURY: Make sure the vehicle is turned off and in
gear or park, with the emergency brake engaged and the wheels blocked.
Make sure the Extender is secured onto the vehicle.
Make sure the Extender is clean and dry before loading.
Do not exceed this Extender’s maximum weight capacity of 350 pounds.
All persons not involved in loading or unloading the
Extender must stand clear of the unit.
1. Attach the Truck Extender to
the vehicle as explained in the
Assembly instructions.
2. Load the Truck Extender, making sure
the objects are secured in the truck
bed so they will not tip up out of the
bed and over the Truck Extender.
3. Secure the load to the Truck
Extender with appropriate lashing
materials (not included).
Note: The Truck Extender and load
will increase the overall vehicle length.
Use care when parking, turning, or
backing up with the load attached.
4. Remove the Truck Extender from
the vehicle when not in use.
NOTICE! Contact local Department of
Transportation to verify all safety guidelines
are being followed before transporting load.
CAUTION! Do not exceed 350 lb.
capacity. Be aware of dynamic loading.
Sudden load movement may briefly create
excess load causing product failure.

Page 6 For technical questions, please call 1-888-866-5797. Item 69650
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY:
Remove load from the Extender before performing any maintenance or service.
Do not use damaged equipment. If the Extender is damaged
have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect
the general condition of the
Extender. Check for:
• loose hardware, weld
fractures, excessive rust,
• misalignment or binding of parts,
• cracked or broken parts,
bent pins, and
• any other condition that may
affect its safe operation.
2. Clean the Extender after each use.
Make sure dirt, oil, grease, and
debris are not on the Extender.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST IN THIS
DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY
THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR
HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR
ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 7For technical questions, please call 1-888-866-5797.Item 69650
Parts List and Assembly Diagram
Part Description Qty
1 T-Support 1
2 Angled Pin 2
3 R-Pin 2
Part Description Qty
4 L-Extension 1
5 Warning Flag (not shown) 1
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 792363696500 when ordering parts.

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
