Disinfect&Fog Disinfecto Electrostatic Sprayer User manual

Disinfecto
Electrostatic Sprayer
Ownership Manual

Disinfecto Electrostatic Sprayer Manual
The Disinfecto Cordless Electrostatic Sprayer is here and it’s a game
changer!
Thank you for your purchase of this device from Disinfect & Fog. Please
read through this operating manual for the best practices of the use and
maintenance of your new Disinfecto sprayer.
Product Features
• Rechargeable Lithium-Ion battery
• Low noise
• Easy to use
• Lightweight
• LED Battery status indicator
• Excellent coverage
• Electrostatic generator for improved uniformity of droplets and
surface coverage
• Adjustable atomization (switchable at output)
• Electrostatic charge of solution (o!/on switch)
Product Name: Disinfecto Electrostatic Sprayer
Battery: 12 V, 2500mAH Lithium-Ion
Charge Time: 90 minutes
Run Time: 3-3.5 hours
Capacity: 500ml solution tank
Weight: 2.2 lbs. (3.3 lbs. w/tank full)
Optimum Spray Distance: 1-3 feet
Droplet diameter: 60-120 um
Flow Rate: 40Um/4.2 oz./min
Specifications
Page 1

Page 2
• Remove the sprayer from the box
• Remove the solution tank (bottle) by sliding the spring-loaded lock
switch (black). The bottle will slide out downwards from the
sprayer
• Fill the solution tank with the desired amount of disinfectant and
insert, checking the fluid tube is in the tank, use the guide rails to
slide the tank back into position. The locking mechanism should
click when secure
• You are now ready for use
Operation (please see Warning section prior to first-time operation - Page 5)
• Once the disinfectant is in the tank and locked in position in the
sprayer, move to an open area to determine the spray distance
and output setting requirements (atomization)
• Pull the trigger in the grip, inspect the output distance and type of
atomization
• Determine if you wish to select the "Electrostatic" setting as well
(see black slide switch across from trigger area)
• Recommended spray distance of 30-50 cm (12-20 inches)
• Ensure continuous movement as you walk around areas/surfaces
you wish to disinfect to prevent over wetting
Note: For PPE recommendations, consult the disinfectant solution Safety
Data Sheets (SDS) from the disinfectant manufacturer.
How to Use
Disinfecto Electrostatic Sprayer Manual

Disinfecto Electrostatic Sprayer Manual
Maintenance and Cleaning
• After each operation, remove any unused solution (disinfectant)
by unlocking the tank from the sprayer and emptying
• Rinse out the tank and fill half the tank with warm water
• Reinsert the tank ensuring it locks in place
• Pull the trigger and spray the water through the unit for 30
seconds (this cleans the line of excess solution)
• Wipe o!any excess water at the output, the sprayer is ready to be
stored away until the next use
• A black plastic tool is provided with the unit to move the output
nozzle should cleaning be required. The nozzle is turned like a
screw to remove, clean, and then screwed back in place using the
same tool
• Lengthy periods of storage (1+ week) without usage should have
the preceding maintenance performed before storage
• Do not immerse the sprayer (base, trigger, handle, etc.) in water or
solution, keeping the sprayer away from wet areas such as the
sink, solution, etc.
• The integrated battery charger should be charged a minimum of 2
hours on the first charge. The running time is approx. 3-3.5 hours,
subsequent charging will be approx. 90 minutes
• Extended periods of storage time may require charging before
next use (once a month)
NOTE: The sprayer must be charged when the last light is lit on the LED
battery level display
NOTE: The lock mechanism must be in the proper position, securely
holding the tank before operation
NOTE: When spraying water during the maintenance procedure, run the
sprayer for a minimum of 30 seconds to flush the unit
Page 3

Page 4
Disinfecto Electrostatic Sprayer Manual
Item Common Faults Causes Resolution
1Low or no output
flow (spray)
Tank filter (end of
tube) is blocked
Nozzle (output) is
blocked
Pipeline is blocked
Low battery
(insu!cient power)
Clean the filter (pin)
2 Spray not normal
The nozzle is
damaged
Nozzle adjustment
improper setting
(output atomizing)
Diaphragm pump
issue
Inspect nozzle for
potential replacement
3 Leaking
Tank is not securely in
place
Hose connection issue
Check seal and ensure
the lock is engaged to
secure the tank
Locate source of leak,
contact service if
problem persists
Readjust (use tool)
Contact service for
diaphragm repair
Clean (removable) the
nozzle
Clean the pipeline
(disassembly may be
required, contact
service)
Charge or replace the
battery
4No power/
operation
Battery issue Charge or replace the
battery
The fuse is loose or
blown
Poor switch contact
Replace the fuse
(contact service)
Repair or replace
switch (contact
service)
Troubleshooting

Disinfecto Electrostatic Sprayer Manual
Warning
• Intended for disinfection usage, we do not encourage or
recommend use with pesticides, paint, fertilizers, growth
hormone or other related fluids. Contact Disinfect & Fog for
recommended solutions
• Do NOT use for spraying paints, solvents, or corrosive fluids
• Turn o!room fans when using
• Outdoor usage, be mindful of strong winds to prevent spraying of
user
• In the event of leaking, do not use until the leaking has been
resolved
• Wear standard PPE, consult the disinfectant solution Safety Data
Sheets (SDS) for recommendations from the disinfectant
manufacturer
• Follow the guidelines for proper charging of the battery
For any questions and/or service issues, please contact Disinfect &
Fog.
To reorder disinfectant, visit www.disinfectandfog.com/disinfectants.
Page 5

www.disinfectandfog.com
[e-mail]
1-855-561-4512
