DK2 Power OPC524 User manual

OPC524
4 INCH KINETIC CHIPPER
SWING OPEN CHUTES • KOHLER® COMMAND PRO ENGINE • TOWABLE
ASSEMBLY GUIDE
PARTS AND SERVICE 702-331-5353 | WWW.DK2POWER.COM
DK2 USA WEST
4301 S VALLEY VIEW BLVD.
SUITE 10-11 LAS VEGAS, NEVADA
89103 USA
DK2 USA EAST
3750 SOUTH AVENUE,
NORTH UNIT TOLEDO, OHIO
43615 USA
DK2 CORPORATE HEAD OFFICE
5330 MAINWAY
BURLINGTON, ONTARIO
L7L6A4 CANADA

2 | OPC524 man. v.210518
ENGLISH
TABLE OF CONTENTS
SPECIFICATIONS ....................................................................................... 3
SECTION I: ASSEMBLY
CHECK THE PACKAGING ................................................................................ 5
STEP 1: INSTALLING THE WHEELS ........................................................................ 6
STEP 2: INSTALLING THE CHIP CHUTE.................................................................... 7
STEP 3: INSTALLING THE FEED CHUTE ................................................................... 8
STEP 4: INSTALLING THE TOW BAR AND STAND ASSEMBLY ................................................ 9
STEP 5: INSTALLING THE AXLE ASSEMBLY ................................................................ 10
STEP 6: INSTALLING THE CHIP CHUTE DEFLECTOR........................................................ 11
KOHLER ENGINE INSTRUCTIONS ........................................................................ 12
REVERSING YOUR DK2 POWER OEM BLADES ............................................................. 13
SECTION II: OPERATION
BEFORE TURNING THE KEY AND PULL STARTING THE ENGINE ............................................. 15
SECTION III: PARTS & WARRANTY
PARTS LIST ............................................................................................ 17
PARTS DIAGRAM ....................................................................................... 18
WARRANTY ....................................................................................... 19

OPC524 man. v.210518 | 3
ENGLISH
SPECIFICATIONS
Item Number OPC524
Engine Model KOHLER CH270
Engine 7 HP 4000 RPM Command Pro Commercial
Tree Diameter 4”
Chipper Auto Adjusting up to 4” Diameter Trees and Brush
Cutting Blades Double-Edge Cut Reversible
Expulsion Chute Tool-Free Swing Open and Adjustable 180°
Wheels Bearing Mounted ATV Rims and Tires (O-Road Only)
Dimensions 91” x 46” x 30”
Weight 300 lb
Shipping Dimensions 34” x 22” x 35”
Shipping Weight 330 lb
Warranty 3 Year Engine - 1 Year Chassis

SECTION I
ASSEMBLY

OPC524 man. v.210518 | 5
ENGLISH
ASSEMBLY
CHECK THE PACKAGING
1. Open and unpack all items. Leave lots of working space.
2. Inspect all parts.
3. The chipper is shipped in a crate. Leave the sides folded down and use as your workspace.
NOTE: Upon inspection of parts, if you find any damage or missing parts, please call DK2 POWER
at 702-331-5353 or contact us via our website www.dk2power.com. We will replace any missing
parts to you for free.
PLEASE DO NOT RETURN TO THE STORE

6 | OPC524 man. v.210518
ENGLISH
ASSEMBLY
STEP BY STEP INSTRUCTIONS
STEP 1: INSTALLING THE WHEELS
ASSEMBLY STEPS
1. Remove all hardware from the axle.
2. Install the wheel with the stem facing out, then washer, then nut.
1. Install wheel with valve stem on the outside.
2. Washer
3. Nut

OPC524 man. v.210518 | 7
ENGLISH
ASSEMBLY
STEP BY STEP INSTRUCTIONS
STEP 2: INSTALLING THE CHIP CHUTE
1. Tip the unit back and balance it with a helper.
2. Place the chip chute on the chipper.

8 | OPC524 man. v.210518
ENGLISH
STEP 3: INSTALLING THE FEED CHUTE
ASSEMBLY
STEP BY STEP INSTRUCTIONS
1. Install the feed chute on the two hinges. To seat the hinge pins for the first time, a rubber mallet
may be used to tap the pins into the hinges. These are tight fitting to reduce vibration noise.
2. Close the chute and latch it.
3. Plug the safety shut o wire connectors together.
4. You can now use the chute by the handles to tip the unit back so you can perform the next step
and install the hitch.

OPC524 man. v.210518 | 9
ENGLISH
ASSEMBLY
STEP BY STEP INSTRUCTIONS
STEP 4: INSTALLING THE TOWBAR AND STAND ASSEMBLY
1. Grab the feed chute and tip the unit back, raising the front end up.
2. With the front end raised, install the tow bar hitch using bolts.
3. Assemble tow stand and insert the hitch pin.
4. Lower the unit back to level and rest on the drop stand.
5. Insert the tow bar and secure with tow bar screw lock.

10 | OPC524 man. v.210518
ENGLISH
STEP 5: INSTALLING THE AXLE ASSEMBLY
ASSEMBLY
STEP BY STEP INSTRUCTIONS
