DMX4ALL DMX-LED-Dimmer CC1 User manual

DMX-LED-Dimmer CC1
User Manual

DMX-LED-Dimmer CC1 2
For your own safety, please read this user manual and warnings
carefully before installation.
Description
The DMX-LED-Dimmer CC1 is designed for controlling LEDs, which are operated
with constant current and works with up to 48V DC.
Output with selectable constant current modules
Different constant current modules with different output currents are available for
connection. The constant current modules are available as accessories and are not
included in the scope of delivery.
Power supply from 12V up to 48V
The DMX-LED Dimmer CC1 works with supply voltages from 12V to 48V.
0% to 100%
The connected LEDs can be dimmed via PWM of 0% up to 100%.
DMX FAIL-Function
An adjustable DMX FAIL-Function offers the option to hold the current state (HOLD)
or to adopt a predefined value if the DMX signal fails.
RDM support
The DMX-LED-Dimmer CC1 the configuration via RDM or DMX.
Top hat rail mounting available
Suitable for the DMX-LED-Dimmer CC1 the DIN rail housing 350 is available as
accessory.

DMX-LED-Dimmer CC1 3
Data sheet
Power supply: 9-48V DC
20mA@12V; 11mA@24V; 6mA@48V
(current consumption without LED-Driver)
Protocol: DMX512
RDM
DMX channels: 1 Channel
DMX-FAIL: HOLD / 0-100%
Output: 1 current limited dimmable LED-Output
Output current according to used
constant current-module
PWM-Frequency: 244 Hz
Dimensions: 29,2mm x 82mm
Constant current-module are not included in delivery !

DMX-LED-Dimmer CC1 4
Connection
DMX-LED-Dimmer CC1
GND
DMX-
DMX+
ADDRESS
DMX OUT
8-48V GND
9-48V
DMX IN
OUT- OUT+

DMX-LED-Dimmer CC1 5
LED-Display
The integrated green LED is a multi-function display.
During the normal operation the LED lights permanently. In this case the device is
working.
Furthermore, the LED shows the current status. In this case the LED lights up in
short pitches and then is missing for longer time.
The number of the flashing lights is equal to the event number.
Status
-
Number
Error
Description
2 No DMX No DMX-Signal is recognized
3 Addressing error Please check the adjusted DMX address
DMX-Addressing
The start address is adjustable via the DIP-switches.
Thereby switch 1 has the valency 2
0
(=1), switch 2 the valency 2
1
(=2) and so on until
switch 9 has the valency 2
8
(=256). The switches showing ON represent in sum the
starting address.
In total all switches showing ON represent the starting-address.
Address Switch Address Switch
1 ... ...
2 508
3 509
4 510
5 511

DMX-LED-Dimmer CC1 6
Constant current-modules
The following constant current-modules are available as accessory for the DMX-LED-
Dimmer CC1:
- Constant current LED-Driver LDD-300H (300mA)
- Constant current LED-Driver LDD-350H (350mA)
- Constant current LED-Driver LDD-500H (500mA)
- Constant current LED-Driver LDD-600H (600mA)
- Constant current LED-Driver LDD-700H (700mA)
- Constant current LED-Driver LDD-1000H(1000mA)
- Constant current LED-Driver LDD-1200H(1200mA)
- Constant current LED-Driver LDD-1500H(1500mA)
Plug the constant current module in such way, that the output of the module (Vout)
points to the screw terminals:

DMX-LED-Dimmer CC1 7
Setting the operating modes
Der DMX-LED-Dimmer CC 1 has several operating modes (MODE) set as follows:
•Turn on the device
•Set switch 9 and 10 on ON
•Set switch 10 on OFF
•Adjust the operating mode via switch 1-8
•Set switch 9 on ON
•Set switch 10 on OFF
•The LEDs lights up 4x to confirm for takeover
•Set about switch 1-9 the DMX-address
Switch 7 OFF: DMX-FAIL ALL ON not active
Switch 7 ON: DMX-FAIL ALL ON active
Switch 8 OFF: DMX-HOLD not active
Switch 8 ON: DMX-HOLD active

DMX-LED-Dimmer CC1 8
DMX-FAIL Function
The DMX-LED-Dimmer CC1 has a DMX-FAIL Function, which stores the last value
after a DMX-Signal failure. This function leaves the output unchanged (HOLD) or
activated with 100% (ALL ON).
A power failure occurs that the last value will be rejected !
If the DMX-HOLD Function is not activated so through the output 0% will be
outputted.
The DMX-HOLD Function can be activated via switch 7 and 8 during the operating
mode adjustment:
Switch 7 OFF DMX-FAIL ALL ON not active
Switch 7 ON DMX-FAIL ALL ON active
Switch 8 ON DMX-HOLD active
Switch 8 OFF DMX-HOLD not active
Via the RDM parameter DMX_FAIL_MODE the level can be adjusted
also.

DMX-LED-Dimmer CC1 9
RDM (up to Hardware V1.3 with Firmware V1.3 or higher)
RDM is the shortcut for Remote Device Management.
As soon as the device is in the system, device-dependent settings can be made
remotely via RDM command due to the uniquely assigned UID. A direct access to the
device is not necessary.
If the DMX start address is set via RDM, all address switches at the DMX-LED-
Dimmer CC1 must be set to OFF ! A DMX start address set via the address
switches always has priority !
This device supports the follwoing RDM commands:
Parameter ID
Discovery
Command
SET
Command
GET
Command
ANSI/
PID
DISC_UNIQUE_BRANCH

E1.20
DISC_MUTE

E1.20
DISC_UN_MUTE

E1.20
DEVICE_INFO

E1.20
SUPPORTED_PARAMETERS

E1.20
PARAMETER_DESCRIPTION

E1.20
SOFTWARE_VERSION_LABEL

E1.20
DMX_START_ADDRESS

E1.20
DEVICE_LABEL

E1.20
MANUFACTURER_LABEL

E1.20
DEVICE_MODEL_DESCRIPTION

E1.20
IDENTIFY_DEVICE

E1.20
FACTORY_DEFAULTS

E1.20
DMX_PERSONALITY

E1.20
DMX_PERSONALITY_DESCRIPTION

E1.20
DMX_FAIL_MODE

E1.37
SERIAL_NUMBER
1)

PID:
0xD400
1) Manufacturer depending RDM control command (MSC - Manufacturer Specific Type)

DMX-LED-Dimmer CC1 10
Manufacturer depending RDM control command:
SERIAL_NUMBER
PID: 0xD400
Outputs a text description (ASCII text) of the device serial number.
GET Send: PDL=0
Receive: PDL=21 (21 Byte ASCII-Text)

DMX-LED-Dimmer CC1 11
Factory Reset
Before running the factory reset, read all steps carefully.
To reset the DMX-LED-Dimmer CC1 to delivery state, proceed as follows:
-Turn off device (power supply)
-Set DIP switch 1 up to 10 to ON
-Turn on the device (power supply)
-The LED lights up 20x during ca. 3 seconds
While the LED lights up set DIP switch 10 to OFF
-Now, the Factory Reset is executed
The LED lights up with error code 4
-Turn off the device (power supply)
-Now, the device can be used
If a Factory Reset is needed again, this procedure can be repeated at any
time.

Dimensions
DMX-LED-Dimmer CC1
(all details in mm)
12

DMX-LED-Dimmer CC1 13
Accessories
Top-hat rail mounting 350
Constant current LED-Module
- Constant current LED-Driver LDD-300H
- Constant current LED-Driver LDD-350H
- Constant current LED-Driver LDD-500H
- Constant current LED-Driver LDD-600H
- Constant current LED-Driver LDD-700H
- Constant current LED-Driver LDD-1000H
- Constant current LED-Driver LDD-1200H
- Constant current LED-Driver LDD-1500H

CE-Conformity
This
uses high frequency. In order to maintain the properties of
the module with regard to CE conformity, installation into a
closed metal housing in accordance with the EMC directive
2014/30/EU is necessary.
Disposal
Electronical and electronic
in domestic waste. Dispose the product at the end of its
service life in accordance with applicable legal
regulations. Information on this can be obtained from your
local waste disposal company.
Warning
This
Parents are liable for consequential damages caused by
nonobservance for their children.
DMX-LED-Dimmer CC1
This
assembly (board)
is controlled by a microprocessor and
uses high frequency. In order to maintain the properties of
the module with regard to CE conformity, installation into a
closed metal housing in accordance with the EMC directive
2014/30/EU is necessary.
Electronical and electronic
products must not be disposed
in domestic waste. Dispose the product at the end of its
service life in accordance with applicable legal
regulations. Information on this can be obtained from your
local waste disposal company.
This
device is no toy. Kee
p out of the reach of children.
Parents are liable for consequential damages caused by
nonobservance for their children.
14
is controlled by a microprocessor and
uses high frequency. In order to maintain the properties of
the module with regard to CE conformity, installation into a
closed metal housing in accordance with the EMC directive
products must not be disposed
in domestic waste. Dispose the product at the end of its
service life in accordance with applicable legal
regulations. Information on this can be obtained from your
p out of the reach of children.
Parents are liable for consequential damages caused by

Risk-Notes
You purchased a technical product. Conformable to the best
available technology the
Failure risk:
The device can drop out partially or completely at any time without warning. To
reduce the probability of a failure a redundant system structure is necessary.
Initiation risk:
For the installation of
the board, the board must be connected and adjusted to
foreign components according to the device paperwork. This work can only be
done by qualified personnel, which read the full device paperwork and understand
it.
Operating risk:
The Change or the oper
ation under special conditions of the installed
systems/components could as well as hidden defects cause to breakdown within
the running time.
Misusage risk:
Any nonstandard use could cause incalculable risks and is not allowed.
Warning: It is not
allowed to use the device in an operation, where the safety of
persons depend on this device
DMX-LED-Dimmer CC1
You purchased a technical product. Conformable to the best
available technology the
following risks should not excluded:
The device can drop out partially or completely at any time without warning. To
reduce the probability of a failure a redundant system structure is necessary.
the board, the board must be connected and adjusted to
foreign components according to the device paperwork. This work can only be
done by qualified personnel, which read the full device paperwork and understand
ation under special conditions of the installed
systems/components could as well as hidden defects cause to breakdown within
Any nonstandard use could cause incalculable risks and is not allowed.
allowed to use the device in an operation, where the safety of
persons depend on this device
.
15
You purchased a technical product. Conformable to the best
following risks should not excluded:
The device can drop out partially or completely at any time without warning. To
reduce the probability of a failure a redundant system structure is necessary.
the board, the board must be connected and adjusted to
foreign components according to the device paperwork. This work can only be
done by qualified personnel, which read the full device paperwork and understand
ation under special conditions of the installed
systems/components could as well as hidden defects cause to breakdown within
Any nonstandard use could cause incalculable risks and is not allowed.
allowed to use the device in an operation, where the safety of

DMX4ALL GmbH
Reiterweg 2A
D-44869 Bochum
Germany
Last changes: 18.06.2020
© Copyright DMX4ALL GmbH
All rights reserve. No part of this manual may be reproduced in any form (photocopy, pressure, microfilm or in
another procedure) without written permission or processed, multiplied or spread using electronic systems.
All information contained in this manual was arranged with largest care and after best knowledge. Nevertheless
errors are to be excluded not completely. It is pointed out that neither a guarantee nor the legal responsibility or
any liability for consequences which are due to incorrect information is assumed. This document does not contain
assured characteristics. The guidance and the features may be changed at any time and without previous
announcement
