8W-10 POWER DISTRIBUTION
Component Page
Battery ............................8W-10-6
Capacitor-Ignition ...................8W-10-13
Circuit Breaker .....................8W-10-11
Cluster ........................8W-10-19, 20
Coil-Ignition-No. 1 ...............8W-10-14, 15
Coil-Ignition-No. 2 ...............8W-10-14, 15
Coil-Ignition-No. 3 ...............8W-10-14, 15
Coil-Ignition-No. 4.............8W-10-13, 14, 15
Coil-Ignition-No. 5 ...............8W-10-14, 15
Coil-Ignition-No. 6 ...............8W-10-13, 15
Coil-Ignition-No. 7 ..................8W-10-15
Coil-Ignition-No. 8 ...............8W-10-13, 15
Fuse 1 ..........................8W-10-7, 9
Fuse 2 ..........................8W-10-7, 9
Fuse 3 .......................8W-10-7, 10, 11
Fuse 4 ..........................8W-10-7, 10
Fuse 5 ..........................8W-10-7, 11
Fuse 6 ..........................8W-10-7, 10
Fuse 7 .......................8W-10-7, 10, 16
Fuse 8 .......................8W-10-7, 11, 16
Fuse 9............................8W-10-16
Fuse 10 ....................8W-10-7, 8, 11, 16
Fuse 12 .......................8W-10-7, 8, 16
Fuse 13 .........................8W-10-8, 16
Fuse 14 .........................8W-10-8, 16
Fuse 15 .........................8W-10-8, 16
Fuse 16 ........................8W-10-18, 20
Fuse 18 ......................8W-10-8, 16, 18
Fuse 19 ......................8W-10-8, 16, 18
Fuse 21 .........................8W-10-8, 16
Fuse 22 .........................8W-10-8, 17
Fuse 23 .........................8W-10-8, 17
Fuse 24 ......................8W-10-8, 17, 19
Fuse 25 ......................8W-10-8, 17, 19
Fuse 26 ...........................8W-10-19
Fuse 27 .........................8W-10-8, 17
Fuse 33 ...........................8W-10-16
Fuse 34 ...........................8W-10-18
Fuse 35 ...........................8W-10-10
Fusible Link ........................8W-10-6
G110..............................8W-10-6
G111..............................8W-10-6
Component Page
G113.............................8W-10-12
G208 .............................8W-10-19
Generator ..........................8W-10-6
Injector-Fuel-No. 1 ...............8W-10-14, 15
Injector-Fuel-No. 2 ...............8W-10-14, 15
Injector-Fuel-No. 3 ...............8W-10-14, 15
Injector-Fuel-No. 4 ............8W-10-13, 14, 15
Injector-Fuel-No. 5 ...............8W-10-14, 15
Injector-Fuel-No. 6 ...............8W-10-14, 15
Injector-Fuel-No. 7 ...............8W-10-14, 15
Injector-Fuel-No. 8 ...............8W-10-13, 15
Junction Block . 8W-10-7, 8, 9, 10, 11, 16, 17, 18, 19
Module-Antilock Brakes ............8W-10-8, 16
Module-Brake Provision ............8W-10-7, 10
Module-Front Control ...........8W-10-9, 12, 20
Module-Heated Seat .................8W-10-11
Module-Integrated Power .........8W-10-7, 9, 12
Module-Powertrain Control . 8W-10-8, 11, 13, 17, 20
Module-Seat Memory ................8W-10-11
Motor-Sunroof ......................8W-10-10
Power Distribution Center . . 8W-10-2, 6, 7, 8, 9, 10,
11, 16, 17, 20
Relay-A/C Clutch .................8W-10-8, 17
Relay-Accessory Delay ...............8W-10-11
Relay-Auto Shut Down ..........8W-10-7, 11, 12
Relay-Blower Motor-Front ............8W-10-10
Relay-Blower Motor-Rear .............8W-10-16
Relay-Fuel Pump .................8W-10-8, 16
Relay-Rear Window Defogger ..........8W-10-16
Relay-Run Remote ..................8W-10-10
Relay-Run/Start ..................8W-10-9, 18
Relay-Starter Motor .............8W-10-7, 9, 20
Relay-Transmission Control .........8W-10-8, 16
Relay-Wiper High/Low ................8W-10-9
Relay-Wiper On/Off ..................8W-10-9
Starter ..........................8W-10-6, 9
Switch-Ignition ..........8W-10-9, 10, 17, 18, 19
Switch-Seat-Driver ..................8W-10-11
Switch-Seat-Passenger ...............8W-10-11
Switch-Stop Lamp ..................8W-10-17
Wiring-Trailer Tow 7-Way ...........8W-10-8, 17
HB 8W-10 POWER DISTRIBUTION 8W - 10 - 1
