DOM GUARD User manual

Assembly and operating instructions
For the digital “GUARD” handles of the system families
ENiQ
ELS
DOM Tapkey
Translation of the German original instructions
11/2019

Contents
About this manual and manufacturer information
................................................. 5
Keep the manual available .............................................................................................5
Text layout features ........................................................................................................5
Directions........................................................................................................................5
Mutually applicable documents ......................................................................................6
Warranty and liability ......................................................................................................6
Copyright ........................................................................................................................6
Documentation Officer....................................................................................................6
Manufacturer's address ..................................................................................................7
Information available online............................................................................................7
Safety
....................................................................................................................... 8
Intended use...................................................................................................................8
Ambient conditions .........................................................................................................8
Fundamental safety information .....................................................................................8
Avoid risks of explosion.............................................................................................8
Risk of injury by swallowing small parts ....................................................................8
Risk of injury when drilling holes or screwing............................................................9
Danger of injury when shortening the spindle...........................................................9
Danger of injury while attaching ................................................................................9
Avoid property damage and functional problems.........................................................10
Qualification of the staff................................................................................................11
Layout features of warning notes .................................................................................12
Layout features of notes indicating property damage ..................................................12
Description
............................................................................................................. 13
Characteristics and function of the handles..................................................................13
GUARD Slimline set reading on one side ...............................................................14
GUARD Slimline set reading on one side with short plate and rosette...................14
GUARD Slimline set reading on both sides.............................................................15
Mechanical GUARD Slimline set.............................................................................15
GUARD Compact Slimline.......................................................................................16
GUARD Compact Slimline without rosettes............................................................16
Mechanical GUARD Slimline rosette set.................................................................17
GUARD Wideline set reading on one side..............................................................17
GUARD Wideline set reading on one side with rosettes.........................................18
GUARD Wideline set reading on both sides...........................................................18
Mechanical GUARD Wideline set............................................................................19
GUARD Compact Wideline set reading on one side...............................................19
GUARD Wideline Compact without rosettes...........................................................20
GUARD Wideline rosette set...................................................................................20
Overview of the lever handles.................................................................................21

Task and function .........................................................................................................24
Overview of the most important components of the handles .......................................26
Long plate handles reading on one side .................................................................26
Components of mechanical long plate handle sets.................................................28
Components of the Compact Slimline set ...............................................................29
Components of the Slimline rosette set...................................................................31
Compact Wideline set reading on one side.............................................................32
Components of the Wideline rosette set .................................................................33
LED displays on the reading field.................................................................................34
Scope of supply............................................................................................................35
GUARD Slimline set reading on one side ...............................................................36
GUARD Slimline set reading on one side with short plate and rosette...................37
GUARD Slimline set reading on both sides.............................................................38
Mechanical GUARD Slimline set.............................................................................39
GUARD Compact Slimline.......................................................................................40
GUARD Compact Slimline without rosettes ............................................................41
Mechanical GUARD Slimline rosette set.................................................................42
GUARD Wideline set reading on one side ..............................................................43
GUARD Wideline set reading on one side with rosettes.........................................44
GUARD Wideline set reading on both sides ...........................................................45
Mechanical GUARD Wideline set............................................................................46
GUARD Compact Wideline set reading on one side...............................................47
GUARD Wideline Compact without rosettes...........................................................48
GUARD Wideline rosette set...................................................................................49
Combination GUARD with third-party handle..........................................................50
Available accessories...................................................................................................51
Adapter sleeves.......................................................................................................52
Batteries...................................................................................................................54
Technical data ..............................................................................................................54
Storing handle
........................................................................................................55
Installation
..............................................................................................................56
Preparing installation....................................................................................................56
Align lever handle on the mechanical handle...............................................................58
Attaching lever handle on the electronic handle...........................................................60
Insert spindle ................................................................................................................63
Shortening spindle...................................................................................................64
Use spindle without reducing bushes......................................................................64
Use adapter sleeves for smaller spindle hubs.........................................................66
Use adapter sleeve for 10 mm spindle hub.............................................................71
Installing handle............................................................................................................72
GUARD Slimline set reading on one side ...............................................................73
GUARD Slimline set reading on one side with short plate and rosette...................86
GUARD Slimline set reading on both sides...........................................................101

Mechanical GUARD Slimline set...........................................................................111
GUARD Compact Slimline.....................................................................................120
GUARD Compact Slimline without rosettes..........................................................130
Mechanical GUARD Slimline rosette set...............................................................137
GUARD Wideline set reading on one side............................................................144
GUARD Wideline set reading on one side with rosettes.......................................156
GUARD Wideline set reading on both sides .........................................................172
Mechanical GUARD Wideline set..........................................................................182
GUARD Compact Wideline set reading on one side.............................................191
GUARD Wideline Compact without rosettes.........................................................201
GUARD Wideline rosette set.................................................................................207
Combination GUARD with third-party handle........................................................220
Using handle
........................................................................................................ 224
Putting the handle into operation................................................................................224
Creating a transponder...............................................................................................225
Cleaning handle..........................................................................................................225
Changing batteries......................................................................................................226
Following use
....................................................................................................... 234
Removing handle........................................................................................................234
Remove mechanical cover and rosettes ...............................................................234
Taking away cover of electronic handle ................................................................237
Removing assembly profiles..................................................................................238
Removing spindle..................................................................................................239
Removing outer lever handle.................................................................................239
Keep removed parts safe ......................................................................................239
Disposal of handle......................................................................................................240
Contact
................................................................................................................. 241

Keep the manual available
5
About this manual and manufacturer
information
These assembly instructions will assist you in the secure assembly of the door
handles of the GUARD family. The door handles are subsequently referred to
as “handle”.
Keep the manual available
These instructions form part of the handle.
Keep these instructions with the handle.
Ensure that the instructions are available to the installer/operator.
You must pass on these instructions if you sell the handle or pass it on in
any other way.
Text layout features
Various elements in this manual have specific design features. This enables
you to distinguish easily between the following elements:
Normal text
•Listing - first level
−Listing - second level
Working steps
Tips contain additional information for installation and operation.
Directions
Directions used in these instructions are with a direction of view towards the
reading field of the electronic handle:
•The battery compartment is “at the top”
•The side on which the handle is fitted to the door is the “rear”, the side with
the cover is the “front”.
•“Outside” is the outside of the door to which the electronic handle is
normally fitted.
•“Inside” is the inside of the door.
All other directions can be derived from these.

About this
manual and manufacturer information
6
Mutually applicable documents
The following types of documents in particular are applicable:
•Assembly and operating instructions from third-party suppliers such as the
manufacturer of the lock or the door
•Declarations of conformity or incorporation
•Instructions about device functions, conditions and signalling
•Programming instructions for the programming medium used
Observe and follow the information from the applicable documents.
Warranty and liability
Our general terms and conditions do in principle apply. Warranty claims and
liability claims in the event of personal injury or material damage are always
ruled out if they can be traced back to one or more of the following causes:
•Inappropriate use of the handle
•Failure to heed the information in these instructions
•Incorrect assembly
•Repairs which are carried out incorrectly
•Disaster situations due to outside influences and force majeure
Copyright
This documentation may not be reproduced either in whole or in part, stored or
transmitted, disclosed or translated in any form or by any means without the
prior written consent of DOM Sicherheitstechnik GmbH & Co. KG.
This documentation is updated at regular intervals. The publisher is always
grateful to receive information about any errors or suggestions regarding this
documentation.
© DOM Sicherheitstechnik GmbH & Co. KG, Wesselinger Strasse 10–16,
50321 Brühl, Germany
Documentation Officer
DOM Sicherheitstechnik GmbH & Co. KG
Abteilung Produktmanagement
Wesselinger Straße 10–16
D-50321 Brühl

Manufacturer's address
7
Manufacturer's address
DOM Sicherheitstechnik GmbH & Co. KG
Wesselinger Straße 10–16
D-50321 Brühl
Telephone: [phone]
Telefax: [phone]
Email: [e-mail]
Internet: www.dom-security.com
Information available online
You can download these instructions and other information about the GUARD
family on the product details page at the following Internet address:
www.dom-security.com

Safety
8
Safety
Intended use
The GUARD family door handles are used for access control in buildings. The
system is based on RFID technology (radio-frequency identification). The door
handles can also be used on escape and rescue doors in accordance with
DIN EN 179 and DIN EN 1125.
Reading and understanding these instructions plus observing and following all
information in these instructions, particularly the safety instructions, all form
part of appropriate use. Any other form of use is deemed to be inappropriate
and will lead to forfeiture of warranty and liability claims.
Use in areas where there is a risk of explosion in particular is deemed to be
inappropriate.
Ambient conditions
Ensure that the handles are only used under the following ambient conditions:
•Temperature range: –25 °C to +65 °C
•Air humidity: 20% to 99% (non-condensing)
Fundamental safety information
The handles are built in line with the current state of technology and the
recognised safety rules. Working with and on the handles does nevertheless
involve residual risks which could cause a danger to life and limb. It is
therefore essential that the safety instructions below are observed and
followed.
Avoid risks of explosion
The handles are not suitable for areas where there is a risk of explosion.
Installing and operating the handles in an area where there is a risk of
explosion can lead to serious injuries or death.
Only install and operate the handles in areas where there is no explosive
atmosphere.
Risk of injury by swallowing small parts
Children can become injured after swallowing small parts.
Make sure that small parts e.g. locking media or screws are kept out of the
reach of children.

Fundamental safety information
9
Risk of injury when drilling holes or screwing
Risk of damage to eyes as a result of drilling dust or chips flying around.
Wear safety glasses.
Use a device to extract the drilling dust or chips.
Danger of injury to fingers or hands due to slipping during drilling.
Wear suitable safety gloves.
Observe and follow the instructions in the documents for the drill.
Danger of injury to fingers or hands due to slipping during screwing.
Wear suitable safety gloves.
Danger of injury when shortening the spindle
Danger of injury to eyes and hands when shortening the spindle.
An incorrectly clamped spindle which slips can result in injury. Metal splinters
due to incorrect shortening of the spindle can result in eye injuries.
Wear safety glasses and safety gloves.
Ensure that the spindle to be shortened is correctly attached in the clamping
device.
Shorten the spindle in the proper way.
Danger of injury while attaching
Danger of injury to the hands on edges of the assembly profile or the lock.
The hands can be injured due to slipping when screwing the components or
touching sharp edges.
Wear suitable safety gloves.

Safety
10
Avoid property damage and functional problems
Material damage due to incorrect storage over a long period possible.
Store the handle and its components in the original packaging in a dry, dust-
free location.
Material damage due to inappropriate assembly and operation of the handle.
Read these instructions through carefully prior to assembly and
commissioning of the handle.
Follow the instructions step by step.
Never touch the electronic components of the handle.
Protect the parts of the handle against damp.
Prevent the formation of scratches on the handle through careful handling.
Attach the screws with the torque indicated.
Material damage due to inappropriate removal of the handle.
Read these instructions through carefully prior to removal of the handle.
Follow the instructions step by step.
Protect the door leaf with a cover before releasing the cover of the handle
with a rosette lifter.
Never touch the electronic components of the handle.
Prevent the formation of scratches on the handle through careful handling.
Protect the parts of the handle against damp.
Loss of date and time possible following a battery change.
The loss of date and time can hamper/block the correct application of
authorisations with schedules.
Check whether the date and time are still correct with the corresponding
programming medium following a battery change.
Correct the date and time if necessary.
Damage to the electronic components of the handle due to contact possible.
Never touch the electronic components of the handle.
Touch an earthed metal object such as a radiator or a tap for discharging an
electrostatic charge.

Qualification of the staff
11
Reduced range or malfunction of the reading field possible due to metal
objects in the vicinity of the reading field.
Ensure that no metal objects are located in the immediate vicinity of the
reading field.
Malfunction due to the interaction of two reading fields.
If the distance is too short, an authorised closing device may be delayed or
remain undetected.
Fit the handles next to one another with at least 50 cm lateral distance from
one to the next.
Malfunction due to the presence of external systems.
External systems can emit interfering fields or interfering signals. This can
result in an authorised closing device being delayed or not detected at all and
programmes for the device can be disturbed.
Ensure that external systems do not affect the function of the handle.
Material damage possible due to incorrect maintenance or cleaning.
Do not lubricate any parts of the handle.
Clean the housings and closing devices with a lightly wetted soft cloth
without using any cleaning agent.
Qualification of the staff
People who undertake work with and on the handles must have basic
technical abilities so that they can effect screw connections and drill holes if
necessary.
People who put the handles into operation must understand their way of
working and the interaction of the individual components.

Safety
12
Layout features of warning notes
WARNING
Notices with the word WARNING warn of a hazardous
situation which can possibly lead to death or serious injuries.
CAUTION
Notices with the word CAUTION warn of a situation which
can lead to light or moderate injuries.
Layout features of notes indicating property damage
ATTENTION!
These instructions warn about a situation which could lead to
material damage or malfunctions.

Characteristics and function of the handles
13
Description
Characteristics and function of the handles
The GUARD family is made up of handles with wide plates (Wideline) or
narrow plates (Slimline). The handles may consist of long plates, short plates
with cylinder rosette or a lever handle rosette with cylinder rosette.
Combinations of handles with or without reading field are possible.
Handles with a reading field are labelled as “digital” handles. Handles without
a reading field are labelled as “mechanical” handles.
The handles of the GUARD family can be supplied in the following variants:
Slimline
Slimline
Compact
Wideline
Wideline
Compact
digital handles
reading on
one side
X
X
X
X
reading on
both sides
X
–
X
–
mechanical handles and
rosettes
X
X
X
X
The covering of the reading fields can be supplied in the following three
colours
•white
•grey
•black
The assembly of the handles remains the same regardless of the colour of the
cover.
GUARD Slimline rosettes replace conventional oval rosettes.
GUARD Wideline rosettes replace conventional round rosettes.
You can combine the handles of the GUARD family with third-party products.
Individual handles can also be supplied in addition to the handle sets for this
purpose.

Description
14
GUARD Slimline set reading on one side
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
au
thorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever handle without special
authorisation.
The handles are also available with
a cylinder hole for the
additional
use of a locking cylinder.
GUARD Slimline set reading on one side with short plate and rosette
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can activate
the
outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever handle without special
authorisation.
The handles are also available with
a cylinder hole for the additional
use of a locking cylinder.

Characteristics and function of the handles
15
GUARD Slimline set reading on both sides
Handles with a reading field on both
sides control access from both
sides. Only people with a
corresponding authorised
transponder can activate the lever
handle and open the door from the
respective side.
The
handles are also available with
a cylinder hole for the additional
use of a locking cylinder.
Mechanical GUARD Slimline set
For handles without a reading field
the access authorisation can be
controlled just with a locking
cylinder.
The door can be
opened with the
lever handle if the locking cylinder
is unlocked.
The mechanical handles and
rosettes are also available for a
cylinder without a hole. The door
can always be opened with the
lever handle in this case.

Description
16
GUARD Compact Slimline
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever h
andle without special
authorisation.
Handles with a separate cylinder
rosette enable the covering of the
locking cylinder hole and locking of
the door with a locking cylinder
which is present.
GUARD Compact Slimline without rosettes
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever handle wi
thout special
authorisation.

Characteristics and function of the handles
17
Mechanical GUARD Slimline rosette set
For handles without a reading field
the access authorisation can be
controlled just with a locking
cylinder.
The door can be opened with the
lever handle if the locking cylinder
is un
locked.
This handle is also available without
a hole for a cylinder. The door can
always be opened with the lever
handle in this case.
GUARD Wideline set reading on one side
Handles with a reading field on one
side control access from outside.
Only p
eople with a corresponding
authorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever handle without special
authorisation.
The handles are also available
with
a cylinder hole for the additional
use of a locking cylinder.

Description
18
GUARD Wideline set reading on one side with rosettes
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can
activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely mechanical side with the
lever handle without special
authorisation.
The handles are also available with
a cylinder hole for the additional
use of a loc
king cylinder.
GUARD Wideline set reading on both sides
Handles with a reading field on both
sides control access from both
sides. Only people with a
corresponding authorised
transponder can activate the lever
handle and open the door from the
respec
tive side.
The handles are also available with
a cylinder hole for the additional
use of a locking cylinder.

Characteristics and function of the handles
19
Mechanical GUARD Wideline set
For handles without a reading field
the access authorisation can be
controlled just with a locking
cylinder.
Th
e door can be opened with the
lever handle if the locking cylinder
is unlocked.
The mechanical handles and
rosettes are also available for a
cylinder without a hole. The door
can always be opened with the
lever handle in this case.
GUARD Compact Wideline set reading on one side
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
p
urely mechanical side with the
lever handle without special
authorisation.
Handles with a separate cylinder
rosette enable the covering of the
locking cylinder hole and locking of
the door with a locking cylinder
which is present.

Description
20
GUARD Wideline Compact without rosettes
Handles with a reading field on one
side control access from outside.
Only people with a corresponding
authorised transponder can activate
the outer lever handle and open the
door from outside.
The door can be opened from the
purely me
chanical side with the
lever handle without special
authorisation.
GUARD Wideline rosette set
For handles without a reading field
the access authorisation can be
controlled just with a locking
cylinder.
The door can be opened with the
lever handle if
the locking cylinder
is unlocked.
The mechanical handles and
rosettes are also available for a
cylinder without a hole. The door
can always be opened with the
lever handle in this case.
